解决SolidWorks2012-2014无法安装Simulation，Motion,Flow simulation，Toolbox 等插件我的笔记本电脑注册表，网上找了一些方法重装都试了，根本不行，正正找了10个小时，重装了5次软件；就差重装系统了，重装系统太麻烦，里面还有自己安装的许多大型软件，在win10系统上2014也不行，最后，总结了目前亲自安装最靠谱的方法如下：方案一+方案二方案一：1）主要是因为Microsoft KB3072630这个补丁引起的，去把这个补丁卸载了：（win7）进入控制面板--卸载程序--查看已安装的更新(左上角)--搜索“KB3072630”（右上角）--找到后，点击右键卸载。
之后重新启动电脑。
重启电脑后，在去SolidWorks安装包中点“setup”，启动安装程序后，点击第二个修复（repair），等修复完成后就可以用了。
（2）装完之后肯定有simulation了，如果再想安装flow simulation再点击SolidWorks安装包中点“setup”点击第一个修改，选择flow simulation 序列号9000 0000 0003 3107 V8F3 PG44（断网安装）（3）再运行SSQ激活flowsimulation（管理员身份运行），这样就好了。
这个方法适用solidworks2012~2014版本解决之道如下：win+R打开运行，输入regedit进入注册表编辑器2.在注册表中找到HKEY_LOCAL_MACHINE\SOFTWARE\Policies\Microsoft\Windows\Installer，没有右键window文件夹建一个项，命名为Installer3.在Installer上新建一个Dword值，32位即可，名字为“RemappedElevatedProxiesPolicy”，右键新建文件修改，设值为14.打开自己原来的安装包，setup，修复，单单修复solidworks即可5.修复完成后打开solidworks，可以发现工具-插件里的插件已经齐全了，toolbox也可以正常使用了，将“RemappedElevatedProxiesPolicy”的值改为0，这个bug就修复了。
