FIXED PARTS DECK AND DECK STANCHIONSD o v e t a i l f o u n d a t i o n d o u b l e t r a n s v e r s a l s i n g l eR a i s ed o u b lc aGeneral Lashing System Co.,LtdFIXED PARTS HOLDF l u s h I S O s o c k e td o u b le t r a n s v e r s a lGeneral Lashing System Co.,LtdLOOSE PARTS HOLDM i d l o c kGeneral Lashing System Co.,LtdLOOSE PARTS HOLDB r i d g e f i t t i n g sH a n g i n g s t a c k e r sGeneral Lashing System Co.,LtdFLUSH ISO FOUNDATIONS 埋入式底座General Lashing System Co.,LtdTYPE H T D AA-A1 AA-A2 AA-A3 AA-A4110 105 9828 18 16205 180SpecificationWeldable shop primerStandard distances 203/216/258 mmMin. breaking loads tension 500 KN / shear 420 KN Standard height 110mmAll item are approved by major classification societies Centre marking for easy installationRAISED STOWAGE PLATES 带孔底板Application SpecificationWeldable shop primerStandard distances 203/216/258 mmMin. breaking loads shear 420 KNAll item are approved by major classification societiesCentre marking for easy installationGeneral Lashing System Co.,LtdRAISED ISO FOUNDATIONS 立式底座SpecificationWeldable shop primerStandard distances 203/216/258 mmMin. breaking loads tension 500 KN / shear 420 KNOther dimensions on requestAll item are approved by major classification societiesCentre marking for easy installationGeneral Lashing System Co.,LtdRAISED ISO FOUNDATION 立式底座SpecificationWeldable shop primerStandard distances 203/216/258 mmMin. breaking loads tension 500 KN / shear 420 KNMade of casting steelAll item are approved by major classification societiesCentre marking for easy installationGeneral Lashing System Co.,LtdDOVETAIL PLATES 燕尾底板Weldable shop primerStandard distances 203/216/258 mmMin. breaking loads tension 500 KN / shear 420 KNAll item are approved by major classification societiesCentre marking for easy installationGeneral Lashing System Co.,LtdWELDABLE CONES 可焊接锥SpecificationWeldable shop primerMin. breaking load shear 420 KNAll item are approved by major classification societiesCentre marking for easy installationWelding chamfer all aroundGeneral Lashing System Co.,LtdGUIDE FITTINGS 导座SpecificationWeldable shop primerMin. breaking loads shear 420 KNOther dimensions on requestAll item are approved by major classification societiesGeneral Lashing System Co.,LtdD-RINGS D 型环AL-A1 (MBL: 500KN)AL-C1 (MBL: 360KN)Welding recommendationGeneral Lashing System Co.,LtdSpecificationClamp weldable shop primer D-ring hot dip galvanisedAll item are approved by major classification societiesGLSLASHING PLATES 眼板Typical arrangement of lashing platesfor double cross lashing systems SpecificationWeldable shop primerMin. breaking loads tension 500 KNOther dimensions materials and finishes on requestAll item are approved by major classification societiesCentre marking for easy installationGeneral Lashing System Co.,LtdLASHING POT 窝座TYPE: AL-M1General Lashing System Co.,LtdSpecificationWeldable shop primerMin. breaking loads tension 360 KNAll item are approved by major classification societies Centre marking for easy installationi o n AL-J1D-RINGS D 型环SpecificationClamp weldable shop primer D-ring hot dip galvanised Min. breaking loads 500 KNAll item are approved by major classification societiesGeneral Lashing System Co.,LtdGLSD-RINGS D 型座AL-H1SpecificationClamp weldable shop primer D-ring hot dip galvanised Min. breaking loads tension 360 KNAll item are approved by major classification societiesGeneral Lashing System Co.,LtdTURNBUCKLES 开式花篮螺丝TYPE: BA-A1Turnbuckles Spanner SpecificationHot dip galvanisedMin. breaking loads tension 500 KNAll item are approved by major classification societiesStand distances MIN 920~~MAX 1400mmGeneral Lashing System Co.,LtdTURNBUCKLE 节杆花篮螺丝TYPE: BA-K1Standard distancesMin: 1080mm Max:1490mmApplicationSpecificationHot dip galvanisedMin. breaking loads tension 500 KNAll item are approved by major classification societiesGeneral Lashing System Co.,LtdTURNBUCKLES 闭式花篮螺丝TYPE: BA-D1Jaw/HookJ/JH/HSpecificationHot dip galvanisedMin. breaking loads tension 500 KNAll item are approved by major classification societiesStand distances MIN 890~~MAX 1360mmGeneral Lashing System Co.,LtdLASHING RODS 拉杆BB-B1 BB-C1 BB-F1SpecificationMade of high tensile steelHot dip galvanisedMin. breaking loads tension 500 KN Other dimensions on requestAll item are approved by major classification societiesApplicationGeneral Lashing System Co.,LtdEXTENSION RODS 接长杆Standard distances 550mmStandard distances 310mmL=260--550L=310--600BB-D1 BB-E1SpecificationHot dip galvanisedMin. breaking loads tension 500 KNOther dimensions materials and finishes on request All item are approved by major classification societiesGeneral Lashing System Co.,LtdSINGLE STACKING CONES 单锥BC-A2 BC-A3 BC-B3General Lashing System Co.,LtdSpecificationHot dip galvanisedMin. breaking loads shear 420 KN Compression up to 1200 KNAll item are approved by major classification societiesDOUBLE STACKING CONES 双锥L = 203/216/258Hot dip galvanisedMin. breaking loads shear 420 KN / Compression up to 1200 KNOther dimensions and finishes on requestAll item are approved by major classification societiesGeneral Lashing System Co.,LtdGLSLOCKABLE STACKING CONES 安全单锥SpecificationHot dip galvanisedMin. breaking loads shear 420 KNCompression up to 1200KNAll item are approved by major classification societiesGeneral Lashing System Co.,LtdTWISTLOCKS 扭锁BD-A2BD-B1BD-C1General Lashing System Co.,LtdSEMI-AUTOMATIC TWISTLOCKS 半自动扭锁BD-J1Cone marked yellowBD-J1BD-J1General Lashing System Co.,LtdSpecificationHot dip galvanisedMin. breaking loads tension 500 KN / shear 420 KNMIDLOCKS 中锁Marked redTYPE: BD-K2General Lashing System Co.,LtdSpecificationHot dip galvanisedMin. breaking loads tension 500 KN / shear 420 KN All item are approved by major classification societiesApplicationDOVETAIL TWISTLOCKS 燕尾底锁General Lashing System Co.,LtdSpecificationHot dip galvanisedMin. breaking loads tension 500 KN / shear 420 KN Compression up to 1200 KNAll item are approved by major classification societiesR LBD-D1/BD-D2/R L45 °Standard45 °Pint-sizeDOVETAIL TWISTLOCKS 燕尾底锁RLBD-E1/55° StandardGeneral Lashing System Co.,LtdBD-E2/RLLine loadSpecificationHot dip galvanisedMin. breaking loads tension 500 KN / shear 420 KNCompression up to 1200 KNAll item are approved by major classification societiesB D-EDOVETAIL TWISTLOCKS 燕尾底锁General Lashing System Co.,LtdBD-F1/BD-G1/R LR L55° transversal45° transversalSpecificationHot dip galvanisedMin. breaking loads tension 500 KN / shear 420 KN Compression up to 1200 KNAll item are approved by major classification societiesDOVETAIL TWISTLOCKS 燕尾底锁R LBD-H1/Breech-Twistlock BD-L1/R LSide-TwistlockGeneral Lashing System Co.,LtdSpecificationHot dip galvanisedMin. breaking loads tension 500 KN / shear 420 KN All item are approved by major classification societiesBRIDGE FITTINGS 桥锁BE-A1General Lashing System Co.,LtdHot dip galvanisedOther dimensions materials and finishes on request All item are approved by major classification societiesPRESSURE ELEMENTS 支撑General Lashing System Co.,LtdApplicationSpecificationMin breaking tension load 850 KN Finish paintedAll item are approved by major classification societiesRO-RO 滚装船CRINKLE BARD-RINGTYPE: CA-A1TYPE:CA-B1Min breaking loads 200 KN Min breaking loads 100 KN and 200 KNFLUSH POT WEB LASHING TYPE:CA-C1TYPE:CA-D1Min breaking loads 50 KNSpecificationAll item are approved by major classification societiesGeneral Lashing System Co.,LtdLASHPOTS 十字底座TYPE: CA-E1TYPE: CA-F1SpecificationWeldable shop primerMin. breaking loads tension 200 KNAll item are approved by major classification societiesGeneral Lashing System Co.,LtdFLUSH LASHPOTS 多用途底座SpecificationWeldable shop primerMin. breaking loads tension 500 KN / shear 420 KNStandard distances for double foundations 203/216/258Other dimensions materials and finishes on requestAll item are approved by major classification societiesGeneral Lashing System Co.,LtdGLSTENSION LEVERS / LASHING CHAINS CB-B1ChainsCB-C1The length of chain according to customs requirementExamples for arrangement of guide fittingsGeneral Lashing System Co.,LtdCB-D1 CB-D2 CB-D3With arbitrarySpecificationWeldable shop primerMin. breaking loads tension 200 KNAll item are approved by major classification societiesLASHING TURNBUCKLES 花篮螺丝TYPE: CE-A1Hot dip galvanisedMin. breaking loads 200 KNAll item are approved by major classification societiesGeneral Lashing System Co.,LtdLASHING TURNBUCKLE 花篮螺丝TYPE ： C E -B1Effective distance L=415~565General Lashing System Co.,LtdSpecificationHot dip galvanised Min. breaking loads 200 KNAll item are approved by major classification societiesSPEED LASH 快速连接器 TYPE: CE-A1SpecificationHot dip galvanisedMin. breaking loads 200 KNAll item are approved by major classification societiesGeneral Lashing System Co.,LtdTRAILER HORSES 托车托架General Lashing System Co.,LtdSpecificationMin. breaking loads 800 KN Weight-controlled rolling gearAll item are approved by major classification societiesTYPE: CF-A1 Weight 130 kgTRAILER JACKSTYPE: CF-B1SpecificationMin loads 800 KNWeight-controlled rolling gearAll item are approved by major classification societiesGeneral Lashing System Co.,LtdWHEEL CHOCKSCAR CHOCKS TYPE: CH-A1 TRAILER CHOCKS TYPE: CH-B1 Weight: 1.2 KG Weight: 5.2 KGSpecificationMade of long life rubberOther dimensions on requestGeneral Lashing System Co.,LtdOPERATING RODS 开锁杆 FOR SEMI-AUTOMATIC TWISTLOCKSDA-A2L=4.0ML=6.0MSpecificationMade of AluminiumOther lengths on requestGeneral Lashing System Co.,LtdSTORAGE BIN / BIN RACKS STORAGE BINSTYPE: DA-B1SpecificationStorage bins with hot dip galvanized / Flat racks with finish paintMain dimensions and strength in accordance with iso-normsFlat racks with CSC certificateOther dimensions and finishes upon requestGeneral Lashing System Co.,LtdLIFTING FOUNDATIONS 起吊底座 T Y P E:D B-A1SpecificationWeldable shop primerMin breaking loads tension 500KNOther dimensions materials and finishes upon requestGeneral Lashing System Co.,LtdSPREADER AND LIFTING GEARHot dip galvanizedMain dimensions and strength in accordance with iso-normsAll item are approved by major classification societiesMin breaking load 600 knGeneral Lashing System Co.,LtdCONTAINER CORNER 集装箱角件 Bottom corner fittingTYPE: DD-A2General Lashing System Co.,LtdCONTAINER DIMENSIONSBell Lines I SO-Container43'(13103mm) 40' ISO (12192mm)(12192mm) 35' /30' ISO24'(Matson) (7430mm)2*20'(2*6058mm)8'6''(2591mm)(2600mm)(2600mm)8'6''(2591mm)8'(2438mm)8'(2438mm)8'(2438mm)(2500mm)/(2500MM)8'(2438mm)/(2438mm)8' od.8'6''(2438mm)od(2591)8'(2438mm)9'6 1/2''9'6''(2896mm)9'6''(2896mm)9'6''9'6 1/2''8' 9'8'6'' 9'6''8'6''8'6''8'6''8'9'6''9'6'' 1/2''9'6''9'6''8'6''9'6''53'(16150mm)49'(14935mm)24 1/2'(2*7442mm)48'(14630mm)45'(13720mm)General Lashing System Co.,Ltd。
![集装箱尺寸规格表[参考]](https://img.taocdn.com/s1/m/0f23c098ac51f01dc281e53a580216fc700a53d7.png)
集装箱尺寸规格表[参考] 集装箱尺寸规格表是一个重要的参考工具，它提供了不同类型集装箱的外部尺寸和内部尺寸。
这些尺寸是确定集装箱能否顺利装载和运输的关键因素。
下面是一个常见的集装箱尺寸规格表：
尺寸仅供参考，实际尺寸可能因具体的设计和制造标准而略有差异。
在使用集装箱时，请务必参考制造商提供的技术规格和尺寸表。
除了以上常见的集装箱尺寸，还有一些其他类型的集装箱，包括框架集装箱、开顶集装箱、冷藏集装箱等。
这些类型的集装箱具有不同的尺寸和特点，以满足特定运输和装载需求。
框架集装箱是一种没有顶盖和侧壁的集装箱，通常用于装载大型、重型货物，如机器、建筑设备等。
开顶集装箱是一种顶部可开启的集装箱，通常用于装载大型
货物或需要从顶部装载和卸载货物的场合。
冷藏集装箱是一种专门用于冷藏货物运输的集装箱，具有制冷设备，以确保货物在运输过程中保持适当的温度。
在使用不同类型的集装箱时，务必根据货物的性质、尺寸和运输需求选择合适的集装箱类型。
同时，还需要考虑运输线路、交通规则和限制等因素，以确保集装箱能够顺利运输并达到目的地。
国际上通常使用的干货柜(DRYCONTAINER)有：
外尺寸为20英尺*8英尺*8英尺6吋，简称20尺货柜；
外尺寸为40英尺*8英尺*8英尺6吋，简称40尺货柜；
外尺寸为40英尺*8英尺*9英尺6吋，简称40尺高柜。
20尺柜：内容积为5.69M * 2.13M *2.18M，配货毛重一般为17.5吨，体积为24-26m3; 12.12m2.
20尺柜：外尺寸为6.096M * 2.4384M *2.5908M
40尺柜：内容积为11.8M * 2.13M * 2.18M，配货毛重一般为22吨，体积为54 m3; 25.134m2.
40尺柜：外尺寸为12.192M * 2.4384M *2.5908M
40尺高柜：内容积为11.8M * 2.13M * 2.72M，配货毛重一般为22吨，体积为68 m3; 25.134m2.
40尺高柜：外尺寸为12.192M * 2.4384M *2.8956M
45尺高柜：内容积为13.58M * 2.34M * 2.71M，配货毛重一般为25吨，体积为86 m3; 31.7772m2.
集装箱车尺寸及规格参数表如以下几种
1.杂货集装箱参数表参数
2.敞顶集装箱参数表
3.硬顶集装箱参数表
4.板架集装箱参数表
5.冷冻型集装箱参数表
6.干散货集装箱参数表
7.通风集装箱参数表
8.罐状集装箱参数表。
国际标准集装箱规格尺寸表
国际标准集装箱规格尺寸表如下：
尺寸内部尺寸外部尺寸门口尺寸容积最大重量
20英尺集装箱 5.9米长x 2.35米宽x 2.39米高 6.06米长x 2.44米宽x 2.59米高 2.34米宽x 2.28米高33.2立方米24,000公斤
40英尺集装箱12.03米长x 2.35米宽x 2.39米高12.19米长x 2.44米宽x 2.59米高 2.34米宽x 2.28米高67.7立方米30,480公斤
40英尺高柜集装箱12.03米长x 2.35米宽x 2.69米高12.19米长x 2.44米宽x 2.89米高 2.34米宽x 2.58米高76.4立方米30,480公斤45英尺高柜集装箱13.56米长x 2.35米宽x 2.69米高13.72米长x 2.44米宽x 2.89米高 2.34米宽x 2.58米高86立方米30,480公斤
说明：内部尺寸是指集装箱内部的净空间尺寸，外部尺寸是指集装箱外部的整体尺寸，门口尺寸是指集装箱的门的开口尺寸。
容积是指集装箱能够装载的货物总体积，最大重量是指集装箱能够承受的最大重量。
20尺箱(普通箱):内部尺寸: 5.900*2.350*2.393 (米)门宽：2.342米;门高：2.280米容积: 33.200 立方米自重: 2.230 吨 ;载重: 21.770 吨 ;总重: 24.000 吨20尺箱(加重箱):内部尺寸: 5.900*2.311*2.390 (米)门宽：2.286米;门高：2.280米容积: 33.230立方米自重: 2.300 吨 ;载重: 28.180 吨 ;总重: 30.480 吨40GP箱内部尺寸: 12.036*2.350*2.392 (米)门宽：2.340米;门高：2.280米容积: 67.700 立方米自重: 3.700 吨 ;载重: 26.780 吨 ;总重: 30.480 吨40HC箱内部尺寸: 12.036*2.350*2.697 (米)门宽：2.338米;门高：2.585米; 容积: 76.300 立方米自重: 3.970 吨 ;载重: 26.510 吨 ;总重: 30.480 吨以上是集装箱的实际规格，国际铁路联运装箱时必须注意：1. 20尺普柜装载限重为：21.5吨，柜重加货重不超过24.00吨;2. 40尺装载限重为：25.5吨，柜重加货重不超过29.00吨;3.选用海运加重箱，铁路要加收加重费。
Dry / Steel Door openings (mm) Internal dimensions (mm) Weight (kg) Volume (m3)Type Size Width Height Length Width Height toload lineMax.GrossTareMax.PayloadCapacityto load line20" std 20' x 8' x 8' 6" 2,340 2,274 5,896 2,350 2,385 27,000 2,150 24,850 33 40" std 40' x 8' x 8' 6" 2,339 2,274 12,035 2,350 2,393 32,500 3,700 28,800 67 40" high 40' x 8' x 9' 6" 2,340 2,577 12,035 2,350 2,697 34,000 3,800 30,200 76 45" high 45' x 8' x 9' 6" 2,340 2,585 13,556 2,352 2,697 32,500 4,800 27,820 86。
全）集装箱尺寸、箱型及代码对照表（收藏20GP、40GP和40HQ是三种最常用的集装箱1）20GP的尺寸为：长20英尺X宽8英尺X高8.5英尺，简称20尺普柜。
2）40GP的尺寸为：长40英尺X宽8英尺X高8.5英尺，简称40尺普柜。
3）40HQ的尺寸为：长40英尺X宽8英尺X高9.5英尺，简称40尺高柜。
长度单位换算方法：1英寸=2.54cm1英尺=12英寸=12*2.54=30.48cm集装箱的长宽高计算：1）宽度：8英尺=8*30.48cm=2.438米2）普柜高度：8英尺6英寸=8.5英尺=8.5*30.48cm=2.59米3）高柜高度：9英尺6英寸=9.5英尺=9.5*30.48cm=2.89米4）小柜长度：20英尺=20*30.48cm=6.096米5）大柜长度：40英尺=40*30.48cm=12.192米集装箱的箱体体积计算：1）20GP的体积=长*宽*高=6.096*2.438*2.59米≈38.5CBM，实际可装货物约30m32）40GP的体积=长*宽*高=12.192*2.438*2.59米≈77CBM，实际可装货物约65m33）40HQ的体积=长*宽*高=12.192*2.438*2.89米≈86CBM，实际可装货物约75m345HQ的尺寸和体积又是多少？长=45英尺=45*30.48cm=13.716米宽=8英尺=8*30.48cm=2.438米高=9英尺6英寸=9.5英尺=9.5*30.48cm=2.89米45HQ的箱体体积=长*宽*高=13.716*2.438*2.89≈96CBM，实际可装货物约85m38 种常见的集装箱及代码1）干货箱：箱型代码GP；95码22G12）干货高箱：箱型代码GH（HC/HQ）；95码25G13）挂衣箱：箱型代码HT；95码22V14）开顶箱：箱型代码OT；95码22U15）冷冻箱：箱型代码RF；95码22R16）冷高箱：箱型代码RH；95码25R17）油罐箱：箱型代码TK；95码22T18）框架箱：箱型代码FR；95码22P1明细如下▼仔细观察一下上表，发现“规律”了吗？1）箱型代码第一个字母为“G”的，都是普通集装箱（普通箱和挂衣箱、冷冻箱、框架箱等特种箱相对），因为G就是General，表示普通的、一般的、通用的2）箱型代码第二个字母为“H”的，都高箱，因为H就是High，表示高的3）95码第一位数字为2 的是20英尺，开头为4的是40英尺，开头为L的是45英尺4）95码第二位数字为2的非高箱（8.5英尺高）；为5的为高箱（9.5英尺高）——这个要特别注意：5 并不代表45英尺，如40HQ的95代码为45G1，这个极易让人误以为是45HQ的柜子，其实45G1指的是40HQ（如下图）▼对了，95码是啥意思？95码就是联合国UN/ISO标准代码库里面所提供的95版本的数字-字符型代码版权声明：本文为国际货代精英原创，欢迎分享，无须授权即可转载。
附录 A（规范性附录）集装箱栓固转锁的功能，尺寸，强度要求和试验A.1 总则转锁用于集装箱定位和固定：——箱垛内集装箱彼此间（通过对集装箱角件的作用）；——或与运输工具（通过对集装箱底角件与车辆栓固底座的作用）。
转锁也可用于连接并起吊集装箱。
起吊用的转锁应经过专门检验。
A.2 栓固转锁的形式和说明A.2.1 手动转锁A.2.1.1 具有固定底部、单锁、双位置的手动转锁一种具有固定底部的手动转锁，其构成如下：——一个能相对于固定底部转动的有锁眼的顶锥；——一个中间板，如有设置，其具有轴环和固定底部；——一个安装在轴上其柄尾向上的手柄，它能在水平面内转动，有两个止位点，一端为全锁，另一端为全解（见图A.1）。
a) 全解位置b) 全锁位置说明：1 ——解锁；2 ——闭锁。
图A.1 具有固定底部、单锁、双位置的手动转锁A.2.1.2 具有双锁、三位置的手动转锁一种具有双锁、三位置手动转锁，其构成如下：——一个有锁眼的顶锥和一个底锥，由轴刚性连成一体；——一个有轴环的中间板；——一个安装在轴上其柄尾向上的手柄，它能在水平面内转动，并有下列三个位置（见图A.2）：32GB/T 17382–201X/ISO3874:2017∙位置一：顶锥插入吊起的集装箱且拨到闭锁位置，底锥位于解锁位置使其能与底层一集装箱接合；∙位置二：底锥插入底层一集装箱的顶角件且拨到闭锁位置，顶锥全解，承接所装载的集装箱底角件置于底层集装箱顶部；∙位置三：在底层集装箱顶角件内的底锥位于闭锁位置，上面集装箱底角件内的顶锥位于闭锁位置。
a) 位置一 b) 位置二 c) 位置三说明：1 ——解锁；2 ——闭锁。
图A.2 具有双锁、三位置的手动转锁A.2.2 半自动转锁半自动转锁既可以是单功能的，也可以是双功能的，其组成如下：——一个有方向指示的顶锥和一个底锥，两者由机械装置刚性连成一体；——一个有轴环的中间板；——一个无论在集装箱放在转锁上时（见图A.3）或把转锁的底锥插入集装箱顶角件时（见图A.4）均可使锥体自动闭合的内部机械装置；——一个用于解锁的装置。
