A P P L I C A T I O N SA/V Rentals AirportsAudio/VisualAuditoriums / Theatres BanksBars / Lounges / Nightclubs Boardrooms Business MusicConference Facilities Convenience Stores Educational FacilitiesFitness Clubs / Gymnasiums Hotels / Hospitality Houses of WorshipIndustrial / Warehouses MuseumsMusic Distribution OfficesPublic Address Restaurants Retail Stores Theme Parks Training RoomsType8-channel mixer/pre-amplifier Output Power +4 dBm, +20 dBm (max.)Power Bandwidth 30 - 20k Hz, +20 dBm 0.5% THD 250 - 20k Hz, +18 dBm 0.5% THD Frequency Response 20 - 20k Hz, ±1 dBTotal Harmonic 0.01% at 1k Hz, rated outputDistortion Inputs8 input ports: every port accepts any input module 1 Bridging Input/OutputInput Sensitivity Input port #1 to #8: 100 mV / 10k Ω& Impedance Bridging Input/Output: 100 mV / 3.3k ΩOutputsMain: Balanced, 150/600 ΩAux: Unbalanced, 10k Ω, 0 dBm Output RegulationLess than 1.5 dB, no load to full load (1k Hz)Dynamic RangeMaster volume set to min.:90 dB (Band Pass: 20 - 20k Hz,Master volume set to max.:77 dBwith T one Controls centered)T one Controls Bass: ±10 dB at 100 Hz; Treble: ±10 dB at 10k Hz Indicators Normal, Peak, Power, Protect, and Signal LEDs ProtectionSelf-protection, with internal AC fuses Power Consumption 18 WTemperature Range 12°F to 140°F (-10°C to +60°C)ColorBlackDimensions (W x H x D)16.5” x 3.9” x 12.1” (420 x 99.1 x 307.5 mm)Weight (without modules)11.7 lbs (5.3 kg)Other FeaturesOutput connects approx. 5 seconds after switching power on.900 SERIESMIXER/PRE-AMPLIFIER Tel:800-733-7088 Fax:Visit to download:900 Series Architect and Engineering Specifications 900 Series Installation Manual 900 Series CAD Files900 Series Module Guide900 SERIESMIXER/PRE-AMPLIFIER Tel:800-733-7088 Fax:800-733-9766 TOA EL E C T R O N I C S, I N C.601 G ATEWAY B LVD., S UITE300S OUTH S AN F RANCISCO, CA 94080TEL: 800-733-7088FAX: 800-733-9766900S ERIESFemale Male1/4”RCA Dual RCA 3 Screw 5 Screw RemovableThe two types of muting modules,MUTE-RECEIVE and MUTE-SEND,have mute function circuitry that connects to two common "MUTE" buses,and one common "GROUND" bus when installed in an A-900MK2 mixer/amplifier or M-900MK2 mixer/pre-amplifier.A "BUS" is simply an internal wire that connects from module-slotto module-slot.You can access these buses via rear-panel screw terminals,labeled,"MUTE 1","MUTE 2" and "GND".Mute-type modules connect to both mute buses "out-of-the-box".You can disconnect the module's mute function circuitry from each mute bus by cutting jumper wires on the modules.This allows you to configure systems with multiple levels of priority.MUTE-RECEIVE modules respond to mute bus activation in either of two ways:1) Switch Activation:Connecting a switch closure between the "MUTE" (1 or 2)" and "GND" screw terminals on the rear of the mixer/amplifier activates the mute function circuitry of MUTE-RECEIVE modules connected to the same bus.This is also referred to as "manual muting".2) Auto-Mute:When input signal level to a MUTE-SEND module exceeds a user-adjustable threshold,the module's mute function cir-cuitry activates the mute function circuitry of all MUTE-RECEIVE modules connected to the same bus.This is also referred to as "signal-activated muting".M UTING M ODULESLiterature Order #: L-M900SERIESSpecifications subject to change without notice.© 2003, TOA Electronics, Inc.。

June 2013Product Information EIB 700 Series External Interface BoxEIB 700 SeriesThe EIB 700 units are external interface boxes for precise position measurement. They are ideal for inspection stations and multipoint inspection apparatuses as well as for mobile data acquisition, such as in machine inspection and calibration. The EIB 700 series is ideal for applications requiring high-resolution encoder signals and fast measured-value acquisition.Ethernet transmission also enables you to use switches or hubs for connecting more than one EIB. It is also possible to use WLAN transmission, for example.The EIBs are suited for the following voltage supplies:EIB 741: 100 V AC to 240 V EIB 742: 24 V DCA maximum of four HEIDENHAINencoders, either with sinusoidal incremental signals ( 1 V PP ; 11 µA PP on request) or with EnDat interfaces (EnDat 2.1 and EnDat 2.2) can be connected to the EIB 700 series.The EIB 700 series subdivides the periods of the incremental signals up to 4 096-fold for measured-value generation. The deviations within one signal period areautomatically reduced by adjustment of the sinusoidal incremental signals.The integrated measured-value memory enables the EIB 700 series to save typically 250 000 measured values per axis. Internal or external triggers can be used for axis-specific storage of the measured values.A standard Ethernet interface using TCP/IP or UDP communication is available for data output. This permits direct connection to a PC, laptop or industrial PC. The type of measured-value transfer can be selected through the operating mode (transfer of individual values, block transfer, or transfer upon software request).Driver software for Windows, Linux and LabVIEW as well as example programs and the EIB application software are included in the items supplied, in order to process the measured values on the PC. The driver software enables customers to easilyprogramming their own applications. It also contains program examples demonstrating the capabilities of the EIB 700 series. The EIB application software serves for commissioning and demonstrating the capabilities of the EIB 700 series. This software is made available in the source code and can serve as a platform for the development of one’s own applications.Thanks to the compact dimensions , two EIB 700 series interface boxes fit next to each other in a 19-inch housing. They occupy one height unit.AccessoriesMounting bracketFor installation of two EIB 74x in a 19-inch housing ID 671144-012) Different trigger sources can be assigned to the individual axes3) Can also be used as logical input or output4) The quality of the data cable between the EIB and the PC must be suitable for the requested transfer rate and the cable length.Note:The features can be extended by updating the firmware.Basic circuit diagramOperating modes�����������������������������������������������������������������������������������������������������������������������������������������������������������655780 · 04 · A · 02 · 6/2013 · PDFSoftwareEIB application softwareThe EIB application software covers two applications:Commissioning and demonstration of the EIB 74xThe settings required for easy• configuration of the EIB 74x (e.g. input interface, data packets, operating mode, trigger settings).Management of one or more EIB 74x • units.Simple representation of the positions • transmitted by the EIB 74x.Settings can be saved so that different • application projects can be managed.The User's Guide provides more information.Platform for customer applications The EIB application software is madeavailable in the source code. Based on this application, customers can quickly realize their own applications. The application software was programmed with C++/CLI and Windows Forms in Visual Studio 2008. This programming environment is widely used in technical application programming, but does not necessarily provide state-of-the-art operating systems like Windows 7, for example. However, the customer can adapt the program to other graphic user interfaces.This Product Information supersedes all previous editions, which thereby become invalid. The basis for ordering from HEIDENHAIN is always the Product Information valid when the contract is made.For more informationProduct overview: • Interface Electronics。

Model DB 751Hybrid Bass HeadThe DB 751 Bass Head features a combination of raw power and rich tone that continues the legacy of the DB 750. The DB 751 is a groundbreaking hybrid with a discrete Mosfet output section and a 3-tube preamp. While maintaining the legendary sound of the DB 750, the DB 751 features improvements in the EQ section, a better control layout, detachable rack ears, and thermally controlled fans. This amp has the headroom to bring your tone to life no matter what kind of music you are playing. For sound clips and sample settings be sure to visit our website at:.Aguilar Amplification LLCNew York CitySpecifications:Power Output:975 watts @ 2 ohms, 750 watts @ 4 ohms, 400 watts @ 8 ohms Preamp Section:Three 12AX7sPower Section:12 complimentary lateral MOSFETsTransformer:Custom Aguilar toroidal power transformer.EQ Section:passive tone stack with active midrange element, bass: +12 / -12 @ 40Hz; midrange: +12 / -12 @ 750Hz; treb: +12 / -7 @ 4kHz Deep Switch: Adds 5 dB of broad-band boost at 30 HzBright Switch:Adds 5 dB of broadband boost at 5-7 kHzEffects Loop:Send is push/pull for line or instrument level; Return is push/pullfor parallel or series operationInputs:One 1/4" input jack with an active/passive switchOutputs:Two Neutrik Speakon speaker outputs, Jensen XLR balancedoutput (-32dB) with a pre/post EQ switch and a ground lift switch.Tuner out.Cooling:High quality whisper fans with thermal speed control Dimensions:17" W x 14" D x 5.25" HRack Size:Three Spaces, Includes detachable rack earsWeight:42 lbsWarranty: Ten Year LimitedOptional: Footswitch, Tolex Head cases in DB series colors, Rack bagFront Panel Features:Input:-6 dB Switch:Inserts a –6dB pad in the signal path to allow flexibility when adjusting the gain for a bass with very high outputGain Knob:Controls the gain of the preamp sectionBright Switch:Adds 5dB of broadband boost at 5-7 kHzTreble Knob:+12 / -7 dB @ 4 kHz.Midrange Knob:+12 / -12 @ 750HzBass Knob:+12 / -12 @ 40 HzDeep Switch:Adds 5dB of broadband boost at 30 HzMaster Knob:Controls volumeClip Light:Flashes if the preamp is clipping. Turn down either the “Gain”, the EQ, or “Master” volume.FX Send:Sends the signal to your effects units. Connect the input of your effects unit to this jack FX Return:Returns the signal from your effects units to the amplifier.Connect the output of your effects unit to this jack.Effects Loop:The “Send” knob is push/pull for selecting line or instrument level. This allows you to use a studio effects unit (line level) or a stomp box (requires instrument level) in the FX loop. Adjust the amount of “Send” so as to get maximum performance from your effects unit and the “Return” to get the right amount of effected signal.The “Return” knob is push/pull for parallel or series operation. In parallel mode, the effected signal is mixed to the dry sound. In series mode, the effects in the loop will process the entire signal. The amount of effects can be adjusted with the return knob. If you pull the return knob out for series operation without any effects plugged in the loop, the loop will be open and no sound will result.XLR Balanced Output:Use the Pre-EQ setting in a concert situation where the sound engineer is taking a signal into the house-mixing console. The engineer is now getting their feed before the preamp stage, which allows them to use appropriate EQ for the venue. The EQ on stage will still be controlled by your settings. If the engineer wants your EQ settings included in the mix, set the control to Post EQ and your settings on stage will be sent to the house. The D.I. output is –32dB. This level is the correct output for a signal going into the preamp on a mixer. Our balanced output uses the highest quality Jensen output transformer. If you hear any ground noise, change the position of the ground lift switch under the outputFootswitch:Use the optional Aguilar footswitch to mute the signal for silent tuning.Rear Panel:Speaker Outputs:Two Neutrik Speakon connectors are provided. Use 12 gauge or larger speaker cable for proper connections.Tuner out:This output sends the signal to your connected tuner. This output will still be active when you mute the DB 751.Aguilar DB751Diagnostic and ProtectionThe DB751 is equipped with a self-diagnostic and status/protection circuit. Upon power-up, the unit’s blue status LED will blink for approximately 45 seconds. During this time several circuit parameters are verified, or allowed to become self calibrated.1. The high B+ voltage to the preamp tubes is slowly ramped up, allowing the tube heaters to warm up before full current is drawn by the valves.2. DC offset at the amp’s output is monitored. Only if none is present (normal condition), will the unit proceed with the self-check protocol.3. Temperature on the MOSFET heat sink is checked, and again only if normal temperature is detected, will the status check continue.4. If all the voltages, offsets, and temperature are in accordance with factory specifications, then the amp’s input, and output relays will be energized. This will then cause the operate LED to illuminate and the status LED to stop blinking. The amp is now ready for normal operation.5. The circuit continues monitoring the above parameters to protect both the DB 751 and the speakers connected to the amp in the event of unit or user error. This will be indicated by the status LED’s blinking.6. If the status LED continues blinking, or starts blinking during amplifier use, this indicates a system fault. The amplifier requires servicing in order for normal operation to resume.Limited WarrantyAguilar Amplification’s DB 751 hybrid bass amp is warranted to the original owner for a period of ten years from the date of purchase against defects in materials and workmanship. * Tubes are covered by the warranty for a period of 90 days. Abuse, negligence, and normal wear and tear are not covered by the terms of this warranty.The warranty period starts from the date of purchase from an authorized Aguilar dealer. Please register your DB 751 for warranty by going to and selecting “Online Registration” from the Support menu. It is important to save your original sales receipt. You will be asked to send a copy with your amplifier.Before sending your unit to Aguilar for repair, you must receive a return authorization numberfromus.Contactusviaphone,fax,oremail(**************************)with a description of the problem. We will then issue to you a return authorization number. You are responsible for all shipping charges. You must ship the unit to us freight prepaid. We will return the unit to you freight collect. For safe shipment, the product should be shipped in its original packaging. If you no longer have this, we can arrange to sell you replacement-packing materials.Aguilar Amplification LLC is not responsible for shipping damage, either to or from our service center. Claims must be filed with the carrier.The only company authorized to perform work under this warranty is Aguilar Amplification LLC of New York, NY.*If you purchased your DB 751 outside the USA, please contact your local Dealer or Distributor for your country’s specific warranty period and repair procedure.。

©2012 A t l a s S o u n d L .P . A l l r i g h t s r e s e r v e d . A t l a s S o u n d a n d S t r a t e g y S e r i e s a r e t r a d e m a r k s o f A t l a s S o u n d L .P . A l l o t h e r t r a d e m a r k s a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s . A T S 004406 R e v A 5/12DSP8807Self Contained, Compact Multi-Zone Digital Controlled Sound Masking ProcessorGeneral DescriptionThe Atlas Sound DSP8807 is a self-amplified, sound masking controller with extensive digital signal processing (DSP) and telephony interface capabilities. All aspects of signal routing, processing and prioritization are administered through an intuitive Graphic User Interface (GUI) managed via a local Windows ® based laptop or desktop computer. The software has the ability to expand up to (253) systems with over 2,000 zones (2,048) with primary and secondary assignment in a zone paging dialing plan. It also provides the ability to set up “All zone” page, “Group zone“ page (up to 32 groups) and “Single zone“ page with an architectural dialing plan (2-digit DTMF) set up in the GUI. AVB (Audio Video Bridge) audio networking allows distribution of paging, BGM and line level inputs between multiple DSP8807 and/or DSP2212 units across TCP/IP data networks.The DSP8807 has 8 channels of independent on-board digital class-D amplifiers capable of delivering 50W RMS per 70.7V output. Additionally, a simultaneous line level output rated at 1V/600Ω (nominal) per zone is available for driving higher power amplifiers. The DSP8807 includes two independent, uncorrelated pink noise generators, which are random and non-repeating up to 215 hours with 1⁄3-octave EQ adjustments programmable on a per zone basis.Each DSP8807 is capable of managing remote ambient level sensing microphones (ALM-1) for each zone (x8), via a single CAT5e cable up to 1,000 feet from the DSP8807. These microphones can provide automatic adjustment of the masking level based on real- time noise levels with set up and control via the GUI.Features• A VB (Audio Video Bridge) Audio Networking Allows Distribution of Paging, BGM and Line Level Inputs Between Multiple DSP8807 and/or DSP2212 Units Across TCP/IP Data Networks • User Friendly GUI and Easy Network Setup• Built-In Amplification for Each Output (50W @ 70.7V x 8)• Line Level Outputs (x8) for Expansion to External Amplifiers • Expandable - Up to 256 Units (2048 Zones) • Non Repeating Pink Noise Sources • Front Panel Visual Status LED’s for All I/O • Parametric EQ for All Paging / Line Sources • 1⁄3 Octave EQ for All Masking Zones• C omprehensive Telco Interface Facilitates Complex Paging Scenarios for Multi Floor Buildings • Paging Mic Input for Evacuation or General Announcements • Optional Ambient Sensing Microphones for Automatic System Adjustment • UL / CUL and FCC Listed DSP8807 FrontDSP8807 Back238751461. A mplifier Outputs (50 Watts x8 @ 70.7V)2. Line Level Outputs for Expansion to External Amplifiers (x8)3. R J45 Inputs for Optional Ambient Sensing Microphones (x8)4. T elco Page Input (Loop Start). Use with 2-5 Digit GUI Defined DTMF Dial Plan5. B GM, and Line Inputs6. Paging Mic Input with 32VDC Switchable Phantom Power7. Contact Closure Inputs (x4)8. TCP/IP Network Input (Parallel Input Also on Front Panel)©2012 A t l a s S o u n d L .P . A l l r i g h t s r e s e r v e d . A t l a s S o u n d a n d S t r a t e g y S e r i e s a r e t r a d e m a r k s o f A t l a s S o u n d L .P . A l l o t h e r t r a d e m a r k s a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s . A T S 004406 R e v A 5/12SpecificationsSystem Performance / DSP ProcessorsDynamic Range >102dB A-Weighted Frequency Response 80Hz–20kHz (±3dB) at Rated Output Distortion THD+N.001% Typical at +4dBu, 1kHz, 0dB GainInput Sensitivity ≤ 1.0% at 1kHz at Rated Output Interchannel Crosstalk > 80dB Typical Crosstalk Input To Output > 80dBChannel Separation > 100dB at 1kHz (In Thru Out) Common Mode Rejection Ration (CMRR) >50dB, 80Hz – 20kHz Typical > 55dB at 1kHzProcessor Capacity  264 MIPS, 528MFLOPS, Continuous OperationSample Rate Audio Conversion 48kHz D/A Converter Type (Audio) 24-bit Sigma Delta D/A Performance Dynamic Range (Converter) > 100dB A-Weighted A/D Performance Dynamic Range > 110dB A-WeightedNon-Volatile MemoryMemory Storage For All Programs And Set Up Protected For 24 Hours In Power Brown Out, Interruption, or Computer Shut Down. Data Settings Good for Ten Years W/O Refresh DSP Manual RestartFront Restart Manual Button To Reload DSP’sCODEC – DSP Protection All I/O Protected With Buffers From Spikes and Transients or Sneak CurrentsSystem Inputs (Unless Noted Located On Rear Panel)Power AC MainsIEC 3-pin with Ground, 100VAC-240VAC, 50Hz-60kHz with ON/OFF Manual Switch With Replaceable FuseNetwork – Data RJ45 Module Jack (EIA 568B)Telco Loop Start2-Pin Dockable Keyed Connector Input Transformer 600ΩRing Voltage 105V – 14V (POTS – VoIP) DTM F Dial Plan Single, Group, or All Page Microphone3-Pin Dockable Keyed Connector Background MusicR CA Connector 10k Ω (Sum to Mono)Master Override2-Pin Dockable Keyed Connector (1V – 70.7V nominal)Ambient Sensing Microphones (x8)R J45 Modular Jack (EIA 568B) No Polarity System Outputs (Unless Noted Located On Rear Panel)Speakers (x8)2-Pin Dockable Keyed Connector(70.7V at 50 Watts RMS)Audio Line level (x8)3-Pin Dockable Keyed Connector (1v nominal) M icrophone Frequency Level 80Hz – 18kHz M usic 80Hz – 20kHz Line out 80Hz – 18kHz Telco250Hz – 4kHzNetwork system linkRJ45 Modular Jack (EIA 568B)System Amplifiers (x8)Frequency Response 80Hz – 20kHz, (±.25dB)Total Distortion.001% Typical at +4dB, 1kHz,0dB GainTransformer Output 70.7V and IV Line Level Efficiency 85% or Better Gain Control Adjustable to 34dB Power SupplyUL / CUL /CE RecognizedInput Impedance 50k ΩOutput Impedance 8ΩCarrier Frequency 400kHz Peak Current 1.2A MTBF (Mean Time Between Failure) 100,000 HoursEMC / EMI Radiation  F CC Part 15 Class B, EN6100, CISPR 22System Mechanical Data Length 14" (358mm)Width 19" (482.6mm)Height3.5" (88.9mm)Material (Outer Housing) C RS (Cold Roll Steel) 18AWG(.047" Nominal)FinishFlat Black Powder Coat With Zinc Undercoat Corrosion ResistantPrinted Circuit Boards UL Recognized UL94VO Electronic Components RoHS Operating Temperature 0˚ to +50˚C Storage Temperature -40˚ to +85˚CHumidity 95% Non-Condensing (Max.) ©2012 A t l a s S o u n d L .P . A l l r i g h t s r e s e r v e d . A t l a s S o u n d a n d S t r a t e g y S e r i e s a r e t r a d e m a r k s o f A t l a s S o u n d L .P . A l l o t h e r t r a d e m a r k s a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s . A T S 004406 R e v A 5/12Specification Friendly Text1. D igital Signal Processor (DSP) with Noise Masking and Amplification – DSP shall provide multi-zone digital DSP-GUI controlled processor and digital amplifiers capable of simultaneous distribution of masking, paging, and background music signals. DSP shall include status lights on front panel. DSP shall: a. Be 2RU High. b. I nclude 8x8 I/O with 8 ambient noise sensor connections and 8 channels of 50 Watts class D amplifiers. c. I nclude two independent pink/white noise generators that arerandom and non-repeating over 215 hours. d. D SP shall include parametric EQ, Graphic EQ, Volume, Tonecontrols, Network Volume Control, Telco compressor, Matrix, mixer, and ambient mic monitoring. e. Include telephone interface.f. U tilize Audio Video Bridge AVB Protocols that are IEEE802.1 standards.g. P rovide status indication of Processors running, Mute, Page Active,Masking Active, Mic Active, Amplifier channels, Emergency Audio Inputs, and System Power h. M anufacturer Atlas Sound DSP8807 with ALM-1 Ambient SensingMicrophones or approved equal.ApplicationsThe Atlas Sound DSP8807 digital processor “Privacy” system is a self contained, compact multi-zone digital DSP-GUI controlled processor and digital amplifier capable of simultaneous distribution of masking, paging, and background music signals for use in:• Hospitality• Government Facilities • Education Transportation • Corporate • Industrial • RestaurantsArchitect and Engineer SpecificationsThe Atlas Sound DSP8807 unit shall provide automatic mixing, set up and administration of all 8x8 inputs / outputs per zone (channel) via an intuitive ‘simple to use’ Graphic User Interface (GUI) managed via a local Windows ® based laptop or desktop computer. The DSP8807 shall include 8 channels of independent on-board digital class-D amplifiers that shall deliver 50 Watts RMS at 70.7V output. An audio line level output rated at 1V/600Ω (nominal) per zone shall drive higher power amplifiers. The DSP8807 shall have two (2) independent uncorrelated pink and white noise generators which are random and non-repeating up to 215 hours with EQ adjustments programmable on a per zone basis.The DSP8807 shall provide dynamic control and management based on IEEE802.1 AVB standards (Audio-Video Bridging) with independent 1⁄3 Octave (28) band EQ *(Filter type is Butterworth @ 19dB and Linkwitz-Riley at 24dB) and Parametric EQ for calibration of all PA, ambient level sensing and automatic volume control on a per zone basis. Paging (PA) presets shall be assigned in 10dB increments (10, 20, 30dB) per zone with automatic gain control (AGC) for all Telco and microphone paging inputs. The DSP8807 GUI called the ‘DSP Series Masking ControlSoftware’ shall control system setup. The software shall have the ability to expand up to (253) systems with over 2,000 zones (2,048) withprimary and secondary assignment in a zone paging dialing plan. It shall also provide the ability to set up All zone page, Group zone page (up to 32 groups) and single zone page with an architectural dialing plan (2-digit DTMF) set up in the GUI.Each DSP8807 shall be capable of managing remote ambient level sensing microphones (ALM-1) for each zone (x8) wired via a singleCAT5e cable up to 1,000 feet from the DSP8807 for automatic adjustment of the masking level based on real-time noise levels with set up and control via the GUI. Frequency response shall be 80Hz – 20kHz (±3dB) at rated output with .001% THD typical at 4dBu, 1kHz at 0dB gain and a Dynamic range of 102dB A-weighted. Mechanical dimensions shall be (L x W x H) 14" (358mm) x 19" (483mm) x 3.5" (89mm). All Power Components shall be UL Recognized, Boards Are UL94v0 and RoHS. DSP8807 shall be UL / CUL / FCC and CB (International) Listed.©2012 A t l a s S o u n d L .P . A l l r i g h t s r e s e r v e d . A t l a s S o u n d a n d S t r a t e g y S e r i e s a r e t r a d e m a r k s o f A t l a s S o u n d L .P . A l l o t h e r t r a d e m a r k s a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s . A T S 004406 R e v A 5/12D S P 8807B l o c k D i a g r a m。
