4G通信中的MIMO智能天线技术智能天线通常也称作自适应天线阵列，可以形成特定的天线波束，实现定向发送和接收，主要用于完成空间滤波和定位。
从本质上看，它利用了天线阵列中各单元之间的位置关系，即利用了信号的相位关系克服多址干扰及多径干扰，这是它与传统分集技术的本质区别。
MIMO系统是指在发射端和接收端同时使用多个天线的通信系统，其有效地利用随机衰落和可能存在的多径传播来成倍地提高业务传输速率。
其核心技术是空时信号处理，即利用在空间中分布的多个时间域和空间域结合进行信号处理。
因此，可以被看作是智能天线的扩展。
智能天线系统在移动通信链路的发射端/或接收端带有多根天线，根据信号处理位于通信链路的发射端还是接收端，智能天线技术被定义为多入单出（MISO，MultipleInputSingleOutput）、单入多出（SIMO，Single Input Multiple Output）和多入多出（MIMO，Multiple Input Multiple Output）等几种方式。
二、多入多出智能天线收发机结构及研究进展从图1可以看出，比特流在经过编码、调制和空时处理（波束成行或空时编码）后，映射成不同的信息符号，从多个天线同时发射出去；在接收端用多个天线接收，进行相应解调、解码及空时处理。
图1 多输入多输出智能天线收发机结构MIMO系统中的空时处理技术主要包括波束成形（beamforming）、空时编码（space-timecoding）、空间复用（spacemultiplexing）等。
波束成形是智能天线中的关键技术，通过将主要能量对准期望用户以提高信噪比。
波束成形能有效地抑制共道干扰，其关键是波束成行权值的确定。
1.MIMO系统的发射方案MIMO系统的发射方案主要分为两种类型：最大化数据率的发射方案（空间复用SDM）和最大化分集增益的发射方案（空时编码STC）。
最大化数据率发射方案主要通过在不同天线发射相互独立的信号实现空间复用。
