图 1
如上图1所示；用光标点中有 ‘？’的网元，然后打开菜单Supervision执行Start命令，激活对网元的监控。
终端开始对选定的网元进行搜索监控，CT终端显示如下内容，如图2所示；
图 2
搜索完毕后，CT终端显示被监控的网元为绿色，右边方框显示出被监控网元的告警数量和Local网络地址及各种标示符。
图 3
然后打开菜单Supervision执行Login 命令,成功登录监控1650SMC单元后，监控终端的CT 进入设备子架的图形界面，如下图4所示；
图 1
如上图1所示；用光标点中有 ‘？’的网元，然后打开菜单Supervision执行Start命令，SupervisionÆStart’，激活对网元的监控。
终端开始对选定的网元进行搜索监控，CT终端显示如
图 2
搜索完毕后，CT终端显示被监控的网元为绿色，右边方框显示出被监控网元的实时告警数量Local网络地址及各种标示符。
图 3
成功登录监控1670SM单元后，监控终端的CT界面进入设备机架的图形界面，如下图4所示；
图11
图18
个指示灯：。
阿尔卡特程控交换机常用操作F1〔Ctrl+V〕——确定、保存F2〔Ctrl+C〕——返回、退出Ctrl+W ——屏幕刷新箭头键——通过上下左右键在各菜单项中进行选择回车键——用于进入下层菜单和选中某项菜单项Ctrl +F——向下翻页Ctrl+B——向上翻页Ctrl+I〔Tab〕——查看当前菜单项的帮助文件Backspace——删除键1.Chcp 437 命令清除乱码界面。
2.Telnet 登陆程控交换机IP地址。
登陆账号：mtcl登陆密码：mtcl.3.Mgr进入系统菜单主页面。
下面是mgr界面选项的一些翻译（1）Shelf 注：ACT架构设置选项（2）Media Gateway 注：媒体网关管理（3）Dect System 注：Dect无线系统（4）System 注：系统设置选项（5）Translator 注：号码编译管理选项（6）Categories 注：类别管理选项（7）Attendant 注：服务总机、话务台设置选项（8）Users 注：分机管理（9）Profiled Users 注：使用模板创建用户（10）Set Profiles 注：模板功能管理（11）Groups 注：组设置选项（12）Abbreviated Numbering 注：缩位拨号设置（13）Phone Book 注：本设置（14）Entities 注：实体管理（15）Trunk Groups 注：中继组管理（16）External Services 注：外界服务（17）Inter-Node Links 注：节点互连（18）X25 注：X25管理（19）DATA 注：数据（20）Applications 注：应用4.创建分机号码：在Mgr主菜单下选择Users按下回车，然后选择Creat进入创建用户分机号码界面。
Directory Name:________(设置名称，只支持英文)Directory First Name:______(设置姓，只支持英文)Directory Number:___________(此项为分机号码设置选项)Shelf Address:______(此项默认值为255，由于根据现实情况程控交换机只有两个ACT-28框架，因此我们只能在这选项中设置0或者1，要么ACT0、要么ACT1) Board Address:________(此项默认值为255，选择板位号。
OXE数字程控交换机分机操作简明手册一、普通话机使用简要说明：1、呼叫话务员摘机，拨02、呼叫内线摘机，拨分机号码（话机号码或坐席号码），通话后挂机。
3、呼叫外线摘机，拨9，听二次拨号音后拨外线号码。
如对方为电脑话务员，也可直接拨分机号。
如为数字话机（4035话机），通话后按“DTMF”键，再拨对方分机号。
4、回叫应答如为模拟分机，摘机后可听到“你有一个回叫。
”，如保持摘机，可自动对主叫振铃。
也可在摘机后立即拨*67取消回叫。
如为数字分机，留言灯会闪烁，按此键，会提示有新信息，拨*67可查询到回叫分机号码，不做其他操作，稍后会自动对回叫分机振铃。
5、转接在通话过程中，模拟话机可拍叉（或按R键），将通话方保留，听语音提示后，拨分机号码（数字话机可在通话过程中直接拨分机号码），听回铃音或分机应答后挂机，就可将通话转接到其他分机。
6、转移立即转移—摘机，拨*60，再拨要转去的目的分机号码，挂机。
所有来话均自动转移到设定的目的分机上。
4010分机也可按“转移”键，再输入要转移到的目的分机号码，挂机，转移灯亮，屏幕显示转移到某分机号码。
取消再按“转移”键，提示转移取消。
忙线转移—摘机，拨*61，再拨要转去的目的分机号码，挂机。
本机忙线时所有来话均自动转移到设定的目的分机上。
无应答转移---摘机，拨*62，再拨要转去的目的分机号码，挂机。
本机无人应答时所有来话均自动转移到设定的目的分机上。
取消转移----摘机，听提示时，拨*64，可取消已设定的转移功能。
7、提醒服务设定---摘机，拨*66HHMM，其中：HH—两位数表示的小时，MM--两位数表示的分钟取消---摘机，拨*65。
当系统设定多次叫醒时，*66可用来设定叫醒，也可用来取消设定。
设定---摘机，拨*66按提示输HHMM，其中：HH—两位数表示的小时，MM--两位数表示的分钟。
再次摘机，拨*66，提示已设定的时间，按2，可取消当前提示的时间；按3，可按提示输入下一次叫醒时间。
Alcatel OmniPCX Office RCE安装手册V2.00中网比高科技（北京）有限公司目录1、装机准备 (4)1．1、设备准备 (4)1．1．1、到货验收 (4)1．1．2、通电开机 (4)1．1．3、连接OMC (4)1．1．4、OMC识别硬件 (7)1．1．5、license导入及检测 (8)1．1．6、系统清零 (9)1．1．7、系统初始化 (9)1．1．8、入仓准备发货 (10)1．2、商务准备 (10)2、现场装机 (12)2．1、输入基本信息 (12)2．2、配置号码计划 (13)2．3、分机号码设定 (14)2．3．1、分机拨入号码设定 (14)2．3．2、主叫显示设定 (15)2．4、分机等级及权限控制 (16)2．4．1、分机等级对应的号码限制分析表设定 (16)2．4．2、分机等级设定 (17)2．5、中继设定 (19)2．5．1、模拟中继线设定 (19)2．5．2、PRI中继线设定 (20)2．5．3、中继组设定 (20)2．6、话务台设定 (21)2．7、自动话务员设定 (22)2．7．1、自动话务员启动 (22)2．7．2、自动话务员设置 (23)2.8. 1使用密码打电话： (23)2.8. 2、分机组的设置 (24)2.8. 4、设置系统IP地址 (25)2.8. 5、三会议功能的开启 (26)2.8. 6、外线外转的开启 (26)2．8.8、远程维护设置 (27)2．9、话机类型 (28)2.9. 1、各种话机型号 (28)2.9. 2、4018/4019话机操作手册 (29)2.9. 3、4029话机操作手册 (31)2.9. 4、4068话机操作手册 (32)3语音信箱操作说明 (33)3. 1. 1数字话机语音信箱基本操作 (33)3. 2. 1、模拟话机语音信箱基本操作 (34)4、配线架跳线 (35)5、出现问题解决方法 (35)5．1、没有数字话机的问题 (35)5．2、DID拨入不送忙音问题 (35)5.3、常见问题补充： (36)1、装机准备1．1、设备准备1．1．1、到货验收设备到货工程人员应配合仓库验收。
Alcatel-Lucent OXO Connect Announcements User ManualJune 20183EH21069USAC Ed. 1Legal noticeThe Alcatel-Lucent name and logo are trademarks of Nokia used under license by ALE. To view other trademarks used by affiliated companies of ALE Holding, visit: /en/legal/ trademarks-copyright. All other trademarks are the property of their respective owners.The information presented is subject to change without notice. Neither ALE Holding nor any of its affiliates assumes any responsibility for inaccuracies contained herein.© 2018 ALE International. All rights reserved. DisclaimerWhile efforts were made to verify the completeness and accuracy of the information contained in this documentation, this document is provided “as is”. To get more accurate content concerning Cross Compatibilities, Product Limits, Software Policy and Feature Lists, please refer to the accurate documents published on the Business Partner Web Site.In the interest of continued product development, ALE International reserves the right to make improvements to this documentation and the products it describes at any time, without notice or obligation.The CE mark indicates that this product conforms to the following Council Directives:•2014/53/EU for radio equipment•2014/35/EU and 2014/30/EU for non radio equipment (including wired Telecom Terminal Equipment)•2014/34/EU for ATEX equipment•2011/65/EU (RoHS)•2012/19/EU (WEEE)Chapter 1Overview1.1Description of the Announcements (4)Chapter 2Operation2.1Selecting Announcements (5)2.2Creating Announcement Messages (6)2.2.1Recording announcements (.wav) on a PC (6)2.2.2Recording Automatic Call Distribution messages using a phone set (7)2.2.3Converting an announcement file (7)2.2.4Recording Automatic Call Distribution messages using a professional studio (7)This document is the user manual of the Announcements application. It applies to OXO Connect and OXO Connect Evolution.Announcements are broadcast while telephone traffic is being processed. No default announcements are provided by the call center, but default announcements (A-law and µ-law) designed for test purposes are available for download in OMC. For a running system, customized announcements must be created and downloaded.1.1 Description of the AnnouncementsThe different types of announcement are:•Welcome announcement This announcement is broadcast when a call arrives in the group.•Queue announcements (Waiting 1, Waiting 2, Estimated Waiting Time)•Waiting 1 is used when the call joins the queue for the first time; it is broadcast once only.•Waiting 2 is used after Waiting 1 or Estimated Waiting Time; it is broadcast continuously until the call leaves the queue (this announcement may contain music).•Estimated Waiting Time is broadcast to advise the caller that they are likely to have a certain minimum waiting time in the queue before their call is answered.•Deterrence announcement This announcement is broadcast when the queue is saturated. It can also be broadcast when the Automatic Call Distribution ports dedicated to Automatic Call Distribution traffic are saturated (this depends on the configuration of the Automatic Call Distribution ports dedicated to deterrence).•Closing announcement This announcement is broadcast when the Automatic Call Distribution group is closed.•Customer code announcement This announcement is broadcast to ask the caller to enter a customer code.On the system, a set of announcements for each Automatic Call Distribution group is permitted. The minimum and maximum durations of the announcements in a set are shown in the table below.Announcement Minimum Duration Maximum DurationWelcome0 seconds60 secondsWaiting 10 seconds60 secondsWaiting 220 seconds300 secondsEstimated Waiting Time0 seconds60 secondsDeterrence0 seconds60 secondsClosing0 seconds60 secondsCustomer code0 seconds60 seconds2.1 Selecting AnnouncementsTo select the announcement you want to use, do the following:1.Click ACD Voice Messages. The ACD Voice Messages window appears. This window has thefollowing two areas:•The ACD Groups area is used to select the announcements for each group or all the groups.•The Transfer selected messages area is used to import or export announcements to the call center or to the system.The ACD Groups area contains a table allowing you to:•see which announcements are present in the system,•select an announcement to be added or replaced.To change from Transfer mode to Delete mode, click on the button Mode.It is not possible to delete announcements at the same time as adding or replacing announcements.Note:Default messages are available which take into account the coding (A-law or µ-law) used in your country.2.In the Transfer selected messages area, click the button to the right of the field Load from thisdirectory and transfer.The Select Folder window is displayed.The announcements are by default saved in:C:/Program Files/PCXTools/OMC/R500_xxx/VoiceMessages/a_law56 messages are available (7 for each Automatic Call Distribution group). Each message isidentified by a file made up of 3 figures x, y and z and with the extension .wav:•x corresponds to the number of the Automatic Call Distribution group (1 to 8)•y is always equal to 0•z corresponds to the message of the Automatic Call Distribution group (1 to 7)The messages types are as follows:•1 corresponds to the Welcome message•2 to the Waiting 1 message•3 to the Waiting 2 message•4 to the Deterrence message•5 to the Closing message•6 to the Estimated Waiting Time message•7 to the Customer code messageFor example, file 305.wav corresponds to the Closing message for group 3.Remark:on starting the Automatic Call Distribution, the system does not contain any messages. To conduct tests, it is therefore essential to load the default Automatic Call Distribution messages.3.Select the announcements and click the transfer button ( => ). The messages selected aretransferred to the call center.4.Click OK. The ACD Voice Messages window disappears.Note:When deleting an announcement, the action is not executed using the transfer button ( => ) but using the delete button (X) instead (this button is only accessible in Delete mode).2.2 Creating Announcement MessagesTo create your own announcement messages, you can use the recording software available on your PC (Window/Accessories/Multimedia/Sound Recorder) or any multimedia application.2.2.1 Recording announcements (.wav) on a PCProceed as follows:1.On your PC, open a recording tool by clicking Start > Programs > Accessories > Multimedia (orEntertainment) > Sound Recorder. The following window is displayed:In order to record the message, your computer must be fitted with a sound card. Otherwise, a message informs you that the recorder is operating in restricted mode.2.If the sound card is available and configured, start to record your message by clicking on the redbutton in the bottom right of the window.3.To stop the recording, click the rectangular button.4.To check and listen to the recorded message, click the triangular button.5.If you are happy with the message, record it by clicking File > Save. Give it a file name and checkthe message format.Caution:announcements must have the format CCITT A-law/µ-law 8 KHz, 8 bits, mono. The announcements created must have the same name as the default messages.6.If the format is not correct, click Change and select the format CITT A-law/µ-law 8 KHz, 8 bits,mono. Click OK to confirm and OK again to save the message.2.2.2 Recording Automatic Call Distribution messages using a phone setYou can record Automatic Call Distribution messages using any one of the following telephones:•8038 Premium DeskPhone•8058s Premium DeskPhone•8039 Premium DeskPhone,•8068 Premium DeskPhone•8068s Premium DeskPhone•8078s Premium DeskPhoneA special menu allows you to record each announcement message for each Automatic Call Distributiongroup. To access this menu:•on a 8038 Premium DeskPhone/8058s Premium DeskPhone, 8039 Premium DeskPhone, 8068 Premium DeskPhone/8068s Premium DeskPhone or 8078s Premium DeskPhone, follow the path Menu/operator/Advanced/Voice/Automatic Call Distribution.•2.2.3 Converting an announcement fileIf the format of your file is not compatible, convert it using the following procedure:•Open the .wav file to be modified in Sound Recorder and click File > Properties to check the file format.•If the format shown is different from CCITT A-Law/µ-law 8 kHz, 8 bits, mono, click Convert Now....A window opens; select the format CCITT A-Law or CCITT µ-law and click OK to confirm.•Save your file.2.2.4 Recording Automatic Call Distribution messages using a professional studioFor optimum quality, the services of a professional recording studio should be used. If this option is chosen, observe the file format required.。
程控机基本操作使用说明1、进入PABX维护状态：LOGI ADMIN1PASS：XXXX2、进入PABX维护程序：LD XX XX为程序号码退出维护程序：****回到本程序的开始：**3、增加1个新的分机用户1）查看新员工所在部门其它同事的端口号，话机类型必须一样。
知道分机号，查看端口号：>LD 20REQ: PRTTYPE: DNBCUST 0DN 分机号码DATEPAGEDES例：查看6193的端口号：>LD 20REQ: PRTTYPE: DNBCUST 0DN 6193DATEPAGEDN 6193CPNDCPND_LANG ROMANNAME XXXPLN 27DISPLAY_FMT FIRST,LASTTYPE 500TN 040 0 00 05 MARP DES WW 15 OCT 2001其中TN即为卡板端口号，本例中TN为40-5。
2）查看可使用的新号码LD 20REQ：PRTTYPE：LUDNCUST 0DN 619CUSTOMER 00 - UNUSED DNS：6191 6196 61993）查看可使用的端口号LD 20REQ： LUUTYPE：500TNCDENTYPE 500 TN 020 0 00 04 4DTYPE 500 TN 020 0 00 08 4D4）新建分机LD 11REQ CPY 1TYPE 500CFTN 40 5 (CFTN 为源端口号，以此端口数据为样本进行拷贝) DES WW*** MAKE PRINTER READY ***TN 20 4 (新的端口号)DN 6199 (新的分机号码)NEW 500 TN 020 0 00 04 DN 61995）加分机显示名LD 95REQ：NEWTYPE：NAMECUST 0CPND_LANGDIGDN 6199NAME XX （输入姓名）XPLNDISPLAY_FMT4、删除分机LD 11REQ：OUTTYPE：500TN 20 45、修改代答组：LD 11REQ：CHGTYPE：500TN 20 4ECHG YESITEM RNPG 11（新的代答组号）ITEM5、查看数字话机端口状态LD 32. STAT 4 15答案是下述3种之一：DSBL(disable)；IDLE(enable)；Busy 只有DSBL是不正常的6、启动数字话机端口LD 32. ENLU 4 15如果端口状态为BUSY，先：. DISU 4 157、修改电话号码先找一个空号，之后把原号码改到这个号码。
CommandBackup Data1.swinst2.SoftInst3.選Save & restore operations4.選Immediate Save operations5.選Immediate save on floppy6.選Save mao data7.Do you want to save mao tool (Y/N) ?按Y8.按EnterOPS Restore1.swinst2.SoftInst3.選OPS configuration4.選Restore OPS from a DOS floppy5.you have to put the DOS floppy with OPS files in drive. Is Dos floppy on drive (Y/N Q to quit)按Y6.按Y7.按YCreate an empty database1.swinst2.SoftInst3.選Database tools4.選Create an empty database5.按Y6.按Y7.按YRestore Database1.swinst2.SoftInst3.選Save & restore operations4.選Restore operations5.Restore from floppy6.do you want to restore operations? 按 YCONNECT 9600login: mtclPassword: mtclA4400>mgrmgrShelf Events Routing Discriminator Dect system Security and Access Control SystemTranslator 前.後置碼,分機號碼,外線允撥碼Categories 類別表Attendant 總機群Users 分機設定Profiled Users 分機資料拷貝Groups 代接群,尋線群Abbreviated Numbering 簡碼Phone BookEntitiesTrunk Groups 外線群External Services 外線類別設定Inter-Nodes LinksX25DATAApplicationsSpecific Telephone ServicesAtmOther System Param. Z2 Board Initialization Parameters SIO ParametersTimersToneVoice GuideIncoming Greeting GuidesAlarm SetV24 PortUA sets Audio ParametersZ Board Audio ParametersTone detector ParametersMigration Interfaces ConfigFree AddressesFree Numbers Ranges ListFree Directory NumbersRecordable Voice GuidesBroadcastSoftware PackageIsdn Basic Call Control IEZ2 Board Dynamic ParametersNode Number (reserved) : 1Instance (reserved) : 1Country for external signalling + TaiwanNode Number : 1Network Number : 0Line Lockout Incident Storage + FalseDisplay LanguagesDisplay Language 0 + EnglishDisplay Language 1 + EnglishUsers Languages1 - Nationality Choice + English1 - Display Language No. : 01 - Voice Guide Language No. : 12 - Nationality Choice + English2 - Display Language No. : 02 - Voice Guide Language No. : 1DPNSS PABXs addresses ListMax Nb Trunks Conf.N : 2 三方會議最大外線數PIN length : 4 PIN code碼長Other System Param.No detect.of On-hook tone + False 忙音拆線之條件(1)ToneTime Base = 10ms- Tone 2 : Hold tone 28-50, 0-50, 29-50, 0-250- Tone 19 : Dial tone 26-0- Tone 20 : External tone ( virtual dial tone after seizing trunk ) 29-0- Tone 25 : Ringing ( 25HZ ring ) 27-0- Tone 29 : local ringing 27-100, 0-200- Tone 30 : Network ringing 27-100, 0-200- Tone 31 : Forwarded station ringing 27-100, 0-200- Tone 55 : Tone replacing 'please wait music' same as Tone 2- Tone 56 : Function accepted (V oice guide backup tone) and MW tone 25-0 - Tone 61 : Congestion tone 21-25, 0-25- Tone 62 : Dissuation tone 21-50. 0-50- Tone 136 : Congestion tone 21-25, 0-25- Tone 22 : Busy tone ( mono tone ) 26-50, 0-50- Tone 27/ 67 /183 : Ring back tone ( mono tone ) 26-100, 0-200- Tone 27/ 67 /183 : Ring back tone ( dual tone ) 24-100, 0-200- Tone 69 : Mail LED ringing tone for Z station behind US shelf 30-6, 0-100- Tone 181 : Mail LED ringing tone for Z station behind ACT shelf 30-6, 0-100- V oice guide 253: Callback on free and consult message, backup tone: 56- V oice guide 139: You can overflow onto your correspondent's voice mail system by dialing X. - X: the suffix of voice mail deposit.- It is mandatory to record this voice guide and put it into the flash card.TimerTime Base = 100ms- Timer 2 : Routing on going off-hook time-out 30- Timer 4 : Time-out for ringing before overflow on no reply 150- Timer 7 : Recall on hold time-out ( attendant ) 300- Timer 8 : Time-out for parking and waiting for paging 1200- Timer 9 : Ringing tone time-out 0- Timer 18 : Time-out for presumption of external end of dialing ( in DTMF ) 30- Timer 39 : Time-out for release of a trunk recall on night forwarding 1800- Timer 85 : Time-out for keeping the DISA call 1200- Timer 131 : wait time-out before sending DTMF to VPS 10- Timer 132 : Recall to operator after transfer a external call by the operator 150- Timer 42 : Time-out for authorization of enquiry call after seizing trunk 20Voice Guide (外接保留音源設定)Node Number (reserved) : 1Instance (reserved) : 1Voice Guide No. : 171Function + Z Voice GuideVoice Guide Start + NOBack Up Tone : 56Equipment AddressShelf : 0Board : 4Terminal : 19Tone detector ParametersOn-hook tone 忙音拆線之條件(2)Number of periods (On-hook) : 5Minimal pulse timer (On-hook) : 20Maximal pulse timer (On-hook) : 60Minimal silence timer (On-hook) : 20Maximal silence timer (On-hook) : 60Z Board Audio ParametersNode Number (reserved) : 1Instance (reserved) : 1Instance (reserved) : 1Off Hook Validation Time : 12On Hook Valid.For Decad.Time : 32（此值不可超過Max.Dur.Loop Break Hookflash） Max.Dur.Active Phase : 10Min.Dur.Active Phase : 1Max.Dur.Inactive Phase : 10Min.Dur.Inactive Phase : 1Min.Dur.InterDigit Decadic : 20Earth Button Valid Dur : 10Filtering After On Hook Dur : 40Min.Dur Loop Break Hookflash : 20Max.Dur.Loop Break Hookflash : 32Min.Detection DTMFQ23 : 29Positive Twist For DTMFQ23 : 6Negative Twist For DTMFQ23 : 249Rec.Gain For QDSP : 108Rec.Send Gain For QDSP : 160Send_Gain_For_QDSP : 51GDSP Echo B9 : 0GDSP Echo B10 : 0GDSP Echo B11 : 0GDSP Echo B12 : 0Translator(Prefix)Attendant Call 總機代碼 Personal Trunk Group Seizure Professional trunk seize外線抓取碼(送假外線音) Pers.Trk Grp seiz.With Overlap.專案密碼Modem Trunk Seizure ARS Prof.Trg Grp SeizureSet features 分機功能碼 ARS Prof.Trg Grp Seiz.with overlap General Features 代接功能碼 ARS Personal Trk GrpLocal Features 系統功能碼 ARS Personal Trk Grp with overlap. External Features 外線功能碼 ARS Modem TG With OverlappingDirect Abbreviated No. 指定簡碼 Local Short Dialling PrefixData Transfer Open Routing No.DISA X25 Physical AddressIncoming Call Greeting Guide X25 ISDN Access No.Abbreviated Dialling Area 簡碼 Hybrid AccessNetwork No. Virtual AccessProfessional TG With Overlapping外線群抓取碼 Entity Voice Mail Box No.Routing No. Hybrid LinkRobot Call Hybrid TG AddressVPN Overflow Ars ServerIndivid.Attendant Call Unlocking DISAAttendant Group Call 總機群代碼Entity CallSet featuresImmediate forward 立即跟隨 Cancel Remote forward 取消遙控跟隨Immediate forward on busy 立即忙線跟隨 UnusedForward on no reply 無人應答跟隨 Canc.auto.call back on busy 取消忙線預約Forward on busy or no reply忙線或無人應答跟隨Personal directory Progr. 個人簡碼設定Forward cancellation 取消跟隨 Personal Directory Use 個人簡碼使用Forward cancel.by destinat. 指定取消跟隨項目 LanguageOverfl.no reply on associate Contrast programmation 分機可程式功能Cancel Overfl.on associate Alarm ConsultationSet group exit 退出Group Camp On Control 忙線駐留設定Set group entry 進入Group Overfl.busy to assoc.setProtection against beeps Overf.busy/no repl.assoc.setPadLock 話機上鎖 Voice Guide ListeningAuto-Allocation 自動來話分配 Suite Don't DisturbSubstitution 分機替代功能 No Ringing 來電不振鈴Password modification 修改密碼 Tandem : Absent SecretaryCharging meter readout Tandem : Filtering activationDo not disturb 勿干擾 Force Set Type IdentificationSet In/Out of service 分機加入.退出系統 Privilege substitution 分機替代功能特權碼Associated Direct. No modif. Remote forward 遙控跟隨General FeaturesGroup call pick-up 同群代接Direct call pick-up 不同群代接Agent processing group call pickupLocal FeaturesSpeed call to associated set Conversation Recording Consult Call back list 取消點燈 Pabx address in DPNSSLast Caller Call back Direct Paging CallPaging call answer InfocenterVoice Mail Consultation 單機進入信箱功能碼 Voice Mail DepositWake-up/appointment remind 提醒服務 Select.Principal LineTone test Vg tone測試 Select.Line secondaryCollect telex Z dialing Behind UACollect text Mask remote identityCollect fax Recordable Voice Guides Message deposit 點燈碼 Suite Wake UpText deposit Suite Wake Up CancelImage deposit Physical_Room_CallACD prefixes ACD前置碼 Switch off Message LED 滅燈碼Meet me Conference 29方會談功能碼 Room status management Cancel Wake-up 取消提醒服務 Mini barVoice Mail Manager AccessExternal FeaturesDirect trunk seizure 指定外線抓取碼Business account codeRedial last number 末碼重撥Night service answeringDTMF frequencies testPark Call/Retrieve 駐留Waiting call consultation 單機穿梭交談Decimal End to End DiallingDTMF End to End Dialling DTMF切換Malicious callCommon Hold 系統保留Not Used (Dialling Key)Secret/ IdentityAlphapageManual Hold 一般保留Translator(Suffix)Broker Call 取消轉接Three-Party Conference 三方會談Intrude 插話Booking On Free Or Busy Set 無人回答或忙線預約Busy Camp On 忙線駐留Loudspeaker PagingCall AnnouncementEnquiry Call 詢問電話Paging RequestProject NumberDecimal End To End DiallingDTMF End To End Dialling DTMF切換Malicious CallVoice Mail DepositCamp On ControlBy pass on Do Not DistrubPIN (Personal Ident.No.) 專案密碼External Numbering Scheme 外線碼長設定Numbering Discriminator＞Go down hierarchy＞CreateCategoriesAccess Category 外線進線參數設定Go down hierarchy：-Public Access Category 外線等級-Private Access Category 專案密碼等級-Business Access Category-Network Access Category-Trunk Group Access CategoryConnection Category 內外線連接等級Transfer Category 轉接等級（Transfer Category Id : 5設1才可外線轉外線）Private Calls Connect.Categ.Phone Facilities Categories 分機功能等級IP Quality of service CategoryUsersProgr.KeysNot Assigned 未使用 DataProgrammed 可程式鍵 ISDN Filtering KeyVisiophone Data supervision keyTelesurveillance Screening Supervision 經理/秘書功能監視Executive Mail Enquiry 轉接Forwarding On Ringing BrokerAbsent Secretary Forward 立即跟隨Screening Key 經理/秘書功能 Redial 重撥Unscreening Key 解除經理/秘書功能 MailTrunk Group Supervision 監視外線群 Redial Memory 記憶重撥Trunk Supervision 監視外線 Transfer 轉接Set Supervision 監視分機 ISDNSecretary Call Repertory 個人簡碼Executive Call Booking 忙線/無人應答預約Multi-line 傳送文字訊息 Three-Party Conference 三方會議Routing Secretary Intrude 插話ACD Resources Busy Camp On 忙線駐留ACD Listening Loudspeaker pagingACD General Forwarding Call AnnouncementHeadset 耳機鍵 Paging RequestProject Number Decimal End To End DiallingDTMF End to End Dialling DTMF切換 Malicious CallVoice Mail Message Deposit Camp On Control 忙線駐留設定Network Executive Call Network Secretary CallGeneral Forwarding of Pilot Closing PGAttendants Assistant Homeworker Perm. connexionUsers(UA)Node Number (reserved) : 1Directory Number : 162 分機號碼Directory name : 分機名稱Directory First Name :Location Node : 1Shelf Address : 0Board Address : 9 卡片位址Equipment Address : 0 port位址Set Type + 4035T 分機型式Entity Number : 1Identifier of Domain : 0Language Id. : 1 語言類別Secret Code : **** 分機密碼Confirm : ****Associated Set No. : 162 無人應答或忙線回跳分機號碼Cost Center Id : 255Cost Center Name : ----------Charging Category + Justified 計費輸出Public Network Category : 2 外線等級External Forwarding Category : 255Tel.Facility Category Id : 0 分機功能類別Connection Category Id : 0 連接類別Hunting Group Dir No. : -------- 尋線群群號ACD Group Directory No. : --------自動來話分配群群號Pick up Group Name : 3 代接群Reserved Time Slot + FalseVoice Mail Dir.No. : --------取留言分機號碼或群號Voice Mail Type + No Voice MailPaging Trunk Group : 255Paging Beeper : ----Tele-Marketing Agent + FalseISDN Subscr.External + TrueInternal + FalseISDN Teleservice + PhoneHotel-Set Function + AdministrativeUse Type Of Dir. No. + NormalNumber Of Set Users : 1Multiline station + YESDialled number masked + NORouting Table : 0Associated Videophone + FalseVIP (Very Important Pers.) + FalseSecretary Directory Number : 162Calls Priority : 0PCBT Associated + NOUrgent Call + NOPIN (Personal Ident.No.)PIN No. : --------等級升降密碼(專案密碼)PIN With Secret Code + True 要按個人密碼Type of control + By categoryPIN group number : 1Can Be Called By Name + YESDisplayed Name : 162Count Errors Of Secret Code : 0ACD station + NO 自動來話分配分機Incidents Teleservice + NOVoice Guide listening Class : 7Caller Category : 4VSI Transparency + FalseType of Keyboard + Default keyboardCount Errors Of Business Code : 0Stap + Off-hookUse Personal Calling Number + FalsePIN group control + No groupCCA operator + FalseA4980 + NoZ IVR + FalseNOMADIC + FalseAdd On Module 1 + 40 Keys 外接DSSAdd On Module 2 + NoneAdd On Module 3 + NoneExternal Alphanumeric Keyboard + NoneInternal Alphanum.Keyboard + NoneV24 Extension + FalseS0 Extension + FalseMac/PC + NOZ Adaptor + FalseCalled Associated Dect set : --------Call by name and mini mail + Yes 4020.4035可傳文字訊息Multi-Line PropertiesAutomatic Incoming Seizure + TrueAutomatic Outgoing Seizure + TrueSelective Filtering + FalseOverflow on no reply + FalseOverflow on busy + FalseTake supervision off-hook + True 該分機響鈴時,監視分機可直接拿起聽筒應答Access Code to UUS messages + NOAccess Code to UUS messages + NOPhone book Name (Call by name) : ------------Phone book First Name : --------Remote UA + FalseNS Right (Notification server) + NOCSTA routing + FalseTandemTandem Directory Number : --------撥一號碼,數支分機響鈴Main set in the tandem + FalseUA 3G featuresEmulation + UA 3G4035 FeaturesNavigator + UA 3GUser(Z)Node Number (reserved) : 1Directory Number : 104 分機號碼Directory name : 分機名稱Directory First Name :Location Node : 1Shelf Address : 0Board Address : 3 卡片位址Equipment Address : 0 port位址Set Type + ANALOG 分機型式Entity Number : 0Identifier of Domain : 0Language Id. : 1 語言類別Secret Code : **** 分機密碼Confirm : ****Associated Set No. : 104 無人應答或忙線回跳分機號碼Cost Center Id : 255Cost Center Name : ----------Charging Category + Justified 計費輸出Public Network Category : 2 外線等級External Forwarding Category : 255Tel.Facility Category Id : 0 分機功能類別Connection Category Id : 0 連接類別Hunting Group Dir No. : -------- 尋線群群號ACD Group Directory No. : --------自動來話分配群群號Pick up Group Name : 3 代接群Reserved Time Slot + FalseVoice Mail Dir.No. : --------取留言分機號碼或群號Voice Mail Type + No Voice MailPaging Trunk Group : 255Paging Beeper : ----Tele-Marketing Agent + FalseISDN Subscr.External + TrueInternal + FalseISDN Teleservice + PhoneHotel-Set Function + AdministrativeUse Type Of Dir. No. + NormalNumber Of Set Users : 1Multiline station + NODialled number masked + NORouting Table : 0Associated Videophone + FalseVIP (Very Important Pers.) + FalseSecretary Directory Number : 104Calls Priority : 0PCBT Associated + NOUrgent Call + NOPIN (Personal Ident.No.) PIN No. : --------等級升降密碼(專案密碼)PIN With Secret Code + True 要按個人密碼Type of control + By categoryPIN group number : 1Can Be Called By Name + YESDisplayed Name : 104Count Errors Of Secret Code : 0ACD station + NO 自動來話分配分機Incidents Teleservice + NOVoice Guide listening Class : 7Caller Category : 4VSI Transparency + FalseType of Keyboard + Default keyboardCount Errors Of Business Code : 0Stap + Off-hookUse Personal Calling Number + FalsePIN group control + No groupCCA operator + FalseA4980 + NoZ IVR + FalseNOMADIC + FalseCalled Associated Dect set : --------DATA Cx Category Id : 0Message Led + True 語音點燈Ext.Alarm Equipment + Alarm On Opened LoopPhone book Name (Call by name) : ------------ Phone book First Name : --------Modem Trunk Group Info Trunk Group Id : 255Trunk Number : 255Ghost Z + FalseGhost Z Feature + WithoutCSTA routing + FalseCmf 4600 (DTMF frequencies) + FalseHunting GroupNode Number (reserved) : 1Instance (reserved) : 1Directory Number : 440 群號Directory Name : ----------------Identifier of Domain : 0Type of Hunting Group + Local Hunting GroupSearch Type + Cyclical 響鈴方式Release After Timer + FalseOverflow Directory Number : -------- 無人應答回跳號碼 Authorized Camp on Calls % : 50Connection Category Id : 0 連接類別Public Network Category : 0 外線等級Withdrawal Authorized + TrueDir.No Allocated to the group[ Add ] [ Remove ] [ Next ] [Previous] Dir.No Allocated to the group : 402Entity Number : 10Prioritar Group + FalseCSTA routing + FalseVoice MailVoice Mail Number : --------Voice Mail Password : 0000Language Voice Mail : 1Pickup Private Call + FalseEntitiesNode Number (reserved) : 1Entity Number : 10Name : ----------------Attendant Group Manager : -1 設總機群群號Priority + NOTrafic Overflow + DisallowedInstallation No (ISDN) : ------------------------------Supplement.Install.No (ISDN) : ------------------------------Caller Id.Secret + SendAdv.Of Charg.2 requests(AOC2) + NOAdv.Of Charg.3 requests(A0C3) + NOVoice Mail Box No.for attendt : --------Calls DistributionOverflow Routing No. : --------Forwarding on routing + YES1st Night Routing : 440 夜間響鈴號碼2nd Night Routing : --------3nd Night Routing : --------1st Day Routing : 440 日間響鈴號碼2nd Day Routing : --------3nd Day Routing : --------1st MODE 1 Routing : -------- 總機啟動Forwording 12nd MODE 1 Routing : --------3nd MODE 1 Routing : --------1st MODE 2 Routing : -------- 總機啟動Forwording 22nd MODE 2 Routing : --------3nd MODE 2 Routing : --------Calls PriorityNormal Public Trk grp Ent. : 6Urgent Public Trk grp Ent. : 5Normal Private trk grp Ent. : 10Urgent Private Trk grp Ent. : 9Normal Public DDI Entity : 6Urgent Public DDI Entity : 5Normal Private DDI Entity : 10Urgent Private DDI Entity : 9Normal Int Callee DDI Entity : 12Urgent Int Callee DDI Entity : 11Normal Public Non Answer DDI : 4 Voice GuideUrgent Public Non Answer DDI : 3 Waiting Guide : 255 無語音卡時設2 外接設171 Normal Private Non Answer DDI : 8 Operator Waiting Guide : 110Urgent Private Non Answer DDI : 9 Overflow Timer : 0Trunk GroupsNode Number (reserved) : 1Trunk Group Id : 0Trunk Group Type + NDDI (BCA)Trunk Group Name : ----------Number Compatible With : 0Remote Network : 15Shared Trunk Group + FalseSpecial Services + NothingNode number : 1Transcom Trunk Group + FalseAuto.reserv.by Attendant + FalseOverflow trunk group No. : -1 外線群忙線, Overflow之外線群 Tone on seizure + False 系統不送假外線音(需配合抓取碼)Private Trunk Group + FalsePaging Trunk Group + FalsePaging Table Id : -1Paging Signalization + NDDISecurity Patrol + FalsePrefix Sending + Falseauto.DTMF dialing on outgoing call + YES 外撥時,自動送DTMF DDI transcoding + FalseNode Number (reserved) : 1Trunk Group Id : 0Instance (reserved) : 1Trunk Group Type + NDDI (BCA)Public Network Ref. : ------VG for non-existent No. + YESEntity Number : 11 外線進線Supervised by Routing + NOVPN Cost Limit for Incom.Calls : 0Immediat Trk Listening For VPNCall + YESVPN TS % : 50Csta Monitored + NOMax.% of trunks out CCD : 0Ratio analog.to ISDN tax : ------TS Distribution on Accesses + YESDialling end to end + NODTMF end to end signal. + NOPaying Incoming Calls + NOTS Permanently assigned + YESMin. Nb.of digits on seize : 0Trunk group used in DISA + NODISA Secret Code : --------Routing To Executive + NODissuasion For ACD + NODTO joining + YES忙音拆線之條件(3) Automated Attendant + NOCalling party Rights category : 0Access Cluster Id : -1Collect Calls Allowed + YESCreate: TrunkNode Number (reserved) : 1Trunk Group Id : 0Instance (reserved) : 1Physical Address : 0-8-3 外線卡槽位Trunk Category Id : 0Directory Name : --------Trunk Routing Number : -------- 個人專線Channel Specialization + Mixed(DID設In Only) Data Transparency + YESTrunk CategoryNode Number (reserved) : 1Instance (reserved) : 1Trunk Category Id : 0Connection Category Id : 0Waiting Guide + True Tone 255之保留音Trunk Type + NDDI (BCA) 外線型式Signalling Type + Not RelevantOverflow Timer on No Reply : 300 無人應答時,回跳秒數Overflow Timer on Waiting : 300 忙線時,回跳秒數NDDI TrunkDefault Transmission + True 不偵測外線撥號音Default Transmission Delay : 10 系統時間後開始送碼Type of Dialling + MF Q23 撥號型式Interdigit Timer on Sending : 9 碼與碼間之間隔Off-hook Presumption Timer : 30 時間後可按轉接End of Selection + FalseLine Type + Long lineBattery Inversion Masking + False 要極性反轉NDDI Trunk - UKSubtype NDDI + Loop GuardedNDDI Trunk - ExportMasking Release + True 不二次極性反轉Wait for Caller Release Timer : 50Exchange Type + W48Loop Feeding Digit Make Time : 20Loop Feeding Digit Break Time : 30Wait for Seizure Ack.Timer : 20Min.Incoming Seizure Time : 10Wait for Called Answer Timer : 1200Answer Signal Time : 12Wait for Called Party Answer + FalseLoop Detection on Seizure + FalseCharging on Answer + TrueWait for Called Party Reanswer + FalseUnavailable Time Betw.2 Seizes : 10 外線釋放後可被再抓取之時間**DID Trunk之Incoming DTMF Receive設TrueApplicationsAccountingReal Time Tickets Output + V24Nb of Last Masked Called Digits 計費外線號碼隱藏碼數Usual Calls : 0Project calls : 0Personal Calls : 0Local Local Calls : 0Local Network Calls : 0Local Transit Calls : 0Real Time Tick.Outp.Parameters：Real Time Printer V24 + /dev/scc0a (2) 輸出post Printing format + Reduced 輸出單行模式PIN (Personal Ident.No.) + Masked PIN code輸出隱藏Filter：計費輸出之項目(建議全選)Public Local Outgoing CallsPIN (Public Network Outgoing CallsLocal Network CallsPrivate Local Outgoing CallsPrivate Network Outgoing CallsPublic Local Incoming CallsPublic Network Incoming CallsPrivate Local Incoming CallsPrivate Network Incoming CallsPriority Incoming CallsData Outgoing Incoming CallsPublic Outgo.of 0 Unit CallsNon Ticketed SubscriberLocal Local CallsLocal Transit CallsLocal/Netw Meter. Tick. Duration 0Management TicketsSpecific Telephone ServicesFacilitiesOnly 1 Call back Function on busy + TrueConference Code Length : 4 29方會議密碼碼長Adjust audio gain + True數位話機通話中可調受話大小聲Redial Internal Calls + NO 末碼重撥外線Routing Table 熱線設定表。
