迈拓硬盘进入C区教程迈拓硬盘的固件一般都只存放在一个磁头上。

而有几份则要跟据硬盘的型号而定。

早期的硬盘（即６Ｅ之前的）都只有两份，就是所谓的主固件区和次固件区（Ａ区和Ｂ区），存放方式为前边存放一组固件，紧接着后边再存放一组固件，即两组固件。

这两组固件在通常情况下是一致的，如果第一份坏掉了，只要第二份是好的，那么它就会自动选择第二份固件进行工作。

也就是说两份固件中只要有一份是完好的，硬盘就会正常工作。

在６Y即以后的硬盘，厂家的技术更为完善了，两份固件中只要有一份固件是好的，硬盘就会自动的修复另一份固件。

同时也多了一个工作区域，自修复区域即Ｃ区，其作用就是对固件区进行修复，它是一个单独的区域。

因为Ａ区、Ｂ区采用ＵＢＡ线性的寻址方式有一个很大的局限，16bit寻址模式最大范围就是FFFF，32bit寻址模式最大范围就是FFFFFFFF，当装下两份固件以后，剩下的空间就非常少了，也就不能再满足加入第三份固件的空间了。

所以厂家在基本固件区（A区、B区）的后面又开拓了一片区域出来，存放第三份固件，即Ｃ区。

当硬盘具有备用固件区（Ｃ区）时，在通电启动后，ＢＯＯＴ－ＲＯＭ首先会自动读取基本固件区的模块代码文件，并检查它们是否正常。

如果结构不正确或者不能读取，那么就会转向备用固件区（Ｃ区），这个时候硬盘是从Ｃ区启动。

要想硬盘重新回到基本固件区工作就必须修复基本固件区的程序模块。

迈拓C区与日立C区不同，并不能像日立硬盘一样通过备份C 区固件回写A,B区固件来实现对A,B区损坏固件的修复，如果硬盘A,B区固件都损坏了，而我们又找不到匹配的固件来做修复，那么唯一的办法就是通过跳转C区跑校准修复A,B区固件。

迈拓6E大部分盘，6Y以后所有盘都有C区。

下面我们就来看看如何进入C区：首先准备好匹配的C区引导文件，以我们手上这块硬盘为例，具体型号为：Model：6Y080L0, Code：YAR41BWO, SN：Y3Jxxxxx。
