MPSW55, MPSW56One Watt Amplifier TransistorsPNP SiliconFeatures•Pb−Free Packages are Available*MAXIMUM RATINGSRating Symbol Value UnitCollector−Emitter Voltage MPSW55MPSW56V CEO−60−80VdcCollector−Base Voltage MPSW55MPSW56V CBO−60−80VdcEmitter−Base Voltage V EBO−4.0VdcCollector Current − Continuous I C−500mAdcTotal Device Dissipation @ T A = 25°C Derate above 25°C P D 1.08.0WmW/°CTotal Device Dissipation @ T C = 25°C Derate above 25°C P D 2.520WmW/°COperating and Storage JunctionTemperature RangeT J, T stg−55 to +150°C THERMAL CHARACTERISTICSCharacteristic SymbolMax Unit Thermal Resistance, Junction−to−Ambient R q JA125°C/W Thermal Resistance, Junction−to−Case R q JC50°C/W Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect device reliability.*For additional information on our Pb−Free strategy and soldering details, please download the ON Semiconductor Soldering and Mounting TechniquesReference Manual, SOLDERRM/D.†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our T ape and Reel Packaging Specifications Brochure, BRD8011/D.MPSW56RLRP TO−922000/Ammo Pack MPSW56RLRPG TO−92(Pb−Free)2000/Ammo Pack MPSW55RLRAG TO−92(Pb−Free)2000/T ape & Reel Device Package Shipping†MPSW55G TO−92(Pb−Free)5000 Units/Bulk ORDERING INFORMATIONx= 5 or 6A= Assembly LocationY= YearWW= Work WeekG= Pb−Free Package(Note: Microdot may be in either location)MARKING DIAGRAMMPSW5xAYWW GGCOLLECTOR2EMITTERBENT LEADTAPE & REELAMMO PACKSTRAIGHT LEADBULK PACK−92 1 WATT(TO−226)−10STYLE 1ELECTRICAL CHARACTERISTICS (T A = 25°C unless otherwise noted)CharacteristicSymbolMinMaxUnitOFF CHARACTERISTICSCollector −Emitter Breakdown Voltage (Note 1)(I C = −1.0 mAdc, I B = 0)MPSW55MPSW56V (BR)CEO−60−80−−VdcEmitter −Base Breakdown Voltage(I E = −100 m Adc, I C = 0)V (BR)EBO −4.0−Vdc Collector Cutoff Current(V CE = −40 Vdc, I B = 0)MPSW55(V CE = −60 Vdc, I B = 0)MPSW56I CES−−−0.5−0.5m AdcCollector Cutoff Current(V CB = −40 Vdc, I E = 0)MPSW55(V CB = −60 Vdc, I E = 0)MPSW56I CBO −−−0.1−0.1m AdcEmitter Cutoff Current(V EB = −3.0 Vdc, I C = 0)I EBO −−0.1m AdcON CHARACTERISTICS (1)DC Current Gain(I C = −50 mAdc, V CE = −1.0 Vdc)(I C = −250 mAdc, V CE = −1.0 Vdc)h FE10050−−−Collector −Emitter Saturation Voltage(I C = −250 mAdc, I B = −10 mAdc)V CE(sat)−−0.5Vdc Base −Emitter On Voltage(I C = −250 mAdc, V CE = −5.0 Vdc)V BE(on)−−1.2VdcSMALL −SIGNAL CHARACTERISTICSCurrent −Gain — Bandwidth Product(I C = −250 mAdc, V CE = −5.0 Vdc, f = 20 MHz)f T 50−MHz Output Capacitance(V CB = −10 Vdc, f = 1.0 MHz)C obo−15pF1.Pulse Test: Pulse Width v 300 m s, Duty Cycle v2.0%.Figure 1. DC Current GainI C , COLLECTOR CURRENT (mA)400200100806040h F E , D C C U R R E N T G A I NI B , BASE CURRENT (mA)Figure 2. Collector Saturation Region V C E , C O L L E C T O R -E M I T T E R V O L T A G E (V O L T S )I C , COLLECTOR CURRENT (mA)Figure 3. “On” VoltagesV , V O L T A G E (V O L T S )I C , COLLECTOR CURRENT (mA)Figure 4. Base −Emitter Temperature CoefficientV B , T E M P E R A T U R E C O E F F I C I E N T (m V /C )°θC , C A P A C IT A N C E (p F )Figure 5. CapacitanceV R , REVERSE VOLTAGE (VOLTS)1005.0V CE , COLLECTOR-EMITTER VOLTAGE (VOLTS)I C , C O L L E C T O R C U R R E N T (m A )Figure 6. Current −Gain — Bandwidth ProductI C , COLLECTOR CURRENT (mA)f , C U R R E N T -G A I N — B A N D W I D T H P R O D U C T (M H z )T Figure 7. Active Region — Safe OperatingAreaPACKAGE DIMENSIONSTO −92 (TO −226) 1 WATTCASE 29−10ISSUE OSTYLE 1:PIN 1.EMITTER2.BASE3.COLLECTORNOTES:1.DIMENSIONING AND TOLERANCING PER ANSI Y14.5M, 1994.2.CONTROLLING DIMENSION: INCHES.3.CONTOUR OF PACKAGE BEYOND DIMENSION R IS UNCONTROLLED.4.DIMENSION F APPLIES BETWEEN DIMENSIONS P AND L. DIMENSIONS D AND J APPLY BETWEEN DIMENSIONS L AND K MINIMUM. THE LEADDIMENSIONS ARE UNCONTROLLED IN DIMENSION P AND BEYOND DIMENSION K MINIMUM.SECTION X −XNOTES:1.DIMENSIONING AND TOLERANCING PER ASME Y14.5M, 1994.2.CONTROLLING DIMENSION: INCHES.3.CONTOUR OF PACKAGE BEYOND DIMENSION R IS UNCONTROLLED.4.DIMENSION F APPLIES BETWEEN DIMENSIONS P AND L. DIMENSIONS D AND J APPLY BETWEEN DIMENSIONS L AND K MINIMUM. THE LEADDIMENSIONS ARE UNCONTROLLED IN DIMENSION P AND BEYOND DIMENSION K MINIMUM.SECTION X −XSTRAIGHT LEAD BULK PACKBENT LEAD TAPE & REEL AMMO PACKDIM MIN MAX MIN MAX MILLIMETERSINCHES A 0.1750.205 4.44 5.21B 0.2900.3107.377.87C 0.1250.165 3.18 4.19D 0.0180.0210.460.53F 0.0160.0190.410.48G 0.0450.055 1.15 1.39H 0.0950.105 2.42 2.66J 0.0180.0240.460.61K 0.500---12.70---L 0.250--- 6.35---N 0.0800.105 2.04 2.66P ---0.100--- 2.54R 0.135--- 3.43---V0.135--- 3.43---DIM MIN MAX MIN MAX MILLIMETERSINCHES A 0.1750.205 4.44 5.21B 0.2900.3107.377.87C 0.1250.165 3.18 4.19D 0.0180.0210.460.53G 0.0940.102 2.40 2.80J 0.0180.0240.460.61K 0.500---12.70---N 0.0800.105 2.04 2.66P ---0.100--- 2.54R 0.135--- 3.43---V0.135--- 3.43---ON Semiconductor and are registered trademarks of Semiconductor Components Industries, LLC (SCILLC). SCILLC reserves the right to make changes without further noticeto any products herein. SCILLC makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does SCILLC assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation special, consequential or incidental damages.“Typical” parameters which may be provided in SCILLC data sheets and/or specifications can and do vary in different applications and actual performance may vary over time. All operating parameters, including “Typicals” must be validated for each customer application by customer’s technical experts. SCILLC does not convey any license under its patent rights nor the rights of others. SCILLC products are not designed, intended, or authorized for use as components in systems intended for surgical implant into the body, or other applications intended to support or sustain life, or for any other application in which the failure of the SCILLC product could create a situation where personal injury or death may occur. Should Buyer purchase or use SCILLC products for any such unintended or unauthorized application, Buyer shall indemnify and hold SCILLC and its officers, employees, subsidiaries, affiliates,and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such claim alleges that SCILLC was negligent regarding the design or manufacture of the part. SCILLC is an Equal Opportunity/Affirmative Action Employer. This literature is subject to all applicable copyright laws and is not for resale in any manner.PUBLICATION ORDERING INFORMATION分销商库存信息:ONSEMIMPSW55G MPSW56RLRAG MPSW56RLRPG MPSW55RLRAG MPSW56RLRA。
