FMA-A2000系列气体质量流量计和控制器

Mass and Volumetric Gas Flow MetersFor Clean GasesU U p to 18 Hour Battery Charge on Portable“-B” Models U R anges of 0 to 0.5 SCCM Up to 0 to 3000 SLM U R eports Mass Flow, Volumetric Flow,Temperature, and Pressure U <10 ms Response Time—Field Adjustable U 130+ Gas Calibrations IncludingPure and Mixed Gases U P ressure, Temperature and Volumetric orMass Flow Simultaneously Displayed U N IST 5-Point Certificate Included U N o Straight Runs of Pipe Required U No Warm-Up TimeU Turndown Ratio of 200:1 (0.5% Maximum Flow)U RS232 StandardU Custom Live Gas Blend Programming U Store Up to 20 User Defined Gas BlendsThe FMA-1600A Series mass and volumetricflow meters use the principle of differential pressure within a laminar flow field to determine the mass flow rate. A laminar flow element (LFE) inside the meter forces the gas into laminar (streamlined) flow. Inside this region, the Poiseuille equation dictates that the volumetric flow rate be linearly related to thepressure drop. A differential pressure sensor is used to measure the pressure drop along a fixed distance of the LFE. This, along with the viscosity of the gas, is used to accurately determine the volumetric flow rate. Separate absolute temperature and pressure sensors are incorporated and correct the volumetric flow rate to a set of standard conditions. This standardized flow rate is commonly called the mass flow rate and is reported in units such as standard cubic feet per minute (SCFM) or standard liters per minute (SLM).Standard units include a 0 to 5V output (4 to 20 mA optional) and RS232 communications. The gas select feature can be adjusted from the front keypad or via RS232 communications. Volumetric flow, mass flow, absolute pressure, and temperature can all be viewed or recorded through the RS232 connection. It is also possible to multi-drop up to 26 units on the same serial connection to a distance of 38 m (125'). These flow meters are available in a portable version (“-B” option), the battery charge will last up to 18 hours.FMA-1600A SeriesSpecificationsAccuracy: ±(0.8% of rdg + 0.2% FS)Repeatability: ±0.2%Turndown Ratio: 200:1Response Time: 10 ms typical default response time for 63.2% of a step change. A variable register allows response time to be field adjustable to a certain extent via RS232 communications. The primary trade-off for response time is signal noiseOutput: 0 to 5 Vdc standardOperating Temperature: -10 to 50°C (14 to 122°F)Zero Shift: 0.02% FS/°C/atm Span Shift: 0.02% FS/°C/atmHumidity Range: 0 to 100% non-condensing Pressure (Maximum): 145 psig Measurable Flow Rate: 125% FSSupply Voltage: 7 to 30 Vdc (15 to 30 Vdc for 4 to 20 mA output)Supply Current: 35 mA typical current draw; 100 mA available supply recommended Cable Connection: 8-pin mini DINWetted Parts: 302 and 303 SS, FKM, heat cured silicone RTV, glass reinforced PPS, heat cured epoxy, aluminum, gold, brass, 430 FR stainless (416 stainless steel on large sizes), silicon, glassFMA-1603A includes 110 Vac power supply and a 1.8 m (6') cable 8-pin mini DIN connector,Shown smaller than actual size.Exploded View of InternalLaminar Flow Elements Absolute PressureSensorDifferential PressureSensor TemperatureSensorProgram Custom Mixed Calibrationsfor Bioreactors, Chromatography,Welding, Lasers, Stack/Flue, Fuel Gases and MoreComes complete with 24 Vdc universal power supply, 1.8 m (6') cable, 8-pin male Mini-DIN connector, operator’s manual, and NIST certificate. Units are calibrated to air @ 5 psig for 0 to 1 LPM, 15 psig for 2 to 10 LPM, 30 psig for 20 to 100 LPM, and 50 psig for 200 LPM and greater. Calibrations done at ambient 25ºC (77ºF) temperature only.To replace the standard RS232 communications with RS485, add suffix “-RS485” to the model number; for additional cost.Standard input is 0 to 5V, for optional 4 to 20 mA input add suffix “-IN” to the model number; no additional cost.Standard output is scaled to the mass flow rate. For volumetric flow rate as standard output add suffix “-VOL” to the model number; no additional cost. Standard output is 0 to 5V, for optional 4 to 20 mA output, add suffix, “-I” to model number; for additional cost.For two 4 to 20 mA output, add suffix “-I2” to model number; for additional cost.For two 0 to 5V output, add suffix “V2” to model number; for additional cost.**Optional secondary output are scaled the same as the primary output scale. For an alternate output scale add suffix “-T” to the model number for temperature or “-P” for pressure; no additional cost.For a portable version of the meter add suffix “-B” to the model number; for additional cost. Portable versions have an integral battery on the meter and come with one 9V battery installed. Option not available on “-I” or “I2” models where 4 to 20 mA is the chosen output.For units scaled in SCFH, add suffix “-SCFH” to model number; no additional cost. Please specify the desired range in SCFH.For totalizer option, add suffix “-TOT” to the model number; for additional cost. Please specify resolution.This is a 6-digit counter. Examples: For totalizing in liters with 1/100 liter resolution, the max count would be 9999.99. For totalizing in liters with 1 liter resolution, the max count would be 999999.Ordering Examples: FMA-1601A, 0.5 SCCM mass flow meter.FVL-1619A-VOL, 500 SCCM volumetric flow meter.。

第一章1.0 简介为了计算气体的总能量、体积量和瞬时流量而设计了2000型气体测量修正仪。

在计算时，使用了涡轮流量计的脉冲输出（或者超声流量计的输出）以及温度变送器和测量管线压力的压力变送器的输出。

如果需要的话，该修正仪可以使用预先设定的或者实时输入的气体相对密度（即比重）、气体的组分数据和热值。

为了计算气体流量，采用了以下几种计算气体压缩因子（Z因子）的方法，如：AGA 8,ISO12213和AGA 3 ，NX19。

对于一些特定应用场所，也可以采用固定的Z因子。

修正仪能够对所有实时输入的信号进行上、下限报警，而在报警的状态下，可以使用默认值来取代处于报警状态的参数以进行流量计算。

对于发生和取消报警的时间都有指示，同时也提供报警的输出信号。

本修正仪的特点是它采用数字通讯，温度与压力变送器都采用HART协议进行通讯，从而消除了校准修正仪及调节电位器的必要。

这一特点也限制了由于环境温度所带来的流量测量误差，只有温度和压力变送器的温度系数会产生误差。

修正仪有两个RS232/RS485串行数据通讯接口，为了能和系统的其他器件通讯，通讯协议为MODBUS ASCII，还有一个ASCII的串行通讯协议可以和大多数打印机通讯。

为了使操作数据和流量测量结果具有最大的安全性同时保持辅助功能的灵活性，修正仪具有编辑功能：既可以更改已选定的数据同时又利用临界数据保持其安全性。

为确保所有的信号都在设计要求的范围内，对所有的输入输出信号都进行测试。

当报警发生和清除时，每一个报警显示都记录发生和清除的时间。

如有报警发生时，可以选定将报警期间的累计总量单独累计并单独显示。

第二章2000型气体测量修正仪，它包括一个19英寸标准尺寸的安装支架（但只有1/2 宽），还包括和母板连接的许多接插件式的印刷电路板。

修正仪的前面板包括一个液晶显示屏，键盘，操作按钮和LED显示器。

液晶显示屏（LCD）是图形点阵式的，用于显示输入数据和流量信息。

D-xU Unique Built-In DigitalDisplay for Direct Readout in SCCM and SLM Units (FMA-5600 Series)U 13 Flow Ranges,from 0 to 10 SCCM to 0 to 40 SLMU Excellent Performance:±1.5% Accuracy FS, 0.5% Repeatability, and Time Response of 2 SecondsU NIST Certificate IncludedFMA-5000 Series electronic mass flowmeters combine high performance and versatility into a state-of-the-art, compact package. These flowmeters measure themass flow rate of gases in 13 ranges from 0 to 10 SCCM (standard cubic centimeters per minute), to 0 to 50 SLM (standard liters per minute). For the complete listing of ranges, see the “Flow Range Table” on the next page. Accuracy is 1.5% FS over a wide temperature and pressure range. Time response is 2 seconds to within 2% of final flow. These unique flowmeters are available with (FMA-5600) or without (FMA-5700) digital display. The display is a 31⁄2 digit LCD, tiltable to 180°. An optional power supply (12 to 24 Vdc) can be purchased separately (see “Accessory”).With their analog output, integral/remote digital display, insensitivity to temperature and pressure variations, and low cost, the FMA-5600 meters are idealsubstitutes for rotameters; they canFMA-5000also be used to calibrate rotameters. Other applications include chemical and food processing, research and development, gas chromatography, and leak and filter testing.A 0 to 5 Vdc (standard) or 4 to 20 mA (optional) output signal is linearly proportional to gas mass flowrate—for recording, data logging, or control. A 9-pin “D” subconnector for the output signal, input power, and remote display drive is supplied with its mating connector for all FMA-5000 Series units.All wetted surfaces are constructed of corrosion-resistant glass-filled nylon 66 plastic, 316 SS, and FKM O-rings. Ordering option “-ST” replaces the FNPT-ported nylon flow body with a 316 SS flow body with 1⁄4" compression fittings fortubing. (The “-ST” option is available on the FMA-5600 display unit only). The plastic flow body is suitable for use with non-toxic, non-flammable gases; the 316 SS flow body is suitable for higher pressures and hazardous gases.FMA-5610 with tiltable digital display shown smaller than actual size.FMA-5703shown smaller than actual size.N o w A v a i l a b l e i t h a R u gg e d 316 S S F l o w B od y !VERSATILE ELECTRONIC MASSDD-xflow monitoring devices.The flowmeter is operated by 2 RTD coils around the sensor tube, which direct a constant amount of heat into the gas stream. The gas mass flow carries heat from the upstream coil to the downstream coil. The resulting temperature difference (T2 - T1) is detected by the RTD coils, producing the output signal.SPECIFICATIoNSAccuracy: 1.5% FS includinglinearity over 15 to 25°C (59 to 77°F) and 5 to 60 psia; 4% FS over 0 to 50°C (32 to 122°F) and 1 to 150 psiaPower: 12 to 15 Vdc @ 100 mA max Response Time: 800 ms time constant; 2 seconds typical to within ±2% of final value over 25 to 100% FS Temperature Coefficient: 0.08 to 15% FS/°CPressure Coefficient: 0.01% FS/psi Maximum Gas Pressure: 150 psig for nylon flow body, 500 psig for 316 SS flow body; units are calibrated standard for 20 psigGas and Ambient Temperature: 0 to 50°C (32 to 122°F)Leak Integrity (Standard cc/s He): 1 x 10-4 for nylon flow body; 1 x 10-7 for 316 SS flow body Connections: 1⁄4 FNPT standard Electrical Connections: 9-pin sub “D” connector Weight: 0.91 kg (2 lb)†Note 1: To order the FMA-5000 Series with 4 to 20 mA output, add suffix “-I ” to the model number and consult Flow Engineering for price.Note 2: To order the FMA-5600 Series with 316 SS body and 1⁄4" compression fittings, add suffix “-ST” to part number. Consult Flow Engineering for price.factor is used to determine the flow rate and the digital display must be rescaled in the field. Or request “Special Calibration” for _________gas at _________ (temperature) and ___________ (pressure).”†† Add additional cost to price for range code “01” and “02”.Ordering Examples: FMA-5601, flowmeter with display, nylon body and 0 to 10 SCCM range.FMA-5702, flowmeter without display or nylon body, 0 to 20 SCCM.low BodyPlastic Flow Body。

B-59SPeciFicAtioNSAccuracy: ±2% FS Repeatability: ±1%Dimensions: 48 x 43 mm(1.9 x 1.7") for 116°C (240°F) units Length: 121 mm (4.75") for 116°C (240°F) units; 168 mm (6.6") for 204°C (400°F) units Maximum Pressure: 241.3 bar (3500 psig)Maximum temperature: Standard: 116°C (240°F)optional: 204°C (400°F) at 124 bar (1800 psig) max Shipping Weight:Water Meters: 453 g (1 lb) oil Meters: 227 g (8 oz)The FL-2000A Series of general purpose flowmeters is designed to provide economical, accurate flow rate indication for oil and water. These industrial flowmeters utilize a spring-and-piston type assembly, which enables them to be mounted in any position and makes them immune to changes in viscosity. The FL-2000A meters can be used in severe environments, at up to 241.3 bar (3500 psig) and 116°C (240°F). Correlation equations with other fluids, are available in the user’s manual.U ±2% Full Scale Accuracy U ±1% RepeatabilityU Mounts in Any Position U Good Viscosity Stability U D irect Readings for oil or Water U 241.3 bar (3500 psig) Pressure Rating U VU t U F Pressure Drop: Approximate pressure losses in flowmeters using oil at normal temperatures. Add 10% to pressure for equal water flows.connections: 1⁄4 FNPTWetted Parts: Polyphenylene sulfide/ceramic magnet and FKM O-rings; FL-2100A has aluminum body and 302 SS spring; FL-2300ABR has brass body and 302 SS springECONOMICAL IN-LINE FLOWMETERSCAPACITIES: 0.05 to 2.0 GPM of Water, 0.05 to 2.0 GPM of OilFor units with BSPP threads add suffix “-BSPP ” to model number, no additional cost.For 204°C (400°F) units, add suffix “-H ” to model number, for additional cost. * “-H ” option not available with these units.Ordering Examples: FL-2301ABR, for a brass water flowmeter, 1.0 GPM. FL-2102A, aluminum oil flowmeter, 2.0 GPM.FL-2000A0.0510150.5 1.0 1.5 2.0Flow, GPMP r e s s u r e D r o p , p s i1/4"0.00.252460.50.75.02-.20.05-.50.10-1.0.20-2.0FL-2102A shownsmaller than actual size.。

气体质量流量控制器 MFC 流量传感器产品名称气体质量流量控制器 MFC 流量传感器公司名称北京堀场汇博隆精密仪器有限公司价格8000.00/个规格参数建议零售价:¥8000.00加工定制:否品牌:HORIBAMETRON/堀场汇博隆公司地址北京市朝阳区北苑路40号23号、25号联系电话010-******** 130********产品详情提示：以下模板中任意文字及图片均可执行修改、复制、删除的操作，添加更多的图片和文字描述有助于增加产品对买家的吸引力。

产品介绍产品信息重量： 2.8kg毛重： 2.8kg 产地： 北京堀场汇博隆精密仪器有限公司流量规格流量规格： （100,150,200)l/min 调节阀类型：电磁调节阀 调节阀静止状态： 常闭 准确度： ± 1.0%f.s. 线性： ±0.5%f.s.重复性精度： ±0.2%f.s.响应时间：2s（t98）产品性能简介企业介绍北京堀场汇博隆精密仪器有限公司是一支由中方经营管理，中日双方共同协作的国际化团队，是由全球顶级热式质量流量控制器（mfc）制造商——horiba stec与中国知名热式质量流量控制器(mfc)制造商——北京汇博隆仪器有限公司共同出资成立，是以研发、生产、销售热式质量流量控制器为主业的高新技术企业。

公司经营层和整个国际化团队坚持"群策群力，持续发展，立足国内，走向世界"的企业总体发展方向。

力循"中外结合，品质为本"的经营理念，努力在人才、技术、生产、工艺、质量、市场、服务等各个方面引入和完善现代企业经营管理机制，以适应全球经济一体化的市场竞争，为加速我国相关产业的不断发展贡献一份力量。

企业证书购买须知1、货源说明厂家一手货源，公司生产周期短、产品品质有保证2、关于尺码与使用手册里尺寸一致，以收到实物为准3、关于颜色本店产品均为实物拍摄， 与实物平铺图最为接近，收到实物与图片颜色不一致的，可能与电脑显示器的色彩对比度和色温等因素有关4、关于客服如您的提问未能及时回复，可能是因为咨询量过大或系统故障5、关于售后6、关于发货合作快递 中通、德邦本产品的建议零售价是¥8000.00，加工定制是否，品牌是HORIBAMETRON/堀场汇博隆，型号是S4828，类型是质量流量计，测量范围是12（m3/h），精度等级是1.0%，适用介质是气体，工作压力是3（MPa ），工作温度是5~45（℃），产品属性是仪器仪表。

内容：页数前言操作员手册和软件版本的联系安全须知电气测量设备安全使用技巧第一章安装准备工作安装位置的选择采样气体进口和出口条件校验用测试气吹扫气电源交货范围安装需要的材料（不在交货范围）安装清单安装、启动方法第二章气体分析仪的拆箱及安装气体分析仪的拆箱气体分析仪的识别尺寸图气体连接口的安装气体分析仪的安装第三章气路连接分析仪模块连接图气体流路图壳体吹扫压力传感器气路连接吹扫气路的连接第四章电气连接电器模块的连接系统总线的连接Profibus总线单元、RS232/RS485通信单元接线图模拟输出单元接线图八通道模拟输出卡接线图模拟量输入/输出卡接线图离散量输入/输出单元接线图离散量输入/输出卡接线图标准功能块的连接信号、控制和接口线的连接电源线连接安全注意事项24V直流电源线连接115/230V交流电源线连接第五章分析仪系统的操作显示控制单元屏幕信息显示状态灯数字键盘取消键软键文字的输入数值的输入按键的输入密码保护用户接口优先级访问锁菜单栏第六章分析仪系统组态A 节气体组份测量功能量程变换更改量程范围Limas11、Uras14：更改量程范围改变小数点位数过滤器初始化自动量程初始化极限值监测器初始化激活组份选择更改模块名称B节功能模块功能块的定义标准组态功能块子菜单C节系统功能设定时区及时间、日期选择用户界面语言修改密码禁止操作安装系统模块添加系统模块修改系统模块删减系统模块保存组态信息配置状态信号配置互联网连接配置Modbus总线连接配置Profibus总线配置I/O总线D节显示显示的特点显示综述页面综述参数综述用户页面配置显示元素换页显示元素页内位置变换配置柱状图或者点阵图输入数值输入数值的配置按键输入按键输入的配置第八章分析仪系统的校验A 节原理校验控制手动校验自动校验自动校验的测试气供给控制外部控制校验校验方法B节校验数据校验数据子菜单手动校验的校验数据自动校验的校验数据确认外部校验的校验数据当前输出响应C节校验分析仪单元注意事项Caldos15Caldos17Caldos17：校验气的单点校验Caldos15和Caldos17:替换气的校验Limas11Magnos106：Magnos106：单点校验Magnos106：替换气的校验Magnos17:Magnos17：替换气的校验Uras14:氧气检测器：D节校验分析仪模块手动校验手动启动自动校验第九章检查和维护检查检查气路密封性Caldos15和Magnos17：更换温度连接机构Uras14：光学对中Uras14：相位对中Limas11,Uras14:校验检测器的测量Limas11,Uras14：线性化Limas11：更换温度连接机构Limas11：铝化物采样检测器的清洁Limas11:石英采样检测器的清洁Limas11：安全采样器的清洁Limas11UV：指示灯的更换Limas11：放大器的优化气体模块:更换过滤器激活采样泵，采样泵输出的调整改变模拟输出电流的量程大气压力的修正大气压力值的修正校验的复位交叉敏感度载气第十章状态信息，故障修理处理状态系统状态：状态信息系统状态：状态信号状态信息的分类状态信息分析仪系统故障Caldos15、Caldos17、Magnos106、Magnos17故障Limas11故障Uras14故障气体模块故障通报服务附录1 气体分析仪概述气体分析仪分析仪模块带氧气探头的气体模块电气模块系统外壳显示控制单元附录二分析仪模块操作规范Caldos15操作规范Caldos17操作规范Limas11操作规范Magnos106操作规范Magnos17操作规范Uras14操作规范氧气操作规范电气安全前言操作手册内容：AO2000系列气体分析仪的安装、启动、操作和维护等信息，该手册包含了所有功能单元的内容，可能与交货的分析仪有差别。

D-1The FMA-A2000 Series electronic mass flow meters/controllers provide high performance, versatility, and state-of-the-art design in one compact package. The FMA-A2000 uses capillary-type thermal technology to directly measure mass flow of gases. No temperature, pressure, or square root corrections are required.The FMA-A2300/2400 Series comes with an LCD display, and all models have linear 0 to 5 Vdc and 4 to 20 mA output.The FMA-A2000 measures the mass flow rate of gases in 24 ranges from 0 to 100 SLM. For the complete listing, refer to the range table on pageD-20. The FMA-A2000 Series is compatible with most non-corrosive gases. The user is advised to check the wetted materials against gas compatibility.OMEGA’s mass flow controllers use an internal electromagnetic proportional valve to control the mass flow rate. A command signal can be supplied either by the internal setpoint pot or by a 0 to 5 Vdc external source.U ±1% AccuracyU Linear Analog Output U Low CostU Thermal TechnologyU For Flow Rates Up to 100 SLM U Power Supply IncludedFMA-A2000 SeriesGAS MASS FLOW METERS AND CONTROLLERSFor Clean GasesWith Optional Integral Display FMA-A2417 with display, shown smaller than actual size.FMA-A2117 without display,shown smaller than actual size.D-2SPECIFICATIONSAccuracy: ±1% of full scale including linearityRepeatability: ±0.15% full scale or betterTurndown Ratio: 100:1Response Time: 5 seconds Gas Ambient Temperature: 0 to 50°C (32 to 122°F)Temperature Coefficient:0.05% full scale per 1°C or better Pressure Coefficient:0.01% full scale per psi or betterMeters: 20 SLM: 20 psiPolyacetal: 316 SS:Leak Integrity:1 x10-6Wetted Parts:Standard: Optional:Connections: 1⁄41⁄4Control Signal:Control Valve:normally closed Output Signal:1000 Ω500 Ω 316 SS Body: Polyacetal:Input Power:M eters: Controller: Dimensions:Weight:with power supplyNIST calibration (5 data points).* Insert range code from table at top of page to complete model number.For optional 316 stainless steel body, add suffix “-SS ” to model number for additional cost (1⁄4" compression fittings standard). SS body standard on FMA-A22 and FMA-A24 controllers.Note: All controller flow ranges specified are for nitrogen or air at 20 psig; when used for other gases, a correlation factor is needed to determine the flow rate.** Specify gas, inlet/outlet pressure, temperature.For 10-point NIST calibration certificate, add suffix “-NIST10” to model number for additional cost.Ordering Examples: FMA-A2316, mass flow meter with display, calibrated for nitrogen at 20 psig inlet, room temperature for 0 to 45 SLM. ∆P: 5 to 20 psi.FMA-A2102-SS , 316 stainless steel body mass flowmeter without display, 0 to 50 SCCM.6Tubing and fittings of various materials and styles are available. Visit us online for details.more details.。
