姓名：学号：
姓名：学号：
给定网段192.168.100.0/24，按图中网络要求进行子网划分：
R1的fa0口所属的网络需要地址10个；
R1的fa1口所属的网络需要地址60个；
R1的s0口所属的网络需要地址2个；
R2的fa0口所属的网络需要地址30个；
R2的fa1口所属的网络需要地址40个；
R2的s1口所属的网络需要地址2个；
R1连接R2的链路需要地址2个。

给出子网划分方案：
划分出的子网，子网掩码，各个接口分配的地址，给PC分配的地址。

然后对R1、R2进行连线配置，若路由器接口不够，则采用设置环回接口的形式进行模拟，配置完任选一个路由协议进行配置，使得PC之间能互相ping通。
