专利名称：All-optical flip-flop发明人：Fatehi, Mohammad T.,Giles, Clinton Randy申请号：EP94308904.5申请日：19941201公开号：EP0658795A1公开日：19950621专利内容由知识产权出版社提供专利附图：摘要：An all-optical flip-flop device is achieved by employing two optical amplifiers (150,160) arranged so that they together operate in only one of two stable states at a given time. In a first stable state of operation, the first optical amplifier (150) behaves as a laser having a first predetermined characteristic wavelength. The arrangement is switchedto a second stable state of operation in which the second optical amplifier (160) behaves as a laser having a second characteristic wavelength, where the first and second characteristic wavelengths are at least nominally different, when an optical signal pulse is received at the input (SET) of the first optical amplifier. The arrangement is switched back to the first stable state when an optical signal pulse is received at the input (RESET) of the second optical amplifier.申请人：AT&T Corp.地址：32 Avenue of the Americas New York, NY 10013-2412 US国籍：US代理机构：Watts, Christopher Malcolm Kelway, Dr.更多信息请下载全文后查看。
