SURFACE MOUNT SCHOTTKY BARRIER DIODE
Features
·Low Forward Voltage Drop
·Guard Ring Construction for Transient Protection ·Negligible Reverse Recovery Time ·Low Reverse Capacitance
·Ultra-Small Surface Mount Package
·Lead Free By Design/RoHS Compliant (Note 1)·"Green" Device, Note 3 and 4
·Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
Maximum Ratings
@ T A = 25°C unless otherwise specified
MARKING
·Case: SOD-523
·Case Material: Molded Plastic, "Green" Molding Compound, Note 4. UL Flammability Classification Rating 94V-0
·Moisture Sensitivity: Level 1 per J-STD-020C ·Terminal Connections: Cathode Band
·Terminals: Finish - Matte Tin annealed over Alloy 42leadframe.Solderable per MIL-STD-202, Method 208·Marking Code: S4
·Ordering Information: See Last Page ·
Weight: 0.002 grams (approximate)
Thermal Characteristics
@ T A = 25°C unless otherwise specified
Note: 1. No purposefully added lead.
2.Part mounted on FR-4 board with recommended pad layout, which can be found on our website
at /datasheets/ap02001.pdf.
3. Diodes Inc.'s "Green" Policy can be found on our website at /products/lead_free/index.php.
4. Product manufactured with date code 0609 (week 9, 2006) and newer are built with Green Molding Compound. Product manufactured prior to date
code 0609 are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants.
050
25
50
75
100
125
P ,P O W E R D I S S I P A T I O N (m W )
D T ,AMBIENT TEMPERATUR
E (C)
Fig.1Derating Curve
A °100
200
150
0.001
0.01
0.1
1
10
1000
100
200
400
600
800
V ,INSTANTANEOUS FORWARD VOLTAGE (mV)
Fig.2Typical Forward Characteristics
F I ,I N S T A N T A N E O U S F O R W A R D C U R R E N T (m A )
F
110203040
V ,INSTANTANEOUS REVERSE VOLTAGE (V)
Fig.3Typical Reverse Characteristics
R 0.001
0.010.1110100
1000
C ,T O T A L C A P A C I T A N C E (p F )
T V ,REVERSE VOLTAGE (V)
R Fig.4Typ.Total Capacitance vs Reverse Voltage
100
0.1
1.0
10
10
20
30
40
Note: 5. Short duration pulse test used so as to minimize self-heating effect.
Note: 4. Product manufactured with date code 0609 (week 9, 2006) and newer are built with Green Molding Compound. Product manufactured prior to date code 0609 are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants.
6. For Packaging Details, go to our website at /datasheets/ap0200
7.pdf.
