Technical Datasheet DS46IntroductionLuxeon ®III is a revolutionary, energy efficient and ultra compact new lightsource, combining the lifetime and reliability advantages of Light Emitting Diodes with the brightness of conventional lighting.Luxeon III is rated for up to 1400mA operation, delivering increased lumens per package.Luxeon Power Light Sources give you total design freedom and unmatched brightness, creating a new world of light.For high volume applications, custom Luxeon power light source designs are available upon request, to meet your specific needs.Luxeon III StarFeaturesHighest flux per LED family in the worldVery long operating life (up to 100k hours)Available in 5500K white,green, blue, royal blue, cyan Lambertian and side emitting radiation patternsMore energy efficient than incandescent and most halogen lampsLow voltage DC operated Cool beam, safe to the touch Instant light (less than 100 ns) Fully dimmable No UVSuperior ESD protectionTypical ApplicationsReading lights (car, bus, aircraft) Portable (flashlight, bicycle) Mini accent/Uplighters/Downlighters/Orientation Fiber optic alternative/Decorative/Entertainment Bollards/Security/Garden Cove/Undershelf/TaskAutomotive rear combination lampsTraffic signaling/Beacons/ Rail crossing and WaysideIndoor/Outdoor Commercial and Residential Architectural Edge lit signs (Exit, point of sale) LCD Backlights/Light Guidespower light sourceMechanical DimensionsLuxeon III StarSide EmittingNotes:1.Slots in aluminum core PCB for M3 or #4 mounting screw.2.Electrical interconnection pads labeled on the aluminum core PCB with "+" and " " to denote positive and negative, respectively. All positive pads are interconnected, as are all negative pads, allowing for flexibility in array interconnection.3.Electrical insulation between neighboring Stars is required —aluminum board is not electrically neutral.4.Drawings not to scale.5.All dimensions are in millimeters.Flux Characteristics at 700mA, Junction Temperature, T J= 25ºCTable 1.M i n i m u m L u m i n o u s T y p i c a l L u m i n o u sF l u x(l m)o r F l u x(l m)o rR a d i o m e t r i c P o w e r R a d i o m e t r i c P o w e rL u x e o n(m W)(m W)R a d i a t i o nC o l o r E m i t t e rΦV[1,2]ΦV[2]P a t t e r nWhite LXHL LW3C60.065Green LXHL LM3C51.764LambertianCyan LXHL LE3C51.764Blue[3]LXHL LB3C13.923Royal Blue[4]LXHL LR3C275 mW340 mWWhite LXHL FW3C51.758Green LXHL FM3C51.758Side EmittingBlue[3]LXHL FB3C13.921Table 2.T y p i c a l L u m i n o u s F l u x(l m)o rR a d i o m e t r i c P o w e r(m W)L u x e o nΦV[1,2]R a d i a t i o nC o l o r E m i t t e r1000m A P a t t e r nWhite LXHL LW3C80Green LXHL LM3C80LambertianCyan LXHL LE3C80Blue[3]LXHL LB3C30Royal Blue[4]LXHL LR3C450 mWWhite LXHL FW3C70Green LXHL FM3C70Side EmittingBlue[3]LXHL FB3C27Notes for Tables 1 & 2:1.Minimum luminous flux or radiometric power performance guaranteed within published operating conditions. Lumileds main tains a tolerance of ± 10% on flux and power measurements.2.Luxeon types with even higher luminous flux levels will become available in the future. Please consult your Lumileds Authorized Distributor or Lumileds sales representative for more information.3.Typical flux value for 470 nm devices. Due to the CIE eye response curve in the short blue wavelength range, the minimum luminous flux will vary over the Lumileds blue color range. Luminous flux will vary from a typical of 17 lm for the 460 465nm bin to a typical of 30 lm for the 475 480 nm bin due to this effect. Although the luminous power efficiency is lower in the short blue wavelength range, radiometric power efficiency increases as wavelength decreases. For more information, consult the Luxeon Design Guide, available upon request.4.Royal Blue product is binned by radiometric power and peak wavelength rather than photometric lumens and dominant wavelength.Flux Characteristics at 1400mA, Junction Temperature, T J= 25ºCTable 3.Minimum TypicalLuminous LuminousLuxeon Flux (lm)Flux (lm)RadiationColor EmitterΦV[1,2]ΦV[2]PatternRed LXHL LD3C90140Red Orange LXHL LH3C120190LambertianAmber LXHL LL3C70110Red LXHL FD3C90125Red Orange LXHL FH3C120170Side EmittingAmber LXHL FL3C70100Notes for Table 3:1.Minimum luminous flux performance guaranteed within published operating conditions. Lumileds maintains a tolerance of± 10% on flux measurements.2.Luxeon types with even higher luminous flux levels will become available in the future. Please consult your Lumileds Authorized Distributor or Lumileds sales representative for more information.Table 4.D o m i n a n t W a v e l e n g t h[1]T e m p e r a t u r eλD,C o e f f i c i e n t o f T o t a lP e a k W a v e l e n g t h[2]λP,S p e c t r a l D o m i n a n t I n c l u d e d V i e w i n go r C o l o r T e m p e r a t u r e[3]H a l f w i d t h[4]W a v e l e n g t h A n g l e[5]A n g l e[6]R a d i a t i o n C C T(n m)(n m/o C)(d e g r e e s)(d e g r e e s)P a t t e r n C o l o r M i n.T y p.M a x.∆λ1/2∆λD/∆T Jθ0.90V2θ1/2 White4500K5500K10000K——Green520nm530nm550nm350.04160140 Lambertian Cyan490nm505nm520nm300.04160140 Blue460nm470nm490nm250.04160140 Royal Blue[2]440nm455nm460nm200.04160140Optical Characteristics at 700mA, Junction Temperature, T J= 25ºCContinuedTable 5.T e m p e r a t u r e T y p i c a lD o m i n a n t W a v e l e n g t h[1]C o e f f i c i e n t o f T o t a l F l u x T y p i c a lλD,S p e c t r a l D o m i n a n t P e r c e n t A n g l eo r C o l o r T e m p e r a t u r e[3]H a l f w i d t h[4]W a v e l e n g t h w i t h i n o f P e a kR a d i a t i o n C C T(n m)(n m/o C)f i r s t45°[7]I n t e n s i t y[8]P a t t e r n C o l o r M i n.T y p.M a x.C u mΦ45°∆λD/∆T J C u mΦ45°θP e a k White4500K5500K10000K——<15%75° 85°Side Emitting Green520nm530nm550nm350.04<15%75° 85°Blue460nm470nm490nm200.04<15%75° 85°Notes: (for Tables 4 & 5)1.Dominant wavelength is derived from the CIE 1931 Chromaticity diagram and represents the perceived color. Lumiledsmaintains a tolerance of ± 0.5nm for dominant wavelength measurements.2.Royal Blue product is binned by radiometric power and peak wavelength rather than photometric lumens and dominantwavelength. Lumileds maintains a tolerance of± 2nm for peak wavelength measurements.3.CRI (Color Rendering Index) for White product types is 70. CRI for Warm White product type is 90 with typical Rg value of70. CCT ±5% tester tolerance.4.Spectral width at ½ of the peak intensity.5.Total angle at which 90% of total luminous flux is captured.6.θ½ is the off axis angle from lamp centerline where the luminous intensity is ½ of the peak value.7.Cumulative flux percent within ± 45° from optical axis.8.Off axis angle from lamp centerline where the luminous intensity reaches the peak value.9.All white, green, cyan, blue and royal blue products built with Indium Gallium Nitride (InGaN). All red, red orange and abmerproducts built with Aluminum Indium Gallium Phosphide (AlInGaP).10.Blue and Royal Blue power light sources represented here are IEC825 Class 2 for eye safety.Optical Characteristics at 1400mA, Junction Temperature, T J= 25ºCTable 6.T e m p e r a t u r eC o e f f i c i e n t o f T o t a lS p e c t r a l D o m i n a n t I n c l u d e d V i e w i n gD o m i n a n t W a v e l e n g t h[1]H a l f w i d t h[2]W a v e l e n g t h A n g l e[3]A n g l e[4] R a d i a t i o nλD(n m)(n m/o C)(d e g r e e s)(d e g r e e s) P a t t e r n C o l o r M i n.T y p.M a x.∆λ1/2∆λD/∆T Jθ0.90V2θ1/2 Red620.5nm627nm645nm200.05170130 Lambertian Red Orange613.5nm617nm620.5nm180.06170130 Amber584.5nm590nm597nm170.09170130 Optical Characteristics at 1400mA, Junction Temperature, T J= 25ºC,ContinuedTable 7.T e m p e r a t u r e T y p i c a lC o e f f i c i e n t o f T o t a l F l u x T y p i c a lS p e c t r a l D o m i n a n t P e r c e n t A n g l eD o m i n a n t W a v e l e n g t h[1]H a l f w i d t h[2]W a v e l e n g t h w i t h i n o f P e a k R a d i a t i o nλD(n m)(n m/o C)f i r s t45°[5]I n t e n s i t y[6] P a t t e r n C o l o r M i n.T y p.M a x.∆λ1/2∆λD/∆T J C u mΦ45°θP e a k Red620.5nm627nm645nm200.05<30%75° 85°Side Emitting Red Orange613.5nm617nm620.5nm180.06<30%75° 85°Amber584.5nm590nm597nm170.09<30%75° 85°Notes: (for Tables 6 & 7)1.Dominant wavelength is derived from the CIE 1931 Chromaticity diagram and represents the perceived color. Lumileds maintains a tolerance of ± 0.5nm for dominant wavelength measurements.2.Spectral width at ½ of the peak intensity.3.Total angle at which 90% of total luminous flux is captured.4.θ½ is the off axis angle from lamp centerline where the luminous intensity is ½ of the peak value.5.Cumulative flux percent within ± 45° from optical axis.6.Off axis angle from lamp centerline where the luminous intensity reaches the peak value.7.All red, red orange and amber products built with Aluminum Indium Gallium Phosphide (AlInGaP).Electrical Characteristics at 700mA, Junction Temperature, T J= 25ºCTable 8.T e m p e r a t u r eC o e f f i c i e n t o f T h e r m a lF o r w a r d R e s i s t a n c e,F o r w a r d V o l t a g e V F[1]D y n a m i c V o l t a g e[3]J u n c t i o n(V)R e s i s t a n c e[2](m V/o C)t o B o a r dC o l o r M i n.T y p.M a x.(Ω)R D∆V F/∆T J(o C/W)RθJ BWhite 3.03 3.70 4.470.8 2.017Green 3.03 3.70 4.470.8 2.017Cyan 3.03 3.70 4.470.8 2.017Blue 3.03 3.70 4.470.8 2.017 Royal Blue 3.03 3.70 4.470.8 2.017Notes for Table 8:1.Lumileds maintains a tolerance of ± 0.06V on forward voltage measurements.2.Dynamic resistance is the inverse of the slope in linear forward voltage model for LEDs. See Figures 3a and 3b.3.Measured between 25o C ≤T J≤110o C at I F= 700mA.Electrical Characteristics at 1000mA, Junction Temperature, TJ = 25ºCTable 9.T y p i c a l F o r w a r d V o l t a g eV F(V)[1]C o l o r1000m AWhite 3.90Green 3.90Cyan 3.90Blue 3.90Royal Blue 3.90Notes for Table 9:1.Proper current derating must be observed to maintain junction temperature below the maximum. For moreinformation, consult the Luxeon Design Guide, available upon request.2.Allowable board temperature to avoid exceeding maximum junction temperature at maximum Vf limit at 700 mA based on thermal resistance of Star assembly.3.LEDs are not designed to be driven in reverse bias. Please consult Lumileds' Application Brief AB11 for further information.Electrical Characteristics at 1400mA,Junction Temperature, T J= 25ºCTable 10.T e m p e r a t u r eC o e f f i c i e n t o f T h e r m a lF o r w a r d R e s i s t a n c e,D y n a m i c V o l t a g e[3]J u n c t i o nF o r w a r d V o l t a g e V F(V)[1]R e s i s t a n c e[2](m V/o C)t o B o a r dC o l o r M i n.T y p.M a x.(Ω)R D∆V F/∆T J(o C/W)RθJ BRed 2.31 2.95 3.510.7 2.010 Red Orange 2.31 2.95 3.510.7 2.010 Amber 2.31 2.95 3.510.7 2.010Notes for Table 10:1.Lumileds maintains a tolerance of ± 0.06V on forward voltage measurements.2.Dynamic resistance is the inverse of the slope in linear forward voltage model for LEDs. See Figure3.3.Measured between 25ºC ≤T J≤110ºC at I F= 1400mA.Absolute Maximum RatingsTable 11.W h i t e/G r e e n/R e d/C y a n/B l u e/R e d O r a n g e/P a r a m e t e r R o y a l B l u e A m b e rDC Forward Current (mA)[1]10001540Peak Pulsed Forward Current (mA)10002200Average Forward Current (mA)10001400LED Junction Temperature (ºC)135135Storage Operating Temperature (ºC) 40 to +120 40 to +120ESD Sensitivity [2]±16,000V HBM±16,000V HBMNotes for Table 11:1.Proper current derating must be observed to maintain junction temperature below the maximum. For more information, consult the Luxeon Design Guide, available upon request.2.LEDs are not designed to be driven in reverse bias. Please consult Lumileds’ Application Brief AB11 forfurther information.Wavelength Characteristics, T J = 25ºCFigure 1b. White Color Spectrum of Typical 5500K CCT Part, Integrated Measurement.0.00.20.40.60.81.0350400450500550600650700750800Wavelength (nm)R e l a t i v e S p e c r t a l P o w e r D i s t r i b u t i o nFigure 1a. Relative Intensity vs. WavelengthLight Output Characteristics5060708090100110120130140150-20020406080100120Junction T em perature, T J (o C )R e l a t i v e L i g h t O u t p u t (%)Figure 2. Relative Light Output vs. Junction Temperaturefor White, Green, Cyan, Blue and Royal Blue.Figure 3. Relative Light Output vs. Junction Temperatureor Red, Red Orange and Amber.-20020406080100120Junction T em perature , T J (o C )R e l a t i v e L i g h t O u t p u t (%Forward Current Characteristics, T J= 25ºCNote:Driving these high power devices at currents less than the test conditions may produce unpredictable results and may be subject to variation in performance. Pulse width modulation (PWM) is recommended for dimming effects.Figure 4. Forward Current vs. Forward Voltage for White,Green, Cyan, Blue, and Royal Blue.Figure 5. Forward Current vs. Forward Voltage for Red,Red Orange and Amber.Forward Current Characteristics, T J = 25ºC, ContinuedNote:Driving these high power devices at currents less than the test conditions may produce unpredictable results and may be subjectto variation in performance. Pulse width modulation (PWM) is recommended for dimming effects.Figure 6. Relative Luminous Flux vs. Forward Current for White,Green, Cyan, Blue, and Royal Blue at T J = 25ºC maintained.0.00.20.40.60.81.01.21.41.602004006008001000120014001600180020002200If - Forward Current (m A )N o r m a l i z e d R e l a t i v e L u m i n o u s F l u x Figure 7. Relative Luminous Flux vs. Forward Current for Red,Red Orange and Amber at T J = 25ºC maintained.Current Derating CurvesFigure 8. Maximum Forward Current vs. Ambient Temperature.Derating based on T JMAX= 135ºC for White, Green, Cyan, Blue, and Royal Blue. Since Luxeon III may be driven at up to1000mA, derating curves may not be applicable for all operating conditions.Figure 9. Maximum Forward Current vs. Ambient Temperature.Derating based on T JMAX= 135°C for Red, Red Orange, and Amber.Note:For more detailed technical information regarding Luxeon radiation patterns, please consult your Lumileds Authorized Distributor or Lumileds sales representative.Figure 11. Typical Representative Spatial Radiation Patternfor Luxeon Lambertian Emitter Red, Red Orange and Amber.102030405060708090100-100-80-60-40-20020406080100Angular Displacment (Degrees)R e l a t i v e I n t e n s i t y (%)Figure 10. Typical Representative Spatial Radiation Patternfor Luxeon Emitter White, Green, Cyan, Blue and Royal Blue.Average Lumen Maintenance CharacteristicsLifetime for solid state lighting devices (LEDs) is typically defined in terms of lumen maintenance the percentage ofinitial light output remaining after a specified period of time. Lumileds projects that white, green, cyan, blue, and royal blueLuxeon III products will deliver, on average, 70% lumen maintenance at 50,000 hours of operation at a 700 mA forward current or 50% lumen maintenance at 20,000 hours of operation at a 1000 mA forward current. Lumileds projects that red, red orange,and amber Luxeon III products will deliver, on average 50% lumen maintenance at 20,000 hours of operation at a 1400 mAforward current. This performance is based on independent test data, Lumileds historical data from tests run on similar material systems, and internal Luxeon reliability testing. This projection is based on constant current operation with junction temperature maintained at or below 90°C. Observation of design limits included in this data sheet is required in order to achieve this projected lumen maintenance.Figure 12. Typical Representative Spatial Radiation Patternfor Luxeon Emitter White, Green and Blue..102030405060708090100-120-100-80-60-40-20020406080100120Angular Displacement (Degrees)R e l a t i v e I n t e n s i t y (%)Side Emitting Radiation PatternFigure 13. Typical Representative Spatial Radiation Patternfor Luxeon Side Emitting Emitter Red, Red Orange and Amber.。

74HC595D中⽂资料_数据⼿册_参数74HC595; 74HCT5958-bit serial-in, serial or parallel-out shift register with outputlatches; 3-stateRev. 6 — 12 December 2011Product data sheet1. General descriptionThe 74HC595; 74HCT595 are high-speed Si-gate CMOS devices and are pin compatible with Low-power Schottky TTL (LSTTL). They are specified in compliance with JEDEC standard No.7A.The 74HC595; 74HCT595 are 8-stage serial shift registers with a storage register and3-state outputs. The registers have separate clocks.Data is shifted on the positive-going transitions of the shift register clock input (SHCP). The data in each register is transferred to the storage register on a positive-going transition of the storage register clock input (STCP). If both clocks are connected together, the shift register will always be one clock pulse ahead of the storage register.The shift register has a serial input (DS) and a serial standard output (Q7S) for cascading. It is also provided with asynchronous reset (active LOW) for all 8 shift register stages. The storage register has 8 parallel 3-state bus driver outputs. Data in the storage register appears at the output whenever the output enable input (OE) is LOW.2. Features and benefits8-bit serial input8-bit serial or parallel outputStorage register with 3-state outputsShift register with direct clear100MHz (typical) shift out frequencyESD protection:◆HBM JESD22-A114F exceeds2000V◆MM JESD22-A115-A exceeds200VMultiple package optionsSpecified from -40C to+85C and from -40C to+125C3. ApplicationsSerial-to-parallel data conversionRemote control holding register3-state4. Ordering information5. Functional diagramTable 1.Ordering informationType numberPackageTemperature rangeName DescriptionVersion 74HC595N -40?C to +125?CDIP16plastic dual in-line package; 16leads (300mil)SOT38-474HCT595N 74HC595D -40?C to +125?CSO16plastic small outline package; 16leads;body width 3.9mmSOT109-174HCT595D 74HC595DB -40?C to +125?CSSOP16plastic shrink small outline package; 16leads; body width 5.3mmSOT338-174HCT595DB 74HC595PW -40?C to +125?CTSSOP16plastic thin shrink small outline package; 16leads; body width 4.4mmSOT403-174HCT595PW 74HC595BQ -40?C to +125?CDHVQFN16plastic dual in-line compatible thermal enhanced very thin quad flat package; no leads; 16terminals; body 2.5 ? 3.5 ? 0.85 mmSOT763-174HCT595BQ3-state3-state 6. Pinning information3-state6.2Pin descriptionTable 2.Pin description Symbol Pin DescriptionQ11parallel data output 1Q22parallel data output 2Q33parallel data output 3Q44parallel data output 4Q55parallel data output 5Q66parallel data output 6Q77parallel data output 7 GND8ground (0 V)Q7S9serial data outputMR10master reset (active LOW)OE13output enable input (active LOW)DS14serial data inputQ015parallel data output 0V CC16supply voltage7. Functional descriptionTable 3.Function table[1]Control Input Output FunctionSHCP STCP OE MR DS Q7S QnX X L L X L NC a LOW-level on MR only affects the shift registersX↑L L X L L empty shift register loaded into storage registerX X H L X L Z shift register clear; parallel outputs in high-impedance OFF-state↑X L H H Q6S NC logic HIGH-level shifted into shift register stage 0. Contents of all shift register stages shifted through, e.g. previous state of stage 6(internal Q6S) appears on the serial output (Q7S).X↑L H X NC QnS contents of shift register stages (internal QnS) are transferred to the storage register and parallel output stages↑↑L H X Q6S QnS contents of shift register shifted through; previous contents of the shift register is transferred to the storage register and the paralleloutput stages[1]H=HIGH voltage state;L=LOW voltage state;↑=LOW-to-HIGH transition;X=don’t care;NC=no change;Z=high-impedance OFF-state.3-state8. Limiting valuesTable 4.Limiting valuesIn accordance with the Absolute Maximum Rating System (IEC 60134). Voltages are referenced to GND (ground = 0 V). Symbol Parameter Conditions Min Max UnitV CC supply voltage-0.5+7VI IK input clamping current V I < -0.5V or V I>V CC+0.5 V-±20mAI OK output clamping current V O<-0.5V or V O > V CC + 0.5 V-±20mAI O output current V O=-0.5V to (V CC+0.5V)pin Q7S-±25mApins Qn-±35mAI CC supply current-70mAI GND ground current-70-mAT stg storage temperature-65+150?CP tot total power dissipationDIP16 package[1]-750mWSO16 package[2]-500mWSSOP16 package[3]-500mWTSSOP16 package[3]-500mWDHVQFN16 package[4]-500mW[1]For DIP16 package: P tot derates linearly with 12mW/K above 70 ?C.[2]For SO16 package: P tot derates linearly with 8mW/K above 70 ?C.[3]For SSOP16 and TSSOP16 packages: P tot derates linearly with 5.5mW/K above 60 ?C.9. Recommended operating conditions10. Static characteristicsTable 5.Recommended operating conditionsSymbol ParameterConditions74HC59574HCT595UnitMinTyp Max Min Typ Max V CC supply voltage 2.0 5.0 6.0 4.5 5.0 5.5V V I input voltage 0-V CC 0-V CC V V O output voltage 0-V CC 0-V CC V ?t/?Vinput transition rise and fall rateV CC = 2.0 V --625---ns/V V CC = 4.5 V - 1.67139- 1.67139ns/V V CC = 6.0 V--83---ns/V T ambambient temperature-40+25+125-40+25+125C Table 6.Static characteristicsAt recommended operating conditions; voltages are referenced to GND (ground =0V).Symbol ParameterConditions-40?C to +85?C -40?C to +125?C UnitMinTypMaxMinMax74HC595V IHHIGH-level input voltageV CC =2.0V 1.5 1.2- 1.5-V V CC =4.5V 3.15 2.4- 3.15-V V CC =6.0VV CC =2.0V -0.80.5-0.5V V CC =4.5V - 2.1 1.35- 1.35V V CC =6.0V- 2.81.8- 1.8VV OHHIGH-level output voltageV I =V IH or V IL all outputsI O =-20µA; V CC =2.0V 1.9 2.0- 1.9-V I O =-20µA; V CC =4.5V 4.4 4.5- 4.4-V I O =-20µA; V CC =6.0V 5.96.0- 5.9-VQ7S outputI O =-4mA; V CC =4.5V 3.84 4.32- 3.7-V I O =-5.2mA; V CC =6.0V 5.345.81- 5.2-VQn bus driver outputs I O =-6mA; V CC =4.5V 3.84 4.32- 3.7-V I O =-7.8mA; V CC =6.0V5.345.81- 5.2-V3-stateV OL LOW-leveloutput voltage V I=V IH or V ILall outputsI O=20µA; V CC=2.0V-00.1-0.1V I O=20µA; V CC=4.5V-00.1-0.1V I O=20µA; V CC=6.0V-00.1-0.1V Q7S output I O=4mA;V CC=4.5V-0.150.33-0.4V I O=5.2mA;V CC=6.0V-0.160.33-0.4V Qn bus driver outputsI O=6mA;V CC=4.5V-0.150.33-0.4V I O=7.8mA;V CC=6.0V-0.160.33-0.4VI I input leakagecurrentV I=V CC or GND; V CC=6.0V--±1.0-±1.0µAI OZ OFF-state--80-160µAC I inputcapacitance- 3.5---pF 74HCT595V IH HIGH-levelinput voltageV CC=4.5V to 5.5V 2.0 1.6- 2.0-VV IL LOW-levelinput voltageV CC=4.5V to 5.5V- 1.20.8-0.8VV OH HIGH-leveloutput voltage V I=V IH or V IL; V CC=4.5Vall outputsI O=-20µA 4.4 4.5- 4.4-V Q7S outputI O=-4mA 3.84 4.32- 3.7-V Qn bus driver outputsI O=-6mA 3.7 4.32- 3.7-VV OL LOW-leveloutput voltage V I=V IH or V IL; V CC=4.5Vall outputsI O=20µA-00.1-0.1V Q7S outputI O=4.0mA-0.150.33-0.4V Qn bus driver outputsI O=6.0mA-0.160.33-0.4VI I input leakagecurrent V I=V CC or GND; V CC=5.5V--±1.0-±1.0µATable 6.Static characteristics …continuedAt recommended operating conditions; voltages are referenced to GND (ground=0V). Symbol Parameter Conditions-40?C to +85?C-40?C to +125?C UnitMin Typ Max Min Max3-stateI OZ OFF-state--80-160µAI CC additionalsupply current per input pin; I O=0A; V I=V CC-2.1V; other inputs at V CC or GND;V CC=4.5V to5.5Vpins MR, SHCP, STCP, OE-150675-735µA pin DS-25113-123µAC I inputcapacitance - 3.5---pFTable 6.Static characteristics …continuedAt recommended operating conditions; voltages are referenced to GND (ground=0V).Symbol Parameter Conditions-40?C to +85?C-40?C to +125?C UnitMin Typ Max Min Max3-state 11. Dynamic characteristicsTable 7.Dynamic characteristicsVoltages are referenced to GND (ground = 0 V); for test circuit see Figure14.Symbol Parameter Conditions25 ?C-40?C to+85 ?C-40?C to+125 ?C UnitMin Typ[1]Max Min Max Min Max74HC595t pd propagationdelay SHCP to Q7S; see Figure9[2]V CC = 2 V-52160-200-240ns V CC = 4.5 V-1932-40-48ns V CC = 6 V-1527-34-41ns STCP to Qn; see Figure10[2] V CC = 2 V-55175-220-265ns V CC = 4.5 V-2035-44-53ns V CC = 6 V-1630-37-45ns MR to Q7S; see Figure12[3] V CC = 2 V-47175-220-265ns V CC = 4.5 V-1735-44-53ns V CC = 6 V-1430-37-45nst en enable time OE to Qn; see Figure13[4]V CC = 2 V-47150-190-225nsV CC = 4.5 V-1730-38-45nsV CC = 6 V-1426-33-38ns t dis disable time OE to Qn; see Figure13[5]V CC = 2 V-41150-190-225nsV CC = 4.5 V-1530-38-45nsV CC = 6 V-1227-33-38ns t W pulse width SHCP HIGH or LOW;V CC = 4.5 V156-19-22-nsV CC = 6 V135-16-19-nsSTCP HIGH or LOW;see Figure10V CC = 2 V7511-95-110-nsV CC = 4.5 V154-19-22-nsV CC = 6 V133-16-19-nsMR LOW; see Figure12V CC = 2 V7517-95-110-nsV CC = 4.5 V156-19-22-nsV CC = 6 V135-16-19-ns3-statet suset-up timeDS to SHCP; see Figure 10V CC = 2 V 5011-65-75-ns V CC = 4.5 V 104-13-15-ns V CC = 6 V 9 3-11-13-nsSHCP to STCP; see Figure 11V CC = 2 V 7522-95-110-ns V CC = 4.5 V 158-19-22-ns V CC = 6 V 137-16-19-ns t hhold timeDS to SHCP; see Figure 11V CC = 2 V 3-6-3-3-ns V CC = 4.5 V 3-2-3-3-ns V CC = 6 V3-2-3-3-ns t recrecovery timeMR to SHCP; see Figure 12V CC = 2 V 50-19-65-75-ns V CC = 4.5 V 10-7-13-15-ns V CC = 6 V 9-6-11-13f maxmaximum frequencySHCP or STCP; see Figure 9 and 10V CC = 2 V 930- 4.8-4-MHz V CC = 4.5 V 3091-24-20-MHz V CC = 6 V35108-28-24-MHz C PDpower dissipation capacitancef i = 1 MHz; V I =GND to V CC [6][7]-115-----pF74HCT595; V CC = 4.5 V to 5.5 V t pdpropagation delay SHCP to Q7S; see Figure 9[2]-2542-53-63ns STCP to Qn; see Figure 10[2]-2440-50-60ns MR to Q7S; see Figure 12[3]-2340-50-60ns t en enable time OE to Qn; see Figure 13[4]-2135-44-53ns t dis disable time OE to Qn; see Figure 13[5] -1830-38-45ns t Wpulse widthSHCP HIGH or LOW;see Figure 9166-20-24-ns STCP HIGH or LOW; see Figure 10165-20-24-ns MR LOW; see Figure 12208-25-30-ns t suset-up timeDS to SHCP; see Figure 10165-20-24-ns SHCP to STCP; see Figure 11168-20-24-ns t hhold timeDS to SHCP; see Figure 113-2-3-nsTable 7.Dynamic characteristics …continuedVoltages are referenced to GND (ground = 0 V); for test circuit see Figure 14.Symbol Parameter Conditions25 ?C -40?C to +85 ?C -40?C to +125 ?C Unit Min Typ [1]Max Min Max Min Max3-state[1]Typical values are measured at nominal supply voltage.[2]t pd is the same as t PHL and t PLH .[3]t pd is the same as t PHL only.[4]t en is the same as t PZL and t PZH .[5]t dis is the same as t PLZ and t PHZ .[6]C PD is used to determine the dynamic power dissipation (P D in µW).P D =C PD ?V CC 2?f i +∑(C L ?V CC 2?f o )where:f i=input frequency in MHz;f o =output frequency in MHz;∑(C L ?V CC 2?f o )=sum of outputs;C L =output load capacitance in pF;V CC =supply voltage in V.[7]All 9outputs switching.12. Waveformst rec recovery time MR to SHCP; see Figure 1210-7-13-15-ns f max maximum frequencySHCP and STCP; see Figure 9 and 103052-24-20-MHz C PDpower dissipation capacitancef i = 1 MHz; V I =GND to V CC [6] [7]-130-----pFTable 7.Dynamic characteristics …continuedVoltages are referenced to GND (ground = 0 V); for test circuit see Figure 14.Symbol Parameter Conditions25 ?C -40?C to +85 ?C -40?C to +125 ?C Unit Min Typ [1]Max Min Max Min Max3-stateTable 8.Measurement points Type Input OutputV M V M74HC5950.5V CC0.5V CC 74HCT595 1.3V 1.3V3-stateTable 9.Test data74HC595V CC6ns50 pF1kΩopen GND V CC74HCT5953V6ns50 pF1kΩopen GND V CC3-state 13. Package outlineDIP16: plastic dual in-line package; 16 leads (300 mil)SOT38-4Fig 15.Package outline SOT38-4 (DIP16)3-state SO16: plastic small outline package; 16 leads; body width 3.9 mm SOT109-1Fig 16.Package outline SOT109-1 (SO16)3-state SSOP16: plastic shrink small outline package; 16 leads; body width 5.3 mm SOT338-1Fig 17.Package outline SOT338-1 (SSOP16)3-state TSSOP16: plastic thin shrink small outline package; 16 leads; body width 4.4 mm SOT403-1Fig 18.Package outline SOT403-1 (TSSOP16)。

Code 32 MIL-C-229926-44207M3XX-XXXXX212M4XX-XXXXX212M5XX-XXXXXBraided AdaptersAvailable in:AmericasEuropeAsia Pacificsss6-45Order Shell Max. Entry ALeft Hand Thd.Dimensions No.Size Size, Type 1*Class 2B C Max. D Max. E Max 121208.750-20 UNEF 29.0 [1.14]25.4 [1.00]33.5 [1.32]141410.875-20 UNEF 29.7 [1.17]25.9 [1.02]35.3 [1.39]161612 1.000-20 UNEF 30.0 [1.18]26.2 [1.03]37.1 [1.46]181814 1.125-18 UNEF 30.7 [1.21]26.9 [1.06]38.6 [1.52]202016 1.250-18 UNEF 31.2 [1.23]27.7 [1.09]40.1 [1.58]222218 1.375-18 UNEF 32.0 [1.26]28.2 [1.11]41.7 [1.64]242422 1.625-18 UNEF 33.5 [1.32]30.0 [1.18]46.5 [1.83]282824 1.875-16 UN 34.8 [1.37]31.2 [1.23]49.8 [1.96]323228 2.062-16 UNS 36.3 [1.43]32.5 [1.28]52.8 [2.08]363628 2.312-16 UNS 37.6 [1.48]33.8 [1.33]56.1 [2.21]4040282.625-16 UN38.9 [1.53]35.3 [1.39]58.9 [2.32]*For larger than maximum type 1 entry sizes, a two-piece adapter will be supplied. Contact Tyco Electronics for information.Table of DimensionsEntry Dimensions Size Z ± 0.20 (± 0.51)YDia. Min.W Max.03 4.75 [.187]9.98 [.393]39.6 [1.56]04 6.35 [.250]11.58 [.456]39.6 [1.56]057.92 [.312]13.08 [.515]42.9 [1.69]069.53 [.375]14.76 [.581]42.9 [1.69]0711.13 [.438]16.33 [.643]46.0 [1.81]0812.70 [.500]17.91 [.705]—0914.27 [.562]17.91 [.705]49.3 [1.94]1015.88 [.625]21.11 [.831]49.3 [1.94]1117.48 [.688]22.68 [.893]52.3 [2.06]1219.05 [.750]24.21 [.953]52.3 [2.06]1320.62 [.812]24.21 [.953]55.6 [2.19]1422.23 [.875]27.46 [1.081]55.6 [2.19]1523.83 [.938]29.03 [1.143]59.9 [2.36]1625.40 [1.000]30.61 [1.205]59.9 [2.36]1828.58 [1.125]35.08 [1.381]69.6 [2.74]2031.75 [1.250]38.25 [1.506]72.6 [2.86]2234.93 [1.375]41.43 [1.631]75.9 [2.99]2438.10 [1.500]44.60 [1.756]79.0 [3.11]2844.45 [1.750]50.90 [2.004]85.3 [3.36]Entry Size DimensionsBraided Adapters(continued)6-46Spin-Coupling AdaptersBase Dimensions Part Shell AY Z Number Size L.H. Thread Class 2B± .020 (±0.51)Min.1212.750-20 UNEF 20.24 [.797]12.47 [.491]1414.875-20 UNEF 23.44 [.923]14.35 [.565]1616 1.000-20 UNEF 26.42 [1.040]17.53 [.690]1818 1.125-18 UNEF 31.17 [1.227]18.19 [.716]2020 1.250-18 UNEF 34.49 [1.358]21.72 [.855]2222 1.375-18 UNEF 37.21 [1.465]25.02 [.985]2424 1.625-18 UNEF 42.82 [1.686]30.48 [1.200]2828 1.875-16 UN 50.06 [1.971]36.58 [1.440]3232 2.062-16 UNS 55.35 [2.179]40.77 [1.605]3636 2.312-16 UNEF 61.01 [2.402]52.96 [2.085]4040 2.625-16 UNS 67.46 [2.656]57.15 [2.250]44442.875-16 UNS70.66 [2.782]62.46 [2.549]*For larger than maximum type 1 entry sizes, a two-piece adapter will be supplied.Contact Tyco Electronics for information.Table of Dimensions204M3XX-XXXMolded Part Size Selection Guide (Spin-Coupling)Uniboot PartsNo.No.(Min.)12202C63212.7 [0.50]14, 16202C64217.5 [0.69]18, 20, 22, 24202C65322.4 [0.88]Available in:AmericasEuropeAsia Pacificsss6-47Tinel-Lock AdaptersTXR32XX00-XXXXXXTXR32XX90-XXXXXXTXR32XX45-XXXXXXDimensionsOrder Shell Max. Entry AC D E Z S Y W No.Size Size Type ILeft Hand Thd Max.Max.Max.+ .010Dia.± .015Max.Class 2B - .020(± 0.38)121208.750-20 UNEF 29.0 [1.14]25.4 [1.00]33.5 [1.32]19.05 [.750]22.28 [.877]26.67 [1.050]52.3 [2.06]22.02 [.867]141410.875-20 UNEF 29.7 [1.17]25.9 [1.02]35.3 [1.39]22.23 [.875]25.46 [1.002]29.84 [1.175]55.6 [2.19]25.17 [.991]161612 1.000-20 UNEF 30.0 [1.18]26.2 [1.03]37.1 [1.46]25.40 [1.000]28.63 [1.127]33.02 [1.300]59.01 [2.36]28.34 [1.116]181814 1.125-18 UNEF 30.7 [1.21]26.9 [1.06]38.6 [1.52]28.57 [1.125]31.81 [1.252]36.19 [1.425]69.6 [2.74]31.52 [1.241]202016 1.250-18 UNEF 31.2 [1.23]27.7 [1.09]40.1 [1.58]31.75 [1.250]34.98 [1.377]39..37 [1.550]72.6 [2.86]34.69 [1.366]222218 1.375-18 UNEF 32.0 [1.26]28.2 [1.11]41.7 [1.64]34.93 [1.375]38.15 [1.502]42.55 [1.675]75.9 [2.99]37.79 [1.488]242422 1.625-18 UNEF 33.5 [1.32]30.0 [1.18]46.5 [1.83]38.10 [1.500]41.33 [1.627]45.72 [1.800]79.0 [3.11]40.97 [1.613]282824 1.875-16 UN 34.8 [1.37]31.2 [1.23]49.8 [1.96]————323224 2.062-16 UNS 36.3 [1.43]32.5 [1.28]52.8 [2.08]————363624 2.312-16 UNS 37.6 [1.48]33.8 [1.33]56.1 [2.21]————4040242.625-16 UN38.9 [1.53]35.3 [1.39]58.9 [2.32]————**For larger than maximum type 1 entry sizes, a two-piece adapter will be supplied. Contact Tyco Electronics for information.Available in:AmericasEuropeAsia Pacificsss6-48CRES-Lock Adapters Code 32 Band Strap AdapterNotes:1. This product is designed to terminate a braided cable shield by means of a band strap and a heat shrinkable lipped boot to a connector.2. See CH00-0250-016 for ordering information, modifications and additional dimensions.3. See drawing BND-XX25S for band strap dimensions and information.4. Adapter to be permanentlymarked with code identification number and full part number (e.g.06090-BND32AB00-1812). Band strap shall bear no part marking.5. All entry sizes are shown in Table II. Maximum entry sizes are ass h o w n in Table I. For larger entry sizes than the maximum, a Type II adapter may be supplied. See CH00-0250-016 for further details.6. Adapter mates to: MIL-C-22992,Class C and R, MS17343, 44, 45and 47 Connectors.7. Anti-rotational set screw, 3 threaded holes 120° ± 5° apart,single mating set screw supplied:AN565DC4H2. Not required for Type II adapters.For additional codes available,contact TycoElectronics.Straight AdapterCode 0045° Adapter Code 45Type II Modification(See Note 5)90° Adapter Code 90Available in:AmericasEuropeAsia Pacificsss6-49CRES-Lock Adapters Code 32 Band Strap Adapter (Continued)Table IOrder Shell Entry Size Ø AØ B C D F Number Size 2Max.Unified Thread Max.Max.Max.Max.Type I 1Class 2B 1212080.7500–20 UNEF 27.229.028.436.61.07 1.14 1.12 1.441414100.8750–20 UNEF 30.229.728.938.41.19 1.17 1.14 1.51161612 1.0000–20 UNEF 33.530.029.240.11.32 1.18 1.15 1.58181814 1.1250–18 UNEF 36.630.730.041.71.44 1.21 1.18 1.64202016 1.2500–18 UNEF 39.931.230.743.21.57 1.23 1.21 1.70222218 1.3750–18 UNEF 42.932.031.244.71.69 1.26 1.23 1.76242422 1.6250–18 UNEF 52.633.533.049.52.07 1.32 1.30 1.95282826 1.8750–16 UN 58.934.834.352.82.32 1.37 1.35 2.08323230 2.0625–16 UNS 65.336.335.655.92.57 1.43 1.40 2.20363634 2.3125–16 UNS 71.637.636.859.22.82 1.48 1.45 2.334040342.6250–16 UN78.038.938.462.03.071.531.512.441. All entry sizes are shown in Table II. Maximum entry sizes are as shown in Table I. For larger entry sizes than the maximum, a Type II adapter may be supplied. See CH00-0250-016 for further details.2. Adapter mates to: MIL-C-22992, Class C and R, MS17343, 44, 45 and 47 Connectors.Table IIEntry Ø Z Ø S Ø Y E Size +0.25/-0.50±0.51±0.38Max.[+0.010/-0.020][±0.020][±0.015]03 4.757.9211.1028.30.1880.3120.438 1.1204 6.359.5212.7029.30.2500.3750.500 1.15057.9211.1214.3030.00.3120.4380.563 1.18069.5212.7015.8830.80.3750.5000.625 1.210711.1214.3017.5031.50.4380.5620.689 1.240812.7015.8819.0532.30.5000.6250.750 1.270914.3017.5020.6533.30.5620.6880.813 1.311015.8819.0522.2334.00.6250.7500.875 1.341117.5020.6523.8035.00.6880.8120.938 1.381219.0522.2325.4035.80.7500.875 1.000 1.411320.6523.8327.0036.00.8120.938 1.063 1.421422.2325.4030.1637.50.8751.0001.1891.48Table II (Continued)Entry Ø Z Ø S Ø Y E Size +0.25/-0.50±0.51±0.38Max.[+0.010/-0.020][±0.020][±0.015]1523.8327.0031.7537.8.0938 1.062 1.250 1.491625.4028.5833.3438.31.000 1.125 1.313 1.511828.5831.7536.5139.81.125 1.250 1.438 1.572031.7534.9039.6941.31.250 1.375 1.563 1.632234.9038.1042.8643.01.375 1.500 1.688 1.692438.1041.2846.8344.51.500 1.625 1.844 1.752641.2844.4549.6146.31.625 1.750 1.953 1.822844.4547.6352.7848.31.750 1.875 2.078 1.903047.6550.8056.3650.01.875 2.000 2.219 1.973250.8054.0059.5351.52.000 2.125 2.344 2.033454.0057.1562.7153.32.1252.2502.4692.10。

Hikvision DS-2DF7C445IXR-AEL(T5) 4 MP 45 × IR Network Speed Dome adopts 1/1.8" progressive scan CMOS chip. With the 45 × optical zoom lens, the camera offers more details over expansive areas.This series of cameras can be widely used for wide ranges of high-definition, such as rivers, forests, roads, railways, airports, ports, squares, parks, scenic spots, stations and large venues, etc. ⏹ 1/1.8" Progressive Scan CMOS⏹ High quality imaging with 4 MP resolution ⏹Excellent low-light performance with powered-by-DarkFighter technology⏹ 45× optical zoom and 16× digital zoom provide close up views over expansive areas ⏹ 120 dB WDR, 3D DNR, HLC, Smart IR⏹ Expansive night view with up to 500 m IR distance⏹ Supports rapid focus⏹Water and dust resistant (IP66)⏹DORIThe DORI (detect, observe, recognize, identify) distance gives the general idea of the camera ability to distinguish persons or objects within its field of view. It is calculated based on the camera sensor specification and the criteria given by EN 62676-4: 2015.DORI Detect Observe Recognize IdentifyDefinition 25 px/m 63 px/m 125 px/m 250 px/m Distance (Tele) 4020 m (13189 ft) 1595.2 m (5233.6 ft) 804 m (2637.8 ft) 402 m (1318.9 ft)⏹SpecificationCameraImage Sensor 1/1.8" progressive scan CMOSMin. Illumination Color: 0.005 Lux @ (F1.5, AGC ON), B/W: 0.0005 Lux @ (F1.5, AGC ON), 0 Lux with IR Shutter Speed 1/3 s to 1/30,000 sSlow Shutter YesDay & Night IR cut filterHLC YesZoom 45 × optical, 16 × digitalMax. Resolution 2560 × 1440LensFOV Horizontal field of view: 60.2° to 1.7° Vertical field of view: 35.2° to 1° Diagonal field of view: 67.4° to 1.8°Focus Auto, semi-auto, manual, rapid focusZoom Speed Approx. 8.5 sFocal Length 5.9 to 265.5 mmAperture Max. F1.5IlluminatorSupplement Light Type IRSupplement Light Range Up to 500 mPTZMovement Range (Pan) 360°Movement Range (Tilt) -15° to 90° (auto flip)Pan Speed Pan speed: configurable from 0.1° to 160°/s; preset speed: 240°/s Tilt Speed Tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s Proportional Pan YesPresets 300Patrol Scan 8 patrols, up to 32 presets for each patrolPattern Scan 4 pattern scans, record time over 10 minutes for each scan Power-off Memory YesPark Action Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan3D Positioning Yes PTZ Status Display Yes Preset Freezing YesScheduled Task Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux outputVideoMain Stream 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720), 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)Sub-Stream 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288);60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)Third Stream 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288);60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)Video Compression Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEGThird stream: H.265/H.264/MJPEGVideo Bit Rate 32 Kbps to 16384 KbpsH.264 Type Baseline profile, main profile, high profileH.265 Type Main profileScalable Video Coding (SVC) H.264 and H.265 encodingRegion of Interest (ROI) 8 fixed regions for each streamAudioAudio Compression G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCMAudio Bit Rate MP2L2: 32 kbps, 40 kbps, 48 kbps, 56 kbps, 64 kbps, 80 kbps, 96 kbps, 112 kbps, 128 kbps, 144 kbps, 160 kbpsNetworkNetwork Storage NAS (NFS, SMB/CIFS), ANRProtocols IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, BonjourAPI Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK User/Host Up to 32 users. 3 user levels: administrator, operator, and userSecurity Password protection, complicated password, HTTPS encryption, 802.1X authentication, watermark, IP address filter, control timeout settings, security audit log, TLS 1.2, host authentication (MAC address)Client iVMS-4200, HikCentral, Hik-ConnectWeb Browser IE11, Chrome 57.0+, Firefox 52.0+, Safari 11+ ImageImage Enhancement BLC, HLC, 3D DNRWide Dynamic Range (WDR) 120 dBDefog Digital defogImage Stabilization EIS (Built-in gyroscope to improve EIS performance) Regional Exposure YesRegional Focus YesImage Settings Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browserImage Parameters Switch YesPrivacy Mask 24 programmable polygon privacy masks, mask color or mosaic configurable SNR ≥ 52 dBInterfaceEthernet Interface 1 RJ45 10M/100M self-adaptive Ethernet portOn-board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB Alarm 7 inputs, 2 outputsAudio 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%;1 output (line out), line level, output impedance: 600 ΩRS-485 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)EventBasic Event Motion detection, video tampering alarm, exception, alarm input and outputSmart Event Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detectionSmart Tracking Manual tracking, auto-trackingAlarm Linkage Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan)Deep Learning FunctionFace Capture Detects up to 15 faces simultaneously.Supports detecting, capturing, grading, selecting of face in motion, and outputs the best face pictureGeneralPower 24 VAC, 3.0 A, 50/60 Hz & Hi-PoE, 42.5 to 57 VDC, 1.41 A (Max. 40 W, includes max. 16 W for IR and max. 10 W for heater)General Function Mirror, password protection Dimension Ø 226 mm × 354 mm (Ø 8.90" × 13.94") Weight Approx. 5.0 kg (11.02 lb.)ApprovalEMC FCC SDoC (47 CFR Part 15, Subpart B);CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);RCM (AS/NZS CISPR 32: 2015);IC VoC (ICES-003: Issue 6, 2019);KC (KN 32: 2015, KN 35: 2015)Safety UL (UL 62368-1)CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2017),BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);LOA (SANS IEC60950-1)Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)Protection IP66 (IEC 60529-2013), TVS 6000V lightning protection, surge protection and voltage transient protection⏹Available Model DS-2DF7C445IXR-AEL(T5)⏹Typical ApplicationHikvision products are classified into three levels according to their anti-corrosion performance. Refer to the following description to choose for your using environment.This model has NO SPECIFIC PROTECTION.Level DescriptionTop-level protection Hikvision products at this level are equipped for use in areas where professional anti-corrosionprotection is a must. Typical application scenarios include coastlines, docks, chemical plants, andmore.Moderate protection Hikvision products at this level are equipped for use in areas with moderate anti-corrosiondemands. Typical application scenarios include coastal areas about 2 kilometers (1.24 miles) awayfrom coastlines, as well as areas affected by acid rain.No specific protection Hikvision products at this level are equipped for use in areas where no specific anti-corrosionprotection is needed.⏹Dimension⏹Accessory⏹OptionalDS-1602ZJ DS-1602ZJ-pole DS-1602ZJ-corner DS-1661ZJHIKYíHíONEfNYf€fON Headquartarela SSS O ianmo Road, Binjiang Dist rift,Hangzhou 310051, ChinaT+86—571—88D7—S998*allow us on social media to pet the latest product and solution information.H kvis onEH ikvision Digital Tech nolagy Co.,Ltd.2022I Data subject to ch ange withou I notice I H kvision GlobalHikvisionCorporate Channe h ikvisionhq。
