The mark <R> shows major revised points.The revised points can be easily searched by copying an "<R>" in the PDF file and specifying it in the "Find what:" field.Solid State RelayOCMOS FETPS7200H-1A4-PIN SOP, 2.2 Ω LOW ON-STATE RESISTANCE1-ch Optical Coupled MOS FETDocument No. PN10294EJ02V0DS (2nd edition) Date Published August 2006 NS CP(K)−NEPOC Series −1998, 2006DESCRIPTIONThe PS7200H-1A is a low on-state capacitance solid state relay containing a GaAs LED on the light emitting side (input side) and MOS FETs on the output side.It is suitable for high-frequency signal control, due to its low C × R, low on-state resistance, and low off-state leakage current.FEATURES• Low C × R (C × R = 9.2 pF • Ω)• Low on-state resistance (R on = 2.2 Ω TYP.) • Low output capacitance (C out = 4.2 pF TYP.) • Low off-state leakage current (I Loff = 0.03 nA TYP.) • High-speed turn-on time (t on = 0.04 ms TYP.) • 1 channel type (1 a output)• Designed for AC/DC switching line changer• Small and thin package (4-pin SOP, Height = 2.1 mm) • High isolation voltage (BV = 1 500 Vr.m.s.) • Low offset voltage• Ordering number of taping product : PS7200H-1A-E3, E4: 900 pcs/reel: PS7200H-1A-F3, F4: 3 500 pcs/reel• Pb-Free productAPPLICATIONS• Measurement equipment<R>Data Sheet PN10294EJ02V0DS2PACKAGE DIMENSIONS (UNIT: mm)MARKING EXAMPLE (LASER MARKING)<R><R>ORDERING INFORMATIONPacking StylePart Number Order Number Solder PlatingSpecificationPS7200H-1A PS7200H-1A-A Pb-Free Magazine case 100 pcsPS7200H-1A-E3 PS7200H-1A-E3-A Embossed Tape 900 pcs/reelPS7200H-1A-E4 PS7200H-1A-E4-APS7200H-1A-F3 PS7200H-1A-F3-A Embossed Tape 3 500 pcs/reelPS7200H-1A-F4 PS7200H-1A-F4-AABSOLUTE MAXIMUM RATINGS (T A = 25°C, unless otherwise specified)Ratings UnitParameter SymbolDiode Forward Current (DC) I F 50 mAVoltage V R 5.0 VReverseDissipation P D 50 mWPowerPeak Forward Current*1I FP 1 AMOS FET Break Down Voltage V L 40 VContinuous Load Current I L 160 mAI LP 320 mAPulse Load Current*2(AC/DC Connection)PowerDissipation P D 100 mW500Vr.m.s.1Isolation Voltage*3 BVTotal Power Dissipation P T 150 mWOperating Ambient Temperature T A−40 to +85 °CStorage Temperature T stg−40 to +100 °C*1PW = 100 µs, Duty Cycle = 1%*2PW = 100 ms, 1 shot*3AC voltage for 1 minute at T A = 25°C, RH = 60% between input and outputPins 1-2 shorted together, 3-4 shorted together.Data Sheet PN10294EJ02V0DS 3Data Sheet PN10294EJ02V0DS4RECOMMENDED OPERATING CONDITIONS (T A = 25°C)Parameter Symbol MIN. TYP. MAX. UnitLED Operating Current I F 2 10 20 mA LED Off VoltageV F 0 0.5 VELECTRICAL CHARACTERISTICS (T A = 25°C)Parameter Symbol Conditions MIN. TYP. MAX. UnitDiode Forward VoltageV FI F = 10 mA 1.2 1.4 VReverseCurrent I R V R = 5 V 5.0 µAMOS FET Off-state Leakage CurrentI LoffV D = 40 V0.03 10 nA Output Capacitance C out V D = 0 V, f = 1 MHz 4.2 pF CoupledLED On-state CurrentI FonI L = 160 mA2.0 mA On-state Resistance R on1 I F = 10 mA, I L = 50 mA2.23.5 ΩR on2 I F = 10 mA, I L = 160 mA, t ≤ 10 ms2.23.5Turn-on Time *1, 2 t onI F = 10 mA, V O = 5 V, R L = 500 Ω, 0.04 0.5 msTurn-off Time *1, 2t off PW ≥ 10 ms0.25 1.0 Isolation Resistance R I-O V I-O = 1.0 kV DC 109Ω Isolation Capacitance C I-OV = 0 V, f = 1 MHz0.4pF*1 Test Circuit for Switching TimePulse InputInput monitormonitorV O V LI F*2 The turn-on time and turn-off time are specified as input-pulse width ≥ 10 ms.Be aware that when the device operates with an input-pulse width less than 10 ms, the turn-on time and turn-off time will increase.Data Sheet PN10294EJ02V0DS5TYPICAL CHARACTERISTICS (T A = 25°C, unless otherwise specified)Ambient Temperature T A (˚C)M a x i m u m F o r w a r d C u r r e n t I F (m A )MAXIMUM FORWARD CURRENT vs.AMBIENT TEMPERATUREAmbient Temperature T A (˚C)F o r w a r d V o l t a g e V F (V )AMBIENT TEMPERATUREFORWARD VOLTAGE vs.Applied Voltage V D (V)O u t p u t C a p a c i t a n c e C o u t (p F )OUTPUT CAPACITANCE vs.APPLIED VOLTAGEAmbient Temperature T A (˚C)M a x i m u m L o a d C u r r e n t I L (m A )MAXIMUM LOAD CURRENT vs.AMBIENT TEMPERATUREAmbient Temperature T A (˚C)O f f -s t a t e L e a k a g e C u r r e n t I L o f f (A )OFF-STATE LEAKAGE CURRENT vs.AMBIENT TEMPERATURELOAD CURRENT vs. LOAD VOLTAGELoad Voltage V L (V)L o a d C u r r e n t I L (m A )–250255075100100806040020 f = 1 MHz1020304060501086402300200100025015050–25025*******2040608010010–710–810–910–1010–1110–1210–13V D = 40 VRemark The graphs indicate nominal characteristics.Data Sheet PN10294EJ02V0DS6Forward Current I F (mA)Turn-on Time t on (ms)N u m b e r (p c s )TURN-ON TIME DISTRIBUTIONForward Current I F (mA)T u r n -o n T i m e t o n (m s )Turn-off Time t off (ms)N u m b e r (p c s )TURN-OFF TIME DISTRIBUTIONN o r m a l i z e d O n -s t a t e R e s i s t a n c e R o nNORMALIZED ON-STATE RESISTANCE vs.AMBIENT TEMPERATUREON-STATE RESISTANCE DISTRIBUTIONRemark The graphs indicate nominal characteristics.Data Sheet PN10294EJ02V0DS7Normalized to 1.0 at T A = 25˚C,I F = 10 mA, V O = 5 V,R L = 500 ΩAmbient Temperature T A (˚C)N o r m a l i z e d T u r n -o n T i m e t o nNORMALIZED TURN-ON TIME vs.AMBIENT TEMPERATURENormalized to 1.0 at T A = 25˚C,I F = 10 mA, V O = 5 V,R L = 500 ΩAmbient Temperature T A (˚C)N o r m a l i z e d T u r n -o f f T i m e t o f fNORMALIZED TURN-OFF TIME vs.AMBIENT TEMPERATURE–25025*******3.02.52.01.00.00.51.5–25025********.02.52.01.00.00.51.5Remark The graphs indicate nominal characteristics.TAPING SPECIFICATIONS (UNIT: mm)8Data Sheet PN10294EJ02V0DSData Sheet PN10294EJ02V0DS 9Data Sheet PN10294EJ02V0DS10RECOMMENDED SOLDERING CONDITIONS(1) Infrared reflow soldering • Peak reflow temperature 260°C or below (package surface temperature) • Time of peak reflow temperature 10 seconds or less • Time of temperature higher than 220°C 60 seconds or less • Time to preheat temperature from 120 to 180°C 120±30 s• Number of reflows Three• Flux Rosin flux containing small amount of chlorine (The flux with a maximum chlorine content of 0.2 Wt% is recommended.)P a c k a g e S u r f a c e T e m p e r a t u r e T (˚C )Time (s)Recommended Temperature Profile of Infrared Reflow(2) Wave soldering • Temperature 260°C or below (molten solder temperature) • Time10 seconds or less• Preheating conditions 120°C or below (package surface temperature) • Number of times One• Flux Rosin flux containing small amount of chlorine (The flux with a maximum chlorine content of 0.2 Wt% is recommended.)(3) Soldering by soldering iron• Peak temperature (lead part temperature) 350°C or below • Time (each pins)3 seconds or less• Flux Rosin flux containing small amount of chlorine (The flux with a maximum chlorine content of 0.2 Wt% is recommended.)(a) Soldering of leads should be made at the point 1.5 to 2.0 mm from the root of the lead. (b) Please be sure that the temperature of the package would not be heated over 100°C.(4) Cautions • FluxesAvoid removing the residual flux with freon-based and chlorine-based cleaning solvent.<R>分销商库存信息:CELPS7200H-1A PS7200H-1A-F3PS7200H-1A-E3-A。
