电源滤波器技术规格书FSBP-10L

电源滤波器技术规格书MODEL：ME210-50单相单节通用型/Single phase,1-stage EMI filters一．常规技术参数（General Specifications）：1. 额定电压（Rated Voltage）：250VAC2. 额定电流（Rated Current）：50A@40℃3. 工作频率（Operating frequency）：50/60Hz4. 温升（Temperature Rise）：30℃max* 测试依据（Measuring method）：VDE0565-3 -2.3.3and -4.55. 泄漏电流（Leakage Current）：0.5mA max /P (@250VAC 50Hz)* 测试依据（Measuring method）：UL1283 -26 and Fig. 26.1二．气候类别（Climatic Category）：25/085/21 （-25℃~+85℃）三．耐压测试（Withstand Voltage）：PN---E 2000VAC for 60 secondsP---N 1760VDC for 60 seconds四．绝缘电阻（Insulation Resistance）：200M ohm minimum @ 500VDC between line and ground五．过载（Overload）：1.4 times rated current for 1 minute, once per hour六．电路参数原理图（Circuit Diagram）：L 0.2mHCx 0.47uFCy 4.7nFR 0.22MΩ七．外型及尺寸（Outline Drawing and Dimensions）：Unit: mm八．插入损耗（Insertion Loss）：测试依据(Measured Method)Measured in 50Ω system, as IEC/CISPR NO.17插入损耗数据图表LINE TO GROUND(PN—E)共模（dB）LINE TO LINE(P---N)差模（dB）P/N .1 .15 .5 1 5 10 30 .1 .15 .5 1 5 10 30 ME210-50 6 9 18 24 50 62 45 20 21 52 70 66 60 60九.单只重量（Weight）：550g（±20%）十.标识(Marking)：1.生产厂商名称ME（民恩）2.产品名称电源滤波器3. 产品型号ME210-504. 工作电压及电流250VAC 50A5. 工作频率50/60Hz6. 工作温度-25℃~+85℃7. 输入输出端Line & load。

滤波器型号及性能参数滤波位置电源相位应用领域滤波器型号选择型号技术参数额定电压额定电流介质耐压最大泄漏电流进入设备单相医疗设备GOODBETTERBESTH 250V AC 3A6A10A15A L-G2250VDC @120V AC 60HZ 2µAL-N1450VDC@250V AC 50HZ 5µAEAH/EBH250V AC 1,3,6,10A L-G1500VDC @120V AC 60HZ 2µAL-N1450VDC@250V AC 50HZ 5µAEJH 250V AC 1,3,6,10,15,20 L-G1500VDC @120V AC 60HZ 2µAL-N1450VDC@250V AC 50HZ 5µAEJM 250V AC 1,3,6,10,15A L-G1500VDC @120V AC 60HZ 0.010mAL-N1450VDC@250V AC 50HZ 0.017mA MV 250V AC 3,6,10,20A L-G2250VDC @120V AC 60HZ 0.07mAL-N1450VDC@250V AC 50HZ 0.13mA HZ 250V AC 3A L-G2250VDC @120V AC 60HZ 2µAL-N1450VDC@250V AC 50HZ 5µAHT 250V AC 6A10A15A L-G2250VDC @120V AC 60HZ 2µAL-N1450VDC@250V AC 50HZ 5µAHQ 250V AC 3A/6A L-G2250VDC @120V AC 60HZ 2µAL-N1450VDC@250V AC 50HZ 5µA 大噪音工业设备EMC 250V AC 3,6,10,A15,20,30AL-G2250VDC @120V AC 60HZ 0.21mA@120V AC 60HZ 0.73mAL-N1450VDC@250V AC 50HZ 0.43mA进入设备单相@250V AC 50HZ 1.52mA FC 250V AC 6,12,16,25,36 L-G2250VDC @120V AC 60HZ 3.8mAL-N1450VDC@250V AC 50HZ 6.7mA S 250V AC 3,6,10,20 L-G2250VDC @120V AC 60HZ 0.4mAL-N1450VDC@250V AC 50HZ 0.7mA V/W 250V AC 3,6,10,20 L-G2250VDC @120V AC 60HZ 0.50mAL-N1450VDC@250V AC 50HZ 0.82mA T 250V AC 3,6,10,15,20 L-G2250VDCL-N1450VDC普通工业设备EDP/EOP 250V AC 1,3,6,10 L-G1500VDC @120V AC 60HZ 0.22mAL-N1450VDC@250V AC 50HZ 0.38mAB 250V AC 1,2,3,5,10,20,30 L-G2250VDCL-N1450VDCK 250V AC 1,2,3,5,10,20,30,40,60L-G2250VDC VK 0.5mA EK 0.21mAL-N1450VDC VK 1.0mA EK 0.36mA DK 250V AC 1,3,6,10,20 L-G2250VDC VDK0.4mA EDK0.22mAL-N1450VDC VDK0.7mA EDK0.38mA R 250V AC 1,2,3,5,10,20L-G2250VDC VR0.4mA ER0.21mAL-N1450VDC VR07mA ER0.36mA IEC320插座式SRB 250V AC L-G1500VDCL-N1450VDCEEA/EEB250V AC 1,3,6,10 L-G2250VDC @120V AC 60HZ 0.22mAL-N1450VDC@250V AC 50HZ 0.38mA EF 250V AC 1,3,6,10 L-G2250VDC @120V AC 60HZ 0.21mAL-N1450VDC@250V AC 50HZ 0.36mAEEJ 250V AC 1,3,6,10,15,20 L-G1500VDC @120V AC 60HZ 0.22mAL-N1450VDC@250V AC 50HZ 0.38mA EJS 250V AC 1,3,6,10,15,20 L-G1500VDC @120V AC 60HZ 0.22mAL-N1450VDC@250V AC 50HZ 0.38mA EBF 250V AC 1,3,6,10 L-G1500VDC @120V AC 60HZ 0.22mAL-N1450VDC@250V AC 50HZ 0.38mA ED 250V AC 1,3,6,10,15 L-G1500VDC @120V AC 60HZ 0.22mAL-N1450VDC@250V AC 50HZ 0.38mA EC 250V AC 1,3,6,10 L-G1500VDC @120V AC 60HZ 0.22mAL-N1450VDC@250V AC 50HZ 0.38mA EJT 250V AC 1,3,6,10,15,20 L-G1500VDC 1--15 200.22/0.38mA 0.20/0.40mAL-N1450VDC白色家用电器WG 250V AC 16A @120V AC 60HZA,B&C D,E&F0.74mA 0.10mA1.25mA 0.17mA三相FCD 相对相480V AC 6,16,25,36,50 L-G2250VDC相对线270V AC L-L1450VDCADT 480V AC 63,100,160,200L-G2210VDC @277V AC60HZ 1.3A@277V AC60HZ 2.6A@277V AC50HZ 4.6AL-L2158VDCAYO 相对相440V AC 3,6,10,20 L-G1500VDC相对线250V AC L-L1450VDCAYA 440V AC 16,25,36,50 L-G1500VDC @120V AC 60HZ 1.62mAL-L1450VDC@250V AC 50HZ 2.82mAAYC 480V AC 16,25,36,63,80,110,150,180 L-G 1850VDCL-L 1850VDCL-N 1450VDC@120V AC 60HZ 1.62mA@250V AC 50HZ 2.82mAA 440V AC 20,30,45,60 L-G 1500VDCN-G 1500VDCL-N 1450VDC @120V AC 60HZ 1.4mA @250V AC 50HZ 3.4mA滤波位置电源相位应用领域滤波器型号选择型号技术参数额定电压额定电流介质耐压最大泄漏电流从设备单医疗设备GOODBETTERBESTHEAH/EBHEJHEJMMVHZHTHQEN550XclassAX,Y,Z 250V AC 1,2,3,4,6 L-G2250VDC @120V AC 60HZ 0.30mAL-N1450VDC@250V AC 50HZ 0.50mA SK 250V AC 3,6,10,20,30,40L-G2250VDCL-N1450VDCEMC出来从设备出来相单相X辐射（CISPR）S 250V AC 3,6,10,20 L-G2250VDC @120V AC 60HZ 0.40mAL-N1450VDC@250V AC 50HZ 0.70mA V/W 250V AC 3,6,10,20 L-G2250VDC @120V AC 60HZ 0.50mAL-N1450VDC@250V AC 50HZ 0.82mA EP/VPG 250V AC 6,10 L-G2250VDCL-N1450VDCT 250V AC 3,6,10,15,20 L-G2250VDCL-N1450VDCclassBZU 250V AC 6.5A L-G2250VDC @120V AC 60HZ 0.30mAL-N1450VDC@250V AC 50HZ 0.50mA N 250V AC 6,10 L-G2250VDC @120V AC 60HZ 1.2mAL-N1450VDC@250V AC 50HZ 2.0mA Q 250V AC 3,6,20 L-G2250VDCL-N1450VDCFCIEC320插座式SRBEEJEJSEBFEDEC普通工业设备EDP/EOPBKDKREMC恶劣环境AQ 250V AC 3,6 L-G2250VDCL-L1450VDC三相FCD ADT AYO AYA AYC A。

1IEC Appliance Inlet C14 with Filter 2-Stage, Fuseholder 1-pole, Line Switch 2-poleSee below:Approvals and CompliancesC1470° CDescription- Panel mount :Screw-on mounting from front side - 4 Functions :Appliance Inlet Protection class I , Fuseholder for fuse-links 5 x 20 mm 1-pole , Line Switch 2-pole , Line-filter in standard version , 2 positions - Quick connect terminals 6.3 x 0.8 mmCharacteristics- Compact design with optimal shielding - All single elements are already wired- Plug removal necessary for fuse-link replacement - 2-stage line filter with increased attenuation With EMC-shield- Suitable for use in equipment according to IEC/UL 60950Suitable for use in medical equipment according to IEC/UL 60601-1Other versions on request- Medical version M80References Alternative: version with 1-stage filter FKHWeblinkspdf datasheet , html-datasheet , General Product Information , Distributor-Stock-Check , Accessories , Detailed request for productT echnical DataRatings IEC1 - 10 A @ Ta 40 °C / 250 VAC; 50 Hz Ratings UL/CSA 1 - 10 A @ Ta 40 °C / 125 VAC; 60 Hz Leakage Current standard < 0.5 mA (250 V / 60 Hz)Dielectric Strength> 1.7 kVDC between L-N > 2.7 kVDC between L/N-PE Test voltage (2 sec)Allowable Operation Tempe-rature-25 °C to 85 °CClimatic Category 25/085/21 acc. to IEC 60068-1IP-Protection from front side IP 40 acc. to IEC 60529Protection Class Suitable for appliances with protection class I acc. to IEC 61140TerminalQuick connect terminals 6.3 x 0.8 mm Panel Thickness S Screw: max 8 mmMounting screw torque max 0.5 Nm Material: HousingThermoplastic, black, UL 94V-0appliance inlet/-outletC14 acc. to IEC 60320-1,UL 498, CSA C22.2 no. 42 (for cold conditions) pin-temperature 70 °C, 10 A, Protection Class IFuseholder1-pole, Shocksafe category PC2 acc. to IEC 60127-6,for fuse-links 5 x 20 mm Rated Power Acceptance @ Ta 23 °C5 x 20: 1.6 W (1 pole)Power Acceptance @ Ta > 23°C Admissible power acceptance at higher ambient temperature see derating cur-vesLine Switch2-pole, non-illuminated, acc. to IEC 61058-1Technical DetailsLine FilterStandard Version, IEC 60939, UL 1283, CSA C22.2 no. 8 Technical DetailsMTBF> 1'200'000 h acc. to MIL-HB-217 FApprovals and CompliancesDetailed information on product approvals, code requirements, usage instructions and detailed test conditions can be looked up in Details about ApprovalsSCHURTER products are designed for use in industrial environments. They have approvals from independent testing bodies according to national and international standards. Products with specific characteristics and requirements such as required in the automotive sector according to IATF 16949, medical technology according to ISO 134485 or in the aerospace industry can be offered exclusively with customer-specific, individual agree-ments by SCHURTER.ApprovalsThe approval mark is used by the testing authorities to certify compliance with the safety requirements placed on electronic products. Approval Reference T ype: FKHDApproval Logo Certificates Certification Body DescriptionVDE Approvals VDE Certificate Number: 40004665UL Approvals UL UL File Number: E72928Product standardsProduct standards that are referencedOrganization Design StandardDescriptionDesigned according to IEC 60320-1Appliance couplers for household and similar general purposesDesigned according to IEC 60939Passive filters for suppressing electromagnetic interferenceDesigned according to IEC 60127-6Miniature fuses. Part 6. Fuse-holders for miniature fuse-linksDesigned according to IEC 61058-1Switches for appliances. Part 1. General requirements Designed according to UL 498Standard for Attachment Plugs and ReceptaclesDesigned according to UL 1283Electromagnetic interference filtersDesigned according to CSA C22.2 no. 42General Use Receptacles, Attachment Plugs, and Similar Wiring DevicesDesigned according to CSA C22.2 no. 8Electromagnetic interference (EMI) filters Application standardsApplication standards where the product can be usedOrganization Design StandardDescriptionDesigned for applications acc.IEC/UL 60950IEC 60950-1 includes the basic requirements for the safety of informationtechnology equipment.Designed for applications acc.IEC 60601-1Medical electrical equipment - Part 1: General requirements for basicsafety and essential performanceDesigned for applications acc.IEC 60335-1Safety of electrical appliances for household and similar purposes. Meetsthe requirements for appliances in unattended use. This includes the en-hanced requirements of glow wire tests acc. to IEC 60695-2-12 and -13. CompliancesThe product complies with following Guide LinesIdentification Details Initiator DescriptionCE declaration of conformity SCHURTER AG The CE marking declares that the product complies with the applicablerequirements laid down in the harmonisation of Community legislation onits affixing in accordance with EU Regulation 765/2008.RoHS SCHURTER AG EU Directive RoHS 2011/65/EUChina RoHS SCHURTER AG The law SJ / T 11363-2006 (China RoHS) has been in force since 1 March2007. It is similar to the EU directive RoHS.REACH SCHURTER AG On 1 June 2007, Regulation (EC) No 1907/2006 on the Registration,Evaluation, Authorization and Restriction of Chemicals 1 (abbreviated as"REACH") entered into force.White paper Glow wire test SCHURTER AG Meets the requirements of IEC 60335-1 for appliances in unattended use.This includes the enhanced requirements of glow wire tests acc. to IEC60695-2-12 and -13.Medical Equipment SCHURTER AG Suitable for use in medical equipment according to IEC/UL 60601-123Dimension [mm]Case 45Diagrams Standard versionNLPE’L’1)2)1) Line2) Load Medical version (M5)LPE’L’1)2)1) Line 2) LoadDerating Curves 1-poleA d m i s s i b l e p o w e r a c c e p t a n c e i n W a t tAmbient air temperature Ta °C4Attenuation Loss- - - - 50Ω differential mode _____ 50Ω common modeStandard version1 A2 A4 A6 A10 AMedical version (M5)1 A2 A4 A6 A10 AAll VariantsPackaging unit 10 Pcs AccessoriesDescriptionAssorted CoversRear Cover0859.0074Mating Outlets/ConnectorsCategory / DescriptionAppliance Outlet Overview completeIEC Appliance Outlet F, Screw-on Mounting, Front Side, Solder Terminal4787IEC Appliance Outlet F, Snap-in Mounting, Front Side, Solder or Quick-connect Terminal4788IEC Appliance Outlet F or H, Screw-on Mounting, Front Side, Solder, PCB or Quick-connect Terminal5091Appliance Outlet further types to FKHDConnector Overview complete4782 Mounting: Power Cord, 3 x 1 mm² / 3 x 18 AWG, Cable, Connector: IEC C1347824785 Mounting: Power Cord, 3 x 1 mm² / 3 x 18 AWG, Cable, Connector: IEC C1347854300-06 Mounting: Power Cord, 3 x 1 mm² / 3 x 18 AWG, Cable, Connector: IEC C134300-06IEC Connector C15 for hot conditions 120°C, Rewireable, Straight4781IEC Connector C15 for hot conditions 120°C, Rewireable, Angled4784Connector further types to FKHD...The specifications, descriptions and illustrations indicated in this document are based on currentinformation. All content is subject to modifications and amendments. Information furnished is believed18.12.2185。

资料范本本资料为word版本，可以直接编辑和打印，感谢您的下载滤波器主要参数与特性指标-滤波器的主要性能参数地点：__________________时间：__________________说明：本资料适用于约定双方经过谈判，协商而共同承认，共同遵守的责任与义务，仅供参考，文档可直接下载或修改，不需要的部分可直接删除，使用时请详细阅读内容滤波器的主要参数（Definitions）：中心频率（Center Frequency）：滤波器通带的频率f0，一般取f0=（f1+f2）/2，f1、f2为带通或带阻滤波器左、右相对下降1dB或3dB边频点。

窄带滤波器常以插损最小点为中心频率计算通带带宽。

截止频率（Cutoff Frequency）：指低通滤波器的通带右边频点及高通滤波器的通带左边频点。

通常以1dB或3dB相对损耗点来标准定义。

相对损耗的参考基准为：低通以DC处插损为基准，高通则以未出现寄生阻带的足够高通带频率处插损为基准。

通带带宽（BWxdB）：指需要通过的频谱宽度，BWxdB=（f2-f1）。

f1、f2为以中心频率f0处插入损耗为基准，下降X（dB）处对应的左、右边频点。

通常用X=3、1、0.5 即BW3dB、BW1dB、BW0.5dB 表征滤波器通带带宽参数。

分数带宽（fractional bandwidth）=BW3dB/f0×100[%]，也常用来表征滤波器通带带宽。

插入损耗（Insertion Loss）：由于滤波器的引入对电路中原有信号带来的衰耗，以中心或截止频率处损耗表征，如要求全带内插损需强调。

纹波（Ripple）：指1dB或3dB带宽（截止频率）范围内，插损随频率在损耗均值曲线基础上波动的峰-峰值。

带内波动（Passband Riplpe）：通带内插入损耗随频率的变化量。

1dB带宽内的带内波动是1dB。

带内驻波比（VSWR）：衡量滤波器通带内信号是否良好匹配传输的一项重要指标。

FMP-10&FMS-10MPO TesterManualPlease read this guide before useSpecificationFMP-10&FMS-10FMS-10MPO Light SourceOptical Interface12cores MPO port(female)Wavelength850nmSpectral type VCSELChannel12Data Interface USBWavelength Recognition ReservedModulation CW（Low/High Power mode）、270Hz、1kHz、2kHz FMP-10MPO Power MeterSensor InGaAsOptical Interface12cores MPO port(female)Calibrated Wavelength850nm,1300nm,1310nm,1550nmChannel12Test Range-60dBm~+3dBmResolution±0.01dBUncertainty±0.5dBMaximum input power+13dBmUnit dBm/dB(REF)Threshold Setting4wavelengthReference Setting4wavelengthData storage300setsData interface USBWavelength Recognition YesPolarity Test According to TIA-568-C.0Frequence Recognition270Hz、1kHz、2kHzGeneralDisplay TFT-LCDAuto Power-Off YesPower Supply NiMH batteries/AC adapterWorking Hours≥10hoursWorking Temp0℃~50℃Humidity0~95%（non condensing）Dimension190L×105W×55H mmWeight About700gSafety InstructionsWarningTo avoid the risk of injury or death,always observe the followingprecautions before initializing the unit:To prevent hazardous radiation exposure,use only the controls oradjustments and perform only procedures specified for the lasersource.If using a voltage-reducing autotransformer to power theunit,ensure that the common terminal connects to the earthed poleof the power sourceUse only the type of power cord supplied with the unit.Willfully interrupting the protective earth connection is prohibited.Never look into the end of an optical cable connected to an opticaloutput device that is ser radiation is invisible,and directexposure can severely injure the human eye..for moreinformation,see the user’s manual of the laser source in use.Do not use the unit outdoors.To prevent potential fire or shock hazard,do not expose the unit toany source of excessive moisture.Do not operate the unit outdoorsDo not interrupt the protective earth grounding.Any such action can lead to a potential shock hazard that can result in serious personalinjuryTo prevent potential fire or shock hazard,do not expose the unit toany source of excessive moisture.Unless absolutely necessary,do not attempt to adjust or performany maintenance or repair procedure when the unit is open ed andconnected to a power source.Repairs are to be carried out only by a qualified technician.Do not attempt any adjustment,maintenance,or repair procedure to the unit’s internal mechanism if immediate first aid is not accessible Disconnect the power cord from the unit before adding or removingany components.Operationg the unit in the presence of flammable gases or fumes isextremely hazardousDo not perform any operating or maintenance procedure that is not described in the user’s manualStandard ConfigurationFMP-10&FMS-10tester、power adapter、Standard MPO jumper。

EMI 电源滤波器
电源滤波器是低通滤波器的一种，是由电容、电感等无源元件构成的双向网络，利用阻抗失配原理抑制电源线上的干扰。

其滤波范围通常在0.015-50MHz之间,对此频带范围内的干扰信号提供最高可达100dB 以上衰减。

电源滤波器主要技术参数说明
1.插入损耗
插入损耗是衡量滤波器滤波效果的指标，通常以分贝数或频率特性曲线来表示。

它是指滤波器接入线路前后，电源传给负载的功率比或端口电压比。

IL=10lg Po/P2(dB) 或IL=20lg V o/V2(dB)
Po、P2、V o、V2分别表示滤波器接入前后负载端的功率和电压。

实验室测量一般在50/50Ω系统下进行。

2.最大泄漏电流
泄漏电流是指滤波器相线、中线对地（外壳）在250V AC、50Hz下流过的最大电流。

为保证安全，对不同类型、不同应用场合的滤波器，此项指标有不同规定。

3.绝缘电阻
绝缘电阻是指滤波器相线、中线对地之间的阻值。

通常用绝缘电阻表测试。

4.试验电压
试验电压指滤波器线至线、线至地间的抗电电压。

试验时间为1分钟。

滤波器不出现打火、击穿、损坏及性能下降等现象。

军用直流电源滤波器
产品及应用
●专为军用设备电磁兼容国军标GJB152A 中CE102、CE106、CE107标准而设计。

●应用于军用直流通信电源、车载电源、机载设备中。

●可根据用户要求定制专用产品。

技术参数
额定电压
额定电流
耐压测试
绝缘电阻 气候类别 5~600VDC 1~200A
线-线:200VDC~1000VDC 线-地:500VDC(AC)~1500VDC
200M Ω @500VDC
55/85/21
产品列表
产品型号
额定电压(VDC)
额定电流(A)
外型尺寸 插入损耗 连接方式
ET-MD1B22DW 1001图1 图1 ET-MD2B12DW 1002图2 图2 ET-MD3B12DW 1003图3 图3 ET-MD4B22AW 1004图4 图4 软 线 ET-MD6B12BL 1006图5 图5 ET-MD10B12HL 10010图6 图6 焊 片 ET-MD5B15X61005图7 图7 ET-MD15M12-410015图8 图8 连接器 ET-MD20B12EW 40020图9 图9 ET-MD30B33LW 100 30 图10 图10 软 线 ET-MD60B22GB 100 60 图11 图11 ET-MD100B12LB
100
100
图12
图12
螺 栓 外形尺寸图：
【图1】 【图2】
【图3】【图4】【图5】【图6】【图7】【图8】
【图11】【图12】
插入损耗：。

北京泰派斯特成立于1997年，是国内较早从事电磁兼容（EMC ）、防信息泄漏（TEMPEST ）的专业公司，拥有从事多年EMC工作经验的专业人才，在行业中较早通过GB/T19001-2008idt £09001:2008质量体系认证、GJB 9001B-2009 国军标质量体系认证。

多年来为中国航天、航空、二炮、中船重工、中国电子科技集团、兵器、核工业、通信、铁路、医疗、汽车等部门和领域提供优质的产品和服务，为多项国家重点工程做出了贡献，是多家单位的分承制方或合格、优秀供应商。

经营范围：1、EMI产品导电衬垫（导电橡胶、铍铜簧片、金属丝网、导电泡棉、螺旋管等）导电化合物（导电胶、导电涂料、导电腻子等）电磁屏蔽胶带（磁屏蔽胶带、法兰保护胶带、导电箔带、导电布胶带、导电转移胶带等）通风波导、屏蔽视窗屏蔽电缆、电缆屏蔽材料、屏蔽热缩管等2、电子元器件EMI/RFI滤波器（电源滤波器、军用滤波器、信号滤波器、屏蔽室滤波器等）EMI铁氧体材料（吸收磁珠、磁环、磁夹等）滤波组件（方舱滤波组件、计算机滤波组件、通讯滤波组件等）进口器件（电容、电阻、晶振、模块等3、导热材料（导热绝缘垫、热传导胶带、导热硅脂等4、微波吸收材料（吸波橡皮、吸波海绵、吸波涂料、铁氧体吸波材料等）5、整机产品及服务：提供符合EMC及TEMPEST要求的计算机与其它电子设备，加固计算机、屏蔽室、方舱、车辆，承接建筑屏蔽工程，EMI/RFI模拟仿真，EMC、TEMPEST 技术支持，举办EMC、TEMPEST技术讲座。

我公司以诚实守信、质量第一、客户至上”为经营理念，价格合理、周到服务、客户满意”为宗旨。

目录一、电源滤波器基本知识介绍 (3)1 •概述 (3)2. EMI电源滤波器部分技术参数简介 (3)3. EMI电源滤波器的选用 (4)4. EMI电源滤波器使用注意事项 (5)二、电源滤波器 (6)1. 滤波器命名说明 (6)2. 军用滤波器 (12)3. 直流系列 (18)4. 交流单相通用滤波器 (22)5. 交流单相高性能滤波器 (26)6. 三相系列 (30)三、屏蔽室系列 (33)1. 屏蔽室电源滤波器 (33)2. 屏蔽室信号滤波器 (35)1、夏弗纳滤波器 (37)四、EMI吸收元件 (38)1、EMI吸收磁珠382、EMI多孔吸收磁珠403、EMI表贴吸收磁珠414、EMI吸收磁夹42五、标准D型滤波连接器 (45)六、EMI片状滤波器 (49)、电源滤波器基本知识介绍1. 概述电磁干扰(EMI)电源滤波器是由电感，电容组成的无源器件。
