注塑、模具行业术语：英汉对照版！（一）模具专业基本用词 Professional Terms1．塑料— plastic, resin2．样件— sample3．钢料— steel4．注塑机— injection machine, press5．产品— part, product, moulding6．模具— mold, mould, toolA 简易模（样板模）— prototype moldB 量产用模具— production mold7．三维造型（数模）—3D model, 3D data8．二维产品图— 2D part drawing9．设计— design10．制造— manufacture, build up, construction, fabrication, make11．检验— check, inspection12．测量— measure, inspection13．修改— change, modify, correction14．工程更改— engineer change15．质量— quality16．数量— quantity17．基准— datum, reference（二）如何解析2D 产品图？How to read 2D part drawing?一．产品几何 Geometry1．点— point2．线（边）— line, edge3．面 faceA 侧面— sideB 表面— surfaceC 外观面— appearance surface4．壁厚— wall thickness, stock thickness5．加强筋（骨位）— rib6．孔— hole7．细长的槽— slot8．柱位— boss9．角— cornerA 圆角— filletB 倒角— chamferC 尖角— sharp corner10．斜度— angle, taper11. 凹槽—recess , groove二. 分模信息 Splitting1．分型线— parting line (P/L), splitting line2．主分模方向— main direction, line of draw3．浇口设定— gating一．产品标识 Part Identification1．产品名称— part name (P/N)2．产品编号+版本号— part number + revision (Rev.) 3．型腔号— cavity number4．材料标记— material symbol5．模具编号— mold number (no.)6．日期印— dating insert, date code7．循环印— cycling code8．公司标志— company logo二. 技术要求 Specification (Special Requirement)1．项目启动表 Kick-off sheet1）项目名称— program name, project name2）产品名称— part name, product name, part description 3）产品编号— part number (P/N)4）客户模号— customer mold no.5）项目启动日期— kick off date, start date6）项目完成日期— due date, lead time7）内模件用钢— tool steel8）型腔数量— number of cavities9）数据文件编号— data file no.10）注塑材料— resin, plastic, raw material11）收缩率— shrink, shrinkage, shrink factor12）注塑机吨位— molding machine size, injection machine size13）成型周期— cycle time14）型腔光洁度— cavity polish15）型芯光洁度— core polish16）皮纹（晒纹）— texture, grain17）拔模斜度— draft angle, removal taper18）注塑件颜色及光泽— molded color & gloss19）模具加工地— manufacturing facility20）热流道供应商—manifold manufacturer, manifold supplier21）浇口位置— gate location / position22）浇口类型— gate type产品标识— stamp information, part identification特殊要求— special instructions1．产品质量及外观要求 Part Quality & Appearance Requirement1）尺寸及公差 Dimension & Tolerance① 重要尺寸— critical dimension, important dim., key dim.② 理论尺寸— nominal dimension③ 实际尺寸— actual dimension④ 公差— tolerance⑤ 公差带— tolerance range⑥ 尺寸超差— dimension deviation⑦ 接受（合格）— accept, OK⑧ 拒绝（不合格）— reject, refuse, obsolete, NG⑨ 让步接受— concession, special admit⑩ 返工— re-work2）产品缺陷（常见的）Defects (normal)① 缩水— sink mark, shrinkage② 飞边，毛边— flash, burr③ 段差— mismatch discrepancy④ 银丝纹，蛇纹— snake marks, streak⑤ 弯曲，变形— warpage, distortion⑥ 打不饱（缺料）— short shot⑦ 熔接线— weld line⑧ 多胶— unwanted plastic⑨ 拉伤—damage2．产品外观 Part Appearance① 产品颜色— part color② 产品光泽— gloss③ 皮纹粒度— grain3．常用词汇、词组及短语 Normal Word, Short Sentence1）单边— per side2）双边— both sides3）加入，添加— add, incorporate4）去除，取消— remove, cancel5）满足…的要求，符合，与…要求一致—according to, conform to, satisfy, meet6）要求，需要— require, need, demand7）确认—be approved, agreed by …8）允许— permit, allow9）在…范围之内— within10）不可以，不允许，禁止— free from, prevent, avoid11）…，除非有另指—… unless otherwise specified12）…或少于—…or less13）自动化运作— automatic operation14）未注尺寸（详细形状）见三维造型Non dimensioned contour (detailed shape) see 3D model.15）分型线上的飞边（披缝）或段差应小于…Burrs or discrepancy on the P/L shall be … or less.标题栏 Title Block1．产品名称— part name2．图纸编号 + 版本号（索引号）—drawing no. + level (index)3．一般公差— general tolerance（三）如何阅读制模标准？How to read tooling standard?一．模具结构术语 Mold Construction TermsA．模架 Mold Base1．模架量化特征 Measurement Feature① 长 X 宽 X 高— Length X Width X Height② 模具高度尺寸（模厚）— stack height of mould③ 模具重量— total weight of mould, mould thickness2．定模底板— front plate, top clamping plate, clamp plate, clamping plate3．定模板— cavity plate, fixed mould plate, A – plate4．动模板— core plate, moving mould plate, B – plate5．支撑板— support plate, backing plate6．间隔板,方铁— support blocks, rails, risers, spacer block 7．顶杆固定板— retaining plate, ejector retaining plate8．顶板— ejector plate，bottom clamping plate9．动模底板— back plate10．导柱— guide pillar, leader pin, guide pin 11．导套— guide bush, leader pin bush12．复位杆— return pin, push-back pin13．弹簧— spring14．撑头— support pillar15．顶针板导柱、导套— ejection guide pin / bush 16．垃圾钉— stop pin, stop button17．模脚— standing-off pillars18．标牌— plaque scutcheonB．成型零部件 moulding components1．型芯— core insert2．型腔— cavity insert3．镶针— core pin4．镶块— sub-insert, split5．滑块— slide, sliding split6．斜顶— lifter, angled-lift split, loose coreA 斜顶头— lifter headB 斜顶杆— lifter rod, lifter shaft7．成型顶杆— moulding face pin, form pin C．浇注系统 Feed System1．塑料 Mouldinga．主流道— sprueb．分流道 runner① 主分流道— main runner② 二级分流道— branch runner分流道断面形状 cross-sectional shape of runner① 圆形— full round② 半圆形— semicircular③ 梯形— trapezoidalc．浇口 gate常用浇口形式 normal gate type :① 边缘浇口（J型浇口）— edge gate, J – gate② 侧浇口— side gate③ 潜伏式浇口— sub-gate, subsurface gate, submarine gate, cashew gate④ 潜伏式二次浇口(隧道式浇口) —tunnel gate onto feeder post⑤ 点浇口— pin gate⑥ 直接浇口(主流道型浇口) — sprue gate, direct gate⑦ 护耳式浇口— tab gated．模腔— impressione．冷料井— cold slug wellf．热流道— hot runner2．模具零件 mold componentsa．定位圈— locating ring, location ring, register ringb．浇口套— sprue bushc．挡圈— stop ringd．浇口镶块— gate inserte．热流道板— manifoldf．热嘴— hot drophot sprue分型面及其锁紧、排气 Parting Surface, inter-locking & venting1．分型线— parting line ( P/L )2．镶拼线— bodyline, joint line3．平 / 不平的分型面— flat / non – flat parting surface4．封胶面— shut off surfaces, seal-off surfaces5．擦穿位— shut off6．碰穿位— kiss-off7．管位— parting line lock8．分型面的释放(避空) — relief of parting surface9．分型面的平衡— balancing of parting surface10．锁紧角度— locking angle11．锁紧力— clamping force12．锁模块— safety strap13．精定位— Interlock, die lock14．困气— air trap15．排气槽— vent, vent slotE．滑块机构 Slide1．驱动 Actuation① 斜导柱— angle pin, horn pin, cam pin② 弹簧— spring③ 油缸— hydraulic cylinder2．制动 Detention① 滑块固定器— slide retainer② 弹簧制动器— spring-loaded detention (plunger)③ 挡钉、挡板— stop pin, stop plate, slide stop3．导轨— gib, guide strip4．锁紧块（楔紧块）— heel block, locking heel, wedge block, chase block5．耐磨片— wear plate, wear strip6．压板— retainer, gib7．螺钉— screw8．定位销— dowel pinF．斜顶机构 Lifter1．斜顶头— lifter head2．斜顶杆— lifter rod, lifter shaft3．开口销— split pin4．固定板（压板）— retainer plate5．耐磨片— wear plate6．铜导套— bronze bushing7．衬套— spacer8．导轨— L – gib9．滑动块— slideG．顶出系统 Ejection System1．基本词汇 Basic Word① 顶出行程— ejection stroke② 模具开档— daylight③ 粘模— stick④ 产品脱模—part is push off from, clear part of mould, separation of part2．顶板机构 Ejector plate assembly① 顶板— ejector plate② 顶板固定板— retaining plate③ 推板— stripper plate④ 推板导柱— ejector guide pin⑤ 推板导套— ejector guide bush⑥ 撑头— support pillar3．复位机构 Return System① 复位杆（回程杆）— return pin, push – back pin② 垃圾钉— stop pin, stop button③ 压簧— compressed spring④ 碟簧—a stack of ―Belleville‖ washers⑤ 早复位机构— early return system⑥ 强制复位机构— positive return system4．顶出方法 Ejection Techniques1）顶杆顶出— pin ejection2）顶管顶出— sleeve ejection3）顶块顶出— bar ejection4）扁顶顶出— blade ejection5）顶板顶出— stripper ejection6）油缸顶出— hydraulic ejection7）气顶— air ejection8）阀门顶出— valve ejection5．顶出元件 Ejection Elements1）拉料杆— sprue puller, sucker pin2）顶杆— ejector pin3）阶梯式顶杆— stepped ejector pin1）顶管— ejection sleeve, sleeve2）扁顶— ejector blade, slabbed off ejector pin3）顶块— stripper bar4）顶环— stripper ring5）推板— stripper plate6）加速顶— accelerated ejection1．顶出辅助机构 Supplementary operating system1）弹簧柱塞器— spring – loaded plunger2）弹珠定位器— ball catch system3）插销式锁扣— Latch – lock4）尼龙拉杆装置— friction puller device2．电器元件 Electric Components1）压力传感器— pressure transducer2）限位开关— limit switchF．冷却系统 Cooling System1．基本词汇 Basic Word1）温差— temperature variation2）水孔（水道）—waterlines, water-ways, flow-way, channel3）水路— cooling circuit4）水路示意图— water schematic, schematic circuit5）冷却液— coolant, coolant fluid6）内连接— interconnect7）外连接— external connection8）出口、入口— outlet、inlet9）漏水— water leakage2．水路分布 Circuits1）阶梯式水路— stepped system2）分隔板水路— baffled hole system3）斜孔式水路— angled hole system3．水路元件 Components1）闷头（螺塞、止水栓）—（threadless）brass pressure plug : female plug & male2）隔水片— baffle3）密封圈— O – ring4）快插水路接头—quick disconnect fitting, quick connection adaptor5）弯头— elbow6）偶合器（连接器、接头）— adaptor (including a plug & a socket)7）橡皮管— rubber hose1）分水板,集水块— water manifoldG．螺纹、螺纹孔 & 螺钉 Thread, thread hole & screw1．螺纹— thread2．管螺纹— pipe thread3．螺纹孔— screw hole, tapped hole4．起吊孔— handling hole, jack screw hole, eye bolt hole 5．螺钉— screw6．内六角螺钉— socket headed cap screw （s.h.c.s.）7．沉头螺钉— flat headed cap screw （f.h.c.s）8．螺栓— bolt9．螺母— nut10．锁紧螺母— locknut11．螺纹标准 Thread Standard① 公制标准— Metric② 英制标准— Imperial③ 英制管螺纹标准— British Standard Pipe thread （BSP）④ 美制管螺纹标准— NPT⑤ 美制粗螺纹标准— United Coarse thread （UNC）⑥ 美制细螺纹标准— United Fine thread （UNF）H．润滑 Lubrication1．润滑槽— grease groove2．加油管— grease line3．油杯— lubrication fittingI. 测量仪器 Measuring Instruments1．游标卡尺— vernier caliper2．千分尺— micrometer3．高度规— height gauge4．刻度规— dial gauge5．三坐标测量仪（三次元）— Coordinate Measure Machine （CMM）6．塞规— pin gauge7．圆角量规— radii gauge8．轮廓投影机—profile projectorJ．注塑机参数 Injection Machine Parameter1．注塑机规格参数 Injection Machine Specification① 锁紧类型 clamp typea．油缸— hydraulicb．肘杆式— toggle② 垂直注塑机导柱间距— tie bar vertical clearance③ 水平注塑机导柱间距— tie bar horizontal clearance④ 台板尺寸— platen dim.⑤ 最小 / 最大模厚— mold height Min. / Max., Min. / Max.mold thickness⑥ 最小 / 最大注塑机开档— open daylight Min. / Max.⑦ 锁紧行程— clamp stroke⑧ 锁紧力— clamping force⑨ 顶出行程— ejector stroke⑩ 顶出力— ejector force !你想成为学霸吗。
