华为 S5720-EI 系列交换机 产品彩页文档版本 1.0 发布日期2016/10/26华为技术有限公司版权所有© 华为技术有限公司2013。
保留一切权利。
非经本公司书面许可，任何单位和个人不得擅自摘抄、复制本文档内容的部分或全部，并不得以任何形式传播。
商标声明和其他华为商标均为华为技术有限公司的商标。
本文档提及的其他所有商标或注册商标，由各自的所有人拥有。
注意您购买的产品、服务或特性等应受华为公司商业合同和条款的约束，本文档中描述的全部或部分产品、服务或特性可能不在您的购买或使用范围之内。
除非合同另有约定，华为公司对本文档内容不做任何明示或默示的声明或保证。
由于产品版本升级或其他原因，本文档内容会不定期进行更新。
除非另有约定，本文档仅作为使用指导，本文档中的所有陈述、信息和建议不构成任何明示或暗示的担保。
华为技术有限公司地址：深圳市龙岗区坂田华为总部办公楼邮编：518129网址：客户服务邮箱：support@客户服务电话：400-830-2118前言产品概述S5720-EI下一代增强型千兆以太网交换机系列（以下简称S5720-EI），是华为公司自主研发的新一代千兆以太网交换机，提供灵活的全千兆光/电/Combo口接入以及增强的万兆上行端口扩展能力。
该系列交换机基于新一代高性能处理器和华为公司统一的VRP（Versatile Routing Platform）软件平台，提供更大的表项规格，更高的硬件处理能力，可集成无线控制器功能，可扩展支持MACSec功能，具备更加完善的业务处理能力，增强的安全控制，灵活的以太组网，成熟的IPv6特性，智能iStack堆叠，方便的运行维护等特点。
广泛应用于企业园区接入、汇聚，数据中心千兆接入等多种应用场景。
产品外观产品特性和优势轻松的运行维护•电源端口前置的款型可以满足300mm深的机柜放置，整台设备可以前面板单面维护，简化了运维，而且机柜的摆放更加灵活，可以灵活选择机柜靠墙放置或者机柜背靠背放置，满足客户机柜深度小、机房空间有限的需求，并为客户节省空间。
S7700系列智能路由交换机S7700系列智能路由交换机产品概述S7700系列是华为公司面向下一代企业网络架构而推出的新一代高端智能路由交换机。
该产品基于华为公司智能多层交换的技术理念，在提供稳定、可靠、安全的高性能L2~L4层交换服务基础上，进一步提供MPLS VPN、业务流分析、完善的H-QoS策略、可控组播、资源负载均衡、一体化安全等智能业务优化手段，同时具备超强扩展性和可靠性。
S7700系列广泛适用于园区网络、数据中心核心/汇聚节点，可对无线、话音、视频和数据融合网络进行先进的控制，帮助企业构建交换路由一体化的端到端融合网络。
通过部署内置华为首款以太网络处理器ENP的X1E单板，同时将系统软件升级到V2R5C00版本，S7700可以升级为敏捷交换机，客户可以享有敏捷交换机带来的创新体验。
S7700系列提供S7703、S7706、S7712三种产品形态，支持不断扩展的交换能力和端口密度。
S7700作为新一代智能交换机采用了全新的硬件平台，左后风道散热整机架构，打造业界最佳能效比交换设备。
关键部件冗余设计，最小化设备宕机与业务中断风险。
创新节能控制芯片，整机智能节电，为网络绿色可持续发展提供领先的解决方案。
产品特点S7700升级为敏捷交换机，让网络更敏捷地为业务服务•S7700支持随板AC，业务单板同时兼具无线AC功能，无需额外购买AC硬件；整机最大可管理1K AP，16K用户；整机转发性能可达T-bit，解决外置AC处理性能瓶颈，助力客户从容面向高速无线时代。
•S7700支持统一用户管理功能，屏蔽了接入层设备能力和接入方式的差异，支持PPPoE/802.1X/MAC/Portal等多种认证方式，支持对用户进行分组/分域/分时的管理，用户、业务可视可控，实现了从“以设备管理为中心”到“以用户管理为中心”的飞跃。
•SVF超级虚拟交换网，创新实现不仅将盒式交换机纵向虚拟为框式交换机板卡，而且将AP纵向虚拟为框式交换机的端口，使得原来“核心/汇聚+接入交换机+AP”的网络架构，虚拟化为一台设备进行管理，提供业界最简化网络管理方案。
S5720-EI系列下一代增强型千兆以太网交换机S5720-EI系列下一代增强型千兆以太网交换机产品概述S5720-EI下一代增强型千兆以太网交换机系列（以下简称S5720-EI），是华为公司自主研发的新一代千兆以太网交换机，提供灵活的全千兆光/电/Combo口接入以及增强的万兆上行端口扩展能力。
该系列交换机基于新一代高性能处理器和华为公司统一的VRP（Versatile Routing Platform）软件平台，提供更大的表项规格，更高的硬件处理能力，可集成无线控制器功能，可扩展支持MACSec功能，具备更加完善的业务处理能力，增强的安全控制，灵活的以太组网，成熟的IPv6特性，智能iStack堆叠，方便的运行维护等特点。
广泛应用于企业园区接入、汇聚，数据中心千兆接入等多种应用场景。
12S5720-56C-PWR-EI-AC S5720-56C-PWR-EI-AC1•48个10/100/1000Base-T以太网端口，4个万兆SFP+•一个扩展子卡插槽•PoE+•可插拔双电源，默认配置一个AC电源，其中S5720-56C-PWR-EI-AC支持交流或直流供电，S5720-56C-PWR-EI-AC1支持交流供电•交换容量：598Gbps•包转发率：252MppsS5720-56C-EI-48S-AC S5720-56C-EI-AC •48个千兆SFP，4个万兆SFP+•一个扩展子卡插槽•可插拔双电源，支持交流或直流供电，默认配置一个AC电源•交换容量：598Gbps•包转发率：252Mpps•48个10/100/1000Base-T以太网端口，4个万兆SFP+•一个扩展子卡插槽•可插拔双电源，支持交流或直流供电，默认配置一个AC电源•交换容量：598Gbps•包转发率：252Mpps•支持华为Easy Operation简易运维方案，提供新入网设备Zero-Touch 安装、故障设备更换免配置、USB开局、设备批量配置、批量远程升级等功能，便于安装、升级、业务发放和其他管理维护工作，降低了运维成本。
DataSheetIntroductionBuilding on next-generation, high-performance hardware and the Huawei Versatile Routing Platform (VRP), the S2720-EI supports intelligent stack (iStack), flexible Ethernet networking, and diversified security control. It provides customers with a green, easy-to-manage, easy-to-expand, and cost-effective 100M to the desktop solution.Product OverviewModels and AppearanceModel DescriptionS2720-12TP-EI ● 4 × Ethernet 10/100 Base-Tx ports, 4 × Ethernet 10/100/1000 Base-T ports, 2 ×Gig SFP ports, 2 ×combo Gig ports● AC power supply● Forwarding performance: 12.6Mpps● Switching capacity: 68GbpsS2720-12TP-PWR-EI ● 4 × Ethernet 10/100 Base-Tx ports, 4 × Ethernet 10/100/1000 Base-T ports, 2 ×Gig SFP ports, 2 ×combo Gig ports● AC power supply● PoE+● Forwarding performance: 12.6Mpps● Switching capacity: 68GbpsS2720-28TP-PWR-EI-L ● 16 × Ethernet 10/100 Base-Tx ports, 8 × Ethernet 10/100/1000 Base-T ports, 2 ×Gig SFP ports, 2 ×combo Gig ports● 8 ×PoE+ ports● AC power supply● Forwarding performance: 20.4Mpps● Switching capacity: 68GbpsS2720-28TP-EI ● 16 × Ethernet 10/100 Base-Tx ports, 8 × Ethernet 10/100/1000 Base-T ports, 2 ×Gig SFP ports, 2 ×combo Gig ports●AC power supply●Forwarding performance: 20.4Mpps●Switching capacity: 68GbpsS2720-28TP-PWR-EI●16 × Ethernet 10/100 Base-Tx ports, 8 × Ethernet 10/100/1000 Base-T ports, 2 ×Gig SFP ports, 2 ×combo Gig ports●AC power supply●PoE+●Forwarding performance: 20.4Mpps●Switching capacity: 68GbpsS2720-52TP-EI●32 × Ethernet 10/100 Base-Tx ports, 16 × Ethernet 10/100/1000 Base-T ports, 4 ×Gig SFP ports●AC power supply●Forwarding performance: 34.8Mpps●Switching capacity: 336GbpsS2720-52TP-PWR-EI●32 × Ethernet 10/100 Base-Tx ports, 16 × Ethernet 10/100/1000 Base-T ports, 4 ×Gig SFP ports●AC power supply●PoE+●Forwarding performance: 34.8Mpps●Switching capacity: 336GbpsPower SupplyPoE Power Supply ConfigurationThe S2720-EI series PoE switches, including S2720-12TP-PWR-EI, S2720-28TP-PWR-EI-L, S2720-28TP-PWR-EI, S2720-52TP-PWR-EI, have built-in PoE power modules.The S2720-12TP-PWR-EI and S2720-28TP-PWR-EI-L has a built-in power module and does not support pluggable power modules. The built-in power module can provide 124 W PoE power, which ensures full PoE power on 8 ports in compliance in 802.3af or on 4 ports in compliance with 802.3at. The switch cannot connect to an RPS power supply.The S2720-28TP-PWR-EI and S2720-52TP-PWR-EI has a built-in power module and does not support pluggable power modules. The built-in power module can provide 370 W PoE power, which ensures full PoE power on 24 ports in compliance in 802.3af or on 12 ports in compliance with 802.3at. The switch cannot connect to an RPS power supply.Non-PoE Power Supply ConfigurationThe S2720-EI series non-PoE switches have a single internal power module and do not support pluggable power modules. Product Features and HighlightsFlexible Ethernet Networking●In addition to traditional Spanning Tree Protocol (STP), Rapid Spanning Tree Protocol (RSTP), and Multiple Spanning Tree Protocol (MSTP), the S2720-EI supports Huawei-developed Smart Ethernet Protection (SEP) technology and the latest Ethernet Ring Protection Switching (ERPS) standard. SEP is a ring protection protocol specific to the Ethernet link layer, and applies to various ring network topologies, such as open ring topology, closed ring topology, and cascading ring topology. This protocol is reliable, easy to maintain, and implements fast protection switching within 50 ms. ERPS is defined in ITU-T G.8032. It implements millisecond-level protection switching based on traditional Ethernet MAC and bridging functions.●The S2720-EI supports Smart Link, which implements backup of uplinks. One S2720-EI switch can connect to multiple aggregation switches through multiple links, significantly improving reliability of access devices.●The S2720-EI supports Ethernet OAM (IEEE 802.3ah/802.1ag) to fast-detect link faults.Diversified security control●The S2720-EI supports 802.1x authentication, MAC address authentication, and combined authentication on a per port basis and implements dynamic policy delivery (VLAN, QoS, and ACL) to users.●The S2720-EI collects and maintains information about access users, such as IP addresses, MAC addresses, IP address leases, VLAN IDs, and interface numbers in a DHCP snooping binding table. In this way, IP addresses and access interfaces of DHCP users can be tracked. You can specify DHCP snooping trusted and untrusted ports to ensure that users connect only to the authorized DHCP server.●The S2720-EI supports strict ARP learning. This feature prevents ARP spoofing attackers from exhausting ARP entries so that users can connect to the Internet normally.Easy maintenance●The S2720-EI can be managed and maintained using Simple Network Management Protocol (SNMP) V1, V2, and V3, Command Line Interface (CLI), web-based network management system, or Secure Shell (SSH) V2.0.●The S2720-EI supports Super Virtual Fabric (SVF), which virtualizes the "Core/aggregation + Access switch + AP" structure into a logical device. The S2720-EI enables the simplest network management solution in the industry. It allows plug-and-play access switches and APs. In addition, the S2720-EI supports service configuration templates. The templates are configured on core devices and automatically delivered to access devices, enabling centralized control, simplified service configuration, and flexible configuration modification. The S2720-EI functions as a client in an SVF system●The S2720-EI can use the GARP VLAN Registration Protocol (GVRP) to implement dynamic distribution, registration, and propagation of VLAN attributes. GVRP reduces manual configuration workload and ensures correct configuration. Additionally, the S2720-EI supports MUX VLAN, which involves a principal VLAN and multiple subordinate VLANs. Subordinate VLANs are classified into group VLANs and separate VLANs. Ports in the principal VLAN can communicate with ports in subordinate VLANs. Ports in a subordinate group VLAN can communicate with each other, whereas ports in a subordinate separate VLAN can communicate only with ports in the principal VLAN. The S2720-EI also supports VLAN Central Management Protocol (VCMP) and VLAN-Based Spanning Tree (VBST) protocol.iStack●The S2720-EI supports intelligent stack (iStack). This technology combines multiple switches into a logical switch. Member switches in a stack implement redundancy backup to improve device reliability and use inter-device link aggregation to improve link reliability. iStack provides high network scalability. You can increase ports, bandwidth, and processing capacity of a stack by simply adding member switches to the stack. iStack also simplifies device configuration and management. After a stack is set up, multiple physical switches are virtualized into one logical device. You can log in to any member switch in the stack to manage all the member switches in the stack.Excellent network traffic analysis●The S2720-EI supports the sFlow function. It uses a method defined in the sFlow standard to sample traffic passing through it and sends sampled traffic to the collector in real time. The collected traffic statistics are used to generate statistical reports, helping enterprises maintain their networks.Product SpecificationsFunctions and FeaturesThe following table lists the functions and features available on the S2720-EI.MAC address table 16K MAC address entriesMAC address learning and agingStatic, dynamic, and blackhole MAC address entriesInterface-based MAC learning limitingVLAN 4K active VLANsGuest VLAN and voice VLANGVRPMUX VLANVLAN assignment based on MAC addresses, protocols, IP subnets, policies, and interfaces1:1 and N:1 VLAN mappingEthernet loop protection RRPP ring topology and RRPP multi-instanceSmart Link tree topology and Smart Link multi-instance, providing millisecond-level protectionswitchoverSEPERPS (G.8032)STP (IEEE 802.1d), RSTP (IEEE 802.1w), and MSTP (IEEE 802.1s)Reliability EFM OAM (802.3ah)CFM OAM (802.1ag)ITU-Y.1731DLDPLACPIP routing Static route, RIP, RIPng, OSPFIPv6 Neighbor Discovery (ND)Path MTU (PMTU)IPv6 ping, IPv6 tracert, and IPv6 TelnetMulticast IGMPv1/v2/v3 snoopingControllable multicastInterface-based multicast traffic statisticsMLDv1/v2 snooping (Multicast Listener Discovery snooping)QoS/ACL Rate limiting by an interfaceEight queues on each interfaceWRR, DRR, SP, WRR+SP, and DRR+SP queue scheduling algorithmsRe-marking of the 802.1p priority and DSCP priorityRate limiting in each queue and traffic shaping on interfacesSecurity Port isolation, port security, and sticky MACMFFBlackhole MAC address entriesLimit on the number of learned MAC addressesIEEE 802.1x authentication and limit on the number of users on an interfaceAAA authentication, RADIUS authentication, HWTACACS authentication, and NACSSH V2.0Hypertext Transfer Protocol Secure (HTTPS)CPU defenseBlacklist and whitelistDHCP relay, DHCP server, DHCP snoopingDHCPv6 relay, DHCPv6 server, DHCPv6 snoopingSuper Virtual Fabric (SVF) Working as an SVF client that is plug-and-play with zero configurationAutomatically loading the system software package and patches of clients One-clickand automatic delivery of service configurationsSupports independent running clientManagement and maintenance iStackVirtual Cable Test (VCT)Remote configuration and maintenance using Telnet SNMPv1/v2c/v3RMONeSight and web-based NMSHTTPSLLDP/LLDP-MEDSystem logs and multi-level alarms802.3az EEEInteroperability Supports VBST (Compatible with PVST/PVST+/RPVST)Supports LNP (Similar to DTP)Supports VCMP (Similar to VTP)Hardware SpecificationsThe following table lists the S2720-EI hardware specifications.Memory (RAM) 512 MBFlash memory Hardware 512MB, customer available 240MB Switching capacity 52-Port: 336 Gbps, others: 68 Gbps Forwarding performance ●S2720-12TP-EI: 12.6Mpps●S2720-12TP-PWR-EI: 12.6Mpps●S2720-28TP-PWR-EI-L: 20.4Mpps●S2720-28TP-EI: 20.4Mpps●S2720-28TP-PWR-EI: 20.4Mpps●S2720-52TP-EI: 34.8Mpps●S2720-52TP-PWR-EI: 34.8MppsMean Time Between Failures (MTBF), years ●S2720-12TP-EI: 23.8●S2720-12TP-PWR-EI: 23.8●S2720-28TP-PWR-EI-L: 42●S2720-28TP-EI: 49●S2720-28TP-PWR-EI: 40●S2720-52TP-EI: 31●S2720-52TP-PWR-EI: 38Mean Time To Repair (MTTR), hours 2Availability > 0.99999Surge protection Service port protection Common mode: ±7 kVPower supply port protection ●DC: ±1 kV in differential mode; ±2 kV in common mode●AC: ±6 kV in differential mode; ±6 kV in common mode Dimensions (W x D x H) ●S2720-12TP-EI: 250 mm * 180 mm * 43.6 mm●S2720-12TP-PWR-EI: 320 mm * 220 mm * 43.6 mm●S2720-28TP-PWR-EI: 442 mm * 310 mm * 43.6 mm●S2720-28TP-EI/S2720-28TP-PWR-EI-L: 442 mm * 220 mm *43.6 mm●S2720-52TP-EI: 442 mm * 220 mm * 43.6 mm●S2720-52TP-PWR-EI: 442 mm * 310 mm * 43.6 mmWeight ●S2720-12TP-EI: ≤ 2 kg●S2720-12TP-PWR-EI/ S2720-52TP-EI/ S2720-28TP-EI /S2720-28TP-PWR-EI-L: ≤ 5 kg●S2720-28TP-PWR-EI/ S2720-52TP-PWR-EI: ≤ 6 kgAC input voltage Rated voltage range 100V AC to 240V AC; 50/60 HzMaximum voltage range 90V AC to 264V AC; 47 Hz to 63 HzMaximum power consumption (100% throughput, full speed of fans) ●S2720-12TP-EI: 12.85W●S2720-12TP-PWR-EI: without PD: 15.61W; with PD: 160.5W(PoE: 123.2W)●S2720-28TP-PWR-EI: without PD: 37.8W; with PD: 444.9W(PoE: 370W)●S2720-28TP-EI: 20.1W●S2720-28TP-PWR-EI-L: without PD: 24.8W; with PD: 167W(PoE: 123.2W)●S2720-52TP-EI: 40.3W●S2720-52TP-PWR-EI: without PD: 53.7W; with PD: 435W (PoE:370W)Temperature Operating temperature Operating temperature:●0m to 1,800m: 0°C to 45°C●1,800m to 5,000m (decreases 1°C for every 220m increase inaltitude)Storage temperature -40°C to +70°CNoise under normal temperature (27°C, sound power) ●S2720-12TP-EI: Noise-free (no fans)●S2720-12TP-PWR-EI: Noise-free (no fans)●S2720-28TP-PWR-EI-L: Noise-free (no fans)●S2720-28TP-EI: Noise-free (no fans)●S2720-28TP-PWR-EI: less than 48.6 dBA●S2720-52TP-EI: less than 44.5 dBA●S2720-52TP-PWR-EI: less than 48.3 dBARelative humidity 5%RH to 95%RH, noncondensingOperating altitude 0 m to 5000 mNetworking and ApplicationsThe S2720-EI provides 100M desktop access functions for a high performance network, such as voice VLAN, NAC and so on.Ordering InformationProduct Description1 S2720-12TP-EI (4 × Ethernet 10/100 Base-Tx ports, 4 × Ethernet 10/100/1000 Base-T ports,2 × Gig SFP ports, 2×combo Gig ports, AC 110/220V)2 S2720-12TP-PWR-EI (4 × Ethernet 10/100 Base-Tx ports, 4 × Ethernet 10/100/1000 Base-T ports, 2 × Gig SFPports, 2 ×combo Gig ports,124W PoE AC 110/220V)3 S2720-28TP-PWR-EI (16 × Ethernet 10/100 Base-Tx ports, 8 × Ethernet 10/100/1000 Base-T ports, 2 × Gig SFPports, 2 ×combo Gig ports,370W PoE AC 110/220V)4 S2720-28TP-PWR-EI-L (16 × Ethernet 10/100 Base-Tx ports, 8 × Ethernet 10/100/1000 Base-T ports, 2 × Gig SFPports, 2 ×combo Gig ports, 8 ports PoE+, 124W PoE AC 110/220V)5 S2720-28TP-EI (16 × Ethernet 10/100 Base-Tx ports, 8 × Ethernet 10/100/1000 Base-T ports, 2 × Gig SFP ports, 2×combo Gig ports, AC 110/220V)6 S2720-52TP-EI (32 × Ethernet 10/100 Base-Tx ports, 16 × Ethernet 10/100/1000 Base-T ports, 4 × Gig SFP ports,AC 110/220V)7 S2720-52TP-PWR-EI (32 × Ethernet 10/100 Base-Tx ports, 16 × Ethernet 10/100/1000 Base-T ports, 4 × Gig SFPports, 370W PoE AC 110/220V)More InformationFor more information about Huawei Campus Switches, visit or contact us in the following ways:●Global service hotline: /en/service-hotline●Logging in to the Huawei Enterprise technical support website: /enterprise/●Sending an email to the customer service mailbox: ********************Copyright © Huawei Technologies Co., Ltd. 2018. All rights reserved.No part of this document may be reproduced or transmitted in any form or by any means without prior writtenconsent of Huawei Technologies Co., Ltd.Trademarks and Permissionsand other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.All other trademarks and trade names mentioned in this document are the property of their respective holders.NoticeThe purchased products, services and features are stipulated by the contract made between Huawei and thecustomer. All or part of the products, services and features described in this document may not be within thepurchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, andrecommendations in this document are provided "AS IS" without warranties, guarantees or representations ofany kind, either express or implied.The information in this document is subject to change without notice. Every effort has been made in thepreparation of this document to ensure accuracy of the contents, but all statements, information, andrecommendations in this document do not constitute a warranty of any kind, express or implied. Huawei Technologies Co., Ltd. Address:Huawei Industrial Base Bantian, Longgang Shenzhen 518129 People's Republic of China Website:。
