UC1838A
UC2838A
UC3838A
Magnetic Amplifier Controller
FEATURES
•Independent 1% Reference
•Two Uncommitted, Identical
Operational Amplifiers
•100mA Reset Current Source
with –120V Capability
•5V to 40V Analog Operation
•5WDILPackage
10VCC
VREF92.5V
REFERENCE
INV.IN
8E/AOUT
3INV.IN6
7N.I.IN
2
1N.I.IN
C/LOUTC/LE/A3.5V
15DR1
16DR2RESET14VM11
512134
GNDGNDGNDGND201k5kBLOCK DIAGRAM
04/99UDG-97174DESCRIPTION
TheUC1838Afamilyofmagneticamplifiercontrollerscontainsthecircuitrytogen-
erateandamplifyalow-levelanalogerrorsignalalongwithahighvolt-
age-compliantcurrentsource.Thissourcewillprovidetheresetcurrentnecessary
toenableamagneticamplifiertoregulateandcontrolapowersupplyoutputinthe
range of 2A to 20A.
Bycontrollingtheresetcurrenttoamagneticamplifier,thisdevicewilldefinethe
amountofvolt-secondsthemagneticamplifierwillblockbeforeswitchingtothe
conductingstate.Magneticamplifiersareidealforpost-regulatorsformulti-
ple-outputpowersupplieswhereeachoutputcanbeindependentlycontrolledwith
efficienciesupto99%.Withasquareorpulse-width-modulatedinputvoltage,a
magneticamplifierwillblockaportionofthisinputwaveform,allowingjustenough
topasstoprovidearegulatedoutput.WiththeUC1838A,onlythemagneticampli-
fiercoil,threediodes,andanoutputL-Cfilterarenecessarytoimplementacom-
plete closed-loop regulator.
TheUC1838Acontainsaprecision2.5Vreference,twouncommittedhigh-gainop
ampsandahigh-gainPNP-equivalentcurrentsourcewhichcandeliverupto
100mA of magnetic amplifier reset current and with –120 volt capability.
Thesedevicesareavailableinaplastic“bat-wing”DIPforoperationovera–20°C
to+85°Ctemperaturerangeand,withreducedpower,inahermeticallysealed
cerdipfor –55°C to +125°C operation.Surface mount versions are also available.
This improved “A”version replaced the non “A”version formerly introduced.元器件交易网www.cecb2b.comUC1838A
UC2838A
UC3838A
ABSOLUTE MAXIMUM RATINGS
Supply Voltage,VCC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40V
Magnetic Amp. Source Voltage,VM. . . . . . . . . . . . . . . . . . . . . . . .40V
Reset Output Voltage,VR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .–120V
Total Current Source Voltage,VM-VR. . . . . . . . . . . . . . . . . .–140V
Amplifier Input Range. . . . . . . . . . . . . . . . . . . . . .–0.3V toVCCReset Input Current,IDR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .–10mA
Power Dissipation at TA= 25°C
Q, N, DP Package. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2W
J, L Package. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1W
Power Dissipation at T (leads/case) = 25°C
Q, N, DP Package. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5W
J, L Package. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2W
Operating Temperature Range. . . . . . . . . . . .–55°C to +125°C
Storage Temperature Range. . . . . . . . . . . . .–65°C to +150°C
Lead Temperature (Soldering, 10 sec). . . . . . . . . . . . . .300°C
Note:Allvoltagesarewithrespecttogroundpins.Allcurrents
arepositiveintothespecifiedterminal.ConsultPackaging
sectionofDatabookforthermallimitationsandconsiderations
of package.
DR216
15
14
13
12
11
10
91
2
3
4
5
6
7
8DR1
Reset
Gnd
Gnd
VM
VCC
VREFC/LOut
C/LN.I.In
C/LINV.In
Gnd
Gnd
E/AInv.In
E/AN.I.In
E/AOutCONNECTION DIAGRAMS
DIL-16,SOIC-16(TOP VIEW)
J or N Package,DP Package
3
18
17
16N/C
122019
15
144
5
6
7
8
911101213C/LOut
C/LN.I.
InDR2
DR1
Reset
N/C
N/C
GND
VMC/LInv.In
GND
N/C
N/C
E/AInv.In
VCCVREFN/CE/AN.I.In
E/AOutPLCC-20,LCC-20(TOP VIEW)
Q,L PackagesNote:All four ground pins must be connected to a common
ground
TEMPERATURE RANGEPACKAGE
UC1838AJ–55°C to +125°CCeramic Dip
UC1838ALCLCC
UC2838ADP–20°C to +85°CPowerSOIC
UC2838ANPlastic Dip
UC2838AQPLCC
UC3838ADP0°C to +70°CPowerSOIC
UC3838ANPlasticDip
UC3838AQPLCCORDERING INFORMATION元器件交易网www.cecb2b.comUC1838A
UC2838A
UC3838A
ELECTRICAL CHARACTERISTICS:Unless otherwise stated, these specifications apply for TA= –55°C to +125°C for theUC1838A, –20°C to +85°C for the UC2838A, and 0°C to +70°C for the UC3838A,VCC= 20V,VM= 5V, TA=TJ.
PARAMETERTEST CONDITIONSUC1838A / UC2838AUC3838AUNITS
MINTYPMAXMINTYPMAX
Reference Section
Supply CurrentVCC=VM= 40V4848mA
Reference OutputTA= 25°C2.472.52.532.452.52.55V
Line RegulationVCC= 5 to 30V15110mV
Load RegulationIO= 0 to –2mA520520mV
Short Circuit CurrentVREF= 0V–30–60–30–60mA
Temperature Stability*Over Operating Temp. Range15251025mV
Amplifier Section(Each Amplifier)
Offset VoltageVCM= 2.5V510mV
Input Bias CurrentVIN= 0V–1–1µA
Input Offset Current100100nA
Minimum Output Swing0.4180.418V
Output Sink CurrentVO= 5V1103011030mA
Output Source CurrentVO= 0V–1–10–20–1–10–20mA
AVOLVO= 1 to 11V100120100120dB
CMRRVIN= 1 to 11V70807080dB
PSRRVCC= 10 to 20V7010070100dB
Gain Bandwidth*0.60.80.60.8MHz
