连续油管钻井水力计算软件开发方案一、软件设计目的此软件定位为一款简单实用的计算软件，使输入数据无需再作任何计算，直接得出结果，并设计对外接口，同时兼顾界面的美观性，以及商业软件的保密性。
二、界面简介此软件分为四个界面，即欢迎登陆界面，工作界面、输出界面和打印界面。
登陆欢迎界面→→（转刀）工作界面。
1、登陆欢迎界面。
欢迎界面画面简介：整体图片式（ps制成），其中有软件名字，连续油管钻井水力系统图片，以及想购买此软件的联系方式。
（此界面按常用软件习惯短暂停留）登陆界面简介：欢迎界面自动转刀登陆界面，此界面中有登陆用户和密码正确，才能进入工作界面。
2、工作界面此界面分为三个部分：输入界面，输出界面，打印确定界面。
（i）输入界面此界面有七个窗口（ii）输出界面此界面有两小部分，第一部分有八个窗体，第二部分六个窗体（iii）打印确定界面此界面用于打印确认输入输出参数。
三、工作部分有哪些功能由于此软件是实际应用软件，得具有通用性，也得考虑人的因素，具体功能初步设计如下：1、有友好的人机交互界面，友好的界面，使使用者有亲切感，以及缓解疲劳。
2、方便直接的输入界面，设计无需鼠标即可方便进行输入，并可以具有自动检错的功能，弹窗口提示错误。
3、有傻瓜式的输出界面，数据输入完，即可完成计算，无需工程人员再进行繁琐的计算，并对结果有一定的纠错能力。
4、通用性方面。
可以从文本中读取数据，并将数据输出到文本，并可进一步形成标本文件，而且可以与打印机连接，实现轻松性。
5、由于不同的工作人员有不同的任务，可以同时使用此软件，登陆界面可以实现多用户登陆，工作完成后，即可为该人员生成标准文本。
6、此软件保留与其他软件交互的接口。
四、软件不足由于本人所学知识有限，可能会导致一些错误以及功能不够强大，界面有待完美等问题会在后续版本中不断的改进。
望大家提出建议与指导。
联系方式：948453545@ 。
流程图 打开软件进入欢迎界面登陆界面时隔两秒输入界面 输出界面 打印界面输入账号密码，正确后进入多个界面 多个界面 输入文本，选择性打印所需文本Development Program on Hydraulic CalculationSoftware of Coiled Tubing DrillingI.Design Goal of the SoftwareThis is a simple and useful calculation software which can directly give the result without doing any calculation of the input data. It is designed with an aesthetic external interface which also has the confidential of business software.II.Screen IntroductionThe software has four screens, that is welcome-and-login screen, working screen, output screen and print screen.Welcome-and-login screen→→ (transfer to) working screen1.Welcome-and-login screenWelcome screen introduction: The whole screen is made up of pictures (using Photoshop).And it contains the software brand, the picture of coiled tubing drilling system and the contact information for purchasing the software. (This screen will stop for seconds as the common software).Login screen introduction: Welcome screen can automatically transfer to login screen. But login screen can’t transfer to working screen without a user’s name and the right code.2.Working screenThis screen is divided into three screens: input screen, output screen and print-and-confirm screen.(i)Input screenThere are 7windows in this screen.(ii)Output screenThis screen is divided into 2 parts. There are 8 forms in the first part and 6 forms in the second part.(iii)Print-and-confirm screenThis screen is used to print and confirm the input and output parameters.III.FunctionsThis is a practical software which should be generic and should apply to humans. So it is designed with the following functions:1.It has a friendly human-computer interface. A friendly interface can make users feelcomfortable and relaxed.2.It has a convenient and direct input screen. People can input information without using themouse. It can also detect errors and pop up a window to prompt the errors.3.It has a very simple output screen. The calculation can be completed as soon as data is inputso engineers don’t need to do complicated calculation any more. And if the result is wrong, the software can correct it.4.It is generic. It can read data from text or output data to text, and then form a sample text. Itcan also connect to a printer so it’s easy for people to print the text.5.Different workers have different tasks but they can use this software at the same time. Loginscreen allows multi-user to log in and after completing tasks the software will generate a standard file for the user.6. It retains the interacting interface with other software.VI. DisadvantagesOwing to my limited knowledge, I may have made some mistakes. And further improvement is called for in subsequent versions, for example, the functions are not enough and the interface needs to be perfect. I hope you can kindly enlighten me with your suggestions and instructions. Email: 948453545@Comment: The central piece of this software is provided by Mr. Guan and students such as XiaZhongwei gave a lot of help and support during the process of making the software.Flow ChartOpen the software Enterwelcome screen Login screenTwo seconds Input screen Output screenPrint screen Input the account and thecode,if right,then enter.Multiple screens Multiple screens Input text, and then print selectivelyNeeded text。
