SUMMARY⏹EN 1010-1 :2004+A1:2010基本要求⏹EN1010-2 :2006+A1:2010印刷机械⏹EN 1010-3 :2002+A1:2009切纸机⏹EN 1010-4 :2004+A1:2009印后机械⏹EN 1010-5 :2005瓦楞纸生产线纸张机械主要涉及危险点⏹Mechanical hazards机械危险：⏹Crushing 挤压⏹Shearing 剪切⏹cutting or severing 切割⏹entanglement缠入⏹drawing-in 卷入⏹trapping 困住⏹impacts 撞击⏹Mechanical hazards generated by:不可控运动机械危险⏹Mass and stability,⏹重量和稳定性⏹Mass and velocity⏹重量和速度纸张机械主要涉及危险点可控运动危险点不可控运动危险点纸张机械主要涉及危险点⏹Slipping, tripping, falling⏹滑倒，绊倒，跌落⏹Electrical hazards 电气危险⏹Direct or indirect⏹Contact 直接或间接接触⏹Thermal radiation (burns)⏹热辐射（烧伤）⏹⏹Thermal hazards 热危险⏹Burns due to possible contact ⏹由于接触的烫伤⏹Hazards generated by noise 噪音⏹Hearing damage 听力损伤⏹Interference with speechcommunication 沟通困难⏹Accidents due to interference with theperception of acousticSignals 由于报警器造成的噪音引起的事故⏹Stress 压力纸张机械主要涉及危险点⏹Hazards generated by radiation辐射危险⏹UV-radiation, laser 紫外辐射，激光辐射⏹Hazards from explosion 爆炸危险⏹Hazards generated by neglect ofergonomic principles in machine 人机工程忽略引起的危险⏹Design Unhealthy body postures 不健康的姿势设计⏹Unsuitable construction,place oridentification of actuators 不舒服的机构，操作器的安排不当⏹Failure, malfunction of controlsystem Faults or failures insafety circuits 安全回路或者控制回路失效引起的风险⏹malfunction of software 软件错误⏹⏹External effects on electricaldevices 对电气设备的外部影响EMCEN 1010-1:2004+A1:2010机械安全性.印刷机和纸张加工机械的设计和构造的安全性要求-通用要求Safety of machinery —Safety requirements for the design and construction of printing and paper converting machines —Part 1: Common requirementsEN 1010-1-基本要求 5.2.1卷入危险防护EN 1010-1-基本要求⏹ 5.2.1.1护罩防护⏹a) 封闭式护罩或者只开口料口的护罩，如果是可开启式护罩，需为连锁护罩⏹b) 对于表面光滑的滚筒等，可以使用安全棒5.2.1.2 跳脱装置，需符合5.2.10.21 cylinder gaps2 nip point3 normal guard position4 tripped guard position5 maximum guard positiona maximum stopping distance ofhazardous motionb maximum length of movement oftrip device.⏹ 5.2.1.3 如果两个部件之间直线距离最大不超过4mm,那么被认为是绝对安全的⏹ 5.2.1.4 如果机器是可行走的，行走部件须有防护⏹ 5.2.1.5 手轮和曲柄不能在设备旋转时一起旋转，如使用可收起的手轮⏹ 5.2.2护罩及连锁⏹ 5.2.2.2对于使用围栏式护罩，其最底下离地高度不能超过200mm,高度不能低于1400mm(地面算起）⏹ 5.2.2.3对于需要频繁打开的护罩，使用连锁式护罩，对于不需要经常打开的，使用固定式护罩，固定式护罩建议使用系留螺丝⏹ 5.2.2.5 如果护罩有下落的危险（一般是大型护罩），需使用气弹簧等防止此类危险，另外护罩关闭使用缓冲器⏹ 5.2.2.6 如果需要观察加工等过程，可使用透明护罩⏹ 5.2.3运行及维护时设置，清洗，故障排除用装置⏹ 5.2.3.1启动位置不能查看到可进入危险区域时，需满足以下条件-当使用围栏防护时人员在里面时不能把门关上或者是人员在设备内部不能启动机器，需要在危险区域外的额外的控制装置（复位）-当使用ESPD（光幕）时，需要在危险区域外的额外的控制装置（复位）5.2.3.2 当护罩打开时进行调试或者其他操作，需要设备进行运转，需要遵循以下两个原则a)点动控制切满足以下要求1）每次操作位移不能超过25mm,或者最大速度不能超过1m/min或者2）在没有持续性危险发生或者1）这种限制时影响机器的正常操作，限制可以放到到如下每次操作位移不能超过75mm,或者最大速度不能超过5m/min注1：如果使用双手控制按钮，以上规则同样适用，并且需满足5.2.8要求注2：为了不影响设备的连续生产，允许不使用模式选择开关，在护罩打开的时候直接切换到点动模式b)在没有任何危险时允许手动操作EN 1010-1-基本要求5.2.3.5安全放卷.在电动放卷机上，危险点需要防护以下任一情况满足即被认为是已经满足要求了-绳索式放卷设备，穿绳和导论之间的卷入点需要防护。
伯朗特五轴伺服配置表
1、P2-08特殊参数写入10参数复位（恢复出厂设置、复位后请重新接通电源）。
2、AL013紧急停止（EMGS）异警P2-17数字输入DI8功能规划（接脚30）021常闭设置为121常开
3、AL015正向极限PL（CCWL）异警P2-16数字输入DI7功能规划（接脚31）023常闭设置为123常开
4、AL014反向极限NL（CWL）异警P2-15数字输入DI6功能规划（接脚32）022常闭设置为122常开
5、电子齿轮比分子N1：P1-44电子齿轮比分母M：P1-45
6、P2。
3.驱器电按设置键S进入d01.SPd；按模式键M进入参数设定模式PAr.000通、、左键选择所要修改参数按设置键S进入该参数设定值；应参数设定值修改再按住设置键S约2秒界面自返应参数设定模式PAr.***；返应参数设定模式PAr.***再按模式键M进入参数EEPROM写入模式EE_SEt；按设置键S进入EEP-模式；再按住向键
约5秒显示EEP---逐渐增加直显示rESEt或FiniSh止设置参数写入完毕。
OMEGAHHM599 Digital Trms Clamp-On MeterOMEGAnet On-Line Service Internet e-mail **************Servicing North America:USA: ISO 9001 Certified Canada:One Omega Drive, Box 4047976 Bergar Stamford, CT 06907-0047Laval (Quebec) H7L5A1 Tel: (203) 359-1660Tel: (514) 856-6928 FAX: (203)359-7700FAX: (514) 856-6886e-mail:**************e-mail:**************SAFETY INFORMATIONThe following safety information must be observed to insure maximum personal safety during the operation at this meter:1. Do not use the meter if the meter or test leads look damaged, or if you suspect that the meter is not operating properly.2. Use caution when working above 60V dc or 30V ac rms. Such voltages posea shock hazard.3. When Using the probes, keep your fingers behind the finger guards on the probes.4. Measuring voltage which exceeds the limits of the clampmeter may damage the meter and expose the operator to a shock hazard. Always recognize the meter voltage limits as stated on the front of the meter.5. If the equipment is used in a manner not specified by the manufacturer, the protection provided the equipment may be impaired.SPECIFICATIONSDisplay: 3¾ digit (4000 counts), 9999counts (Frequency mode), 40 segments analog bar graph and function units sign annunciators.Polarity: Automatic, positive implied, negative polarity indication. Overrange: "4000"or"-4000" Most Significant Digit blinks.Low battery indication: the "" is displayed when the battery voltage drops below the operating level.Measurement rate: 2/sec,nominal. 1/sec, Capacitance and Frequency mode. 20/sec, Analog display.Operating Environment: 0°C to 40°C at < 70% relative humidity.Storage Temperature: -20°C to 60°C, 0 to 80% R.H. with battery removed from meter.Accuracy: Stated accuracy at 23°C ± 5°C, <75% relative humidity. Safety: According to EN61010-1 protection class II overvoltage category (CAT III 600V) pollution degree 2.Auto Power off: 30minutes after rotary switch or mode changes.Clamp jaw: According to EN61010-2-032 CAT IV 600V.Power: single standard 9-volt battery.Battery life: 150 hours typical.Dimensions: 250mm (H) x 100mm (W) x 46mm (D).Weight: Approx. 380g including battery.Accessories: One pair test leads, 9V battery.DC VOLTSRanges: 400mV,4V,40V,400V,600VResolution: 100µVAccuracy:±(0.25%rdg + 1dgt) on 400mV to 400V ranges ±(0.25%rdg + 3dgts) on 600V rangeInput impedance: >10M WOverload protection: 600VDC or AC rmsAC VOLTS (True RMS) (50Hz-500Hz)Ranges: 4V,40V,400V,600VResolution: 1mVAccuracy:±(0.75%rdg + 4dgts) on 50-60Hz±(2.0%rdg + 4dgts) on 40-500HzInput impedance: >10M WEffect Reading: 100 - 3999Overload protection: 600VDC or 600VAC rms RESISTANCERanges: 400W,4K W,40K W,400K W,4000K W,40M W Accuracy:±(0.3%rdg + 5dgts) on 400W range±(0.3%rdg + 1dgt) on 4K W to 400K W ranges±(0.5%rdg + 1dgt) on 4000K W range±(2.0%rdg + 4dgts) on 40M W rangeOpen circuit volts: 0.4VdcOverload protection: 600VDC or AC rmsCONTINUITYAudible indication: less than 40W±20WOverload protection: 600VDC or AC rmsDIODE TESTTest current: 1.0mA±0.6mAAccuracy:±(3.0%rdg + 3dgts)Open circuit volts: 3.0Vdc typicalOverload protection: 600VDC or AC rms FREQUENCY (Autoranging)Ranges: 100Hz,1KHz,10KHz,100KHz,500KHz Resolution: 0.01HzAccuracy:±(0.1%rdg + 2dgts)Sensitivity: 2.0Vrms minEffect reading: 10-9999Overload protection: 600VDC or AC rms CAPACITANCERanges: 4nF,40nF,400nF,4µF,40µFAccuracy:±(3.0%rdg + 20dgts) on 4n Frange(use D ZERO)±(3.0%rdg + 4dgts) on 40nF to 20µF ranges±(6.0%rdg + 4dgts) above 20µFOverload protection: 600VDC or AC rmsDC CURRENT (Put conductor at the center of the jaws)Ranges: 400A,700AResolution: 100mAAccuracy:±(1.5%rdg + 5dgts)*700A to 1200A: ±(2.0%rdg + 5dgts)Overload protection: 1200Adc max. for 1 minuteAC CURRENT (True RMS) (40Hz-500Hz)(Put conductor at the center of the jaws)Ranges: 400A,700AResolution: 100mAAccuracy:±(1.75%rdg + 5dgts) on 50Hz-60Hz±(3.5%rdg + 5dgts) on 40Hz-500Hz*700A to 1000A(50Hz/60Hz): ±(2.5%rdg + 5dgts)Overload protection: 1000Aac max. for 1 minuteOPERATIONBefore taking any measurements, read the Safety Information Section. Always examine the instrument for damage, contamination (excessive dirt, grease, etc.) and defects. Examine the test leads for cracked or frayed insulation. If any abnormal conditions exist do not attempt to make any measurements.In the Data Hold mode, the "HOLD" annunciator is displayed and the last reading is held on the display, the beeper emits a tone. Pressing (MIN / MAX) button when you are in the Data Hold mode causes you to exit Data Hold and enter the MIN MAX Recording mode.In the MIN MAX Recording mode, press (HOLD) button to stop the recording of readings, press (HOLD) again to resume recording.PEAK HOLD Button: (only AC current ranges 40-60Hz)PEAK Hold mode, the "HOLD" annunciator is displayed. {Accuracy:MIN / MAX buttonPress (MIN / MAX) button to enter the MIN MAX Recording mode. The minimum, maximum values are then reset to the present input, the readings are stored in memory, and the "HOLD" annunciator turns on. Push the button to cycle through the minimum (MIN), maximum (MAX), and present readings. The MIN or MAX annunciator turns on to indicate what value is being displayed.In the MIN MAX Recording mode, press (HOLD) button to stop the recording of readings, press again to restart recording. If recording is stopped, the minimum, maximum, or present values and analog diaplay are frozen. In the MIN MAX Recording mode, when a new minimum value is exceed the actual minimum readings or a new maximum value is overload, the minimum or maximum value will held on the display, but the analog display continues to be active.AC current ranges without MIN/MAX function.D ZERO ButtonPress (D ZERO) button to enter the Relative mode, the "D ZERO" annunciator turn on, zero the display, and store the displayed reading as a reference value. Press and hold down the (D ZERO) button for 2 seconds to exit the relative mode.RANGE ButtonPress (RANGE) button to select the Manual Range mode and turn off the "AUTO" annunciator. (The meter remains in the range it was in when manual ranging was selected).In the Manual Range mode. each time you press (RANGE) button, the range (and the input range annunciator) increments, and a new value is displayed. To exit the Manual Range mode and return to autoranging, press and hold down (RANGE) button for 2 seconds. The "AUTO" annunciator turns back on. Voltage Measurements1. Connect the red test lead to the "V" jack and the black test lead to the "COM" jack.2. Set the Function/Range switch to the desired voltage range (AC or DC). The meter will automatically select the best voltage range.3. Connect the test leads to the device or circuit being measured.4. For dc, a (-) sign is displayed for negative polarity; positive polarity is implied. Current Measurements1. Set the Function/Range switch to the desired highest 700A range (AC or DC). In DC current measurement use D ZERO button, offset the residual magnetic of the jaws.2. Press the trigger to open transformer jaws and clamp onto one conductor only. Read the current directly on the display. It is recommended that the conductor be placed at the center of the closed jaws for maximum accuracy.3. When the reading is lower than 400 counts, set the range switch to the next lower range position. For maximum accuracy, select the lower range possible without overranging the meter.Resistance Measurements1. Set the Function/Range switch to the resistance range.2. Remove power from the equipment under test.3. Connect the red test lead to the " + " jack and the black test lead to the "COM" jack.4. Touch the probes to the test points. In ohms, the value indicated in the display is the measured value of resistance.WARNINGThe accuracy of the functions might be slightly affected, when exposed to a radiated electromagnetic field environment, eg, radio, telephone or similar.Continuity Measurements1. Set the Function/Range switch to the "" position.2. Remove power from the equipment under test.3. Connect the red test lead to the " + " jack and the black test lead to the "COM" jack.4. Touch the probes to the test points. the beeper sounds continuously, if the resistance is less than 40W.Diode Tests1. Connect the red test lead to the " + " jack and the black test lead to the "COM" jack.2. Set the Function/Range switch to the "" position.3. Turn off power to the circuit under test.4. Touch probes to the diode. A forward-voltage drop is about 0.6V (typical fora silicon diode).5. Reverse probes. If the diode is good, "4000" is displayed. If the diode is shorted, ".000" or another number is displayed.6. If the diode is open, "4000" is displayed in both directions.Frequency Measurements1. Set the Function/Range switch to the Hz position.2. Connect the red test lead to the " + " jack and the black test lead to the "COM" jack.3. Connect the test leads to the point of measurement and read the frequency from the display.Capacitance Measurements1. Set the Function/Range switch to the " " range.2. Connect the test leads to the " + " jack and the black test lead to the "COM" jack.3. Connect the red test lead to the capacitor and read the eapacitance dircetly from the display.MAINTENANCEWARNINGRemove test leads before changing batteryor performing any servicing.Battery ReplacementPower is supplied by a 9 volt "transistor" battery. (NEDA 1604, IEC 6F22). The "" appears on the LCD display when replacement is needed. To replace the battery, remove the two screws from the back of the meter and lift off the battery cover. Remove the battery from battery contacts.CleaningPeriodically wipe the case with a damp cloth and detergent, do not use abrasives or solvents.WARRANTY / DISCLAIMEROMEGA ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for a period of 13 months from date of purchase. OMEGA Warranty adds an additional one (1) month grace period to the normal one (1) year product warranty to cover handling and shipping time. This ensures that OMEGA's customers receive maximum coverage on each product.If the unit should malfunction, it must be returned to the factory for evaluation. OMEGA's Customer Service Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective it will be repaired or replaced at no charge. OMEGA's WARRANTY does not apply to defects resulting from any action of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unauthorized modification. This WARRANTY is VOID if the unit shows evidence of having been tampered with or shows evidence of being damaged as a result of excessive corrosion; or current, heat moisture or vibration; improper specification; misapplication; misuse or other operating conditions outside of OMEGA's control. Components which wear are not warranted, including but not limited to contact points, fuses, and triacs.OMEGA is pleased to offer suggestions on the use of its various products. However, OMEGA neither assumes responsibility for any omissions or errors nor assumes liability for any damages that result from the use of its products in accordance with information provided by OMEGA, either verbal or written. OMEGA warrants only that the parts manufactured by it will be as specified and free of defects. OMEGA MAKES NO OTHER WARRANTIES OR REPRESENTATIONS OF ANY KIND WHATSOEVER, EXPRESSED OR IMPLIED, EXCEPT THAT OF TITLE AND ALL IMPLIED WARRANTIES INCLUDING ANY WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY DISCLAIMED. LIMITATION OF LIABILITY: The remedies of purchaser set forth herein are exclusive and the total liability of OMEGA with respect to this order, whether based on contract, warranty, negligence, indemnification, strict liability or otherwise, shall not exceed the purchase price of the component upon which liability is based. In no event shall OMEGA be liable for consequential, incidental or special damages.CONDITIONS: Equipment sold by OMEGA is not intended to be used, nor shall it be used: (1) as a "Basic Component" under 10 CFR 21 (NRC), used in or with any nuclear installation or activity; or (2) in medical applications or used on humans. Should any Product(s) be used in or with any nuclear installation or activity, medical application, used on humans, or misused in any way, OMEGA assumes no responsibility as set forth in our basic WARRANTY / DISCLAIMER language, and additionally, purchaser will indemnify OMEGA and hold OMEGA harmless from any liability or damage whatsoever arising out of the use of the Product(s) in such a manner.RETURN REQUESTS / INQUIRIESDirect all warranty and repair requests/inquiries to the OMEGA Customer Service Department. BEFORE RETURNING ANY PRODUCT(S) TO OMEGA, PURCHASER MUST OBT AIN AN AUTHORIZED RETURN (AR) NUMBER FROM OMEGA'S CUSTOMER SERVICE DEP ARTMENT (IN ORDER TO AVOID PROCESSING DELAYS). The assigned AR number should then be marked on the outside of the return package and on any correspondence.The purchaser is responsible for shipping charges, freight, insurance and proper packaging to prevent breakage in transit.FOR WARRANTY RETURNS, please have the following information available BEFORE contacting OMEGA:1.P.O. number under which the product was PURCHASED.2.Model and serial number of the product under warranty, and3.Repair instructions and/or specific problems relative to theproduct.FOR NON-WARRANTY REP AIRS, consult OMEGA for current repair charges. Have the following informationavailable BEFORE contacting OMEGA:1.P.O. number to cover the COST of the repair.2.Model and serial number of product , and3.Repair instructions and/or specific problems relative to theproduct.OMEGA's policy is to make running changes, not model changes, whenever an improvement is possible. This affords our customers the latest in technology and engineering. OMEGA is a registered trademark of OMEGA ENGINEERING, INC. © Copyright 1999 OMEGA ENGINEERING,Where Do I Find Everything I Need for Process Measurement and Control?OMEGA...Of Course!TEMPERATUREþThermocouple, RTD & Thermistor Probes, Connectors, Panels & Assemblies þWire: Thermocouple, RTD & Thermistor þCalibrators & Ice Point ReferencesþRecorders, Controllers & Process Monitors þInfrared PyrometersPRESSURE/STRAIN AND FORCEþTransducers & Strain GaugesþLoad Cells & Pressure GaugesþDisplacement TransducersþInstrumentation & AccessoriesFLOW/LEVELþRotameters, Gas Mass Flowmeters& Flow ComputersþAir Velocity IndicatorsþTurbine/Paddlewheel SystemsþTotalizers & Batch ControllerspH/CONDUCTIVITYþpH Electrodes, Testers & AccessoriesþBenchtop/Laboratory MetersþControllers, Calibrators, Simulators& PumpsþIndustrial pH & Conductivity Equipment DATA ACQUISITIONþData Acquisition &Engineering SoftwareþCommunications-Based Acquisition SystemsþPlug-in Cards for Apple, IBM& CompatiblesþDatalogging SystemsþRecorders, Printers & Plotters HEATERSþHeating CableþCartridge & Strip HeatersþImmersion & Band HeatersþFlexible HeatersþLaboratory Heaters ENVIRONMENTAL MONITORING AND CONTROL þMetering & Control Instrumentation þRefractometersþPumps & TubingþAir, Soil & Water MonitorsþIndustrial Water & Wastewater TreatmentþpH, Conductivity & Dissolved Oxygen Instruments。
DISCO公司產品介紹一：自動切割機什麼是自動切割機？是指被加工物的安裝及卸載作業均採用手動方式進行，只有加工工序實施自動化操作的切割機。
在有些機型上也可實施自動化位置校準作業。
但在機器內部沒有配置清洗、乾燥裝置.位置校準切割操作人員以手動方式將被加工物安裝到工作盤上。
3000系列的設備可自動實施位置校準作業。
300系列和500系列的設備，由操作人員使用顯微鏡進行切割位置對準作業。
操作人員只要按下開始按鈕，機台就可在位置校準工序識別出的切割道進行切割加工。
300系列 - Automatic Dicing Saw300系列切割機/切斷機，利用人工方式完成加工物的安裝調整及識別切割位置的校準作業，並且在設計上力求節省佔地空間，使該機型的外形結構顯得簡潔精巧。
另外，為了滿足各種加工要求，在最大加工物尺寸和加工精度等方面，均擁有種類豐富的產品群。
For 6" frameDAD321DAD322DAC351/DAD361設備概要適用ø 6"加工物的自動切割機DAD321的改良機型，産能更高追求高精度的切斷機和自動切割機最大加工物尺寸160 x 160ø6"(邊長6"方形)*1DAC351: 153 x 153 DAD361: 160 x 160適用框架2-6-1DAC351: - DAD361: 2-5, 2-6X軸可切割範圍(mm)192160192進刀速度有效範圍(mm/s)0.1 - 3000.1 - 5000.1 - 300Y軸可切割範圍(mm)162最小步進量(mm)0.00020.0001定位精度(mm)0.005以內/160(單一誤差)0.003以內/50.001以內/160(單一誤差)0.001以內/5光學尺最小分辨率(mm)-0.00005Z軸有效行程(mm)28.2(ø 2"切割刀片)32.2(ø 2"切割刀片)28.2(ø 2"切割刀片)最小移動量(mm)0.00010.000050.0001重復定位精度(mm)0.0010.0005可使用的最大切割刀片直徑(mm)ø76.2ø58(使用1.5 kW的主軸時)ø76.2θ軸最大旋轉角度(deg)380320DAC351: －DAD361: 380主軸額定功率(kW)1.5 at 30,000 min-1額定力矩(N・m)0.48轉速範圍(min-1)3,000 - 40,000設備尺寸(WxDxH)(mm)500 x 1,050 x 1,455500 x 900 x 1,600500 x 1,050 x 1,455設備重量(kg)約500約420(無變壓器)約470(有變壓器)約550*1另外需要專用夾具。
进口五轴联动立式加工中心生产企业大全五轴联动立式加工中心是立式加工中心大类里比较高端的机型；立式加工中心正在向五轴联动、六轴联动方向发展，目前德国、瑞士、意大利、西班牙、台湾、日本的立式加工中心机都已发展成为五轴联动立式加工中心或六轴联动立式加工中心，其特点是转速高、精度高，可加工复杂工件。
下面介绍一些进口五轴立式加工中心的生产企业：一、瑞士进口的五轴联动立式加工中心1、瑞士FEHLMANN费尔曼五轴联动立式加工中心2、瑞士威力铭▪马黛尔WILLEMIN MACODEL 五轴联动立式加工中心3、瑞士REIDEN雷登五轴联动立式加工中心4、瑞士阿奇夏米尔五轴联动立式加工中心二、德国进口的五轴联动立式加工中心1、德国斯宾纳SPINNER五轴联动立式加工中心2、德国巨浪Chiron五轴联动立式加工中心3、德国wemas威马斯五轴联动立式加工中心4、德国ALZMETALL奥美特五轴联动立式加工中心5、德国Fooke福科五轴联动立式加工中心6、德国STAMA斯塔玛五轴联动立式加工中心7、德国matec马泰克立式五轴加工中心8、德国handtmann海德曼五轴联动立式加工中心9、德国ACROLOC阿卡罗科五轴立式加工中心10、德国KEPPLER凯普乐六轴联动立式加工中心11、德国EDEL易代尔五轴/六轴联动立式加工中心12、德国HEDELIUS赫德鲁斯五轴立式加工中心13、德国PRIMACON普里马康高速立式五轴加工中心三、意大利进口的五轴联动立式加工中心1、意大利FIDIA菲迪亚立式五轴联动加工中心2、意大利parpas帕尔帕斯立式五轴联动加工中心3、意大利MECOF美卡福五轴联动立式加工中心4、意大利皮特卡纳基立式车铣复合五轴加工中心四、西班牙进口的五轴联动立式加工中心1、西班牙MTE梅特五轴联动立式加工中心五、台湾进口的五轴联动立式加工中心1、台湾达佛罗立式五轴联动加工中心。
台湾大前机床五轴龙门加工中心任何人都可以生产机器,但我们一直努力不懈，利用先进的技术,"为我们的客户提高竞争力." 它是我们的宗旨，我们在高速.五轴专业领域里,不断的创新。
发展沿革2009年创立五轴研发中心于台湾台中市中港世贸大楼2009年与义大利TECNAI技术合作研发二轴头2010年GS3225高速五轴产品研发上市2012年承接明日集团高速五轴产品技转案2012年设立生产工厂于台湾台中市大雅区振兴二路56-1号企业使命专精于大型五轴高速龙门工具机研发、制造与行销。
整合欧洲科技与台湾管理为经营特色。
集一流人才促进精密机械产业技术精进。
追求精而美的企业文化。
兼具科技与人性，重视员工自主管理与学习成长。
专注提供航太、能源、交通等产业尖端设备的需求。
经营理念融合科技与人性，创造顾客价值任何人都可以生产机器,但我们一直努力不懈，利用先进的技术,"为我们的客户提高竞争力." 它是我们的宗旨，我们在高速.五轴专业领域里,不断的创新。
「客户的需求是我们不断进步的原动力,服务客户是我们最终的目的」公司的研究发展、生产制造均以此为宗旨。
目前大前科技仍然在进行多种不同领域产品的研发，服务更多不同所需的广大客户，更期待我们的努力能为客户创造更高的价值.高速五轴龙门加工中心机Torque1 天车式天车式结构设计工件不动,工件重量不影响机台的轴向负荷，三轴的高速动态精度表现趋近完美。
唯一採用扭矩电机直接驱动螺母，丝杆固定不动，保证最高动态响应。
性能特性▪丝杆固定不旋转，降低丝杆挠性，提高刚性。
▪扭矩电机不经联轴器，没有延滞驱动，直接驱动螺母带动X / Y 轴。
▪无皮带传动的延滞及磨耗,提高动态响应，具高加减速、高扭力。
源自欧洲的先进设计整机由欧洲设计团队作最完整的FEA 有限元素分析，具高加减速,能满足高精密模具的曲面加工需求。
採用义大利Technai 二轴头具有以下优点:▪ B、C轴採用三个高速、高扭矩永无背隙的扭矩电机(Torque Motor) 驱动▪去除蜗杆、蜗轮、齿轮、皮带会产生背隙、磨耗的传统零件绝对保证精度。
CT-2525CH, CT-2550CH and CT-2570CHPA25383A01 Rev. 07 1-2019CRIMPING HEADS USED WITH THE CT-2500, CT-2500/E; orCT-2500/L, CT-2500/LE TOOLS© Panduit Corp. 2019CT-2525CH CT-2550CH CT-2570CHCT-2525CH Crimping head for installing the following Panduit products:#26 – #22 AWG (0,14 – 0,5 mm2)insulated terminals and splices,#22 – #10 AWG (0,5 – 6,0 mm2) fully insulated disconnects, insulated parallel splices;and specific #22 – #14 AWG (0,5 – 2,5 mm2) barrel insulated disconnects.CT-2550CH Crimping head for installing the following Panduit products:#22 – #10 AWG (0,5 – 6,0 mm2) insulated terminals and splices;and specific insulated disconnects.Reduced crimp effort advantage for #12 – #10 AWG (4,0 – 6,0mm2) terminations.CT-2570CH Crimping head for installing most of the following Panduit products:#22 – #10 AWG (0,5 – 6,0 mm2) non-insulated terminals, disconnects; and specificnon-insulated splices.CRIMPING HEAD INSTALLATION(See Page 2)Monthly Maintenance1. Thoroughly clean all surfaces.2. Oil the locating pins.NOTE: In the interest of higher quality and value, we are constantly improving and updating our products. Consequently, pictures in this manual may sometimes vary from the productenclosed.E-mail:EU Website:/emeaEU Email:emeatoolservicecenter@Technical Support:1-800-777-3300Panduit EuropeEMEA Service CenterAlmelo, NetherlandsTel: +31-546-580-452Fax: +31-546-580-441© Panduit Corp. 2019INSTALLATION INSTRUCTIONS CT-2525CH, CT-2550CHand CT-2570CHCRIMPING HEAD INSTALLATION1. Rotate crimping head adapter fully --clockwise (see Figure 1).2. Press retract slide to lower pistoncompletely.3. Pull out the pins for mounting adifferent crimping head on theadapter.4. Before installing a different crimpinghead, slide the crimp dies to the fullopen position. Lock the head withthe locating pins (see Figure 2),paying attention that the pins arelocked securely before starting.5. The crimping cycle is terminatedwhen the dies are completely closedand the maximum crimping force isreached, which is indicated by theauto retraction of the piston.Refer to the CT-2500, CT-2500/E(PA25346A01); or CT-2500/L,CT-2500/LE (PA28113A01) OperationManual for complete tool and crimpinghead instructions.ATTENTION: The crimping process can be interrupted at any time by releasing the trigger.After having terminated the crimping process and prior to changing the heads, remove battery to avoid unintended starts.DIE CLOSURE GO / NO GO GAGE MEMBERS – CT-2525CHCRIMP POCKET ENGLISH GO / NO GO GAGE MEMBERS METRIC GO / NO GO GAGE MEMBERS AWG / mm2“G” Dia. (GO) “NG” Dia. (NO GO) “G” Dia. (GO) “NG” Dia. (NO GO) Pocket “A” .0835” .091” 2,12 mm 2,31 mm22 – 14 / 0,5 – 2,5 .0765” .084” 1,94 mm 2,13 mm12 – 10 / 4,0 – 6,0 .1005” .108” 2,55 mm 2,74 mmDIE CLOSURE GO / NO GO GAGE MEMBERS – CT-2550CHCRIMP POCKET ENGLISH GO / NO GO GAGE MEMBERS METRIC GO / NO GO GAGE MEMBERS AWG / mm2“G” Dia. (GO) “NG” Dia. (NO GO) “G” Dia. (GO) “NG” Dia. (NO GO) 22 – 14 / 0,5 – 2,5 .1015” .108” 2,57 mm 2,74 mm12 – 10 / 4,0 – 6,0 .1475” .154” 3,74 mm 3,91 mmDIE CLOSURE GO / NO GO GAGE MEMBERS – CT-2570CHCRIMP POCKET ENGLISH GO / NO GO GAGE MEMBERS METRIC GO / NO GO GAGE MEMBERS AWG / mm2“G” Dia. (GO) “NG” Dia. (NO GO) “G” Dia. (GO) “NG” Dia. (NO GO) 22 – 18 / 0,5 – 1,5 .0515” .060” 1,31 mm 1,53 mm16 – 14 / 1,5 – 2,5 .0735” .082” 1,87 mm 2,09 mm12 – 10 / 4,0 – 6,0 .0995” .108” 2,53 mm 2,75 mm。
