神州数码系列交换机升级指南下载

目录1 版本升级操作指导 (1)1.1 设备软件简介 (1)1.1.1 BootWare程序 (1)1.1.2 启动软件包 (1)1.2 软件升级方式简介 (2)1.3 通过命令行进行软件升级 (2)1.3.1 独立运行模式下的软件升级 (3)1.3.2 IRF模式下的软件升级 (9)1.4 通过BootWare菜单升级启动软件包配置 (17)1.4.1 通过管理用以太网口利用TFTP升级启动软件包 (18)1.4.2 通过管理用以太网口利用FTP升级启动软件包 (20)1.4.3 通过Console口利用Xmodem升级启动软件包 (22)1.5 通过BootWare菜单升级BootWare配置 (27)1.5.1 通过管理用以太网口利用TFTP升级BootWare (27)1.5.2 通过管理用以太网口利用FTP升级BootWare (30)1.5.3 通过Console口利用Xmodem升级BootWare (32)2 BootWare菜单介绍 (38)2.1 BootWare菜单的快捷键 (38)2.2 进入BootWare基本段 (38)2.2.1 修改串口参数 (39)2.2.2 升级BootWare扩展段 (40)2.2.3 升级完整的BootWare (40)2.2.4 启动BootWare扩展段 (40)2.2.5 启动备份的BootWare扩展段 (41)2.2.6 进入基本段辅助子菜单 (41)2.3 进行内存测试 (41)2.4 进入BootWare扩展段 (42)2.5 BootWare扩展段主菜单 (42)2.5.1 BootWare扩展段主菜单简介 (42)2.5.2 配置密码恢复功能 (44)2.5.3 启动应用程序 (45)2.5.4 串口子菜单 (45)2.5.5 以太网配置子菜单 (46)2.5.6 文件控制子菜单 (48)2.5.7 恢复出厂配置启动 (52)2.5.8 忽略系统配置文件 (53)2.5.9 BootWare操作子菜单 (53)2.5.10 跳过console口认证 (54)2.5.11 存储器操作子菜单 (54)2.5.12 进入BootWare扩展段辅助子菜单 (55)2.5.13 格式化文件系统 (55)2.6 软件升级失败的处理 (56)1 版本升级操作指导1.1 设备软件简介设备软件包括BootWare程序和启动软件包，它是设备启动、运行的必备软件，为整个设备提供支撑、管理以及丰富的业务。

神州数码Bootrom下的升级配置实验十、交换机BootROM下的升级配置一、实验目的1、了解什么时候采用BootROM升级；2、了解怎样使用BootROM升级交换机。

二、应用环境当交换机的系统文件遭到破坏时，已经无法进入正常的CLI界面进行操作（譬如：对交换机升级不成功的时候），可以进入交换机BootROM方式对交换机重新升级或还原文件。

三、实验设备1、DCS-3926S交换机1台2、PC机1台、tftp server 1台（1台PC也可以，既作为调试机又作为tftp服务器）3、Console线1根4、直通网线1根四、实验拓扑五、实验要求1、按照拓扑图连接网络；2、PC和交换机的24口用网线相连；3、交换机的管理IP为192.168.1.100/244、PC网卡的IP地址为192.168.1.101/24；六、实验步骤第一步：配置TFTP服务器第二步：进入BootROM方式在交换机启动的过程中，按住“ctrl＋b”键，直到交换机进入BootROM监控模式。

操作显示如下：DCS-3926S Management SwitchCopyright (c) 2001-2003 by Digital China Networks Limited.All rights reserved.Testing RAM...33,554,432 RAM OK.Loading BootROM...Starting BootRom...109.13 BogoMIPSVersion: 1.2.0Creation date: Jun 22 2004, 15:47:10Attached TCP/IP interface to sc0.[Boot]:第三步：设置交换机IP地址和升级方式。

在BootROM模式下，执行命令setconfig，设置本机在BootROM模式下的IP地址、掩码、服务器的IP地址、掩码及选择TFTP或者FTP的升级方式。

实验十、交换机BootROM下的升级配置一、 实验目的1、了解什么时候采用BootROM升级；2、了解怎样使用BootROM升级交换机。

二、 应用环境当交换机的系统文件遭到破坏时，已经无法进入正常的CLI界面进行操作（譬如：对交换机升级不成功的时候），可以进入交换机BootROM方式对交换机重新升级或还原文件。

三、 实验设备1、DCS-3926S交换机1台2、PC机1台、tftp server 1台（1台PC也可以，既作为调试机又作为tftp服务器）3、Console线1根4、直通网线1根四、 实验拓扑五、 实验要求1、按照拓扑图连接网络；2、PC和交换机的24口用网线相连；3、交换机的管理IP为192.168.1.100/244、PC网卡的IP地址为192.168.1.101/24；六、 实验步骤第一步：配置TFTP服务器第二步：进入BootROM方式在交换机启动的过程中，按住“ctrl＋b”键，直到交换机进入BootROM监控模式。

操作显示如下：DCS-3926S Management SwitchCopyright (c) 2001-2003 by Digital China Networks Limited.All rights reserved.Testing RAM...33,554,432 RAM OK.Loading BootROM...Starting BootRom...109.13 BogoMIPSVersion: 1.2.0Creation date: Jun 22 2004, 15:47:10Attached TCP/IP interface to sc0.[Boot]:第三步：设置交换机IP地址和升级方式。

在BootROM模式下，执行命令setconfig，设置本机在BootROM模式下的IP地址、掩码、服务器的IP地址、掩码及选择TFTP或者FTP的升级方式。

如设置本机地址为192.168.1.100/24，PC地址为192.168.1.101/24，选择TFTP升级方式，配置如下：[Boot]: setconfigHost IP Address: [192.168.10.22] 192.168.1.100 ！该地址是交换机地址Server IP Address: [192.168.10.151] 192.168.1.101 ！该地址是服务器地址FTP(1) or TFTP(2): [1] 2Network interface configure OK.[Boot]:第四步：开始升级打开PC中TFTP服务器，在往交换机下传升级版本时，请先检查服务器与被升级交换机之间的连接状态，在服务器端使用ping命令，ping通后，在交换机的BootROM模式下执行load命令；若ping不通，则检查原因。

Supporting ZoneDirector 10.0SOFTWARE UPGRADE GUIDEPart Number: 800-71771-001 Rev A Publication Date: 29 November 2017Copyright Notice and Proprietary InformationCopyright 2017 Brocade Communications Systems, Inc. All rights reserved.No part of this documentation may be used, reproduced, transmitted, or translated, in any form or by any means, electronic, mechanical, manual, optical, or otherwise, without prior written permission of or as expressly provided by under license from Brocade. Destination Control StatementTechnical data contained in this publication may be subject to the export control laws of the United States of America. Disclosure to nationals of other countries contrary to United States law is prohibited. It is the reader’s responsibility to determine the applicable regulations and to comply with them.DisclaimerTHIS DOCUMENTATION AND ALL INFORMATION CONTAINED HEREIN (“MATERIAL”) IS PROVIDED FOR GENERAL INFORMATION PURPOSES ONLY. BROCADE and RUCKUS WIRELESS, INC. AND THEIR LICENSORS MAKE NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARD TO THE MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY, NON-INFRINGEMENT AND FITNESS FOR A PARTICULAR PURPOSE, OR THAT THE MATERIAL IS ERROR-FREE, ACCURATE OR RELIABLE. BROCADE and RUCKUS RESERVE THE RIGHT TO MAKE CHANGES OR UPDATES TO THE MATERIAL AT ANY TIME.Limitation of LiabilityIN NO EVENT SHALL BROCADE or RUCKUS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR DAMAGES FOR LOSS OF PROFITS, REVENUE, DATA OR USE, INCURRED BY YOU OR ANY THIRD PARTY, WHETHER IN AN ACTION IN CONTRACT OR TORT, ARISING FROM YOUR ACCESS TO, OR USE OF, THE MATERIAL.TrademarksRuckus Wireless, Ruckus, the bark logo, BeamFlex, ChannelFly, Dynamic PSK, FlexMaster, Simply Better Wireless, SmartCell, SmartMesh, SmartZone, Unleashed, ZoneDirector and ZoneFlex are trademarks of Ruckus Wireless, Inc. in the United States and in other countries. Brocade, the B-wing symbol, MyBrocade, and ICX are trademarks of Brocade Communications Systems, Inc. in the United States and in other countries. Other trademarks may belong to third parties.Ruckus ZoneDirector Upgrade Guide 2Part Number: 800-71771-001 Rev AContentsZoneDirector Upgrade Paths (4)Upgrading ZoneDirector and ZoneFlex APs (4)Importing an AP Firmware Bundle (5)Performing an Upgrade with Smart Redundancy (6)Enabling Secured AP Image Upgrade (6)Verifying the Upgrade (6)Upgrade FAQs (9)Do I Need a Valid Support Contract to Upgrade Firmware? (9)Is My Controller Supported by the Firmware Upgrade? (10)Is My Access Point Supported by the Firmware Upgrade? (10)How Do I Get Support? (10)Ruckus ZoneDirector Upgrade GuidePart Number: 800-71771-001 Rev A3ZoneDirector Upgrade PathsTo upgrade directly to ZoneDirector build 10.0.0.0.1424, you must be running ZoneDirector 9.12 GA or a later release. If you are running an earlier release, you must first upgrade to at least the 9.12 GA build before upgrading to this release.Upgrading ZoneDirector and ZoneFlex APsConsult the Ruckus Support website on a regular basis for updates that can be applied to your Ruckus network devices.After downloading an update package to a convenient folder on your administrative PC, you can complete the network upgrade (of both ZoneDirector and the APs) by completing the following steps. The full network upgrade is successive in sequence. After ZoneDirector is upgraded, it contacts each active AP, upgrades it, and restores it to service. The APs use FTP to download firmware updates from ZoneDirector. If you have an access control list (ACL) or firewall between ZoneDirector and the AP, make sure that FTP traffic is allowed to ensure that the AP can successfully download the firmware update.NOTEUpgrading ZoneDirector and the APs temporarily disconnects them (and any associated clients) from the network. To minimize network disruption, Ruckus Wireless recommends performing the upgrade procedure at an off-peak time.1.Back up your existing configuration.2.Select Administer > Upgrade.A screen similar to the following figure displays. The graphical user interface (GUI) may differ depending on your current softwareversion.FIGURE 1 Upgrade Page3.In the Software Upgrade area, click Choose File.4.Browse to the location where you saved the upgrade package, and click Open.When the upgrade file name appears in the text field, the Choose File button becomes the Upgrade button.Ruckus ZoneDirector Upgrade Guide 4Part Number: 800-71771-001 Rev A5.Click Upgrade and ZoneDirector logs out of the Web User Interface (WebUI), runs the upgrade, and restarts. When the upgrade process is complete, the Status LED on ZoneDirector is steadily lit. You may now log in to the WebUI as Administrator.Importing an AP Firmware BundleWhen Ruckus introduces a new AP model, an AP firmware bundle (also known as a patch) is made available for download from the Ruckus Support website. Download the AP firmware bundle to a local computer, import it into ZoneDirector, and the new AP model is now supported.Beginning in ZoneDirector 10.0 and later releases, the AP firmware bundle allows administrators to import a new Access Point (AP) model patch file to ZoneDirector without requiring a full upgrade of the ZoneDirector firmware. In this way, new APs can be introduced without the need to wait for the next ZoneDirector firmware release.NOTEUpgrading ZoneDirector to a new release deletes all imported AP firmware bundles. Install the required AP firmware bundles only after upgrading ZoneDirector firmware.The steps required for importing an AP firmware bundle are similar to the steps in Upgrading ZoneDirector and ZoneFlex APson page 4.CAUTIONImporting an AP firmware bundle automatically reboots the ZoneDirector to affect the patch, temporarily disconnecting APs (and any associated clients) from the network. To minimize network disruption, Ruckus Wireless recommends performing the upgrade procedure at an off-peak time.FIGURE 2Importing an AP Firmware BundleImporting an AP Firmware BundleRuckus ZoneDirector Upgrade Guide Part Number: 800-71771-001 Rev A5Performing an Upgrade with Smart RedundancyPerforming an Upgrade with Smart RedundancyIf you have two ZoneDirectors in a Smart Redundancy configuration, the upgrade procedure is similar for the active and standy ZoneDirectors. However, the active and standby ZoneDirectors will reverse roles during an upgrade.To upgrade both ZoneDirectors in a Smart Redundancy configuration, complete the following steps.1.Log in to the active ZoneDirector. Do not attempt to manually upgrade the standby ZoneDirector before the active unit. If you doso, some configuration options may be lost during the upgrade process. Be sure to begin the upgrade process from either the Web User Interface (WebUI) of the active ZoneDirector or the shared Management Interface (if configured).2.Select Administer > Upgrade.3.In the Software Upgrade area, click Browse. The Browse dialog box appears.4.Browse to the location where you saved the upgrade package, and click Open.When the upgrade file name appears in the text field, the Browse button becomes the Upgrade button.5.Click Upgrade. The standby ZoneDirector is upgraded first.When the standby ZoneDirector upgrade is complete, the standby ZoneDirector reboots and becomes active (begins accepting AP requests), while the original active ZoneDirector becomes the standby and begins its own upgrade process.All APs are now associated to the original standby ZoneDirector (which is now the active ZoneDirector), and begin upgrading AP firmware to the new version.Each AP reboots after upgrading.Enabling Secured AP Image UpgradeBeginning with ZoneDirector release 9.13, AP firmware image upgrades can be performed using HTTPS by way of TCP port 11443 rather than FTP. In the WebUI, select the check box next to Enable secured AP image upgrade to enable HTTPS upgrade. If HTTPS upgrade is not supported, AP image upgrades fall back to FTP.Verifying the UpgradeAfter you have performed a ZoneDirector upgrade or AP firmware bundle installation, it is important to verify that the ZoneDirector and APs are running the expected software versions. Version details for both the ZoneDirector and AP installed versions can be found in the ZoneDirector Web User Interface (WebUI). If you prefer to use the command line interface (CLI), use SSH to access the ZoneDirector or AP. The following steps include both WebUI and CLI steps, but it is recommended that you verify that both the ZoneDirector and the APs are running the appropriate installed system versions.Ruckus ZoneDirector Upgrade Guide 6Part Number: 800-71771-001 Rev AThe following steps contain a WebUI and a CLI option, select just one of the options in each step.1.To verify the version number, choose one of the following bulleted options.•Open the ZoneDirector WebUI. Select Dashboard , and verify the version number under the System Info heading.FIGURE 3Verifying the Installed Software Version in ZoneDirector WebUI•To verify the installed version using the ZoneDirector CLI, use the show sysinfo command.ruckus# show sysinfo System Overview: Name= ZDScotlandIP Address= 192.168.0.2MAC Address= 24:C9:A1:3F:3E:70 Uptime= 58d 6h 35m Model= ZD1200 Licensed APs= 6Serial Number= 241426000023 Version= 10.0.0.0 build 1424Verifying the UpgradeRuckus ZoneDirector Upgrade Guide Part Number: 800-71771-001 Rev A72.To display information about all active APs, choose one of the following bulleted options.•From the ZoneDirector WebUI, select Monitor > Access Points to display information about all active APs.FIGURE 4Displaying the Active APs in ZoneDirector WebUI•To verify the installed version using the AP CLI, login, enter your password if prompted, and enter the get version command as shown in the following output.login as:Please login: admin password:Copyright (c) 2017 Ruckus Wireless, Inc. All rights Reserved.** Ruckus R710 Multimedia Hotzone Wireless AP: 261503606647Warning: AP is in ZoneDirector-Managed modeCurrent or latest ZoneDirector: 192.168.0.2 / 24:c9:a1:3f:3e:70 Any configuration changes made in CLI may conflict with the ZoneDirector's management and will cause undefined results.rkscli:rkscli: get versionRuckus R710 Multimedia Hotzone Wireless AP Version: 10.0.0.0.1424OKVerifying the UpgradeRuckus ZoneDirector Upgrade Guide 8Part Number: 800-71771-001 Rev A3.(WebUI only). Click one of the highlighted AP MAC addresses. The installed version information is displayed under the Access Points screen similar to the following figure.FIGURE 5Displaying the Installed AP Information in ZoneDirector WebUIUpgrade FAQs•Do I Need a Valid Support Contract to Upgrade Firmware?•Is My Controller Supported by the Firmware Upgrade?•Is My Access Point Supported by the Firmware Upgrade?•How Do I Get Support?Do I Need a Valid Support Contract to Upgrade Firmware?You must have a valid support contract to upgrade or downgrade the ZoneDirector software. If you do not have a valid support contract,contact your reseller to purchase an appropriate support contract. After downloading and installing the software, select Administer >Support from the WebUI for information on activating your support contract.Upgrade FAQsDo I Need a Valid Support Contract to Upgrade Firmware?Ruckus ZoneDirector Upgrade Guide Part Number: 800-71771-001 Rev A9NOTEBy downloading the ZoneDirector software and subsequently upgrading ZoneDirector to version 10.0, be advised that the ZoneDirector will periodically connect to Ruckus, and Ruckus will collect the ZoneDirector serial number, software version, and build number. Ruckus will transmit a file back to the ZoneDirector that will be used to display the current status of theZoneDirector support contract. Any information collected from the ZoneDirector may be transferred and stored outside of your country of residence where data protection standards may be different.Is My Controller Supported by the Firmware Upgrade?This guide supports the following ZoneDirector models:•ZoneDirector 1200•ZoneDirector 3000•ZoneDirector 5000For information about the specific models and modules supported in a ZoneDirector model, refer to the appropriate hardware installation guide.Is My Access Point Supported by the Firmware Upgrade?TABLE 1 Supported Access Point modelsHow Do I Get Support?For product support information and details on contacting the Ruckus Customer Services and Support Team, go directly to the Support Portal using https:// , or go to https:// and select Support .Upgrade FAQsIs My Controller Supported by the Firmware Upgrade?Ruckus ZoneDirector Upgrade Guide 10Part Number: 800-71771-001 Rev A。

神州数码交换机一、指示灯●Power⏹亮（绿色）内部电源工作正常⏹亮（黄色）内部电源供电异常⏹灭电源没上电或电源坏。

●Diag⏹闪（绿色）系统自动诊断检测正在进行⏹亮（绿色）系统自动诊断检测成功完成⏹亮（黄色）系统自动诊断检测出错误●PoE Status⏹绿色Port LEDs 显示每个端口的PoE状态⏹琥珀色闪烁PoE 系统输出的总功率达到最大值95％或剩余可用功率不够维持增加新的PoE 端口来供电。

⏹灭Port LEDs 显示每个端口的“Link/Act”状态二、SFP●SFP-SX 收发器：62.5/125um多模光纤：275m50.0/125um多模光纤：550m●SFP-LX 收发器：9/125um单模光纤：10公里●SFP-LH-40 收发器：9/125um单模光纤：40公里●SFP-LH-70 收发器：9/125um单模光纤：70公里●SFP-LH-120 收发器：9/125um单模光纤：120公里配置命令1、删除配置文件：Switch#set defaultAre you sure?(y\n)=ySwitch#writeSwitch#reload2、进入终端配置enable进入特权用户配置模式disable退出config terminal 进入全局配置模式enable password 0|7 password //0是明文密码，7是密文no enable password删除密码login 使能密码验证（该命令是console进入一般用户配置模式时，必须键入password命令设置的密码）password 0|7 <password>设置一般用户配置模式时的口令exit返回上个模式end 退回特权用户配置模式reload 重启交换机set default 恢复交换机的出厂设置1)诊断：show tech-support [no more] 显示交换机运行信息和各任务状态，诊断交换机的运行是否正常show version显示交换机版本信息hostname 命名no hostname 删除命名ip host <hostname><ip_addr>设置主机与ip地址映射关系language chinese|english设置显示的帮助信息的语言类型2)远程管理authentication securityip <ip-addr>配置允许使用telnet和http方式登录交换机的安全ip地址telnet [vrf <vrf-name>] {<ip-addr> | <ipv6-addr> | host <hostname>} [<port>]以telnet方式登录到ip为<ip-addr>的远程主机上telnet-server enable打开交换机的telnet服务器功能telnet-server max-connection {<max-connection-number>| default}配置交换机telnet服务器支持的最大连接数，default为默认值5ssh-server authentication-retries <number>设置SSH客户端的验证重试次数，默认为3次ssh-server enable 打开交换机的SSH服务器功能{ssh（安全外壳协议）}ssh-server max-connection{<max-connection-number>| default}配置交换机SSH服务器支持的最大连接数，默认为5ssh-server timeout<timeout>1-600设置SSH客户端的验证超时时间，默认180秒3)显示设置terminal length<0-512>显示当前终端每屏显示字符的行数terminal monitor 复制调试信息到当前显示终端show ssh-server 显示SSH服务器的状态是打开还是关闭，以及已经登录SSH的用户信息show telnet login 显示当前与交换机建立telnet连接的telnet客户端的信息show flash显示保存在flash中的文件大小4)配置交换机ip地址Interface vlan <vlan-id>进入VLAN接口配置模式ip address <ip-address><mask> [secondary]设置交换机的指定VLAN 接口的IP地址及掩码，[secondary]为表示配置的IP 地址为从IP 地址5)交换机升级命令（类入侵）copy<source-url><destination-url> [ascii | binary]FTP客户机上下载文件，<source-url>为被拷贝的源文件或目录的位置；<destination-url>为文件或目录所要拷贝到的目的地址；ascii 表示文件传输使用ASCII标准；binary 表示文件传输使用二进制标准（缺省传输方式）Eg：copy <filename> ftp://或者copy ftp:// <filename>后直接回车，系统会出现如下的提示：ftp server ip/ipv6 address [x.x.x.x]/[x:x::x:x] >ftp username>ftp password>ftp filename>要求输入FTP 服务器的地址、用户名、密码及文件名。
