IRLR/U2905HEXFET ®Power MOSFETParameterTyp.Max.UnitsR θJC Junction-to-Case––– 1.4R θJA Case-to-Ambient (PCB mount)**–––50°C/WR θJAJunction-to-Ambient–––110Thermal ResistanceDescription12/8/00 1D -P ak T O -252AAI-Pak TO -251AAl Logic-Level Gate Drive l Ultra Low On-Resistance l Surface Mount (IRLR2905)l Straight Lead (IRLU2905)l Advanced Process Technology l Fast SwitchinglFully Avalanche RatedFifth Generation HEXFETs from International Rectifier utilize advanced processing techniques to achieve the lowest possible on-resistance per silicon area. This benefit, combined with the fast switching speed and ruggedized device design that HEXFET Power MOSFETs are well known for,provides the designer with an extremely efficient device for use in a wide variety of applications.The D-PAK is designed for surface mounting using vapor phase, infrared, or wave soldering techniques. The straight lead version (IRFU series) is for through-hole mounting applications. Power dissipation levels up to 1.5 watts are possible in typical surface mount applications.** When mounted on 1" square PCB (FR-4 or G-10 Material ) .For recommended footprint and soldering techniques refer to application note #AN-994ParameterMax.UnitsI D @ T C = 25°C Continuous Drain Current, V GS @ 10V 42 I D @ T C = 100°C Continuous Drain Current, V GS @ 10V 30A I DMPulsed Drain Current 160P D @T C = 25°C Power Dissipation 110W Linear Derating Factor 0.71W/°C V GS Gate-to-Source Voltage± 16V E AS Single Pulse Avalanche Energy 210mJ I AR Avalanche Current25A E AR Repetitive Avalanche Energy 11mJ dv/dt Peak Diode Recovery dv/dt 5.0V/ns T J Operating Junction and-55 to + 175T STGStorage Temperature RangeSoldering Temperature, for 10 seconds300 (1.6mm from case )°CAbsolute Maximum RatingsPD- 91334EIRLR/U2905IRLR/U2905IRLR/U2905IRLR/U2905IRLR/U2905IRLR/U2905IRLR/U2905IRLR/U2905IRLR/U2905。

Features•Ballast control and half-bridge driver in one IC •Programmable preheat frequency •Programmable preheat time •I nternal ignition ramp•Programmable over-current threshold •Programmable run frequencyData Sheet No. PD60182-IBALLAST CONTROL ICCFL Application Diagram•Programmable dead time •DC bus under-voltage reset •Shutdown pin with hysteresis•Internal 15.6V zener clamp diode on Vcc •Micropower startup (150µA)•Latch immunity and ESD protection •Also available LEAD-FREE (PbF)Descriptionboth 14 lead PDIP and 14 lead SOIC packages. 1IR2156(S ) & (PbF)IR2156(S) & (PbF) 2Absolute Maximum RatingsAbsolute maximum ratings indicate sustained limits beyond which damage to the device may occur. All voltage parameters are absolute voltages referenced to COM, all currents are defined positive into any lead. The thermal resistance and power dissipation ratings are measured under board mounted and still air conditions.Note 1:This IC contains a zener clamp structure between the chip V CC and COM which has a nominal breakdown voltage of 15.6V. Please note that this supply pin should not be driven by a DC, low impedance power sourcegreater than the V CLAMP specified in the Electrical Characteristics section.IR2156(S ) & (PbF)3Recommended Operating ConditionsFor proper operation the device should be used within the recommended conditions.Note 2:Enough current should be supplied into the V CC lead to keep the internal 15.6V zener clamp diode on this lead regulating its voltage, V CLAMP .Electrical CharacteristicsV CC = V BS = V BIAS = 14V +/- 0.25V, V VDC = Open, R T = 39.0k Ω, R PH = 100.0k Ω, C T = 470 pF, V CPH = 0.0V, V CS = 0.0V,V SD = 0.0V, C LO, HO = 1000pF , T = 25o C unless otherwise specified.IR2156(S) & (PbF) 4Electrical CharacteristicsV CC = V BS = V BIAS = 14V +/- 0.25V, V VDC = Open, R T = 39.0kΩ, R PH= 100.0kΩ, C T = 470 pF, V CPH = 0.0V, V CS = 0.0V, V SD = 0.0V, C LO, HO = 1000pF, T A = 25o C unless otherwise specified.IR2156(S ) & (PbF)5Block DiagramIR2156(S) & (PbF) 6State DiagramVCC < 9.5V(VCC Fault or Power Down)orSD > 5.1V(Lamp Fault or Lamp Removal)IR2156(S ) & (PbF)7Timing DiagramsNormal operationIR2156(S) & (PbF) 8Timing Diagrams Fault conditionIR2156(S ) & (PbF)9IR2156(S) & (PbF) 10( A分销商库存信息:IRIR2156STRPBF IR2156PBF IR2156SPBF IR2156S IR2156IR2156STR。

Features••15.6V zener clamp on Vcc •True micropower start up•Tighter initial deadtime control••••Lower power level-shifting circuit•••Low side output in phase with R T•••ESD protection on all leads •Also available LEAD-FREE(NOTE:For new designs, we recommendIR’s new product IRS2153D)SELF-OSCILLATING HALF-BRIDGE DRIVERProduct SummaryTypical Connections600V MAXIR2153(D)(S) &(PbF)Descriptionporates a high voltage half-bridge gate driver with a front end oscillator similar to the industry standard CMOS 555 timer. The IR2153 provides more functionality and is easier to use than previous ICs. A shutdown feature has been designed into the C T pin, so that both gate driver outputs can be disabled using a low voltage control signal. In addition, the gate driver output pulse widths are the same once the rising undervoltage lockout threshold on V CC has been reached, resulting in a more stable profile of frequency vs time at startup.Noise immunity has been improved significantly, both by lowering the peak di/dt of the gate drivers, and by increasing the undervoltage lockout hysteresis to 1V. Finally, special attention has been payed to maximizing the latch immunity of the device, and providing comprehensive ESD protection on all pins.8 Lead SOIC Data Sheet No. PD60062 revOIR2153(D)(S) & (PbF)NOTE:For new designs, we recommend IR’s new product IRS2153DNote 1:This IC contains a zener clamp structure between the chip V CC and COM which has a nominal breakdown voltage of 15.6V. Please note that this supply pin should not be driven by a DC, low impedance power source greater than the V CLAMP specified in the Electrical Characteristics section.Note 2:Care should be taken to avoid output switching conditions where the V S node flies inductively below ground by more than 5V.Note 3:Enough current should be supplied to the V CC pin of the IC to keep the internal 15.6V zener diode clamping the voltage at this pin.Recommended Operating ConditionsFor proper operation the device should be used within the recommended conditions.Absolute Maximum RatingsAbsolute maximum ratings indicate sustained limits beyond which damage to the device may occur. All voltage param-eters are absolute voltages referenced to COM, all currents are defined positive into any lead. The thermal resistance and power dissipation ratings are measured under board mounted and still air conditions.IR2153(D)(S) & (PbF)NOTE:For new designs, we recommendIR’s new product IRS2153DSymbol ComponentMin.Max.UnitsR T Timing resistor value 10— k ΩC TC T pin capacitor value330—pFRecommended Component ValuesIR2153(D)(S) & (PbF)NOTE:For new designs, we recommend IR’s new product IRS2153DElectrical CharacteristicsV BIAS (V CC , V BS ) = 12V, C L = 1000 pF, C T = 1 nF and T A = 25°C unless otherwise specified. The V IN , V TH and I IN parameters are referenced to COM. The V O and I O parameters are referenced to COM and are applicable to the respective output leads: HO or LO.IR2153(D)(S) & (PbF)NOTE:For new designs, we recommendIR’s new product IRS2153DSymbolDescriptionV CC Logic and internal gate drive supply voltage R T Oscillator timing resistor input C T Oscillator timing capacitor input COM IC power and signal ground LO Low side gate driver outputV S High voltage floating supply return HO High side gate driver outputV BHigh side gate driver floating supplyLead Definitions8 Lead PDIP 8 Lead SOICIR2153DIR2153(S)NOTE: The IR2153D is offered in 8 lead PDIP only.Electrical Characteristics (cont.)IR2153(D)(S) & (PbF)NOTE:For new designs, we recommendIR’s new product IRS2153DFunctional Block Diagram for IR2153(S) Functional Block Diagram for IR2153DIR2153(D)(S) & (PbF)NOTE:For new designs, we recommend IR’s new product IRS2153DFigure 1. Input/Output Timing DiagramFigure 3. Deadtime Waveform DefinitionsR TTCLAMPR T Figure 2. Switching Time Waveform Definitions(HO)(LO)IR2153(D)(S) & (PbF)NOTE:For new designs, we recommendIR’s new product IRS2153DLEADFREE PART MARKING INFORMATIONORDER INFORMATIONBasic Part (Non-Lead Free)8-Lead PDIP IR2153 order IR21538-Lead SOIC IR2153S order IR2153S 8-Lead PDIP IR2153D order IR2153DLeadfree Part8-Lead PDIP IR2153 order IR2153PbF 8-Lead SOIC IR2153S order IR2153SPbF 8-Lead PDIP IR2153D order IR2153DPbFIR WORLD HEADQUARTERS: 233 Kansas St., El Segundo, California 90245 Tel: (310) 252-7105This product has been qualified per industrial levelData and specifications subject to change without notice. 2/8/2006Per SCOP 200-002分销商库存信息:IRIR2153SPBF IR2153PBF IR2153DPBF IR2153STRPBF IR2153IR2153SIR2153STR IR2153D。
