User manual TAS1505Register your product and get support at/supportContents1 Important 2Safety 22 Y our wireless speaker 3Introduction 3What's in the box 3Overview of the speaker 33 Get started 4Charge the built-in battery 444 Play from Bluetooth devices 5Play from Bluetooth devices 5Control playback 55 Product information 66 Troubleshooting 7General 7Bluetooth 77 Notice 8Compliance 8Care of the environment 8FCC Statement 8Trademark notice 9EN12EN1 ImportantSafetyImportant safety instructions•Make sure that the power supply voltageCCcorresponds to the voltage on the back or the underside of the unit.•The speaker shall not be exposed todripping or splashing.•Do not place any source of danger on thespeaker (e.g. liquid filled objects, lit candles). •Make sure that there is enough free spacearound the speaker for ventilation. •Please use the speaker safely in anenvironment with temperature between•Only use attachments and accessories specified by the manufacturer.Battery safety precautions•Danger of explosion if a battery isincorrectly replaced. Replace only with the same or equivalent type.• A battery (battery pack or battery installed)shall not be exposed to excessive heat such as sunshine, fire or the like.• A battery in extreme high or lowtemperatures during use, storage ortransportation, and low air pressure at high altitude can pose safety hazards.•Do not replace a battery with an incorrecttype that can defeat a safeguard (for example, some lithium battery types).•Disposing a battery into fire or a hot oven,mechanically crushing or cutting a battery can result in an explosion.•Leaving a battery in an extremely high temperature surrounding, or an extremely low air pressure environment may result in an explosion or leakage of flammable liquid or gas.2Y our portablespeakerCongratulations on your purchase, and welcome to Philips!To fully benefit from the support that Philips offers, register your product at /welcome.What's in the boxCheck and identify the contents of your package:Overview of the speaker Indicate battery or Bluetooth connection status.SpeakerUSB cableQuick start guide Safety sheet Worldwide warrantyLanyard3LED indicatorDC IN••Charge the built-in battery.Turn the speaker on or o .3EN3 Get startedAlways follow the instructions in this chapter insequence.Turn on/offTo turn the speaker on, press and hold" " for two seconds. You will hear theprompt sound and Blue LED indicatorblinks.Auto off in 15 minutes if no Bluetoothconnection.To turn the speaker off, press and hold" " for two seconds. You will hear theprompt sound and Blue LED indicatorturn off.Charge the built-in batteryThe speaker is powered by a built-inrechargeable battery.Connect the USB-C socket on the speaker toan outlet (5V 0.5A) by using the provided USBcable.When the speaker is being charged,Power onLED is solid Red.When the speaker is fully charged,LED is solid Blue.When the speaker is being charged,Power oLED is solid Red.When the speaker is fully charged,LED is o .4EN5EN4 Play from Bluetooth devicesWith this speaker,you can listen to audio from Bluetooth-enabled devices.1 »The LED indicator blinks blue.2 On your Bluetooth device, enableBluetooth and search for Bluetooth devices that can be paired.3 Select [Philips S1505] displayed on yourdevice for pairing and connection. If necessary, input “0000” as the pairing password.»After successful pairing and connection,you'll hear the prompt sound, and the LED indicator turns solid blue.If you cannot find [Philips S1505] on your device, hold down the Power button for 2 seconds to power off before rebooting, and long press it for 2 seconds to enter into pairing mode. 4Play audio on your Bluetooth device to start streaming music.LED indicator (blue)Solid blue ConnectedDisconnect a deviceDisable Bluetooth on your device; orMove the device beyond the communication range.»The speaker beeps twice, and the LEDindicator blinks blue.Reconnect a deviceWhen you turn on the speaker, it will reconnect the last connected device automatically; If not, select [Philips S1505] on your Bluetooth device to start connection.Press for 2 seconds to turn the speakeron.2.5W RMS 6EN5150Hz-18kHz1.5"80V5.0A2DP V1.3, AVRCP V1.6Bluetooth Profile20*The IPX7 rating means the speaker driver can be submerged for up to 30 minutes at a depth of up to 1 m.Philips S1505If you cannot find [Philips S1505] on your device, hold the for 2 seconds to power off, and then long press the button for 6 seconds to clear the pairing information / enter pairing mode.Hereby, TP Vision Europe B.V. declares that this product is in compliance with the essential requirements and other relevantprovisions of Directive 1999/5/EC. You can find the Declaration of Conformity on/support.Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion.MMD Hong Kong Holding Limited may void theuser's authority to operate the equipment.FCC StatementThis device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interferenceto radio communications. However, there isno guarantee that interference will not occurin a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna. (2) Increase the separation between the equipment and receiver. (3) Connect the equipment into an the receiver is connected. (4) Consult the dealer or an experienced radio/TV technician for help.RF Warning StatementThe device has been evaluated to meet general RF exposure requirements. The device can be used in portable exposure conditions without restriction.Trademark noticeMMD Hong Kong Holding Limited is under license. Other trademarks and trade names are those of their respective owners.The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks byEN9Specifications are subject to change without notice.Philips and the Philips Shield Emblem are registered trademarks ofKoninklijke Philips N.V. and are used under license.This product has been manufactured by and is sold under theresponsibility of MMD Hong Kong Holding Limited or one of its a liates,and MMD Hong Kong Holding Limited is the warrantor in relation to this product.TAS1505_00_UM_V1.0。
用户手册43PUS851750PUS851758PUS851765PUS8517Register your product and get support at /TVsupport内容1 主屏幕4 1.1 主屏幕和频道4 1.2 主屏幕更新4 1.3 应用程序和飞利浦电视系列41.4 打开主屏幕42 设置6 2.1 阅读安全说明6 2.2 电视支架和壁挂安装6 2.3 摆放提示6 2.4 电源线6 2.5 天线62.6 圆盘式卫星天线73 遥控器8 3.1 键概述8 3.2 将遥控器与电视配对10 3.3 语音搜索10 3.4 红外传感器11 3.5 电池113.6 清洁114 打开和关闭12 4.1 开机或待机124.2 电视上的按键125 频道13 5.1 安装频道13 5.2 频道列表13 5.3 频道列表排序13 5.4 观看频道13 5.5 收藏频道16 5.6 文本/图文电视175.7 互动电视186 频道安装19 6.1 卫星安装19 6.2 天线安装216.3 频道列表复制237 连接设备25 7.1 关于连接25 7.2 带智能卡的 CAM - CI+26 7.3 家庭影院系统 - HTS26 7.4 智能手机和平板电脑27 7.5 蓝光光盘播放机27 7.6 蓝牙27 7.7 耳机28 7.8 游戏控制台28 7.9 USB 硬盘驱动器28 7.10 USB 键盘29 7.11 USB 闪存盘29 7.12 照相机30 7.13 摄像机30 7.14 电脑308 连接 Android TV32 8.1 网络和互联网32 8.2 Google 帐户338.3 飞利浦电视系列应用程序339 应用程序35 9.1 关于应用程序35 9.2 Google Play35 9.3 启动或停止应用程序36 9.4 锁定应用程序36 9.5 管理应用程序379.6 存储3710 互联网38 10.1 启动互联网3810.2 互联网选项3811 快捷菜单3912 来源40 12.1 切换设备40 12.2 电视输入的选项40 12.3 设备名称和类型4012.4 重新扫描连接4013 网络41 13.1 网络4113.2 蓝牙4114 设置42 14.1 图片42 14.2 声音44 14.3 流光溢彩设置48 14.4 环保设置49 14.5 一般设置49 14.6 时钟、区域和语言设置51 14.7 Android 设置52 14.8 通用接入设置5214.9 锁定设置5215 视频、照片和音乐54 15.1 来自电脑或 NAS54 15.2 收藏夹菜单54 15.3 最流行菜单和最后播放菜单54 15.4 来自 USB 连接54 15.5 播放视频54 15.6 查看照片5515.7 播放音乐5616 电视指南58 16.1 您需要执行的操作58 16.2 电视指南数据5816.3 使用电视指南5817 录制和暂停电视60 17.1 录制6017.2 暂停电视6118 智能手机和平板电脑6318.1 飞利浦电视遥控应用程序6318.2 Google Cast6319 游戏64 19.1 您需要执行的操作64 19.2 游戏手柄64 19.3 通过游戏控制台玩游戏6419.4 游戏控制条6420 流光溢彩65 20.1 流光溢彩风格65 20.2 关闭流光溢彩65 20.3 流光溢彩设置65 20.4 Lounge Light 模式65 20.5 晨起闹钟66 20.6 Ambisleep66 20.7 流光溢彩扩展6620.8 Aurora6721 精品选择69 21.1 关于精品选择69 21.2 电视现有应用程序6921.3 随选视频6922 Freeview Play71 22.1 关于 Freeview Play7122.2 使用 Freeview Play7123 Netflix7224 Alexa73 24.1 关于 Alexa7324.2 使用 Alexa7325 软件74 25.1 更新软件74 25.2 软件版本74 25.3 自动软件更新74 25.4 查看软件更新历史记录74 25.5 开源软件7525.6 开源许可证7526 规格76 26.1 环境76 26.2 功率76 26.3 操作系统76 26.4 接收76 26.5 显示屏类型77 26.6 显示屏输入分辨率77 26.7 连接77 26.8 声音7726.9 多媒体7727 帮助与支持79 27.1 注册电视79 27.2 使用帮助79 27.3 故障检修79 27.4 在线帮助8127.5 支持和维修8128 安全与保养82 28.1 安全82 28.2 屏幕保养8329 使用条款84 29.1 使用条款 - 电视84 29.2 使用条款 - 智能电视8429.3 使用条款 - 飞利浦电视系列8430 版权85 30.1 HDMI85 30.2 HEVC 高级85 30.3 杜比视界和 Dolby Atmos85 30.4 DTS-HD85 30.5 DTS Play-Fi85 30.6 Wi-Fi Alliance85 30.7 Kensington8530.8 其他商标8631 关于第三方提供的服务和/或软件的免责声明87索引881主屏幕1.1主屏幕和频道要充分享受 Android电视的益处，请将电视连接至互联网。
With Azurion, performance and superior care become oneAzurion 7Image Guided Therapy System17% reduction of procedure time with Philips Azurion at St. Antonius Hospital.1The ability to treat one more patient per day today, or in the futureAzurion enables you to provide superior careAzurion helps you optimize your lab performanceAn easy-to-use platform supports you in quickly and easily performing diverse proceduresThis is exemplified by our Image Guided Therapy System - Azurion 7. It allows you to easily and confidently perform a wide range of routine and complex procedures with a unique user experience, helping you optimize your lab performance and provide superior care. Azurion is powered by ConnectOS, a real-time multi-workspot technology designed specifically for the Azurion image guided therapy platform.As the interventional space evolves, we continue to integrate essential lab systems and tools onto the Azurion platform for a better user experience. The Azurion integrated lab offers a seamless user experience that gives you control of all compatible applications from a single touch screen at table side, to help make fast and informed decisions without breaking sterility.With Azurion’s industry leading image guided therapy platform, we reinforce our commitment to you and your patients. Our goal is to help you effectively meet today’s challenges so that you are ready for the future.Treating patients. It’s what you do.You strive every day to provide the best patient care, quickly and reliably, no matter which procedure you are performing.So try to imagine an increased number of procedures, for more patients, carried out consistently and efficiently with fewerpreparation errors. Workflow can be optimized and performed on an intuitive platform designed to make your day a lot easier.“ I t (Azurion) profited from the experienceprovided by the users and it’s for sure something which is incredible easy to use.”Prof. Laurent Spelle, Hospital Bicetre AP-HP, Paris, FranceFull control at table side to enhance decision making You can now control all compatible applications in the interventional lab via the central touch screen module and FlexVision Pro. Not only does this improve workflow within the exam room, it helps reduce the need for team members to leave the sterile area and walk to the control room during procedures. This can save time and help avoid delays.Gain advanced physiologic guidance to help improve treatment outcomesYou can access IntraSight, a comprehensive suite of clinically proven 2-6 imaging, physiology and co-registration 7 tools, via the central touch screen module. These tools allow you to go beyond the angiogram and complete your view of the target vessel, to help you make fast, informed clinical decisions.Azurion with FlexArm – more independent control for physiciansThe FlexArm option further evolves Azurion’s table side control with the intuitive Axsys controller to make procedures flow naturally and easily. When changes or complications occur, the physician can quickly and easily take action. This can also reduce the need to move in and out of the sterile field during a procedure.Designed around you and your procedureAll Azurion systems and interventional tools use the same standardized user interface to support training. Use has been further simplified through a sophisticated help function. You can access digital user guides with one click for on-the-spot assistance. Clear and simple to useOn screen, information clearly stands out against the distinctive black background where active applications are highlighted. Backlit icons and distinctly shaped buttons on the Control Module promote intuitive operation. All controls are designed for easy cleaning to meet stringent sterility requirements. Less clutter and faster workflowWith the Azurion integrated lab, controlling allcompatible applications at the touch screen module can reduce extra interfaces and controls table side. The FlexSpot works according to the same principle. It gives you access to all compatible applications in one compact, customizable workplace that can be placed in the control room or exam room where needed.Save time by setting the display to re-arrange and re-size as applications are opened and closed.At Philips, we are guided by you. With Azurion, we’ve brought the userexperience and simplicity of touch screen controls right where it’s needed to make a difference to lab workflow.Outstanding user experienceFlexSpot Touch screen module ProFlexVision Pro“ T he new integrated system saves us time, because we can control all applications via one user interface.”Dr. med. Peter Ong, Robert Bosch Hospital, Stuttgart, Germany.With Azurion we help you to optimize your lab performanceAzurion’s integrated approach can help you achieve measurable improvements in throughput, cost reduction and staff satisfaction.Do more at table sideWith our enhanced touch screen module, you will experience simpler, smoother procedures, based on familiar tablet interactions. For example, you can now easily mark relevant details on 2D images on the touch screen with your fingertip.Azurion allows you to run an entire case without breaking sterilityThe touch screen module offers total control within the sterile field. Run an entire case table side as you quickly diagnose, navigate, annotate and measure to your exact specifications, even when wearing gloves and under a sterile drape. Table side control saves you from having to go to the control room to access applications.Save time through Instant Parallel WorkingThe Azurion 7 image guided therapy system has been specifically designed to save time by enabling interventional team members to do two tasks at the same time in the exam room and control room - without interrupting each other. As an example, while fluoroscopy/exposure is taking place, a technologist in the control room can instantly review previous images from the same patient, prepare the next exam or finish reporting on another patient. This leads to higher throughput and faster exam turnover without compromising quality of care.Simplify workflowEnter patient information once and it is automatically transferred to connected applications to reduce data entry errors. To save time, IntelliSpace Cardiovascular 8 and IntelliSpace Portal launch automatically with the specific patient on the exam room monitor.Azurion’s full system automatic position control (APC) gives you more flexibility to recall the stored position of the C-arm, table and other parameters for a particular image to simplify positioning.Imagine an easier work dayYou can combine different user centric workspots (FlexVision Pro, FlexSpot and touch screen modules) to view, control and run applications where and when needed. At these workspots you can co-register 9 iFR or IVUS data with the angiogram, so you have the tools in hand to manage procedure quality and patient care. Together these flexible workspots allow you to customize your workflow to boost efficiency.Safeguard clinical performance and enhance lab security over time with Windows 10 platform The standard Windows 10 platform can help support compliance with the latest security and standards to protect patient data. It can also accommodate new software options to extend your system’s clinical relevance over time.Clinical demands are getting more specific. So are we. Our clinical suites are tailored to meet your specific challenges, while offering you the flexibility to carry out procedures in the easiest, most efficient way.We have a flexible portfolio of integrated technologies and services to support the full interventional spectrum. We also offer Hybrid OR solutions that create an innovative care environment for performing open and minimally invasive surgical procedures.Simplified set-up and operationThe Azurion 7 uses a range of ProcedureCards to help optimize and standardize system set-up for all your cases. The system will automatically select the appropriate ProcedureCard(s) based on the (CIS/RIS/HIS) code of the scheduled procedure from the information system. ProcedureCards can increase the consistency of exams by offering presets (e.g. most-frequently used, default protocols and user-specified settings) on the procedure, physician or department level.In addition, hospital checklists and/or protocols can be uploaded into the ProcedureCards to help safeguard the consistency of interventional procedures and reduce preparation errors.Enhance patient care with continuous monitoring The Philips Interventional Hemodynamic System is integrated with the IntelliVue X3 patient monitor, allowing continuous patient monitoring throughout procedures in the interventional workflow. There isno need to change cables, minimizing disruption to vulnerable patients and giving you more time to focus on them. Continuous patient monitoring also results in a gap-free patient record.Increase clinical confidence with 3D imagingThe clinical application software SmartCT enriches our exceptional 3D interventional tools for interventional procedures with step-by-step guidance that is designed to remove the barriers to acquiring 3D images in the interventional lab.Easily control advanced 3D visualization and measurements at table side on the touch screen module. Studies have shown that 3D CT-like imaging can enhance diagnostic accuracy 9,10,11 and support improved patient outcomes.Azurion enables you to provide superior careAs patient volumes rise and procedures become more complex, how do you maintain high standards of quality and safety in your healthcare facility?Clinical suites “ W e always stay in the angio suite because the ease of use has really improved and now we can control everything from the side of the patient in the angio lab itself.”Prof. Vincent Costalat, Centre Hospitalier Universitaire de Montpellier, FranceHigh quality images at low X-ray doseOur ClarityIQ imaging technology provides significantly lower dose across clinical areas, patients, and operators.12 In routine coronary procedures13, ClarityIQ technology reduces patient dose by 67% without affecting procedural performance while maintaining equivalent image quality, compared to a system without ClarityIQ.14,15 In interventional Neuro procedures, ClarityIQ technology reduces patient dose by 65%, compared to a system without ClarityIQ.16 Managing dose efficientlyDoseWise is integrated across the Philips image-guided therapy Azurion portfolio. DoseWise consists of a comprehensive range of radiation dose management tools, training, and integrated product technologies that aim to help you take control over patient care, staff safety, and regulatory compliance. Another feature is the Zero Dose Positioning function. It lets you pan the table, change table height or field-of-view on your Last Image Hold (LIH) image. This enables positioning without the use of radiation on previously recorded last image.Managing dose across your organizationPhilips DoseAware provides real-time feedback in the exam room It displays the invisible nature of radiation in real time, so that you and your staff can see it promptly, easily and simply – and rapidly understand the effect of behavior changes and work patterns.DoseAware Xtend is a dedicated solution for treatment rooms that builds on the capabilities of DoseAware and interfaces seamlessly with the Azurion image-guided therapy system. Thanks to this seamless integration, DoseAware Xtend can provide live individual dose rates (live screen) during procedures, and summarized procedure doses (review screen). It also reminds staffto better protect themselves by providing a warning symbol when the lead protection screen is not being used properly.Perform standardized quality assurance verifications in just 5 minutes17To make it easier for you to routinely perform consistent verification tests of radiation dose and image quality, only Philips offers the User Quality Control Mode (UQCM) tool on its Azurion system.With this option, you can independently verify and audit the radiation and image quality related factors of your Azurion system in a standardized way in just5 minutes, as well as carry out a range of validation and quality assurance tests.High standards of safety and low radiation exposureAs you look for new radiation dose management strategies to continue to enhance patient and staff safety, while maintaining and enhancing yourlevel of care, we can support you in meeting your goals.Azurion – a comprehensive image guided therapy platformThe Azurion 7 integrated lab brings together a range of sophisticated interventional tools, including clinically proven 2-6 imaging and physiology tools, advancedhemodynamic measurements and cardiac informatics to support clinical excellence during procedures.Azurion 7 C/F12With its 12" Flat Detector, the 7 Series provides high-resolution imaging over a large field-of-view with flexible projection capabilities, making it ideal for cardiac interventions. The entire coronary tree can be visualized in a single view with minimal table panning.Azurion 7 C/F20Enhance visibility for diverse cardiac and vascular procedures with the excellent image quality and broad coverage of the next generation 20" Flat Detector. This system supports head-to-toe imaging and patient access from all sides.Azurion 7 C20 with FlexArmCreate a Hybrid OR that provides unlimited imaging flexibility for diverse procedures and exceptional positioning freedom for medical teams with the Azurion 7 and the next generation 20" Flat Detector, combined with the ceiling-mounted FlexArm option. You get a highly cost-effective environment that is ready for the procedures of the future.Azurion 7 C20 with FlexMoveMove to a Hybrid OR with confidence, with the Azurion 7 and the next generation 20" Flat Detector, combined with the ceiling-mounted FlexMove option. FlexMove offers exceptional workflow flexibility to perform open and minimally invasive procedures in the same room.Azurion 7 B12/12The Azurion 7 biplane system with two 12" Flat Detectors provides high-resolution imaging and positioning flexibility to reveal critical anatomical information during congenital heart and electrophysiology procedures.Azurion 7 B20/12The Azurion 7 biplane system with a 20” and 12” Flat Detector provides exceptional clarity of detail and navigational precision to support a wide range of challenging cardiac and vascular interventions.Azurion 7 B20/15Enhance insight and certainty during neuro interventions with the Azurion 7 biplane system. It pairs a 20" frontal with a 15" lateral detector.information,pleasecontactyoursalesrepresentativeorsendanemailto:***************************High productivity combined with low cost of ownershipWith Philips, you get the best service performance which enables you totreat more patients, and professional support to help you deliver cost-efficient care.Best service performance18 enables you to treatmore patients19Staying on top of today’s complex healthcareenvironment is challenging enough without aconstant concern of keeping your systems up andrunning smoothly. With Philips, your operationsare protected by the best overall service engineerperformance for imaging systems according to IMVServiceTrak for 5 years in a row. Philips remotelyconnected systems provide 135 more hours ofoperational availability per year, enabling you totreat more patients.Professional support helps you delivercost-efficient careTo help you fully leverage your financial,technological and staffing resources and realizea high return on your investment, we offerprofessional support through our experiencednetwork of over 7,000 field service engineers, aswell as a flexible service offering that includes:• Innovative financing solutions tailored to meetthe needs of healthcare organizations• A broad range of healthcare consulting programsto help your organization further enhance theefficiency and efficacy of your care deliveryprocess• Philips Healthcare Education can help unlockthe full potential of your staff, technology andorganization to meet new challenges throughinnovative, meaningful and evidence-basedhealthcare education.Cost-effectively manage future upgrades withthe Technology Maximizer programTechnology Maximizer is a program that runs intandem with your Philips Service Agreement.20When you opt into the program, you receivethe latest available software and hardware21technology releases for a fraction of the cost ofpurchasing them individually. The TechnologyMaximizer Plus allows you to further tailorupgrades to reduce costs. No need to wait forbudget approval.No need to buy individual upgrades. Just a cost-effective way to manage ongoing technologyupgrades through your operational budget.Doing business responsibly and sustainablyWhen you choose Philips, you are choosing apartner committed to meet sustainability andcircular economy ambitions. As a leading healthtechnology company, our purpose is to improvepeople’s health and well-being through meaningfulinnovation, positively impacting 2.5 billion lives peryear by 2030.The Azurion is the result of our EcoDesign processand offers significant environmental improvements:• 100% product take-back after customers’acceptance of our trade-in offer.• 100% repurposing of the equipment that isreturned to Philips• Up to 90% of material weight is reused duringrefurbishing, depending on type and age ofproduct• At least 10% lower energy consumption over totalproduct life usage22Read more about our Environmental, Social andCorporate Governance (ESG) commitments here:https:///a-w/about/sustainability.html135 more hours of operational availability on average, per year,enabling you to treat more patients.19Philips remotely connected systems provide1.2.3.4.5.6.7.8.9. 10.11.12.13.14.15.16.17.18.20.22.**********************。
For more than 130 years, we have been creatingmeaningful innovations to improve people’s lives and make the world more sustainable. We are inspired to continually advance the state of precision diagnosis with customer- and patient-centric solutions that deliver clear care pathways and predicable outcomes.In MR, our mission is to achieve a fast, fully automated, and personalized exam for every patient, while acting responsibly towards our planet and society. With AI 1-driven smart connected imaging, optimized workflows, and integrated clinical solutions, we improve your MR department’s productivity, enhance patient and staff experience, and deliver high quality diagnostic outcomes.With this we bring you MR Workspace, our break-through AI 1 engine that delivers efficiency in your daily schedule and consistent image quality to your department.Our vision23P h i l i p s M R W o r k s p a c eContentThe control room:essential to departmental workflow Customize your solution to fit your needs MR Console Plus:Your staff. Satisfied.MR Day Manager:Your schedule. Under control.MR Console Pro:Your workload. Managed.The control room:essential to departmental workflowFast protocols and advancements in patient handling and positioning have brought improvements to MR workflow. However, because inefficiencies in the control room still exist, MR departments struggle to achieve consistent quality and optimal workflow efficiency. Difficult-to-learn exams, complex post-processing, and disconnected schedule management contribute to problems ranging from stressed staff to patient rescans. MR Workspace is the key to bridging these challenges with ease, helping to alleviate technologists’ workload so they can focus beyond just the monitor and on what really matters: the patient.Designed with deep knowledge of day-to-day MR operations, MR Workspace supports efficiency and staff satisfaction in the control room through intelligence, guidance and ease of use. Technologists can prepare exams before patients arriveand aim to achieve consistent quality regardless ofexperience, by using Protocol Assistant, an AI1-drivensolution that learns your protocol preferences andsuggests the most appropriate ones based on clinicalindication.Advanced visualization includes step-by-step guidance sotechnologists can begin post-processing, delivering more2diagnostic information to the radiologist, thus savingreporting time.The intuitive interface, large display of clinical images andessential parameter reveal contribute to outstanding ease-of-use. In addition, MR Workspace helps to keep scheduleson track and makes parallel tasking easy so technologistscan focus on the current patient.Increase scheduleefficiencyWith MR workspace we aim to support you to:Deliver consistentimage qualityImprove staffexperienceReducetraining timeProvide fastertime to resultsGive your staff what they need to do the job right• 80% of examination planning is fully automated• 70% of the display is dedicated to presenting clinical images in crisp detail • Harmonized user experience with IntelliSpace Portal Advanced VisualizationFast forward from learning to doing• Integrated AI 1 assistance, task guidance, and automation • Step by step coaching towards AV analysis • 50% reduction in on-screen parametersBe known for fast results• Results sent to PACS in 30% less time 3• Automated AV segmentation, calculation, and map generation • Comprehensive set of integrated high-end and routine AV applicationsKnow what is coming your way every day• Full visibility and control over daily schedule • Examination preparation before patient arrival • Alerts on patient conditions and schedule changes9Count on image quality. Every, single time• Guided and automated workflow• AI¹ Protocol Assistant suggests the most used protocol • Real-time quality controlYour control room engine for a smooth running departmentMR Console Plus:11MR Console Plus:MR Console Pro:Your workload. Managed.MR Day Manager:Your schedule. Under control.Puts your staff in control of the dailyschedule and supports consistentresults with AI1-driven technology.Supports patient focus while enablingparallel tasking, making workproductive and satisfying.1315MR Console Plus: Your staff. SatisfiedMR Console Plus is the core of MR workspace, providing an intuitive interface, large image viewports, essential parameter reveal, task guidance, and access to other available smart features. This potent combination has the potential to reduce staff training time. Early results 4 show thattechnologists feel that MR Console Plus increases their confidence.Increase staff satisfaction with ease-of-useWhen technologists use MR Console Plus for the first time, they will be struck by how the user interface delivers an intuitive and enjoyable user experience. Diagnostic images are front and center: more than 70% of the display is dedicated to presenting clinical images in crisp detail. This large viewing area helps to enable focus, making it easier to assess image quality while the patient is on the table. The most relevant parameters are presented as the default display, reducing screen clutter. All other parameters are accessible at the touch of a button.Reduce workload and achieve consistent resultsReduce workload and image variability through guided and automated workflow assistance to support onyour aim of delivering consistent results independent of technologist experience.Smart integrated featuresSmartExamuses the power of AI 1 to automate geometry planning and execution of complete MR exams.5 With SmartExam, single click.ScanWise Implant 6entire examination.AutoVoiceand provides breath hold guidance.14P h i l i p s M R W o r k s p a c e17* This product is not CE marked and not available for sale in all countries.Access clinical enhancements and insightsAccess, analyze and quantify data in one unified view, covering multiple clinical domains, including neurology, oncology and cardiology. MR Console Plus brings you clinical enhancements and insights through to a comprehensive set of high-end and routine Advanced Visualization applications, such as Permeability Analysis* and Cartilage Assessment*, that are seamlessly integrated at your fingertips. MR Workspace Advanced Visualization shares the same harmonized user experience as the IntelliSpace Portal solution, which may help to reduce training requirements and allowing you to streamline and scale your AV functionality from the console to an enterprise AV solution.Expert guidance for efficient post-processingSupport consistency in post-processing regardless of technologist expertise and experience. Every AV app includes user guidance that coaches technologists step-by-step. When AV processes require handoff, the technologist can begin the analysis, save their work, and send it to a radiologist anywhere within the enterprise, who can pick up where the technologist finished.This shortens time-to-report by reducing post-processing and potentially reduces reading time for radiologists. AV results are sent to PACS in 30% less time 3.16P h i l i p s M R W o r k s p a c e19MR Day Manager:Your schedule. Under control.Patients who need extra time and reassurance, critical patients from the emergency department and unexpected requests for inpatient studies can make it challenging to stay on schedule. MR Workspace puts your staff in control of the daily schedule with the industry-exclusive MR Day Manager.MR Day Manager allows technologists to plan exams before the scheduled time, which decreases time spent gathering data when the patient arrives. With vitalpatient and schedule information from the HIS/RIS fully integrated in MR Day Manager and available at the click of a mouse, technologists can assign ExamCards before the patient arrives, anticipate roadblocks, and prepare for special situations by entering MR Conditional implant information, pregnancy status, and ambulatory information. MR Day Manager also alerts technologists when a patient has arrived.Controlling schedule drift may decrease patientwaiting times, enhancing the patient experience. It also potentially may decrease staff overtime and enable higher patient throughput.Schedule information• When does the next exam start?• Am I running on schedule?• Who is the next patient?• Are there any notes for this exam?• Did the patient arrive?Patient characteristics• Is this an in- or out-patient?• Does this patient have an implant?• Is this patient pregnant?• Is contrast required for this study?• Are there breathholds in this study?Guidance on open tasks• Is an ExamCard selected?• Are there open post-processing tasks?• Is experting finished?• Is all mandatory info filled in?18P h i l i p s M R W o r k s p a c e21AI-driven to deliver consistent results MR Day Manager’s Protocol Assistant introduces the advantages of AI 1 for all examinations and anatomies, recognizing your preferred protocols for each clinical indication and suggesting the most used protocol for the clinical indication. Protocol Assistant visually indicates the quality of the match, eliminating guesswork and supporting your aim to deliver consistent quality over multiple exams.When needed, a technologist can overrule recommendations or reset learnings when new protocols are updated or preferred. You can export the Protocol Assistant database to your other Philips scanners, so there is consistency throughout the department and new scanners instantly have the same database to consult.23MR Console Pro: Your workload. Managed.The number of parallel tasks that must be performed in the control room by the technologist is staggering. Often, keeping on schedule requires finishing with post-processing one exam or preparing for the next patient while also scanning a patient. Technologists need tools that will help them to efficiently parallel task without stress, while keeping focus on the patient and achieving quality results with confidence.MR Console Pro supports patient focus while enabling parallel tasking, making work productive and satisfying. The high-definition dual monitor set-up allow the technologists to:✓ Never lose sight of your current patient, even while parallel tasking ✓ Assess the quality of the current exam real-time which may help you to detect motion artifacts without sharing a screen with other tasks ✓ Finish post-processing without delaying the next patient ✓ Perform advanced visualization to obtain more diagnostic information without toggling between screens In high volume departments as well as those that sometimes operate with a single technologist in the off-hours, the ability to parallel task provides a significant level of clinical workflow control and ensures that patient focus is always maintained.22P h i l i p s M R W o r k s p a c eConfidence for MR conditional implants The exam starts automatically when door closes.Automated post-processing Post processing with guidance and automation is fully integrated.Automated planning and scanning with AI The AI engine streamlines geometry planning and execution of complete MR exams.AI reconstruction at the source No compromise on speed and quality by using AI at the source of image reconstruction.Plan your day in advance See the entire schedule in advance and prepare exams before patient arrival.Automated patient coaching Patients get informed with automated instructions and announcements throughout the exam.Smart Workflow in the control room 25MR Smart Workflow in the control room Work smart from the start With Philips MR Workspace, you can create highly personalized exams of virtually any patient, even your most challenging ones and with MR Smart Workflow you can even work smarter from the start. Smart Workflow simplifies MR exams at every stage of the process – in the exam room and in the control room. It takes advantage of AI technology to guide and coach operators where needed and automate where possible. Smart Workflow eliminates time-consuming manual tasks, so your MR staff has the bandwidth to efficiently watch over patients of varying conditions and deliver the consistent quality care they deserve.Focus on patients, not technology Imagine automating planning of 80% of MR examinations – directly at the MR console. MR Smart Workflow with MR Workspace makes it possible. Your staff can spend less time with manual tasks and focus more on who matters most, the patients. Even inexperienced operators can scan with confidence, giving patients peace of mind that they’re in good hands – and leading to consistent quality MR results.Automated patent-centric workflow can enhance productivity, increase throughput, and improve the MR experience – for patients and staff alike 24P h i l i p s M R W o r k s p a c e。
EnglishIntroductionCongratulations on your purchase and welcome to Philips! To fully benefit from the support that Philips offers, register your product at/welcome.General description (fig. 1)1Trimming guard2Cutting unit3On/off button4Socket for small plug5Small plug6Battery charge indcator7Supply unitnot shown: cleaning brushImportant safety informationRead this important information carefully before you use the appliance and its accessories and save it for future reference. The accessories supplied may vary for different products.Danger-Keep the supply unit dry (Fig. 2).Warning-To charge the battery, only use the detachable supply unit (A00390) provided with theappliance.-The supply unit contains a transformer. Do not cut off the supply unit to replace it with another plug, as this causes a hazardous situation.-This appliance can be used by children aged from 8 years and above and persons withreduced physical, sensory or mental capabilities or lack of experience and knowledge if theyhave been given supervision or instructionconcerning use of the appliance in a safe wayand understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made bychildren without supervision.-Always check the appliance before you use it.Do not use the appliance if it is damaged, asthis may cause injury. Always replace adamaged part with one of the original type.-Do not open the appliance to replace the rechargeable battery.Caution-This appliance is not washable. Never immerse the appliance in water and do not rinse it under the tap (Fig. 2).-Only use this appliance for its intended purpose as shown in the user manual.-For hygienic reasons, the appliance should only be used by one person.-Never use compressed air, scouring pads, abrasive cleaning agents or aggressive liquidssuch as petrol or acetone to clean theappliance.-Do not use the supply unit in or near wall sockets that contain an electric air freshener to prevent irreparable damage to the supply unit. Electromagnetic fields (EMF)This Philips appliance complies with all applicable standards and regulations regarding exposure to electromagnetic fields.General-The supply unit is suitable for mains voltages ranging from 100 to 240 volts.-The supply unit transforms 100-240 volts to a safe low voltage of less than 24 volts. ChargingCharge the appliance fully before you use it for the first time and after a long period of disuse.It takes approximately 10 hours to fully charge the appliance. When it is fully charged, the appliance has a cordless operating time of up to 45 minutes. 1Make sure the appliance is switched off.2Insert the small plug into the appliance (Fig. 3). 3Put the supply unit in the wall socket.-The charging light on the supply unit lights up green to indicate that the product is charging.Note: The charging light on the supply unit does not change color and does not go out when the product is fully charged.from 11 length settings ranging from 0.5mm to10mm (1/32in. to 13/32in.).1Slide the trimming comb straight into theguiding groove of the appliance (Fig. 5).2Turn the zoom wheel to the desired setting (Fig.6). The desired hair length setting is shown inthe center of the zoom wheel.3Switch the appliance on.4To trim most effectively, move the applianceagainst the hair growth direction. Make surethat the surface of the comb always stays inthe brush or rinse it under the tap.5Carefully shake off excess water and let air drycompletely.6Insert the lug of the cutting unit into the guidingslot and push the cutting unit back onto theappliance (Fig. 12).Ordering accessoriesTo buy accessories or spare parts, visit/service or go to yourPhilips dealer. You can also contact the PhilipsConsumer Care Center in your country (see theinternational warranty leaflet for contact details).Recycling-Do not throw away the product with the normalhousehold waste at the end of its life, but handit in at an official collection point for recycling.By doing this, you help to preserve theenvironment.-This product contains a built-in rechargeablebattery which shall not be disposed of withnormal household waste. Please take yourproduct to an official collection point or aPhilips service center to have a professionalremove the rechargeable battery.-Follow your country’s rules for the separatecollection of electrical and electronic productsand rechargeable batteries. Correct disposalhelps prevent negative consequences for theenvironment and human health.BT3206© 2018 Koninklijke Philips N.V.All rights reserved选择，长度范围在 0.5 毫米到 10 毫米（1/32 英寸到13/32 英寸）之间。
Technology BackgrounderDiagnostic X-rayAs a global player, Philips provides a full digital radiography (DR) portfolio. Known as a vendor of premium DR rooms and mobile units, Philips is expanding access to health care for those with limited budgets and a need for clinical excellence. With more than 100 years of radiography experience, including 20 years of DR experience, Philips has established a foundation of innovative DR solutions that meet the needs of patients and health care providers.Philips PrimaryDiagnost DRNot available for sale in North AmericaPrimary radiography requirements are the ‘must-have’ diagnostic functions essential to general radiography examinations. Philips has designed the PrimaryDiagnost DR to be the only system necessary for these key tasks. It unites general radiography functionality with ease-of-use and reliability. Users benefit from high cost effectiveness throughout the product lifetime. The system consists of a tethered portable detector that works with the X-ray table, on the vertical stand, and for free exposures. It is managed by the intuitive Eleva user interface and requires only three clicks to complete an X-ray examination. The geometry can be adapted quickly for sitting, standing and supine patients, in various positions, to support a wide range of DR applications. All components are counter balanced for easy manual movement and can be placed around the patient.PrimaryDiagnost DR’s single detector configuration is an affo rdable way to extend clinical capacity and offer imaging services based on Philips imaging technology. It has been designedto streamline the examination process, thus giving staff time to focus on patient care, and outcomes.Philips DuraDiagnost (Rel. 3)Not available for sale in North AmericaThe family of DR products is an attractive solution for health care providers with a limited budget but a demand for fast digital workflow. The DuraDiagnost comes with a number of high-end Philips benefits, such as customizable room configurations, the Eleva user interface and UNIQUE image processing, for improved economic value.The Value room configuration offers a cost-effective opportunity to enter the DR workflow. Central to this performance oriented solution is SkyPlate, a single, lightweight (2.8kg), cassette-sized, wireless portable detector. SkyPlate can be easily moved between table and vertical stand to accommodate a wide variety of chest, abdominal and extremity examinations. Ease of use and exam versatility makes this solution a sensible choice. By sharing the SkyPlates between compatible Philips DR systems, cost efficiency can be pushed one step further.With DuraDiagnost, digital radiography rooms can be tailored according to clinician needs, from a fully featured dual-detector room to a versatile single-detector system. DuraDiagnost rooms are floor-mounted digital radiography systems designed to fit in examination rooms with normal ceiling heights. Workflow features, such as a floating tabletop and default Source-to-Image-Distance (SID) positions, simplify examination processes.“With DuraDiagnost we are able to provide our patients with personalized medical care and at the same time remain within a reasonable budget,” said Dr. Kathrin Scharfetter, medical specialist for Diagnostic Radiology and Pediatric Radiology, Radiology Center Eppendorfer Baum, Hamburg, Germany.From left to right: DuraDiagnostEfficiency room, Value room, Focus room, Chest room, Compact roomPhilips MobileDiagnost wDR (Rel. 2)Not available for sale in North AmericaPhilips MobileDiagnost wDR offers the superb quality and full efficiency of Philips’ premium digital radiography rooms designed into a flexible and easy-to-maneuver mobile X-ray system. Quick decisions are made possible thanks to rapid image availability via the lightweight SkyPlate detectors, Philips cassette-sized wireless portable detectors. By sharing the SkyPlates between compatible Philips DR systems cost efficiency can be pushed one step further. To facilitate the daily workflow, SkyFlow, the scatter correction algorithm, provides high chest image contrast without grid handling.“The MobileDiagnost wDR makes you feel that you’re a part of the future of X-ray technology,” said Susan Doheny, senior radiographer, Galway Clinic, Galway, Ireland. “Having the ability to send images wirelessly greatly improves efficiency. The radiologist can have the imagesre ported within minutes, and this report can be made available throughout the hospital.”The MobileDiagnost wDR is designed for the aggressive demands of busy medical facilities. Once the system is positioned around the patient, the MobileDiagnost wDR acquires images in just a few seconds and sends them wirelessly to the hospital network. The combination of the MobileDiagnost wDR system’s UNIQUE image processing algorithm and intuitive Eleva interface allows technologists to react swiftly and perform a multitude of difficult examinations with ease.With the easy-to-maneuver MobileDiagnost wDR every area of the hospital can be reached –new levels of imaging flexibility can be achieved.Philips ProGradeNot available for sale in North AmericaPhilips new ProGrade solution converts analog BuckyDiagnost X-ray rooms to full Philips digital without the hassle and expense of geometry replacement. One day is all it takes. By adding Philips new SkyPlate cassette-sized wireless portable detectors and an Eleva workspot, premium digital imaging, enhanced digital productivity and high patient throughput can be achieved. By sharing the SkyPlates between compatible Philips DR systems cost efficiency can be pushed one step further.Importantly, customers can stay within the trusted Philips family for a truly integrated digital workflow and excellent service support from a single point of contact.ProGrade transforms an examination room on many levels with powerful advantages: ∙Cost effective upgrade of your Bucky equipment to premium Philips digital∙Fully integrated with Eleva for one common platform and smart digital workflow∙High quality digital imaging added to a Bucky systemPhilips ProGrade is a big step up in capabilities without a big change in examination room or investment.Philips DigitalDiagnost (Rel. 4)Not available for sale in North AmericaPhilips DigitalDiagnost is setting the standard in high-end digital radiography, from exceptional performance and flexible rooms to a cutting edge emergency setup. The new release offers SkyPlate detectors, Philips extremely lightweight wireless portable detectors, allowing for enhanced economic value when used in trays instead of a fixed detector. By sharing the SkyPlates between compatible Philips DR systems, cost efficiency can be pushed one step further.DigitalDiagnost allows health care professionals to further customize radiography rooms to match each health center’s clinical and financial needs. DigitalDiagnost can be scaled according to individual application requirements, room conditions and budgetary considerations from single to dual, or even triple detector systems. Health care providers can choose from multiple table designs and vertical stands. Overall, the DigitalDiagnost system is ergonomically designed to enhance the examination experience for both patient and provider.Based on the Eleva concept, the DigitalDiagnost allows for smooth digital workflow and rapid results with excellent UNIQUE image quality to help clinicians make quick decisions in time-critical environments.“With DigitalDiagnost we obtain high quality images irrespective of the type of detector used, whether fixed or wireless, or whether used internally or positioned outside of the Bucky tray,” said Luca Crespi, M.D., chief radiologist, Humanitas Mater Domini, Castellanza VA, Italy.From left to right: DigitalDiagnostHigh performance room, Flex room, Value room, Chest room, Emergency roomJuno DRFThe Juno DRF digital flat-detector system for both radiography and fluoroscopy examinations allows for increased workflow and patient throughput due to enhanced room utilization, which can positively influence your return on investment.The system is capable of a wide range of applications, including all common radiographic procedures, gastrointestinal studies, tomography, and vascular studies. Its unique SID of 180 cm (71in.) and table capacity of up to 284 kg (626 lbs), without any restrictions for movement, allows for diverse exam and patient types.“The flexibility of Juno DRF helps increase patient throughput and efficiency,” said Dr. Olivier Vanovermeire, radiologist, AZ Groeninge Hospital, Kortrijk, Belgium. “We consider this a positive return on investment since the single system configuration enables both radiology and fluoroscopy examinations.”SkyPlate – our lightest, most portable detectorNot available for sale in North AmericaSkyPlate makes performing exams quickly and easy.SkyPlates can be stored directly in the system so youalways have them within reach – along with the sparebattery. (The MobileDiagnost spare battery is chargedin the unit). Use the SkyPlate that matches the examrequirements – either the large 35x43 cm (14x17”), orthe small 24x30 cm (approx. 10x12”).The large SkyPlate comes in handy for free exams and OR tables. The smaller-sized SkyPlate is tailor-made for common incubators at the NICU, as well as adult shoulder, skull and extremity views.SkyPlate’s weight – large is only 2.8 kg, small is only 1.6 kg, including Battery – sets an industry standard. Despite its light weight, SkyPlate offers superb image resolution and sensitivity with excellent X-ray dose efficiency. It uses the same premium Cesium Iodide (CsI) detector technology as in Philips flagship DR systems.Philips SkyPlates are available in two sizes for MobileDiagnost wDR Rel 2, ProGrade, and DigitalDiagnost Rel. 4 systems. DuraDiagnost Rel 3 only offers a large SkyPlate.SkyFlow – let your work flow with SkyFlowNot available for sale in North AmericaWith SkyFlow, Philips offers a novel technology that allows clinicians to combine the ease of a grid-less acquisition workflow with the contrast of a grid image for bedside chest radiography. It supports an efficient workflow by providing a consistent grid-like image impression for a wide range of patient types. Without any user interaction or implications on workflow, SkyFlow enhances image contrast as a grid would.∙Fast and smooth grid-less workflow with fully automatic image contrast enhancement ∙Excellent image quality with grid-like contrast for all patients types, including bariatric ∙Outstanding patient focus with automatic operation, short exam times and comfortable positioningSkyFlow is available for Philips MobileDiagnost wDR Rel. 2 and DigitalDiagnost Rel. 4 systems. Diagnostic confidence with UNIQUEAs image processing is of major importance in creating consistent,high-resolution image quality for all anatomical areas, Philips hasalways placed special emphasis on this area of radiography. AtECR 2014, Philips again demonstrates the excellent image qualityPhilips UNIQUE image processing software is capable ofachieving. Regardless of the digital Philips radiography modality inwhich the image is acquired, the parameters for all systems and detectors are the same. The image can be viewed and evaluated from any suitable monitor, providing flexibility and enhancing diagnostic confidence. UNIQUE image processing supports excellent X-ray dose management, as well as workflow efficiencies.Eleva concept – convenient and efficientPhilips continues to implement the successful Eleva conceptacross more Philips radiography and fluoroscopy systems,providing a convenient and efficient workflow for dedicated patientcare. Designed in close cooperation with technologists, the Elevauser interface facilitates ease-of-use, because all functions are ergonomically positioned. The monitor workstation is equipped with tools and controls on a single user interface that is intuitive to the user and requires minimal interaction. Automatic parameter settings for each patient and a high degree of customization can expedite workflow. Furthermore, systems can be smoothly integrated into existing environments due to Eleva’s state-of-the-art technology and embedded security standards.Ambient ExperiencePhilips Ambient Experience is designed to make hospitalvisits less stressful for the patient. The AmbientExperience complements the Philips DigitalDiagnost andthe EasyDiagnost Eleva DRF room solutions. Thisexciting addition provides a unique opportunity toenhance X-ray rooms, boost clinical investment andestablish a competitive advantage. Customers canchoose to install the complete Ambient Experiencesolution or simply select Ambient Cove Lighting.Dynamic colored lighting, thematic wall projections and audio elements are carefully integrated to engage the senses. This positive distraction may reduce patient anxiety and increase comfort during an exam. Furthermore, in an uncluttered, ergonomically designed work environment, staff can move around more freely to improve workflow.For more information, additional materials and images, go to /ECR and click on the “News Center” tab.。
飞利浦写软件、解PCK全攻略飞利浦手机很多手机如859，855，825，826，9@9C，820,620,630等已进入维修期，出现如开机定屏，不定时死机等故障，此类故障大多由于CPU虚焊和软件问题引起，但当我们处理软件故障时，用编程器把从另外一台好机读出的资料复制到有软件故障的故障机，可开机但又出现PCK锁，怎么办呢？本文就针对用飞利浦6353，6354，6357CPU的飞利浦手机写软件，解PCK的问题，将本人的使用方法与各位分享，不当之处，还望多多指正！方法和步骤：1：用128或免拆把资料写到手机字库（48资料和免拆资料不能通用，但可以用UP128互转。
）2：解PCK写字库工具：1：UP128/192/256/1024；可备份全字库和写全字库，对于一些不联机的手机要用此方法，优点是安全快捷，(如9A9++用UP128写字库)1）打开128程序，选型号M36DR432A,打开PHILIPS 9@9++资料，2）按编程按钮，待编程完成即可。
3）写完后手机就可以开机了，最后进行解PCK操作2：DWLDEV和DOWN5.0；Philips公司原厂刷机工具，免狗，用普通数据线即可，可以写全字库、空字库，采用块擦除的方式，即：边擦除边写入！DWLDEV和DOWN5.0没有解PCK锁功能，写完字库要解PCK锁！使用方法：（以PHILIPS 9@9++为例）1:运行软件后，如下图，先设置好端口，在select a project中选择“5087-RAM 16bits(X16，X16WAP，V21，WAD，X38，Z10）”，KEEP LOSE选择开关置于LOSE端 OFF ON选择开关置于ON端。
2：单击select a file,然后选择正确的文件，单击打开3：单击START，弹出下图界面，然后迅速按手机开机键。
4：如下图，软件自动读出手机字库型号，然后将资料写入手机。
5：大约几分钟字库写完后软件弹出下图界面，写完后手机就可以开机了，最后进行解PCK操作。
用户手册65PUF956775PUF9567Register your product and get support at /TVsupport内容1 遥控器 31.1 按键概述31.2 将遥控器与电视配对41.3 语音搜索41.4 红外接收器42 频道安装 52.1 自动搜索频道52.2 手动设定频道52.3 安装数字频道53 连接设备 63.1 关于连接64 打开/关闭智能电视 85 设置 95.1 画面95.2 声音115.3 节能设置145.4 通用设置145.5 语言设置155.6 通用接入设置165.7 频道锁166 视频、照片和音乐 176.1 来自电脑或 NAS176.2 收藏夹菜单176.3 最流行菜单和最后播放菜单17 6.4 来自 USB 连接176.5 播放视频176.6 查看照片186.7 播放音乐197 电视指南 217.1 您需要执行的操作217.2 电视指南数据217.3 使用电视指南218 环景光设置 228.1 打开或关闭环景光228.2 环景光风格228.3 自定义色彩228.4 助眠模式228.5 环景光扩展228.6 环景光高级设置238.7 环景光APP239 软件 2510 Open Source 2610.1 开源软件2610.2 开源许可证2611 故障排除 2711.1 一般电视问题2711.2 电视频道问题2711.3 画面问题2711.4 声音问题2711.5 连接问题2711.6 网络连接问题2711.7 联系我们2712 规格 2912.1 环境2912.2 显示屏输入分辨率2912.3 多媒体2913 安全与保养 3013.1 安全3013.2 屏幕养护3114 使用条款 3214.1 使用条款 - 电视3215 版权 3315.1 HDMI3315.2 Dolby Atmos 和 Dolby Vision3315.3 DTS-HD3315.4 DTS Play-Fi3315.5 HEVC3315.6 PHILIPS 盾牌3315.7 SDoC3315.8 其他商标3316 关于第三方提供的服务和/或软件的免责声明 35索引 361遥控器1.1按键概述顶部1- 待机 / 开机在电视开机时将其切换到待机。
Important information leaflet 重要信息手册Register your product and get support at/welcome4239.000.8054.1introductionCongratulations on your purchase and welcome to Philips! T o fully benefit from the support that Philips offers,register your product at www.philips. com/welcome.importantRead this user manual carefully before you use the appliance and save it for future reference.Danger-Never immerse the appliance in water or any other liquid,nor rinse it under the tap.-Beware of hot steam that comes out of the steamer.Steam can cause burns.Warning-Check if the voltage indicated on the appliance corresponds to the local mains voltage before you connect the appliance.-Do not use the appliance if the plug,the mains cord or the appliance itself shows visible damage,or if the appliance has been droppedor leaks.-Always return the appliance to a service centre authorised by Philips for examination or repair.Do not attempt to repair the appliance yourself, otherwise the guarantee becomes invalid.-If the mains cord is damaged,you must have it replaced by Philips,a service centre authorised by Philips or similarly qualified persons inorder to avoid a hazard.-Never leave the appliance unattended when it is connected to the mains.-This appliance can be used by children aged 8 or above and by persons with reduced physical,sensory or mental capabilities or lack of experience and knowledge if they have been given instructions in safe use of the appliance or supervision to establish safe use and if they have been made aware of the hazards involved.-Do not allow children to play with the appliance.-Keep the appliance and its mains cord out of the reach of children younger than 8 when the appliance is switched on or is cooling down. -Children aged 8 or above are only allowed to clean the appliance under supervision.-The nozzle of the steamer head can become extremely hot and may cause burns if touched.-Always unplug the appliance before you clean it,attach or detach the brush attachment and before you refill the water tank.Caution-Only connect the appliance to an earthed wall socket.- Do not place the appliance on a surface with the steamer head touching the surface while the appliance is hot/connected to the mains. -Check the mains cord regularly for possible damage.-Do not let the mains cord come into contact with hot steam when it the appliance is in operation.- Do not use the appliance when the water tank is empty.-When you leave the appliance even for a short while,switch off and unplug the appliance.-When you have finished steaming,always switch off and unplug the appliance and let it cool down for 60 minutes before you clean it,attach or detach the brush attachment,empty the water tank or store it.-This appliance is intended for household use only.-Never drag or pull the appliance across the floor.-Steam may damage or cause discolouration of certain wall or door finishes.T ype of water to be used-Y our appliance has been designed to be used with tap water.In case you live in an area with very hard water,fast scale build-up may occur.Therefore,it is recommended to use distilled water to prolong thelifetime of your appliance.-Do not put perfume,vinegar,starch,descaling agents,ironing aids or other chemicals in the water tank,as your appliance is not designed to work with these chemicals.Electromagnetic fields (EMF)This Philips appliance complies with all standards regarding electromagnetic fields (EMF).If handled properly and according to the instructions in this user manual,the appliance is safe to use based on scientific evidence available today.Environment-Do not throw away the appliance with the normal household waste at the end of its life,but hand it in at an official collection point forrecycling.By doing this,you help to preserve the environment (Fig.1).guarantee and serviceIf you need service or information or if you have a problem,please visit the Philips website at or contact the Philips Consumer Care Centre in your country.Y ou find its phone number in the worldwide guarantee leaflet.If there is no Consumer Care Centre in your country,go to your local Philips dealer.简介感谢您的惠顾，欢迎光临飞利浦！为了您能充分享受飞利浦提供的支持，请在 /welcome 上注册您的产品。
Register your product and get support at/welcomeAZ1834E N User manual1 ImportantS afetya Read these instructions.b Keep these instructions.c Heed all warnings.d Follow all instructions.e Do not use this apparatus near water.f Clean only with dry cloth.g Do not block any ventilation openings. Install in accordance with themanufacturer’s instructions.h Do not install near any heat sources such as radiators, heat registers, stoves,or other apparatus (including amplifi ers) that produce heat.i Protect the power cord from being walked on or pinched, particularly at plugs,convenience receptacles, and the point where they exit from the apparatus.j Only use attachments/accessories specifi ed by the manufacturer.k Use only with the cart, stand, tripod, bracket, or table specifi ed by the manufacturer or sold with the apparatus. When a cart is used,use caution when moving the cart/apparatus combination to avoidinjury from tip-over.l Unplug this apparatus during lightning storms or when unused for long periods of time.m Refer all servicing to qualifi ed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cordor plug is damaged, liquid has been spilled or objects have fallen into theapparatus, the apparatus has been exposed to rain or moisture, does notoperate normally, or has been dropped.n Battery usage CAUTION – To prevent battery leakage which may result in bodily injury, property damage, or damage to the unit:•I nstall all batteries correctly, + and - as marked on the unit.•D o not mix batteries (old and new or carbon and alkaline, etc.).R emove batteries when the unit is not used for a long time.•o Apparatus shall not be exposed to dripping or splashing.p Do not place any sources of danger on the apparatus (e.g. liquid fi lled objects, lighted candles).q This product may contain lead and mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal orrecycling information, please contact your local authorities or the Electronic Industries Alliance: .r Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.N oticeA ny changes or modifi cations made to this device that are not expressly approved by Philips Consumer Lifestyle may void the user’s authority to operate the equipment.E nvironmental informationA ll unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.)Y our system consists of materials which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.W indows Media and the Windows logo are trademarks, or registeredtrademarks of Microsoft Corporation in the United States and/or other countries.T his apparatus includes this label:2Y our CD SoundmachineC ongratulations on your purchase,and welcome to Philips! T o fully benefi t from the support that Philips offers,register your product at /welcome.I ntroductionW ith this unit,you can enjoy audio from discs,USB devices,external devices,or radio stations.T he unit supports the following media formats:W hat’s in the boxC heck and identify the contents of your package:•M ain unit•1 x AC power cord•1 x MP3 link cable•Q uick start guide•U ser manualO verview of the main unita S ource selector•T urn on or off the unit, or select a source.b•Skip to the previous/next track.S earch within a track/ disc/USB.Stop play or erase a program.P ROG•P rogram tracks.c D isplay panel•S how current status.d A LBUM +/-•S kip to the previous/next album.e U SB•S elect the USB source.f CDS elect the disc source.•g M ODE•S elect repeat play or random play.h O PEN/CLOSE•O pen or close the disc compartment.i T UNING•T urn to select radio frequency.j V OLUME•A djust volume.k•J ack for a USB mass storage device.l F M antenna•I mprove FM reception.m A UX IN•A udio input jack (3.5mm ) for an external audio device.n A C MAINS•J ack for the supplied AC power cord.o B attery compartment door3 Get startedI f you contact Philips,you will be asked for the model and serial number of this apparatus.The model number and serial number are on the bottom of the apparatus. Write the numbers here:M odel No.__________________________S erial No.___________________________S elect power supplyT he unit can be operated by AC power or batteries.A C power1Connect the AC power cable to:•t he main unit.•t he wall socket.B attery powerOpen the battery compartment on the bottom of the unit.2Insert 6 R14/UM2/C Cell batteres (not supplied) with correct polarity (+/-) as indicated, then close the battery compartment.3The unit is ready to operate.T urn on1Push the s ource selector to C D/USB/AUX, or F M or M W.T urn off1Push the s ource selector to O FF.4 PlayP lay disc1Push the s ource selector to C D/USB/AUX.2 Press CD to select the disc source.3 Press O PEN/CLOSE to open the disc compartment.4Insert a disc with the printed side facing up, then close the disc compartment.5 Press to start play.• .T o pause/resume play, press•T•T•T o select an album, press•Tnormal play.P lay from USB1socket of the unit.2Push the s ource selector to C D/USB/AUX.3 Press U SB to select the USB source.4 Press A LBUM +/-to select a folder.5to select an audio fi le.6 Press to start play.• .T o pause/resume play, pressT•T o search within an audio fi•resume normal play. 5 Play optionsR epeat and random play 1 Press M ODE repeatedly to select:[REP] (repeat): the current track is played repeatedly.• [REP ALL] (repeat all): all tracks are played repeatedly.• [SHUF] (shuf fl e): all tracks are played randomly.• 2 To return to normal play, press M ODE repeatedly until play mode is no longer displayed.P rogram tracks Y ou can program a maximum of 20 tracks. 1 At CD/USB mode, in the stop position, press P ROG to activate the programmode.[PROG] (program) is displayed.» 2 For MP3/WMA tracks, press A LBUM +/- to select an album. 3to select a track number, then press P ROG to con fi rm.4 Repeat steps 2 to 3 to select and store all tracks to program.5 Press to play the programmed tracks.D uring play, [PROG] (program) is displayed.» T •6 Adjust soundA djust volume 1 During play, turn V OLUME to increase/decrease the volume level.7Listen to radioT une to a radio station1Push the s ource selector to F M or M W.2 Turn T UNING to tune to a station.8Listen to an external deviceY ou can also listen to an external audio device through this unit.1Push the s ource selector to C D/USB/AUX.2Connect the supplied MP3 link cable to:t he• AUX IN jack (3.5mm) on the back of the unit.•t he headphone jack on an external device.3Start to play the device (refer to the device’s user manual).9 Product informationS pecifi cationsD iscL aser type S emiconductorD isc diameter12cm/8cmS upport disc C D-DA, CD-R, CD-RW, MP3-CD, WMA-CD T unerT uning range F M: 87.5 - 108MHz; M W: 531 - 1602kHzG eneral informationO utput power2 x 2W RMSA C power220V~, 60HzO peration power consumption18WU SB direct V ersion 2.0/1.1D imensionsM ain Unit (W x H x D)350 x 127 x 217 mmW eight1.97kgU SB playability informationC ompatible USB devices:•U SB fl ash memory (USB 2.0 or USB 1.1)•U SB fl ash players (USB 2.0 or USB 1.1)•m emory cards (requires an additional card reader to work with this unit)S upported formats:•U SB or memory fi le format FAT12, FAT16, FAT32 (sector size: 512 bytes)•M P3 bit rate (data rate): 32-320 Kbps and variable bit rate•W MA v9 or earlier•D irectory nesting up to a maximum of 8 levelsN umber of albums/ folders: maximum 99••N umber of tracks/titles: maximum 999I D3 tag v2.0 or later••F ile name in Unicode UTF8 (maximum length: 128 bytes)U nsupported formats:•E mpty albums: an empty album is an album that does not contain MP3/WMAfi les, and is not be shown in the display.•U nsupported fi le formats are skipped. For example, Word documents (.doc) or MP3 fi les with extension .dlf are ignored and not played.•A AC, WAV, PCM audio fi les•D RM protected WMA fi les (.wav, .m4a, .m4p, .mp4, .aac)•W MA fi les in Lossless formatS upported MP3 disc formats•I SO9660, JolietM aximum title number: 999 (depending on fi le name length)••M aximum album number: 99•S upported sampling frequencies: 32 kHz, 44.1kHz, 48 kHzS upported Bit-rates: 32-320 (kbps), variable bit rates••I D3 tag v2.0 or later•D irectory nesting up to a maximum of 8 levelsM aintenanceC lean the cabinetU se a soft cloth slightly moistened with a mild detergent solution. Do not use a •solution containing alcohol, spirits, ammonia or abrasives.C lean discs•W hen a disc becomes dirty, clean it with a cleaning cloth. Wipe thedisc from the centre out.•Dcleaners, or antistatic spray intended for analogue records.C lean the disc lensA fter prolonged use, dirt or dust may accumulate at the disc lens. To ensure •good play quality, clean the disc lens with Philips CD lens cleaner or anycommercially available cleaner. Follow the instructions supplied with cleaner. 10 T roubleshootingT o keep the warranty valid,never try to repair the system yourself.I f you encounter problems when using this apparatus,check the following points before requesting service.If the problem remains unsolved,go to the Philips web site www. /welcome.When you contact Philips,ensure that the apparatus is nearby and the model number and serial number are available.N o power/No sound•E nsure that the AC power plug of the unit is connected properly.•E nsure that there is power at the AC outlet.•E nsure that the batteries are installed correctly.•A djust the volume.•T he fi le is a non-audio one. Select an audio fi le.N o response from the unit•D isconnect and reconnect the AC power plug, then turn on the unit again.N o disc detected•I nsert a disc.C heck if the disc is inserted with the print side facing inward.••W ait until the moisture condensation at the lens has cleared.•R eplace or clean the disc.U se a fi nalized CD or correct format disc.•P oor radio reception•I ncrease the distance between the unit and your TV or VCR.•F ully extend and adjust the FM antenna.C annot display some fi les in USB device•T he number of folders or fi les in the USB device has exceeded a certain limit.This phenomenon is not a malfunction.•T he formats of these fi les are not supported.U SB device not supported•T he USB device is incompatible with the unit. Try another one.All rights reserved.。
231P4/welcomeZH 用户手册 1客户服务与保修39故障排除和常见问题解答44目录1. 重要 (1)1.1 安全措施与维修 (1)1.2 标志说明 (2)1.3 产品和包装材料的废弃 (3)2. 设置显示器 (4)2.1 安装 (4)2.2 操作显示器 (5)2.3 卸下底座装置（VESA安装） (8)3. USB扩展坞显示器简介 (9)3.1 如何使用USB扩展坞显示器 (9)4. 图像优化 (15)4.1 SmartImage (15)4.2 SmartContrast (16)4.3 Philips SmartControl Premium (16)4.4 SmartDesktop 指南 (23)5. PowerSensor™ (28)6. 技术规格 (29)6.1 分辨率和预设模式 (31)7. 电源管理 (32)8. 有关规定 (33)9. 客户服务与保修 (39)9.1 飞利浦平板显示器像素缺陷规定 (39)9.2 客户服务与保修 (41)10. 故障排除和常见问题解答 (44)10.1 故障检修 (44)10.2 USB扩展坞显示器常见问题解答 (45)10.3 SmartControl Premium 常见问题解答 (46)10.4 一般常见问题解答 (46)1. 重要此电子版用户指南适合使用 Philips 显示器的所有用户。
请在使用您的显示器之前花点时间阅读本 User Manual (用户手册)。
它包含与使用显示器相关的重要信息和注意事项。
产品享受飞利浦保修须符合下列条件：产品适当用于其设计目的、符合操作说明、返修时提供原始帐单或付款收据，帐单或收据应载明购货日期、销售商名称、产品型号及生产号。
1.1 安全措施与维修警告使用本文档中未介绍的控制、调整或过程可能导致碰撞、电气危险和/或机械危险。
在连接和使用计算机显示器时，阅读并遵循下列注意事项：操作•请使显示器远离阳光直接照射、明亮强光线、以及任何其他热源。
Sonic electrictoothbrushDiamondClean5 modes1 brush head1 travel caseWhiter, healthier teeth for lifeHX9351/57Best Philips Sonicare whitening sonic toothbrushPhilips Sonicare's best whitening in our most elegant sonic electric toothbrush.Switch to Philips Sonicare.Proven to improve oral healthA whiter smile in 1 week with our DiamondClean brush head*Up to 7x more plaque removal than a manual toothbrushImproves gum health in just 2 weeks*Choose from 5 modes including Deep Clean and SensitiveSafe and gentle for your oral health needsProvides a superior cleanDeep Clean mode tackles your trouble spotsPhilips Sonicare's advanced sonic technologyDesigned around youTimers encourage thorough 2 minutes of brushingOptimize your brushingPremium charging glass and travel caseHighlightsUp to 2x whiter teethClick on our DiamondClean brush head to gently yet effectively remove surface stains.Densely packed central stain removal bristles work hard to make your smile 2x whiter in just 7 days.*Say goodbye to plaqueDensely-packed, high-quality bristles remove up to 7x more plaque than a manual toothbrush.Look after those gumsWith optimal cleaning from yourDiamondClean, gums will become healthier in 2 weeks*. Removing up to 7x more plaquealong the gum line than a manual toothbrush*,you’ll get your healthiest smile.5 modes to clean your wayWith DiamondClean, you get a truly refreshing clean every day. Our 5 modes cover all your brushing needs; Clean mode – for exceptional daily cleaning, Gum Care – to gently massage gums, Deep Clean – for an invigorating deep clean, Sensitive – for gentle yet effective cleaning of sensitive gums, and White – the ideal mode to remove surface stains.Extra deep cleaningOur Deep Clean mode means you can really focus on specific areas, paying them extra attention. We’ve combined our unique brush head motion with an extended 3 minutes of brushing time so your teeth get a truly deep clean.QuadPacer and SmartimerIt takes just 2 minutes to thoroughly brush your teeth. Our QuadPacer lets you know when you've spent the optimal amount of time on each section of your mouth while ourSmarTimer signals when your total time is up.Together they help you reach yourrecommended brushing time, every time.Philips Sonicare technologyPhilips Sonicare's advanced sonic technology pulses water between teeth, and its brushstrokes break up plaque and sweep it away for an exceptional daily clean.Brush with confidenceWhatever your specific needs, you can be sure of a safe brushing experience withDiamondClean. Our sonic technology is suitable for use with braces, fillings, crowns and veneers, and can even be used in the daily treatment of gum disease.Design with storage in mindCharging a toothbrush has never been so effortless. Simply place your toothbrush into the sleek glass holder after brushing, and it instantly starts charging. Not only does your glass charge fit stylishly into your bathroom, it also doubles as a rinsing glass. Enjoy two weeks of regular use from a single full charge.Our premium travel case lets you store your toothbrush hygienically when you're on the go.SpecificationsModesClean: For exceptional everyday clean Gum Care: Gently massages gums Sensitive: Gentle teeth and gum cleaning White: Removes surface stainsDeep Clean: For an invigorating deep clean Items includedHandle: 1 DiamondCleanBrush heads: 1 DiamondClean standard Travel case: Premium travel caseCharger base: 1Glass charger: 1Design and finishingColor: BlackCleaning performanceSpeed: Up to 62000 brush movement/minPerformance: Removes up to 7x more plaque*Health benefits: Improves gum health in onlytwo weeksWhitening benefits: Whitens teeth 2X better*Timer: Quadpacer and SmarTimerEase of useBattery indicator: Illuminated icon indicatesbattery lifeHandle: Slim ergonomic designDisplay: Illuminated displayBrush head system: Easy click-on brush headsT echnical specificationsBattery: RechargeableBattery type: Lithium IONOperating time (full to empty): Up to 3 weeks*PowerVoltage: 110-220 VServiceWarranty: 2-year limited warranty* based on two periods of two-minute brushings per day,on standard mode© 2021 Koninklijke Philips N.V.All Rights reserved.Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.Issue date 2021‑05‑14 Version: 6.1.1。
