第十章 质心运动定理与动量定理思 考 题10-1 分析下列陈述是否正确：（１） 动量是一个瞬时的量，相应地，冲量也是一个瞬时的量。

（２） 将质量为m 的小球以速度向上抛，小球回落到地面时的速度为。

因与的大小相等，所以动量也相等。

　1v 2v 1v 2v （３） 力F 在直角坐标轴上的投影为、、，作用时间从t ＝０到t ＝t x F y F z F １，其冲量的投影应是111,,t F I t F I t F I z z y y x x ===。

（４） 一物体受到大小为10 N 的常力F 作用，在t ＝3 s 的瞬时，该力的冲量的大小I = Ft = 30 N ·s。

10-2 当质点系中每一质点都作高速运动时，该系统的动量是否一定很大？为什么? 10-3 炮弹在空中飞行时，若不计空气阻力，则质心的轨迹为一抛物线。

炮弹在空中爆炸后，其质心轨迹是否改变?又当部分弹片落地后，其质心轨迹是否改变?为什么?10-4 质量为的楔块A 放在光滑水平面上。

质量为的杆BC 可沿铅直槽运动，其一端放在楔块A 上。

在思考题10-４附图所示瞬时，楔块的速度为，加速度为，求此时系统质心的速度及加速度。

1m 2m A v Aa思考题10-4附图 思考题10-5附图 10-5 质点系由三个质量均为m 的质点组成。

在初瞬时，这三个质点位于思考题10-5 附 0t 图所示位置，并分别具有初速度。

已知CO BO AO v v v ,,,235.1,200k j i v k v ++==B A i v 30=C 。

试 求此时质点系质心的位置及速度。

长度单位为m ，时间单位为s 。

6-6 试求思考题10-6附图所示各均质物体的动量，设各物体质量均为m 。

思考题10-6附图10-7 两个半径和质量相同的均质圆盘A,B ，放在光滑的水平面上，分别受到力 的作用，如思考题10-7附图所示，且B A F F ,B A F F =。

设两圆盘受力后自静止开始运动，在某一瞬时两圆盘的动量分别为。
