160108_Keysight_E4991B_16196C_16092A_16192A_16197A_3GHz 阻抗分析仪操作指南(中文)

L、C、R器件测试步骤1.打开E4991A阻抗分析仪电源。

2.将仪器初始化：按[Preset]键3.选择扫描参数：本实验使用频率扫描（无扫描参数可跳过）a.按[Sweep]键进入扫描目录。

b.该目录下，设置扫描点数，平均点数，扫描参数和扫描类型4.设置扫描范围:100MHz-1Ga.按[start]键→ [1][0][0][M/µ]b.当前菜单下，单击向下箭头[↓]，激活stop菜单c.→ [1[G/n]d.可通过屏幕下方的频率显示范围，检测频率设置是否成功。

5.设置激励信号的大小：a.按[source]键→ [↓] →点击下拉菜单选择，选择激励单位b.当前菜单下，按[↑]箭头，→ [3][0][0][k/m]输入激励信号功率。

6.测试测试台的校准：a.按[cal/compen]键进入校准界面。

b.按[ cal kit menu] ，cal kit type 下拉菜单选择校准件类型（本实验选择7mm校准件），然后返回上一层菜单。

c.按[Cal meun]键→连接开路校准件→按 [meas open] ，此时菜单变灰色，等[meas open]菜单左边出现一个√时，换上短路校准件，按[meas short] ，等[meas short]菜单左边出现一个√时，换上负载校准件。

同样的方法校准load和Low Loss C。

d.最后不要忘记按下[Done]键，完成校准。

e.此时[cal menu]从uncal变成了fix状态，表示校准已完成。

7.进行夹具补偿：（本实验使用安捷伦公司的测试夹具，只需进行open/short补偿，即可获得较高的精度）。

a.把16192A测试夹具和测试台相连，并拧紧，使夹具保持水平。

b.接上被测件，并固定住（这一步非常关键，保证补偿完成后，夹具的状态保持不变）。

c.拆下被测件，进行补偿。

d.按[comp menu]→测试终端断开，按[meas open]e.选择合适的短路连接件，进行连接（尽量不要再移动夹具的两个固定架，同时尽量使短路连接件水平放置，不要倾斜），按 [measopen]键，等补偿完毕，左边出现一个打钩标志，按[Done]，完成补偿。
