2SK3314

2SK3314

2002-01-25 1 TOSHIBA Field Effect Transistor Silicon N Channel MOS Type (π−MOSV)

2SK3314

Chopper Regulator, DC−DC Converter Applications

Motor Drive Applications

l Fast reverse recovery time : trr = 105 ns (typ.) l Built−in high−speed free−wheeling diode l Low drain−source ON resistance : RDS (ON) = 0.35 Ω (typ.) l High forward transfer admittance : |Yfs| = 9.9 S (typ.) l Low leakage current : IDSS = 100 µA (max) (VDS = 500 V) l Enhancement−mode : Vth = 2.0~4.0 V (VDS = 10 V, ID = 1 mA) Maximum Ratings (Ta = 25°C) Characteristics Symbol Rating

Unit

Drain−source voltage VDSS 500 V

Drain−gate voltage (RGS = 20 kΩ) VDGR 500 V

Gate−source voltage VGSS ±30 V

DC (Note 1) ID 15 A Drain current Pulse (Note 1) IDP 60 A

Drain power dissipation (Tc = 25°C) PD 150 W

Single pulse avalanche energy (Note 2) EAS 630 mJ

Avalanche current IAR 15 A

Repetitive avalanche energy (Note 3) EAR 15 mJ

Channel temperature Tch 150 °C

Storage temperature range Tstg −55~150 °C Thermal Characteristics

Characteristics Symbol Max Unit

Thermal resistance, channel to case Rth (ch−c) 0.833 °C / WThermal resistance, channel to ambient Rth (ch−a) 50 °C / W

Note 1: Please use devices on condition that the channel temperature is below 150°C.

Note 2: VDD = 90 V, Tch = 25°C (initial), L = 4.76 mH, RG = 25 Ω, IAR = 15 A

Note 3: Repetitive rating; Pulse width limited by maximum channel temperature.

This transistor is an electrostatic sensitive device. Please handle with caution.

Unit: mm

1. GATE 2. DRAIN (HEAT SINK) 3. SOURCE

JEDEC ―

JEITA ―

TOSHIBA 2-16C1B

Weight: 4.6 g (typ.)

2SK3314

2002-01-25 2Electrical Characteristics (Ta = 25°C) Characteristics Symbol Test Condition Min Typ. MaxUnit

Gate leakage current IGSS VGS = ±25 V, VDS = 0 V — — ±10µA Gate−source breakdown voltage V (BR) GSS IG = ±100 µA, VDS = 0 V ±30 — — V

Drain cut−off current IDSS VDS = 500 V, VGS = 0 V — — 100µA

Drain−source breakdown voltage V (BR) DSS ID = 10 mA, VGS = 0 V 500 — — V

Gate threshold voltage Vth VDS = 10 V, ID = 1 mA 2.0 — 4.0 V

Drain−source ON resistance RDS (ON) VGS = 10 V, ID = 7 A — 0.35 0.49Ω

Forward transfer admittance |Yfs| VDS = 10 V, ID = 7 A 5.0 9.9 — S

Input capacitance Ciss — 2600 —

Reverse transfer capacitance Crss — 280 —

Output capacitance Coss VDS = 10 V, VGS = 0 V, f = 1 MHz

— 880 — pF

Rise time tr — 50 —

Turn−on time ton — 85 —

Fall time tf — 65 — Switching time

Turn−off time toff — 260 — ns

Total gate charge (Gate−source plus gate−drain) Qg — 58 —

Gate−source charge Qgs — 36 —

Gate−drain (“miller”) charge Qgd VDD ≈ 400 V, VGS = 10 V, ID = 15 A

— 22 — nC

Source−Drain Ratings and Characteristics (Ta = 25°C)

Characteristics Symbol Test Condition Min Typ. MaxUnit

Continuous drain reverse current (Note 1) IDR — — — 15 A

Pulse drain reverse current (Note 1) IDRP — — — 60 A

Forward voltage (diode) VDSF IDR = 15 A, VGS = 0 V — — −1.7V

Reverse recovery time trr — 105 180ns

Reverse recovery charge Qrr IDR = 15 A, VGS = 0 V dIDR / dt = 100 A / µs — 0.24 — µC Marking

2SK3314

2002-01-25

3

2SK3314

2002-01-25

4

2SK3314

2002-01-25

5

RG = 25 Ω VDD = 90 V, L = 4.76 mH ÷÷øöççèæ-×××=DDVDSSVDSSASVBBIL21E22SK3314

2002-01-25

6
