版本自校准通止规规格：2mm（工具自带）Weidmuller订货号KNIPEK 订货号压接范围（mm²）压接范围（AWG）9205430000975265 DG A 0.14-6.0 mm²26#-10#拟制/日期审核/日期核准/日期Weidmuller 9205430000 压线钳使用说明工具名称Weidmuller压线钳工具型号CTIN CM 1.6/2.5（0.14-6.0 mm²）订货号：9205430000文件编号 1.0页数1/1页一、本文件适用于型号为CTIN CM 1.6/2.5的Weidmuller 压线钳。
二、Weidmuller 压线钳(KNIPEK 代工生产)常用功能如下图所示：三、端子压接范围图1 压线钳概览图2 压线钳各功能按钮介绍1.CR2025类型电池盒2.卷缩机锁定螺钉3.接触衬套锁紧螺钉4.压接钳口5.显示屏6.模式按钮(内藏式）7.开/关按钮8.压接钳口开度调整轮9.紧急打开杆10.停止位图3 端子压接剖面图图4 更换电池五、使用注意事项1.工具每次更换电池以后都必须进行自校准并且成功以后才能正常使用；2.调整压接钳口开度夹住通止规自我校准时，不宜用力过大将通止规夹持变形，以拔出通止规稍有阻力为宜；3.不能用通止规当做撬棒使用，以免通止规弯曲变形影响校准精度；4.压线钳是精密仪器，避免敲击或磕碰；5.保持工具干燥，避免接触水或者其他液体，以免影响正常使用。
四、更换电池及校准操作校准操作步骤：①用手轻轻顶住1按钮向上打开电池盒→②移除使用过的纽扣电池→③沿着负号方向转动调整轮8降到较低的设置并留在那儿→④装入新的纽扣电池（此时显示屏5显示CAL 字符）→⑤此时用工具自带的2mm 通止规调整压接钳口开度调整轮8使得钳口刚好夹住通止规（保证通止规被夹住的同时还可以被拔出）→⑥用手按住按钮7的同时用通止规按住按钮6→⑦至少5秒钟以后，首先释放按钮6然后释放按钮7→⑧显示屏5显示数字“2.0mm ”→⑨校验成功。
