CNC Flame Cutting MachineThis machine uses gantry structure, dual-side alternating stepper driving motor, US-owned Start SH-2012AH CNC system, with large cutting area, can be added device freely, standard flame cutting config. It’s av ailable for the optional plasma cutting way, at the same time, with the option of the flame plasma dual-use cutting mode. Fully functional, suitable for all types of scale customers cutting stock demand.Working Course and SamplesMain Technical SpecificationModel AD-F3060 Machine size3000*8000mm Effective Cutting Range(mm) 2400*6000Cutting Thickness(mm) Carbon Steel:verge cutter≤120；perforation≤60Cutting WayOxygen+propane or acetyleneCutting Speed （mm/min ） 50-2000(max.4000) Running Speed （mm/min ） 50-8000mm/minVelocity Error （％） ≤±5％ Automatically Adjustable High-precision （mm ） ≤±1.0mmLongitudinal linear precision ±0.2mm/10m Linear repeat precision±0.5mm/10mSynthetic accuracy （consult the right graphic ）1000mm ╳1000mm Crossed speed:500-800mm/min热Guide installation precision 1).Guide rail profile ：0.5mm/10000mm2).The parallelism between rails longitudinal rail surface andhorizontal ：±0.5mm/10000mm Intersection offset 1.0mm Straightness 0.5mm Circular degree1.0mm The diagonal line differential 1.0mm Repeat location accuracy 0.5mm Crossed precision≤0.5mmWorking Environment Requirement1 Working Temperature-10℃-+50℃2 Humidity＜90% without condensation 3 Surrounded EnvironmentVentilated4 Voltage 3×380v±10%220v±10%5 Power Frequency 50Hz6 Input Power 3KW7Ground connecting typeConcentrating direct connection 8Air pressurePreheat Oxygen Pressure: 0.4－0.6MPaCutting Oxygen Pressure: 0.5-0.9Mpa Gas Pressure: 0.05-0.1MpaMachine Specifications:Its cross beam have many specifications, both of them adopt dual drive and lineal guide. Torch quantify is optional according to users demands, also can be configured as abnormity cutting and strip cutting. Application:It can cut mild steel(flame cutting) and high carbon steel, stainless steel, aluminum, copper and other non-ferrous metal (plasma cutting),etc. be widely applied in industries such as machinery, automobile, shipbuilding, petro-chemical, war industry, metallurgy, aerospace, boiler and pressure vessel, locomotive etc.Advantage:SH-2012AH/QG China and USA Joint Company Beijing START System(All-digital stepper drive)1.Adopting industrial grade ARM7 processor chip;2.High reliability, with strong protection for plasma interference,lightning, and surge, past the EMC testing;3.32 M ~ 64M large program storage capacity, not subject tocapacity restriction;4.The system provides 4 inbuilt replay, equipped with arcing andbleeding open function, providing 2 or more frequent open andclosed contacts, simultaneously,. It can output and inputsimultaneously, providing wiring for both the plasma and flame. Agreat convenience for the user installation, providing wiring,improving system reliability. Four inbult relay functions: gas andpreheat oxygen or height control; cutting oxygen or plasma arcing;up / down torch, inhibiting and self-locking function;5.Providing: 8 inputs (optical isolation), 8 outputs (relay output);6.Number of linkage axis: 2 axis, (can be extended to 3-axis)7.Size: (300 × 204 × 93) mm;8.7-inch color LCD screen,the system adopt multi-functional, English, other languages menu, easy to operate.9.fully compatible with IBE, FASTCAM such as CAD / CAM nesting software.10.With 24 type of picture Gallery, has a simple nesting function, use-friendly.Unique design with four-direction controlmodule inhibiting: when X and Y direction,the motor moves to the end or inhibited, theoperation of the entire machine will stopworking. The 4 control module connected bycable and CNC system, connected by theconnector and the scene inverter, each controlmodule (including testing and control circuit,length display communication control and thedisplay and output circuit of speed-controlfrequency converter. 4 flow control module isinstalled in the cabinet. Our practicaltechniques which can limit control of thelong-range high-precision CNC cuttingmachine, substantial increase in productioncapacity, production efficiency, product qualityand economic efficiency of enterprises. Inaddition, it also has a high coefficient of safety production, simple operation, and reduce labor intensity.High-hardness and rigidity longitudinalguide-way:1.Eco and self-smoothen design with lowfriction2.Four direction equal load3.High-precision, easy for maintenance4.High-speed, low noise;5.Slider interchangeability;6.International standard specifications;7.Running smoothly, the new cycle way;8.Fully sealed slider to prevent dustadhesion;Y direction motor flowing device: This device collects our domesticmanufacturing tech nology. After improving, it’s more reasonable, easy fortesting, engine oil changing and installing. The main feature is that themotor can keep the best contacting state with transmitting parts all thetime, and be tighter or loose automatically while working, so as todecreasing friction, improving working quality, and extent the lifespan ofthe machine.Large gear and rack: All the gear and rack of our Gantry CNC cuttingmachine are processed by automaically quenching treatment, Itsaccuracy reach GB/T100967-9standards for the high precision ofprocessing technology. Compared with other craft, it has better workingperformance. Machine works stably with no vibration, improving theprocessing accuracy. Its lifespan has 5-8 times more than the normal rack.The working precision of the whole machine is 0.01mm per step.Steel line transmitting device: strong tensile; impact resistance, longlife, small elongation into a good groove, good flex resistance,improve positioning accuracy. The motor apparatus and fixed wheelrespectively in the rail ends, and the motor is fixed to the motor bracket. The latter contacts with axis guide-rail, which direction is vertical with the guide-rail on the guide-rail, helically wound round wire connected to the motor shaft wound wire rope, and fixed wheel between the helically wound wire round the other end with the nut screw connection, both pitch is the same, the nut is fixed to the nut holder, the latter is fixed to the rack. Motor driven wire rope can be used for the corresponding servo in order to to eliminate wire rope pull oblique bring motion errors, improve positioning accuracy, and more suitable for rapid prototyping of high technology as well as other requirements for positioning accuracy of the transmission equipment.Unlimited exchange torch holder: It adopts domestic initiative unlimitedrotating structure design. Using this structure makes the operation ismore easier, flexible, such as adjusting, cutting hole, cutting plat material.It’s with light weig ht, anti-aging, anti-corrosion, and its lifespan can be upto 10 years. no longer have to worry about strut screw top deformation,rust aluminum.P ositioning plate beams towline:The device is an initiative product of our company in cnc cuttingmachine industry, its role is to ensure the beams towline smooth,accessibile and straight move in the U-slot. The structure of the U-type, maintenance-free type.XY axis high precision planetary reducer:It has the power split and multi-gearmeshing etcs.Good bear capacity, High running stability, no vibration, low noise, and long service life. In addition, Using serv o motor, get better speed on the basis of its original speed, to enhance its torque and match the movement of inertia.Heavy-duty reinforced nylon engineering towline:It has high pressure and tensile load, good toughness, high elasticity and abra sion resistance, flam e retardant, keep stable while high and low temperature,Reach to 500 million reciprocating motion. We chosen the StarTech micro-step industrial grade ARM controller sets and power drive components, reducing unnecessary losses for the hardware incompatibility.Three Italy imported CEME high thermostability solenoid valve is not only the perfect solve solenoid valve can not close flame patterns cause by the high temperature, Individually controlled gas line eli minating the need for you to repeatly adjust the flame.Precision testing before deliveryBefore shippment ,Each CNC machine of China AD CNC Tevhonogy Co.,Ltd strict draw 500 *350mm complex standard detection on A2 paper and draw lines with Φ0.2mm professionalcoarse brush, integrated accuracy ±0.3mm,1000mm*1000mm ,its paintings line accuracy is± 0.4mm.24 hours continuous running test:In order to insure the quality of our cnc cutting machine,the machine will have a 24 hours continous running test,so as to notice the problem of the machine.Main spare parts, & Attendant Document Listplete set of equipment tools and wearing partsinternal hexagonal wrench below 10mm 1setCutting torch cleaner 2pcsPropane fast cutting torch 1#-3# 2setsB.Technical documentsOperation manual 1The inspection standard 1Guide rail installation instructions 1Packing list 1The simple drawing of machine 1（sending to buyer after payment）1 mobile U disk; nozzle 1 and nozzle 2; 1 product specifications, 1set graphics transferring software, 1 pieceelectric cable and 1 set nozzle cleaner.QuatationItem Product Mode AD-F3060 QTYPrice(USD)Remark1FLAMEPLASMACUTTINGMACHINEXF-4-3000X8000 1SET 14500USDTransverse span: 3M; the longitudinal length:8m.Effective cutting width 2m; effective cuttinglength 6MSino US cooperation start system, dual drive, 1flame cutting torch, one plaama cuttingtorch,ARC automatic height control system andcollision, specialized edition software, solenoidvalve relay AIRTAC Taiwan, Germany Schneider,endotracheal REFITET ItalyPayment term1 Lead time: within 7-15 days after receiving your deposit2.30% in advance3.70% before shippement.Guarantee & after sale service1.The whole machine we offer one year guarantee time free, without consumable parts replacement andman-made fault2.Lifelong Technical Support for the machineer-friendly English manual and video for machine using and maintainingLead time: within 7-15 days after receiving your depositChina AD CNC Technology Co., LtdShenbaolong Industrial Park, Sunshine Avenue, Wuhan, ChinaTel: +86-159********Email:doris@Skype:dorisfu0Msn:dorisfu020@web: 。
