低压空气断路器电动操作机构使用说明书一、产品概述低压空气断路器电动操作机构是一种用于控制和操作低压空气断路器的装置。
它采用电动机作为动力源，通过传动装置实现对断路器的开合操作。
本文将详细介绍该机构的使用方法和注意事项。
二、安装步骤1. 安装前，请确保断路器和电动操作机构的型号、规格和参数符合要求，并检查其外观是否完好。
2. 将电动操作机构固定在断路器上，确保安装牢固可靠。
3. 连接电源和控制信号线，确保线路正确接入，切勿接反或短路。
三、操作方法1. 开合操作a. 接通电源后，按下“合闸”按钮，电动机开始运行，传动装置带动断路器合闸。
b. 按下“分闸”按钮，电动机反转，传动装置带动断路器分闸。
c. 操作过程中，应观察断路器的指示灯或指示器，确保其状态与实际操作一致。
2. 急停功能a. 在紧急情况下，按下“急停”按钮，电动机立即停止运行，断路器停在当前位置。
b. 使用急停功能后，需排除故障并重新启动设备，确保其正常运行。
四、注意事项1. 操作人员应熟悉本操作机构的使用方法和安全规程，避免操作失误或事故发生。
2. 使用前，请检查电源和控制信号线路是否正常，确保接线可靠，切勿出现接反或短路现象。
3. 操作过程中，应及时观察断路器的状态变化，如发现异常情况应及时停机检查。
4. 维护人员应定期对操作机构进行检查和保养，确保其正常运行和安全可靠。
5. 在操作机构维护时，应切断电源，并采取相应的安全措施，防止意外触电或其他事故发生。
五、故障排除1. 若操作机构无法正常工作，请先检查电源和控制信号线路是否接触良好。
2. 若电源和信号线路正常，但机构仍无法工作，可能是电动机故障，需联系售后服务人员进行维修或更换。
3. 在维修过程中，切勿随意拆卸或更换零部件，以免影响产品性能或引起其他故障。
六、保养与维护1. 定期对操作机构进行清洁，以防尘埃等杂物进入影响正常运行。
2. 定期检查传动装置和连接部位的紧固情况，确保其牢固可靠。
三菱AE 型低压空气断路器ADVANCED AND EVER ADVANCING01AISO 9001NATIONAL ACCREDITATION OF CERTIFICATION BODIESMitsubishi Electric Corporation's Fukuyama Works, which produces these products, is certified as meetingthe ISO 14001 environmental management system standard.随着信息技术的高度发展，人们越来越要求电源进一步提高供电质量、安全性及易操作性。
由于高频电源设备日益普及，智能化大楼中的配电设备日益向小型化、系统化、网络化发展，对电源设备也有了更新的要求。
为了适应社会环境的变化，三菱电机研制了新一代的低压断路器－Super AE 系列。
1的新一代电气断路器更完备 Super这个目录是以有电气专业知识的人为对象的。
产品使用时，请看一下断路器的产品使用说明书。
AE系列s主单元特点34s晶体脱扣器特点（1/2）56s晶体脱扣器特点（2/2）7个人电脑个人电脑监测例AE-SS MDU8框架自动控制电路连接器提钩孔储能手柄伸缩导轨抽出位置显示位置锁位抽出手柄小孔抽出手柄系列固定用螺栓伸缩导轨位置锁位控制电路端子储能手柄自动控制电路连接器抽出手柄小孔抽出位置显示s产品构成s产品规格s产品规格s连接方式s附件（主单元1/2）附件（主单元2/2）s附件（抽出单元）锁板s晶体脱扣器规格表s晶体脱扣器（一般保护用）S 系列s晶体脱扣器（发电机保护用M 系列）s晶体脱扣器（特殊保护用B 系列）s晶体脱扣器附件的最大额定电流（I的漏电只报警不脱扣，因此最适合于需要连续通电的线路。
如果和分励脱扣装置（s晶体脱扣器附件s工作特性（一般保护用）s通过电流最大时间和B 系列脱扣器s接线图（根据EN50005）s外形尺寸图（1/5）s外形尺寸图（2/5）。
（完整版）低压断路器参数及设定断路器是配电系统中主要的保护电器之一，也是功能最完善的保护电器，其主要作用是作为短路、过载、接地故障、失压以及欠电压保护。
根据不同需要，断路器可配备不同的继电器或脱扣器。
脱扣器是断路器总体的一个组成部分，而继电器，则通过与断路器操作机构相连的欠电压脱扣器、分励脱器来控制断路器。
低压断路器一般由脱扣器来完成其保护功能。
标明低压断路器电流特性的参数很多，容易混淆不清。
在设计文件中，常常在标明断路器的电流值时，不说明电流值的意义，给定货造成混乱。
要完整准确的选择断路器，清楚地标定断路器的各个电流参数是必要的。
1 断路器的额定电流参数国标《低压开关设备和控制设备低压断路器》GB14048.2-94(等效采用IEC947-2)对断路器的额定电流使用两个概念，断路器的额定电流1n和断路器壳架等级额定电流1nm，并给出如下定义：——断路器的额定电流1n，是指脱扣器能长期通过的电流，也就是脱扣器额定电流。
对带可调式脱扣器的断路器则为脱扣器可长期通过的最大电流。
——断路器壳架等级额定电流1nm，用基本几何尺寸相同和结构相似的框架或塑料外壳中所装的最大脱扣器额定电流表示。
国标GB14048.2-94中对断路器额定电流的定义与我们通常所说的概念有些不同。
当我们提及“断路器额定电流”这一概念时，通常是指“断路器壳架等级额定电流”而不是“脱扣器额定电流”。
例如当我们选择一只DZ20Y-100/3300-80A型断路器时，通常我们简单地说其额定电流为100A，脱扣器的额定电流为80A。
多数低压断路器供应商所提供的产品资料中，也一般不提“断路器壳架等级额定电流”这一复杂的说法，而只给出“断路器额电流”这一参数，其实就是“断路器额定电流”作为“断路器壳架等级额定电流”的一种简称，似乎较为合适。
也许标准中对额定电流的定义与平时使用的不一致是导致混乱的原因之一。
“断路器壳架等级额定电流”是标明断路器的框架通流能力的参数，主要由主触头的通流能力决定，它也决定了所能安装的脱扣器的最大额定电流值。
