隔爆直流湿式阀用电磁铁使用说明书

电磁阀的使用说明选型要领：电磁阀选型首先应该依次遵循安全性，可靠性，适用性，经济性四大原则，其次是根据六个方面的现场工况(即管道参数、流体参数、压力参数、电气参数、动作方式、特殊要求进行选择)。

选型依据：一、根据管道参数选择电磁阀的：通径规格(即DN)、接口方式1、按照现场管道内径尺寸或流量要求来确定通径(DN)尺寸。

2、接口方式，一般>DN50要选择法兰接口，≤DN50则可根据用户需要自由选择。

二、根据流体参数选择电磁阀的：材质、温度组1、腐蚀性流体：宜选用耐腐蚀电磁阀和全不锈钢；食用超净流体：宜选用食品级不锈钢材质电磁阀。

2、高温流体：要选择采用耐高温的电工材料和密封材料制造的电磁阀，而且要选择活塞式结构类型的。

3、流体状态：大至有气态，液态或混合状态，特别是口径大于DN25订货时一定要区分开来。

4、流体粘度：通常在50cSt以下可任意选择，若超过此值，则要选用高粘度电磁阀。

三、根据压力参数选择电磁阀的：原理和结构品种1、公称压力：这个参数与其它通用阀门的含义是一样的，是根据管道公称压力来定。

2、工作压力：如果工作压力低则必须选用直动或分步直动式原理；最低工作压差在0.04Mpa以上时直动式、分步直动式、先导式均可选用。

四、电气选择：电压规格应尽量优先选用AC220V、DC24较为方便。

五、根据持续工作时间长短来选择：常闭、常开、或可持续通电1、当电磁阀需要长时间开启，并且持续的时间多余关闭的时间应选用常开型。

2、要是开启的时间短或开和关的时间不多时，则选常闭型。

3、但是有些用于安全保护的工况，如炉、窑火焰监测，则不能选常开的，应选可长期通电型。

六、根据环境要求选择辅助功能：防爆、止回、手动、防水雾、水淋、潜水1、爆炸性环境：必须选用相应防爆等级的电磁阀2、当管内流体有倒流现象时，可选择带止回功能电磁阀。

3、当需要对电磁阀进行现场人工操作时，可选择带手动功能电磁阀。

4、露天安装或粉尘多场合应选用防水，防尘品种(防护等级在IP54以上)。

ZC45B～1000B隔爆型多回转阀门电动装置使 用 说 明 书OPERATION INSTRUCTION MANUAL FOR FLAMEPROOF TYPE ZC ELECTRIC V ALVE ACTUATORS一、概述General Description本系列隔爆型阀门电动装置（简称隔爆电装）是ZC系列阀门电动装置的隔爆型。

ZC45B～ZC250B 为单机形式，ZC350B～1000B为单机叠加减速器形式。

隔爆标志有Ex dⅡBT4Gb和Ex dⅡCT4Gb。

本系列隔爆电装具有ZC系列电装的特点：功能全，性能可靠，控制系统先进，体积小，重量轻，品种规格齐等特点。

本产品性能指标达到GB/T24923-2010 《普通型阀门电动装置技术条件》的规定。

隔爆性能符合GB3836.1-2010《爆炸性环境用防爆电气设备通用要求》、GB3836.2-2010《爆炸性环境用防爆电气设备隔爆型电气设备“d”》及GB/T 24922-2010 《隔爆型阀门电动装置技术条件的规定》。

该系列隔爆型阀门电动装置用于阀瓣做直线运动的阀门，如截止阀、闸阀、节流阀、隔膜阀、水闸等。

可以用于明杆阀，也可以用于暗杆阀，是对阀门实现远控、集控和自动控制的必不可少的驱动装置。

This series flameproof electric valve actuators (flameproof actuator as abbreviation) are explosion-proof type of series ZC electric valve actuators. Types ZC45B～ZC250B are single unit actuators and Type ZC350B～ZC1000B are combination set of an actuator and a gear reducer. Flameproof marks are divided into dⅡBT4 and dⅡCT4. This series flameproof actuators are provided with features of series ZC actuators: of full functions, advanced in control system, small in size, complete in specifications. The performance of flameproof actuators conforms to Std GBT24922-2010 SPECIFICATIONS OF ELECTRIC V ALVE ACTUATORS OF COMMON TYPE.Flameproof performance of these products conforms to Std GB3836.1—2010 ELECTRICAL APPARATUS FOR EXPLOSIVE ATMOSPHERES-- GENERAL REQUIREMENTS and Std GB3836.2-2010 ELECTRICAL APPARATUS FOR EXPLOSIVE ATMOSPHERES—FLAMEPROOF ELECTRICAL APPARATUS“d”and Std JGBT 24922-2010 TECHNICAL SPECIFICATIONS OF FLAMEPROOF ELECTIRIC V ALVE ACTUATORS.This series flameproof electric valve actuators are suitable to valves of which the clacks move linearly, such as globe valves, gate valves, throttle valve, diaphragm valve etc. They can be used for rising stem valves and non-rising stem valves as well. They are necessary devices to carry out remote control, centralized control and automatic control of valve.二、型号表示方法Representation of TypeB表示隔爆型， B means flameproof type表示最大转圈数Means max. travel (revolutions)Output speed (r/min)T为推力型，I为电站型，无字母表示常规转矩型mode: T means thrust mode, I means connection mode forNominal output torque (×10N·m)ZC Product type: ZC例：ZC90T－18/ 40B表示输出公称转矩900N·m（约90kg·m)推力型，输出转速18r/ min，最大转圈数40，防爆型。

Dimensions: [mm]Scale - 2:1Scale - 1,5:176********768748015276874801527687480152T e m p e r a t u r eT T T 7687480152Cautions and Warnings:The following conditions apply to all goods within the product series of WE-TI-HV ofWürth Elektronik eiSos GmbH & Co. KG:General:•This electronic component is designed and manufactured for use in general electronic equipment.•Würth Elektronik must be asked for written approval (following the PPAP procedure) before incorporating the components into any equipment in fields such as military, aerospace, aviation, nuclear control, submarine, transportation (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network, etc. where higher safety and reliability are especially required and/or if there is the possibility of direct damage or human injury.•Electronic components that will be used in safety-critical or high-reliability applications, should be pre-evaluated by the customer. •The component is designed and manufactured to be used within the datasheet specified values. If the usage and operation conditions specified in the datasheet are not met, the wire insulation may be damaged or dissolved.•Do not drop or impact the components, the component may be damaged.•Würth Elektronik products are qualified according to international standards, which are listed in each product reliability report. Würth Elektronik does not warrant any customer qualified product characteristics beyond Würth Elektroniks’ specifications, for its validity and sustainability over time.•The responsibility for the applicability of the customer specific products and use in a particular customer design is always within the authority of the customer. All technical specifications for standard products also apply to customer specific products.Product specific:Soldering:•The solder profile must comply with the technical product specifications. All other profiles will void the warranty.•All other soldering methods are at the customers’ own risk.Cleaning and Washing:•Washing agents used during the production to clean the customer application might damage or change the characteristics of the wire insulation, marking or plating. Washing agents may have a negative effect on the long-term functionality of the product. Potting:•If the product is potted in the customer application, the potting material might shrink or expand during and after hardening. Shrinking could lead to an incomplete seal, allowing contaminants into the core. Expansion could damage the component. We recommend a manual inspection after potting to avoid these effects.Storage Conditions:• A storage of Würth Elektronik products for longer than 12 months is not recommended. Within other effects, the terminals may suffer degradation, resulting in bad solderability. Therefore, all products shall be used within the period of 12 months based on the day of shipment.•Do not expose the components to direct sunlight.•The storage conditions in the original packaging are defined according to DIN EN 61760-2.•The storage conditions stated in the original packaging apply to the storage time and not to the transportation time of the components. Packaging:•The packaging specifications apply only to purchase orders comprising whole packaging units. If the ordered quantity exceeds or is lower than the specified packaging unit, packaging in accordance with the packaging specifications cannot be ensured. Handling:•Violation of the technical product specifications such as exceeding the nominal rated current will void the warranty.•Applying currents with audio-frequency signals may result in audible noise due to the magnetostrictive material properties.•Due to heavy weight of the components, strong forces and high accelerations may have the effect to damage the electrical connection or to harm the circuit board and will void the warranty.•Please be aware that products provided in bulk packaging may get bent and might lead to derivations from the mechanical manufacturing tolerances mentioned in our datasheet, which is not considered to be a material defect.•The temperature rise of the component must be taken into consideration. The operating temperature is comprised of ambient temperature and temperature rise of the component.The operating temperature of the component shall not exceed the maximum temperature specified.These cautions and warnings comply with the state of the scientific and technical knowledge and are believed to be accurate and reliable.However, no responsibility is assumed for inaccuracies or incompleteness.Würth Elektronik eiSos GmbH & Co. KGEMC & Inductive SolutionsMax-Eyth-Str. 174638 WaldenburgGermanyCHECKED REVISION DATE (YYYY-MM-DD)GENERAL TOLERANCE PROJECTIONMETHODTRi001.0002021-03-02DIN ISO 2768-1mDESCRIPTIONWE-TI HV Radial Leaded WireWound Inductor (High Voltage)ORDER CODE7687480152SIZE/TYPE BUSINESS UNIT STATUS PAGEImportant NotesThe following conditions apply to all goods within the product range of Würth Elektronik eiSos GmbH & Co. KG:1. General Customer ResponsibilitySome goods within the product range of Würth Elektronik eiSos GmbH & Co. KG contain statements regarding general suitability for certain application areas. These statements about suitability are based on our knowledge and experience of typical requirements concerning the areas, serve as general guidance and cannot be estimated as binding statements about the suitability for a customer application. The responsibility for the applicability and use in a particular customer design is always solely within the authority of the customer. Due to this fact it is up to the customer to evaluate, where appropriate to investigate and decide whether the device with the specific product characteristics described in the product specification is valid and suitable for the respective customer application or not.2. Customer Responsibility related to Specific, in particular Safety-Relevant ApplicationsIt has to be clearly pointed out that the possibility of a malfunction of electronic components or failure before the end of the usual lifetime cannot be completely eliminated in the current state of the art, even if the products are operated within the range of the specifications.In certain customer applications requiring a very high level of safety and especially in customer applications in which the malfunction or failure of an electronic component could endanger human life or health it must be ensured by most advanced technological aid of suitable design of the customer application that no injury or damage is caused to third parties in the event of malfunction or failure of an electronic component. Therefore, customer is cautioned to verify that data sheets are current before placing orders. The current data sheets can be downloaded at .3. Best Care and AttentionAny product-specific notes, cautions and warnings must be strictly observed. Any disregard will result in the loss of warranty.4. Customer Support for Product SpecificationsSome products within the product range may contain substances which are subject to restrictions in certain jurisdictions in order to serve specific technical requirements. Necessary information is available on request. In this case the field sales engineer or the internal sales person in charge should be contacted who will be happy to support in this matter.5. Product R&DDue to constant product improvement product specifications may change from time to time. As a standard reporting procedure of the Product Change Notification (PCN) according to the JEDEC-Standard inform about minor and major changes. In case of further queries regarding the PCN, the field sales engineer or the internal sales person in charge should be contacted. The basic responsibility of the customer as per Section 1 and 2 remains unaffected.6. Product Life CycleDue to technical progress and economical evaluation we also reserve the right to discontinue production and delivery of products. As a standard reporting procedure of the Product Termination Notification (PTN) according to the JEDEC-Standard we will inform at an early stage about inevitable product discontinuance. According to this we cannot guarantee that all products within our product range will always be available. Therefore it needs to be verified with the field sales engineer or the internal sales person in charge about the current product availability expectancy before or when the product for application design-in disposal is considered. The approach named above does not apply in the case of individual agreements deviating from the foregoing for customer-specific products.7. Property RightsAll the rights for contractual products produced by Würth Elektronik eiSos GmbH & Co. KG on the basis of ideas, development contracts as well as models or templates that are subject to copyright, patent or commercial protection supplied to the customer will remain with Würth Elektronik eiSos GmbH & Co. KG. Würth Elektronik eiSos GmbH & Co. KG does not warrant or represent that any license, either expressed or implied, is granted under any patent right, copyright, mask work right, or other intellectual property right relating to any combination, application, or process in which Würth Elektronik eiSos GmbH & Co. KG components or services are used.8. General Terms and ConditionsUnless otherwise agreed in individual contracts, all orders are subject to the current version of the “General Terms and Conditions of Würth Elektronik eiSos Group”, last version available at .Würth Elektronik eiSos GmbH & Co. KGEMC & Inductive SolutionsMax-Eyth-Str. 174638 WaldenburgGermanyCHECKED REVISION DATE (YYYY-MM-DD)GENERAL TOLERANCE PROJECTIONMETHODTRi001.0002021-03-02DIN ISO 2768-1mDESCRIPTIONWE-TI HV Radial Leaded WireWound Inductor (High Voltage)ORDER CODE7687480152SIZE/TYPE BUSINESS UNIT STATUS PAGE。

QBZ系列矿用隔爆型真空电磁起动器说明书默认分类2010-03-25 12:49:22 阅读456 评论2 字号：大中小\一、适用范围QBZ系列矿用隔爆型真空电磁起动器主要适用于具有爆炸性危险气体（甲烷、煤尘混合物）的煤矿井下，在额定电压380、660V，额定频率50Hz，额定电流至200A的三相交流中性点不直接接地供电系统中，对隔爆型三相鼠笼型电动机直接起动、停止和反转控制。

起动器具有失压、过压、短路、过载、断相及漏电闭锁等保护。

1、起动器采用三极真空交流接触器，主触头密封在真空开关管内，无需维护，具有电弧不外露，适用于频繁操作，主触头磨损小，电寿命长，安全可靠的特点。

2、起动器采用新型换相隔离开关，换相动作可靠，并有经改进的灭弧罩，灭弧效果良好。

3、具有就地和远距离控制电机起动停止的功能，具有JDB型电机综合保护器实现过载、断相、短路及漏电闭锁保护。

二、环境条件a）周围环境温度为-5℃~ +40℃；b）相对湿度不大于95%（+25℃）；c）海拔高度不超过2000m（0.08~0.11MPa）；d）具有甲烷及煤尘混合气体的煤矿井下；e）无破坏金属和绝缘材料的腐蚀性气体的地方；f）与垂直面的安装倾斜度不超过15°；g）在无显著摇动和冲击振动的地方；h）能防止滴水的地方；i）环境污染等级为3级；j）安装类别为Ⅲ类；三、技术特征1、型号含义Q B Z —额定电流 / 额定电压电磁起动器隔爆型真空2、防爆型式起动器为矿用隔爆型：ExdI3、技术参数3.1、本体主要技术数据见表1表13.2、JDB电机综合保护主要技术性能及整定见表23.2.1过载保护特性如表2JDB电流整定表表2-1注：JDB33#线是漏电闭锁线，使用时应和开关电压相符。

表2-23.2.2断相保护特性如表33.2.3短路保护特性如表43.2.4漏电闭锁起动器应具有漏电闭锁保护功能，当主电路对地绝缘电阻降到表5动作值以下时，应实现主电路漏电闭锁，当上升到动作值的1.5倍时，应解除主电路漏电闭锁。

FBKZ型隔爆型电动阀门控制器使用说明书天津百利二通电器有限公司目录一、 概述 (1)二、 防爆性能 (1)三、 主要技术参数 (2)四、 基本工作原理 (2)五、 安装和接线 (3)六、 注意事项 (5)七、 控制器外形图及安装尺寸 (5)一、 概述：FBKZ隔爆型电动阀门控制器（以下称控制器），是与防爆型阀门电动装置配套使用的。

它主要用于控制电动阀门的开关，并完成阀位状态显示。

FBKZ型控制器不仅能与开关型阀门电动装置匹配，它还可根据用户需求提供特殊的控制功能。

控制器的防爆性能符合GB3836.1-2000爆炸性气体环境用电气设备第1部分通用要求和GB3836.2-2000 爆炸性气体环境用电气设备第2部分隔爆型“d”的有关规定,产品性能符合津Q/12YJ4429-2008《阀门电动装置控制设备》的规定。

控制器的有关文件，样机样件均按规定程序通过国家指定的防爆产品审查机关的审查、检验、试验，并取得上述机关颁发的防爆合格证,防爆合格证证号：CE081248。

二、 防爆性能：控制器为隔爆型，其外壳可以承受内部爆炸性气体混合物爆炸产生的压力，并能阻止内部的爆炸引燃外壳周围环境中的爆炸性气体混合物。

控制器的防爆标志为：ExdⅡBT4。

Ex—防爆标志d—防爆型式为隔爆型。

Ⅱ—工厂用电气设备。

B—级别，决定隔爆面参数。

T4—温度组别，允许最高表面温度为135℃。

可燃性气体、蒸汽级别，温度组别举例可参阅GB3836.1-2000标准中的附录B栏目。

控制器各部位隔爆结合面参见（图1）中字母“I”所指处。

上述隔爆面均为圆形配合面隔爆型式。

控制器开度表和指示灯部分为透明件防爆结构。

除开度微调钮、现场/远控钮、开阀/停止/关阀钮的隔爆面长度大于12.5mm外，其余隔爆面长度均为25mm。

三、 主要技术参数：1. 额定电压：380V AC，50Hz 三相四线制（或按要求）2. 环境温度：-20~40℃3. 相对湿度：≤90%（25℃）4. 海拔高度：不高于1000米5. 防护等级：IP67其余参数详见产品铭牌，当产品具有特殊功能时，将提供给用户相关的附加说明以明确特殊部分的技术参数。

sil认证防爆电磁阀使用说明欢迎您使用Sil认证防爆电磁阀！Sil认证防爆电磁阀是一款专为石油、化工、制药、食品等行业需求而设计的高安全、高可靠性的电磁阀。

凭借其精心制作，超强的安全性和可靠性，Sil认证防爆电磁阀可以满足越来越多的行业客户的需求，并可以提供最高质量的服务。

一、 Sil认证防爆电磁阀的特点1、工作环境：Sil认证防爆电磁阀适用于在一般环境中使用，也可用于高温、高压、腐蚀性等恶劣环境下工作，可以满足各类需求。

2、操作性：Sil认证防爆电磁阀具有操作简便、响应快、动作可靠等优点，操作者可以轻松掌握阀门的操作方法，节省时间。

3、安全可靠：Sil认证防爆电磁阀采用先进的技术，拥有安全可靠的功能，可以有效保障阀门使用安全，故障率低。

4、维护方便：Sil认证防爆电磁阀外壳及其他部件耐腐蚀，能在经常恶劣环境中保持原有性能。

使用时，只需要进行定期检查和清洁，就可以保证阀门有效可靠运行。

二、Sil认证防爆电磁阀的安装方法1、准备工作：在安装Sil认证防爆电磁阀之前，应当检查安装场所的环境条件，包括温度、湿度、空气和灯具等是否符合使用要求，以确保阀门的安全和可靠性。

2、安装方法：Sil认证防爆电磁阀安装时应尽量避免在振动的地方安装，并确保正确的安装方式，安装管路应垂直于设备的水平面，以保证阀门的正常工作。

3、接线方法：施工人员在安装完毕后，应当检查Sil认证防爆电磁阀连接线和输入电源是否有良好的接触，以确保阀门的正常使用。

三、 Sil认证防爆电磁阀的使用注意事项1、操作方式：Sil认证防爆电磁阀可以采用手动或自动控制方式操作，施工人员可以根据需要自行选择适用的操作方式，以保证阀门的可靠性和安全性。

2、定期维护：为保证阀门的有效使用，施工人员在使用时应当定期检查阀门的接线、密封以及内腔的清洁，以确保阀门有效工作。

3、安全使用：施工人员在使用Sil认证防爆电磁阀时，应当熟练掌握其使用方法，避免人为操作失误，保证阀门的安全性。

.目录Index1、基本原理和使用条件Basic principle and operating conditions2、产品型号及含义Models and contents3、用途及使用范围Usage and applicable range4、结构及特点Structure and characteristic5、电气性能Electrical property6、型号、技术参数与外形尺寸图Models, technical data, and overall dimension drawing 7、使用注意事项Cautions8、保养及维修Maintenance and service1.基本原理和使用条件 Basic principle and operating conditions1.1 基本原理 Basic principle电磁铁工作时，电源及控制设备向电磁铁供给直流电，电磁铁内部产生强大的磁场，通过壳体磁路和工作气隙对被吸物产生强大磁力而达到搬运物料的目的。

When electromagnet works, the power source and the controlling device supply direct current to the electromagnet. A strong magnetic field will be generated inside the electromagnet, the magnetic field gives enough strong magnetic force on the material through the shell magnetic circuit and the operating clearance to lift the bulk material .1.2 使用条件 using conditions1.2.1 使用地点的海拔高度不超过2000m。

Q/*************企业标准Q/***-2008 DTBF型矿用隔爆型电磁铁2008-**-** 发布2008-**-** 实施*********发布Q/***-2008前言本标准是对Q/NCT1-2002标准的修订。

本标准由*******************公司提出。

本标准由*******************公司技术开发部起草。

本标准起草人：****本标准审核人：****本标准批准人：****本标准历次发布情况：Q/NCT1-2002。

Q/***-2008DTBF 型矿用隔爆型电磁铁1 范围1.1 本标准规定了DTBF 型矿用隔爆型电磁铁(以下简称电磁铁)的基本参数、技术要求、试验方法、检验规则。

1.2 本电磁铁适用于可在周围空气中的甲烷、煤尘等不超过《煤矿安全规程》中所规定的安全含量的矿井中使用。

2 规范性引用文件下列文件中的条款，通过本标准的引用而成为本标准的条款。

凡是注日期的引用文件，其随后所有的修改单（不包括勘误的内容）或修订版均不适用于本标准，然而鼓励根据本标准达成协议的各方研究是否使用这些文件的最新版本，凡是不注日期的引用文件，其最新版适用于本标准。

GB2423.4-1993 电工电子产品基本环境试验规程 试验Db ：交变湿热试验方法 GB3836.1-2000 爆炸性性气体环境用电气设备第一部分通用要求； GB3836.2-2000 爆炸性气体环境用电气设备第一部分隔爆型“d ”； GB3836.3-2000 爆炸性气体环境用电气设备 第三部分：增安型“e ” GB/T14048.1-2006 低压开关设备和控制设备 第一部分：总则 JB/T5244-2001 液压阀用电磁铁MT/T154.2-1996 煤矿用电器设备产品型号编制方法和管理办法 MT/T661-1997 煤矿井下用电器设备通用技术条件 MT/T715-1997 矿用防爆电磁阀AQ 1043-2007 矿用产品安全标志标识3 型式及基本参数3.1 防爆型式 矿用隔爆型“ExdI ”。

请在使用本公司产品前仔细阅读本说明书1）正确的使用本公司产品，不必要的损失和事故将得到避免！您应遵守本说明书的规定，因为意外的损失和事故的发生，往往是一些人的粗心，疏忽和大意引起的！2）开度视窗不得与硬物碰撞。

3）与阀门连接所用螺栓强度不得低于8.8 级。

4）不得在阴雨天户外打开电气箱盖、电机等密封部位。

5）安装或重装后，首次电动操作，必须使阀门处于中间位置检查开、关方向，必须按调试要求进行逐项调试，检查各部件正常后，才能投入使用。

6）安装拆卸调试时不可损伤密封面，密封件和隔爆型阀门电动装置的隔爆面，重装时盖严紧固并必须确保电气箱盖和电缆进出口处密封良好，以防雨水，潮气进入，造成电器元件失效及零件锈蚀。

7）手动操作时应将手-电动切换手柄按箭头方向推动（或拉），若推不到位时应边转动手轮边推动手柄，切换到位后即可手动操作，手轮旋向与输出轴旋向一致，正常顺时针为关阀，逆时针为开阀；电动时切换手柄将自动复位，切不可将手柄强行扳回，否则损坏阀门电动装置。

8）不得在爆炸环境下拆去与电气有关的箱盖带电调试阀门电动装置，打开电气箱盖时，必须先切断电源。

9）阀门电动装置上的阀杆保护套或闷盖应旋紧，取下修理或保养时，用遮盖装置顶部，以防止灰尘、砂石及其它外来物进入内腔，造成阀杆或阀杆螺母的损坏10）阀门电动装置采用阀门专用电动机，为短时工作制，持续工作时间不得超过铭牌标定时间。

11）当阀门不经常工作时，应定期检查保养并进行操作，建议1 月/次，时间不超过10 分钟。

12）对于阀门电动装置在工况环境、规格、性能参数、连接尺寸、电路等方面有特殊要求时，本公司可按特殊要求供货。

！本产品请务必存放于清洁干燥的室内，如果存放于室外，应与地面保持一定的高度，并应做好防雨、防潮保护措施，以防止冷凝水对设备造成的不必要损坏前言感谢使用DZW 系列阀门电动装置，在安装调试之前请仔细阅读本说明书。

关于本说明使用说明书本说明书应交付给最终用户使用，敬请爱惜和妥善保存；在开始操作前务请仔细阅读本使用说明书以充分理解操作该产品的使用方法和调试方法；本使用说明书的内容如有变动恕不另行通知；在编写本说明书时已尽力确保其正确性，如用户发现有任何错误或遗漏，请与我公司市场部联系。

Dimensions: [mm]Bolt used only for mechanical stabilityProduct Marking:Marking760801401YY WW (year-week)760801401Airflow testing was done with 115mm Ø fan and air velocity was measured directly in front of the part between the fan and part.760801401760801401760801401T e m p e r a t u r eT T T 760801401Further informationComponent Libraries:Download_3D_WE-TORPFC_76080X401Altium_WE-TORPFC (23b)Cadence_WE-TORPFC (23b)Eagle_WE-TORPFC (23a)Download_IGS_WE-TORPFC-76080X401L TSpice_WE-TORPFC (23a)PSpice_WE-TORPFC (23a)Download_STP_WE-TORPFC-760801401Free Sample Order:Order free samples of this article directly here!Wurth Electronics Midcom Inc. Headquarters121 Airport Drive57201 Watertown, SDUnited StatesPhone: +1 (605) 886-4385CHECKED REVISION DATE (YYYY-MM-DD)GENERAL TOLERANCE PROJECTIONMETHODWJK001.0012023-12-11ISO 2768-1mDESCRIPTIONWE-TORPFC Toroidal PFC ChokeORDER CODE760801401SIZE/TYPE BUSINESS UNIT STATUS PAGECautions and Warnings:The following conditions apply to all goods within the product series of WE-TORPFC of Würth Elektronik eiSos GmbH & Co. KG:General:•This electronic component is designed and manufactured for use in general electronic equipment.•Würth Elektronik must be asked for written approval (following the PPAP procedure) before incorporating the components into any equipment in fields such as military, aerospace, aviation, nuclear control, submarine, transportation (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network, etc. where higher safety and reliability are especially required and/or if there is the possibility of direct damage or human injury.•Electronic components that will be used in safety-critical or high-reliability applications, should be pre-evaluated by the customer. •The component is designed and manufactured to be used within the datasheet specified values. If the usage and operation conditions specified in the datasheet are not met, the wire insulation may be damaged or dissolved.•Do not drop or impact the components, as the component may be damaged.•Würth Elektronik products are qualified according to international standards, which are listed in each product reliability report. Würth Elektronik does not warrant any customer qualified product characteristics beyond Würth Elektronik’s specifications, for its validity and sustainability over time.•The responsibility for the applicability of the customer specific products and use in a particular customer design is always within the authority of the customer. All technical specifications for standard products also apply to customer specific products.Product specific:Soldering:•The solder profile must comply with the technical product specifications. All other profiles will void the warranty.•All other soldering methods are at the customers’ own risk.Cleaning and Washing:•Washing agents used during the production to clean the customer application might damage or change the characteristics of the wire insulation, marking or plating. Washing agents may have a negative effect on the long-term functionality of the product. Potting:•If the product is potted in the customer application, the potting material might shrink or expand during and after hardening. Shrinking could lead to an incomplete seal, allowing contaminants into the core. Expansion could damage the component. We recommend a manual inspection after potting to avoid these effects.Storage Conditions:• A storage of Würth Elektronik products for longer than 12 months is not recommended. Within other effects, the terminals may suffer degradation, resulting in bad solderability. Therefore, all products shall be used within the period of 12 months based on the day of shipment.•Do not expose the components to direct sunlight.•The storage conditions in the original packaging are defined according to DIN EN 61760-2.•The storage conditions stated in the original packaging apply to the storage time and not to the transportation time of the components. Packaging:•The packaging specifications apply only to purchase orders comprising whole packaging units. If the ordered quantity exceeds or is lower than the specified packaging unit, packaging in accordance with the packaging specifications cannot be ensured. Handling:•Violation of the technical product specifications such as exceeding the nominal rated current will void the warranty.•Applying currents with audio-frequency signals may result in audible noise due to the magnetostrictive material properties.•Due to heavy weight of the components, strong forces and high accelerations may have the effect to damage the electrical connection or to harm the circuit board and will void the warranty.•The temperature rise of the component must be taken into consideration. The operating temperature is comprised of ambient temperature and temperature rise of the component.The operating temperature of the component shall not exceed the maximum temperature specified.These cautions and warnings comply with the state of the scientific and technical knowledge and are believed to be accurate and reliable.However, no responsibility is assumed for inaccuracies or incompleteness.Wurth Electronics Midcom Inc. Headquarters121 Airport Drive57201 Watertown, SDUnited StatesPhone: +1 (605) 886-4385CHECKED REVISION DATE (YYYY-MM-DD)GENERAL TOLERANCE PROJECTIONMETHODWJK001.0012023-12-11ISO 2768-1mDESCRIPTIONWE-TORPFC Toroidal PFC ChokeORDER CODE760801401SIZE/TYPE BUSINESS UNIT STATUS PAGEImportant NotesThe following conditions apply to all goods within the product range of Würth Elektronik eiSos GmbH & Co. KG:1. General Customer ResponsibilitySome goods within the product range of Würth Elektronik eiSos GmbH & Co. KG contain statements regarding general suitability for certain application areas. These statements about suitability are based on our knowledge and experience of typical requirements concerning the areas, serve as general guidance and cannot be estimated as binding statements about the suitability for a customer application. The responsibility for the applicability and use in a particular customer design is always solely within the authority of the customer. Due to this fact it is up to the customer to evaluate, where appropriate to investigate and decide whether the device with the specific product characteristics described in the product specification is valid and suitable for the respective customer application or not.2. Customer Responsibility related to Specific, in particular Safety-Relevant ApplicationsIt has to be clearly pointed out that the possibility of a malfunction of electronic components or failure before the end of the usual lifetime cannot be completely eliminated in the current state of the art, even if the products are operated within the range of the specifications.In certain customer applications requiring a very high level of safety and especially in customer applications in which the malfunction or failure of an electronic component could endanger human life or health it must be ensured by most advanced technological aid of suitable design of the customer application that no injury or damage is caused to third parties in the event of malfunction or failure of an electronic component. Therefore, customer is cautioned to verify that data sheets are current before placing orders. The current data sheets can be downloaded at .3. Best Care and AttentionAny product-specific notes, cautions and warnings must be strictly observed. Any disregard will result in the loss of warranty.4. Customer Support for Product SpecificationsSome products within the product range may contain substances which are subject to restrictions in certain jurisdictions in order to serve specific technical requirements. Necessary information is available on request. In this case the field sales engineer or the internal sales person in charge should be contacted who will be happy to support in this matter.5. Product R&DDue to constant product improvement product specifications may change from time to time. As a standard reporting procedure of the Product Change Notification (PCN) according to the JEDEC-Standard inform about minor and major changes. In case of further queries regarding the PCN, the field sales engineer or the internal sales person in charge should be contacted. The basic responsibility of the customer as per Section 1 and 2 remains unaffected.6. Product Life CycleDue to technical progress and economical evaluation we also reserve the right to discontinue production and delivery of products. As a standard reporting procedure of the Product Termination Notification (PTN) according to the JEDEC-Standard we will inform at an early stage about inevitable product discontinuance. According to this we cannot guarantee that all products within our product range will always be available. Therefore it needs to be verified with the field sales engineer or the internal sales person in charge about the current product availability expectancy before or when the product for application design-in disposal is considered. The approach named above does not apply in the case of individual agreements deviating from the foregoing for customer-specific products.7. Property RightsAll the rights for contractual products produced by Würth Elektronik eiSos GmbH & Co. KG on the basis of ideas, development contracts as well as models or templates that are subject to copyright, patent or commercial protection supplied to the customer will remain with Würth Elektronik eiSos GmbH & Co. KG. Würth Elektronik eiSos GmbH & Co. KG does not warrant or represent that any license, either expressed or implied, is granted under any patent right, copyright, mask work right, or other intellectual property right relating to any combination, application, or process in which Würth Elektronik eiSos GmbH & Co. KG components or services are used.8. General Terms and ConditionsUnless otherwise agreed in individual contracts, all orders are subject to the current version of the “General Terms and Conditions of Würth Elektronik eiSos Group”, last version available at .Wurth Electronics Midcom Inc. Headquarters121 Airport Drive57201 Watertown, SDUnited StatesPhone: +1 (605) 886-4385CHECKED REVISION DATE (YYYY-MM-DD)GENERAL TOLERANCE PROJECTIONMETHODWJK001.0012023-12-11ISO 2768-1mDESCRIPTIONWE-TORPFC Toroidal PFC ChokeORDER CODE760801401SIZE/TYPE BUSINESS UNIT STATUS PAGE。

ZCF300电磁阀使用说明书上海大禹自控阀门有限公司Shanghai Dayu Automatics Control Valve Co.,Ltd.地址：上海市浦东新区航头镇大麦湾工业园区航川路66号邮编：201316电话：************传真：************ E-mail:****************一、概述ZCF300四氟电磁阀应用于强酸、强碱、强氧化剂及有机溶剂等强腐蚀性流体介质以及超纯流体。

例如盐酸、浓硫酸，各种电镀液、芳香族溶剂、脂脂族溶剂、高洁净流体等管路的自动控制。

广泛应用于各种腐蚀性介质自动化流体控制的最佳配套产品。

二、型号编制说明图1五、安装尺寸图3图41、安装前应仔细阅读产品的使用说明书，查核产品是否完全符合使用要求，熟悉安装要点，做好准备工作。

2、安装时电磁阀线圈向上，并保持垂直位置，电磁阀上箭头或标记应与管道流向一致，不得安装在1.电磁阀2.手动阀3.过滤器旁路装置1.电磁阀2.手动阀3.过滤器分路装置有溅水或漏水的地方。

3、电磁阀的工作介质应清洁无颗粒杂质，电磁阀内件表面上的污物及过滤器，须定期清洁干净。

4、在电磁阀发生故障时，为了及时隔离电磁阀，并保证系统正常运行，最好安装旁路装置。

如图3当电磁阀安装在支路时，电磁阀的口径应比主管道的阀门口径小，如图4分路安装。

注意：支路上的阀平时须关闭。

5、不要将阀门安装于管道低凹处，以免蒸汽冷凝水、杂质等沉淀在阀内而妨碍动作。

6、普通型电磁阀不可在易燃易爆危险场合使用。

7、在管道刚性不足情况下，建议把阀前后管子用支架固定，以防电磁阀工作时引起振动。

8、在安装前，要注意看清产品标牌，认真阅读使用说明书，判断产品是否符合使用条件。

9、电磁阀前后管道上需装压力表，以便观察管道压力。

七、电磁阀使用维修1、建议使用单位派专人负责，使用和维护。

2、电磁阀安装后或长时间停用后再次投入运行时，必须通入介质试动作数次，工作正常后方可投入正式使用。

湿式报警阀说明书一、概述1.定义：GB50084－2001《自动喷水灭火系统设计规范》定义：湿式系统wet pipe system 由闭式洒水喷头、水流指示器、湿式报警阀组以及管道和供水设施等组成，准工作状态时管道内充满用于启动系统的有压水的闭式系统。

2.应用范围：自动喷水灭火系统是目前世界上使用最普遍的一种固定灭火设备，主要应用于人员密集、不易疏散、外部增援灭火与救生较困难的性质重要或火灾危险性较大的场所。

湿式系统要求环境温度不低于4℃，且不高于70℃。

常用的场所有：工业及一般燃烧物资仓库、宾馆、商场、医院、剧院、办公楼、会议中心，特别适用于高层建筑和地下工程。

自动喷水灭火湿式系统不适用以下场所：*存有遇水发生爆炸或加速燃烧的物品的场所；*存有遇水发生剧烈化学反应或产生有毒有害物质的物品的场所；*存有洒水将导致喷溅或沸溢的液体的场所；*露天场所。

3.特点：*本系统使用环境温度4℃～70℃*本系统与其它自动喷水灭火系统系统比较，结构相对简单、实用、可靠。

*本系统具有安全可靠、灭火控火成功率高，使用期长，适用范围广、维修方便、成本低廉等优点。

4 . 认证：*本公司的产品通过ISO9001质量体系认证*本公司生产的自动喷水灭火系统湿式报警阀组满足GB5135.2－2003《自动喷水灭火系统第2部分：湿式报警阀、延迟器、水力警铃》*本公司生产的自动喷水灭火系统水流指示器满足GB5135.7-2003《自动喷水灭火系统第7部分：水流指示器》*本公司生产的自动喷水灭火系统闭式洒水喷头满足GB5135.1-2003 《自动喷水灭火系统第1部分：洒水喷头》*本公司生产的自动喷水灭火系统产品被评为“江苏名牌产品”二、系统结构及工作原理1.系统结构示意图如图2.1所示图2.1湿式系统结构示意图2系统各部件说明3系统动作原理：*伺应状态湿式报警系统由消防水箱或稳压泵、气压给水设备等稳压设施维持管道内充水压力，且无水通过阀瓣组件下游系统侧任何出口流出。
