电容触摸屏规格书

电容一体机23.6英寸电容触摸平板技术规格书（型号：ＨＢＹ－Ｄ２３６）备注：标配壁挂架，桌面式支架为选配产品；内容如有更改，恕不另行通知一、产品特性1.结构设计：（1）纯平面结构，人体工程学设计，纤巧美观、流线造型、工艺精良；（2）显示、触控、PC系统一体化超薄设计,仅厚43 mm；2.使用效果：（1）采用最新研发的投射式电容屏，完美10点触摸，支持手写及多点手势；（2）触摸速度小于3ms，精确度好，使用简单便捷、易于维护；（3）抗光干扰，确保操作的准确性（强光直射照常使用）；3.扩充性好：配置灵活，可扩充安装客户需求的各种功能配件；4.安全性高：铝合金+钣金结构，无锐利边缘，耐磨防腐烤漆工艺，整体防暴设计；5.性能稳定：先进的设计理念，严格的生产工艺，产品品质稳定可靠，故障率低；6.安装简便：通电一键开关机，免除现场安装调试。

二、系统设计三、液晶屏参数四、触摸屏参数五、显示参数 (仅做为触摸显示器部分使用)六、电源参数七、工作环境八、随机附件九、电脑参数十、物理规格屏幕23.6寸（对角线603.6mm）有效显示尺寸525.5×297 mm （16：9）整机尺寸（宽×高×厚）576（宽）×352（高）× 43（厚）mm 包装尺寸（宽×高×厚）635（宽）× 445（高）×140（厚）mm 底架标配壁挂架（净重0.78kg），可选配底座背部壁挂与机器连接的孔100×100 mm位尺寸（长×宽）壁挂螺丝规格M4净重（裸机）触显7.23 kg，一体机7.75kg毛重（包装）9.11 kg十一、整机结构图十二、产品细节图十三、产品款式/产品效果图十四、整机实拍图十五、产品配件图。

触摸屏规格承认书Analog Touch panel Specification 品名/Product Name：电容式触摸屏模组机种名/Product Number：HKCZ-21.5CTP-023客户名称/ CUSTOMER NAME：客户确认/CUSTOMER APPROVE：日期/APPROVE DATE:客户签核核准审核确认承制方签核核准审核确认目录目录 (2)适用范围 (3)变更记录 (3)1.产品规格 (5)1.1 产品尺寸 (5)1.2 产品结构 (5)1.3 产品参数 (5)1.4 产品功耗 (6)1.5 产品使用、保存环境 (6)2.可靠性标准规范 (6)3.结构图纸 (7)6.注意事项 (8)深圳华科创智技术有限公司 2 / 8适用范围本规格书为明确规范本公司产品触控面板性能而订定，当本规格书与其它个别规格书内容有抵触情况发生时，仍以本规格书标准为最优先。

本规格书内容如有项目不足或内容需变更时，须经由会议讨论后另订之。

This specification defines performance of input surfaces for our transparent analog touch panels. In the event of a conflict between this specification and applicable individual specification, this specification takes precedence. Items missing from this specification are to be decided subject to discussion.变更记录日期版本描述变更人员2016.6.25 V1.0 初版吴小雄1.产品规格1.1 产品尺寸项目内容单位触摸尺寸21.5 inch视窗比例16:9 NA外形尺寸514.64*310.51 mmSensor外形489.57*289.08 mm可视区476.64*268.11 mm1.2 产品结构项目内容单位玻璃厚度 3 mm玻璃倒角R4.0 mmOCA厚度（上线）0.125 mm纳米银导电膜厚度（上线）0.125 mmOCA厚度（下线）0.05 mm纳米银导电膜厚度（下线）0.125 mm1.3 产品参数项目内容单位表面硬度7H H透过率＞84% %线性度Pitch 6.0mm mm最大支持点数10点NA支持最大分辨率1920*1080Dots NA接口种类USB NA运行系统Android NA1.4 产品功耗项目内容单位振荡频率12 MHZ电源5V V反应时间≦10 ms1.5 产品使用、保存环境项目内容备注使用温度范围湿度20%-90%，非结雾单体状态下以上条件不代表环境试验规状态-10℃-60℃格保存温度范围湿度20%-90%，非结雾单体状态下以上条件不代表环境试验规状态-20℃-70℃格2.可靠性标准规范项目测试条件判定高温存储试验80℃，240h，试验后常温静置2h检查产品功能正常高温高湿试验60℃、90%RH，240h，试验后静置2h检产品功能正常查冷热冲击试验温度-30℃/+70℃，60分钟/循环，试验产品功能正常3.结构图纸6.注意事项1.汗水或油脂等若附着于纳米银线层上，将会影响纳米银线层表面阻抗质特性，故勿在未戴手套下直接触摸表面。

单通道电容式触摸键控制芯片XC2861目录1概述 (3)1.1 特性 (3)1.2 系统框图 (4)2管脚定义 (5)3功能描述 (6)4电气特性 (7)5关键特性 (8)5.1 环境自适应能力 (8)5.1.1环境漂移跟随 (8)5.1.2环境突变校准 (8)5.2 接近检测 (8)6用户设置 (9)6.1 灵敏度设置 (9)6.2 休眠与唤醒控制信号 (9)7应用指南 (10)7.1 触摸键 (10)7.2 接近检测 (11)8PCB设计 (12)8.1 触摸键设计 (12)8.1.1触摸键 (12)8.1.2触摸键的常用结构 (12)8.1.3触摸键设计 (13)8.2 PCB布线 (13)9封装 (14)1概述XC2861是矽励微电子推出的一款支持宽工作电压范围的单输入单输出电容式触摸键控制芯片。

XC2861内部集成高分辨率触摸检测模块和专用信号处理电路，以保证芯片对环境变化具有灵敏的自动识别和跟踪功能，且内置特殊算法以实现防水、抗干扰等需求。

该芯片可满足用户在复杂应用中对稳定性、灵敏度、功耗、响应速度、防水、带水操作、抗震动、抗电磁干扰等方面的高体验要求。

XC2861为方便用户在应用中可对触摸键的灵敏度进行自主控制，特设置了两位灵敏度控制位。

用户只需在PCB设计中对这两个管脚的逻辑电平值进行设置，就能自由选择在具体应用中芯片体现出的检测灵敏度。

XC2861还内置了上电复位及电源保护电路，在典型应用中可无需任何外部器件，也无需软件、程序或参数烧录。

芯片应用的开发过程非常简单，最大限度的降低了方案成本。

XC2861可广泛适用于移动电源、自拍杆、遥控器、灯具调光、各类开关以及小家电和家用电器控制界面等应用中。

1.1特性工作电压：2.5V~5.5V高灵敏度的触摸检测通道，CMOS电平输出无需进行参数烧录4级灵敏度可调（通过设置两位管脚的逻辑电平实现）响应速度快抗电磁干扰能力强防水及带水操作功能接近检测功能独特的环境跟踪和自适应能力低功耗（典型工作电流< 25uA）内置上电复位（POR）和电源保护电路可进入休眠控制1.2系统框图XC2861包含PMU和Touch Key Core两个部分，其系统框图如图1所示。

■Ten Point Projected Capacitive Multi-Touchtechnology■Bright LED backlit display with integratedpowered speakers■Intuitive touch and gesture control tosimply manipulate images on screen Data SheetFUJITSU D75P 15” Capacitive Touchscreen DisplayA great way to expand promotional capabilities in a retail settingIntroductionThe D75P is a bright touch-enabled LCD display designed to complement the styling of the TeamPoS® 7000 range of All-in-One and modular Point of Sale systems. It can also be used with any PoS controller, such as the TP-X II or standard PC systems, providing a stylish and robust Operator or Customer display.The use of two full-screen displays at the checkout or service counter is a great way to expand the promotional capabilities in a retailsetting, as well as improve customer service and satisfaction by displaying a full rolling receipt, or other promotional messages.The D75P incorporates a 10 point multi-touch projected capacitive sensor. This provides for a bright display and enables a user, with appropriate application and operating systemsupport, to manipulate the on-screen image with a range of gestures similar to those employed on the latest generation of smartphones and tablets.In summary the D75P display provides the newest touch technology, exceptionalperformance and reliability resulting in a moreproductive in-store experience.Display configuration The display can be installed with a 3.937” (100mm) VESA mount, or can be used with the optional desktop stand as shown in the pictures.The display operates from a 12V power supply which is normally sourced from a powered USB port on the PoS host controller. If this is notavailable, an external power supply unit canalso be used.For kiosk use, advertising or computer based training, a standard 3.5mm audio-in socket isprovided for the stereo loudspeakers which aresupported by a 1.0W per channel integrated amplifier.Display data can be provided via a digital DisplayPort or analogue VGA interface.A single powered USB cable is made available toenable the display to be powered and data to be communicated from a 12V powered USB port on the host controller.Features■D75P – 15.0” 1024 x 768 resolution, 4:3 aspect ratio■Projected Capacitive Touch Screen ■10 point multi-touch gesture support■400 Cd/m2 typical brightness ■Low-power, long life LED backlight■Wide viewing angle and 8ms response time■Full-screen re-scaling capability if fed at non-native resolution■Stereo speakers with integrated amplifier ■Digital DisplayPort and Analogue VGA ports ■Desktop or VESA mountGeneral specificationsLCD PaneD75P: Active matrix TFT colorBezel: Flat – Zero bezel designSize: 15 inch diagonal screen sizeDisplay area: 11.97” H x 8.98” W (304mm H x 228mm W)Tilt: 0° - 45°Aspect Ratio: 4:3Resolution: 1024 x 768 pixelsColors: 16.7M (8 bit)Response time: 8msBacklight: Long-life LED – 50,000 hours to half-brillianceInput SignalsVideo: Analogue VGA (0.7V p-p), separate sync TTL Digital Display PortAudio: 3.5mm stereo audio in jack socketUSB: Supports touchscreen and optional MSR/KeyboardMultimediaSpeakers: 2x 1.5W integrated into the bottom edges of the display10 ConnectorsAnalogue VGA 15 pin D-SubDigital DisplayPort12V Powered USB for display power and touch data interface on one cable (includes Standard USB type – A connector) Audio-in 3.5mm stereo plug12V DC power-in for optional external power supplyInternal USB header – ribbon under cover for optional MSR/KeypadDimensionsD75P without stand: 14.53” (369mm) W x 1.93” (49mm)D x 11.92” (303mm)HUser ControlsPowerBrightnessVolumeColorTouchscreenProjected Capacitive10 point touch with gesturingEnvironmentalAnti-reflective hardened glassIP53 on front32° to 104° (0° to 40° C) operation10-95% HumidityStand & Mounting OptionsDesktop standVESA mount (100mm x 100mm)Power Consumption<14W Operational<3W StandbyAC Adaptor (option)External 12V DC power adaptorUniversal AC 100-240V, 50/60HzCertificationsFCC, CCC, VCCI, CE, CB, UL, C-Tick, ROHS, WEEE, REACH CompliantContactFUJITSU AMERICA, INC.Address: 1250 East Arques Avenue Sunnyvale, CA 94085-3470, U.S.A.Telephone: 800 831 3183 or 408 746 6000Website: Contact Form: /contact Haveaquestion?Emailusat:*********************.comAbout Fujitsu AmericaFujitsu America, Inc. is the parent and/or management company of a group of Fujitsu-owned companies operating in North, Central and South America and Caribbean, dedicated to delivering the full range of Fujitsu products, solutions and services in ICT to our customers in the Western Hemisphere. These companies are collectively referred to as FujitsuAmericas. Fujitsu enables clients to meet their business objectives through integrated offerings and solutions, including consulting, systems integration, managed services, outsourcing and cloud services for infrastructure, platforms and applications; data center and field services; and server, storage, software and mobile/tablet technologies. For more information, please visit: / and /fujitsuamericaA new world is emerging, where everyone and everything is interlinked, sharing information. This hyperconnected world forms the foundation of modern retail. It is all around us and means retailing without walls for a new, empowered consumer. This is Connected Retail.In response, Fujitsu is focusing on three core capabilities that ultimately deliver retailers a differentiated customer experience.Retail Core Capabilities■Innovative retail solutions – to support and future proof the customer experience in today’s omni-channel world; thisincludes Fujitsu Market Place – our omni-channel PoS application – and new solutions from our innovation labs in around the world■Connected enterprise – within the store, between the front and back office, and between multiple vendors to deliver a seamless and integrated customerjourney, working enterprise solutions, and outcome- based enterprise services ■Global delivery – the assets andcapabilities to deliver consistent cross-border solutionsTo learn more about Fujitsu the LIFEBOOK T935 Premium convertible Tablet PC Ultrabook™ , please contact your Fujitsu sales representative or Fujitsu Business partner, or visit our website. /Fujitsu Green Policy Innovation is ourworldwide project for reducing burdens on the environment. Using our global know-how, we aim to resolve issues ofenvironmental energy efficiency through IT. Please find further information at:/global/about/environment/Fujitsu and the Fujitsu logo are trademarks or registered trademarks of Fujitsu Limited in the United States and other countries. TeamPoS is a trademark or registeredtrademark of Fujitsu Frontech North America Inc. in the United States and other countries. All other trademarks and product names are the property of their respective owners. The statements provided herein are for informational purposes only and may be amended or altered by Fujitsu America, Inc. without notice or liability. Product description data represents Fujitsu design objectives and is provided for comparative purposes; actual results may vary based on a variety offactors. Specifications are subject to change without notice.Copyright© 2015 Fujitsu America, Inc. All rights reserved. FPC65-7509-01 10/15. 15.0916DisclaimerTechnical data are subject to modification and delivery subject to availability. Any liability that the data and illustrations are complete, actual or correct is excluded. Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which by third parties for their own purposes may infringe the rights of such owner.。

TTY6753 2 KEYS 电容式触摸按键规格书 Ver1.0●产品描述 (2)●产品特色 (2)●产品应用 (2)●封装脚位图 (3)●脚位定义 (4)●AC／DC Characteristics (5)1Absolute maximum ratings (5)2 D.C. Characteristics (5)3 A.C. Characteristics (5)●输出指示 (6)●注意事项： (7)●应用线路图 (8)●封装说明 (9)●订购信息 (9)●修订记录 (9)●产品描述提供2个触摸感应按键，一对一直接输出，提供低功耗模式，可使用于电池应用的产品。

对于防水和抗干扰方面有很优异的表现。

●产品特色工作电压范围：2.7V - 5.5V工作电流： 1.8mA (正常模式)；10 uA (休眠模式) @3.3V2个触摸感应按键持续无按键4秒(根据不同产品应用可由FuncEdit修改参数)，进入休眠模式提供一对一的直接输出，未按键为高电平输出可以经由调整CAP脚的外接电容，调整灵敏度，电容越大灵敏度越高具有防水及水漫成片水珠覆盖在触摸按键面板，按键仍可有效判别●产品应用各种大小家电、娱乐产品。

封装脚位图●脚位定义接脚类型●I COMS输入●O COMS输出●P 电源AC ／DC Characteristics2 D.C. Characteristics（Condition : Ta= 25 ± 3 ℃，RH ≦ 65 %，VDD =＋ 5V ，VSS=0V ）3 A.C. CharacteristicsParameterSymbol Test ConditionsMin Typ Max Unit Operating voltage VDD 2.7 5 5.5 V Operating current I OPR1 VDD=5V- 3 - mA Input low voltage for input and I/O portV IL1 0 - 0.3VDD V Input high voltage for input and I/O portV IH10.7VDD- VDD V Output port source current I OH1 V OH =0.9VDD, @5V - 4 - mA Output port sink currentI OL1V OL =0.1VDD, @5V-8-mAParameterSymbol Test Conditions Min Typ Max Unit System clock f SYS1 OSC @5v- 4 - MHz Low Voltage ResetV lvr2.02.22.4V输出指示一提供2 keys 电容触摸按键，输出是采用一对一直接输出。

工业产品设计上工程所需21.5寸电容触摸显示器的详细参数资料
编号：215WXDR
产品参数
液晶参数
尺寸21.5寸
型号215WXDR
分辨率1920*1080
响应时间5ms
亮度450cd/m2
对比度2000:1
可视角度170/160
屏点距0.297
触摸屏参数
触摸屏21.5寸电容触摸屏
供电方式内部供电
表面硬度>=7H
透光率>95%
点击寿命5,000,000次
笔插入5～60G
指插入5～100G
菜单控制：亮度、对比度、自动调整、水平调整、垂直调整、语言选择等以及其方调试
语言：中文、英文、法语、西班牙语、意大利语、德语、俄语、韩语
工作温度：-20℃~65°C
工作湿度：5%-95%无结露
存储温度\-20～+70℃
接口：USB VGA DC
标配：电源(12V4A)电源线VGA线USB线保修卡说明书
外形尺寸：请咨询客服
主要用于：商业管理、机柜嵌入、银行和工厂测试、医疗、酒店、飞机场、电梯间、电梯口、商业写字楼、展览现场、娱乐休闲场所、宾馆等多种个人与公共场合
质保：保修一年终身维护
支持系统：win7 系统。

55英寸落地电容触摸机规格参数产品参数配置Windows版本及配置：Windows 配置Intel 六代酷睿I5 6200U 主频2.3GHz 睿频2.8GHz金士顿 DDR4 2133/2400MHz内存 8G 支持升级西部数据 128G（SSD固态硬盘）支持升级NVIDIA MX150 DDR5 2G 独立显卡网络1 x LAN接口Realtek 8111H 千兆网口，支持网络唤醒，PXE 无盘启动功能1 x MINI PCI-E接口，支持 WIFI/4G/蓝牙BIOS 支持上电开机，定时开机，远程开关机设备智能识别操作系统微软官方正版Windows 10企业版系统音频集成 Realtek ALC662 HD 数字音频解码器，6 声道高保真音频控制器1*LINE_OUT 接口支持音频输出（绿色）1*MIC_IN 接口支持麦克风输入（粉色）USB接口2*USB3.0 接口后置标准 USB3.0 接口2*USB2.0 接口后置标准 USB2.0 接口1*F_USB1 插针 USB2.0 插针，一组有 2*USB2.0 （2*5Pin，2.54mm）1*F_USB2 插针 USB2.0 插针，一组有 2*USB2.0 （2*5Pin，2.54mm）显示接口1*VGA 标准接口支持最高分辨率 1920*1200@60HZ1*HDMI 1.4接口支持最高分辨率 4096*2304@24/30HZ液晶显示屏参数配置：指定品牌-京东方55寸液晶面板尺寸55（BOE）分辨率1920(RGB)×1080 [FHD] 屏幕宽高比16:9显示尺寸1209.6(H)×680.4(V) mm亮度(cd/m2)400(Typ.)对比度1200:1(Typ.)[透射]最佳角度全视角可视角度89/89/89/89 (Typ.)色彩16.7M(8bit)刷新频率60HZ触摸屏参数:触摸技术G+G电容触摸屏响应时间< 5ms触摸点数标配 10 点触摸触摸有效识别> 1.5mm扫描频率200Hz扫描精度4096×4096通信方式全速 USB 2.0,3.0理论点击次数5000 万次以上工作电流/电压180Ma/DC+5V±5%抗光干扰阳光、白炽灯、日光灯等强光变化时正常使用触摸数据输出方式坐标输出操作系统兼容性Win7/ Win 8/Win10/CE/Mac/Android/Linux /XP 固件可升级驱动免驱，即插即用包装说明：名称数量55寸落地电容触摸广告机1台整机尺寸1900mm*757mm*93.5mm（以“外观细节”文档的尺寸为准）包装尺寸1950mm*887mm*260mm 保修卡1本合格证1张1.5米电源线1根扳手、螺丝1套工作环境及电压功耗：工作温度0℃～50℃工作湿度0%～90%贮存温度-20℃～60℃贮存湿度10%～95%工作电压AC90/290v功耗90/140W (Typ./Max.)产品图片：以下效果图仅供参考，具体尺寸请参阅“外观细节文档”。

PRODUCT SPECIFICATIONCustomer Name (客户名称):Customer P/N (客户料号):P /N (产品料号):Date(日期):2017-1-4EDIT （制作）CHECKED （审核）APPROVED （批准）覃艳芳潘丽霞杨少拉东楼Customer Approval 客户批准□Approved 承认□Reject 拒绝Comment 意见:Approved by （确认人）:XH10492A-GDA-A1History of Version变更记录Date日期Ver.版Description描述Page页码Design by变更人ＸＨ１０４５３Ａ－ＧＤＡ－Ａ１基础上2016-08-30A0在10LLL更改盖板外形NOTICE:The content of this specification is subject to change without further notice.assumes no responsibility concerning the accuracy,adequacy,or completeness of this specification.makes no commitment to update,or to keep current the information and material contained in this specification.Such information and material may change to conform to each confirmed order.In no event shall be made responsible for any claims attributed to errors,omissions,or other inaccuracies in the information or material contained inthis specification.shall not be liable for direct,indirect,special incidental,or consequentialdamages arising from the use of such information or material.The software (if any)described in this specification is furnished under a license or nondisclosure agreement,and may be used or copied only in accordance with the terms of such agreement.products are not intended for use in life support appliances,devices,ore of product in such applications is not supported and is prohibited.NOPARTOFTHISSPECIFICATIONMAYBEREPRODUCEDORTRANSMITTED IN ANY FORM OR BY ANY MEANS WITHOUT THE EXPRESSEDWRITTEN PERMISSION OF WGJ.ＸｕｈｏｎｇＸｕｈｏｎｇＸｕｈｏｎｇXuhong Xuhong XuhongContents目录1.General Specification产品规格2.Optical Characteristics光学参数3.Reliability信赖性4.Touch panel description触摸屏功能描述4.1touch panel drawing外形图4.2Block diagram功能结构图4.3Touch panel pin assignment引脚定义5.Appearance Inspection外观检验5.1External appearance examination standard外观检验标准6.Notice注意事项6.1Notice常规注意事项6.2Other instructions其他说明6.3Suggest建议Appendix附件工程图1.General Specification产品规格Item项目C O N TE N T S内容Unit单位Outline Dimension外形尺寸224.00*174.40mmActive Area(W*L)动作区212.20*159.40mmView Area可视区211.20*158.40(10.4inch)mm TOP ITO Glass thickness ITO厚度0.70mmCoverlens thickness玻璃厚度 2.00mm Total总厚度 2.90mmTouch IC触摸IC ILI2301+M2V--Number of touchpoint触点数量10点points Number of button按键数量---Interface Type接口方式USB-Operation Temperature工作温度-20℃~70℃℃Storage Temperature储存条件温度23±3℃；湿度40%~70%RH（装机前）仓储不能超过6个月。
