伊顿公司推出新一代中压环网柜卡盟近日,多元化的工业产品制造商伊顿公司推出用于12kV二次配电应用的新一代中压环网柜，RMU，XIRIAPlus。

该产品的设计秉承了伊顿在真空灭弧室及固体绝缘领域的成熟技术,具有绿色环保、操作安全,以及免维护低成本等特点,产品严格按照最新GB及DL标准进行认证,通过10000次免维护操作寿命测试,并按照有关要求测试丏获得认证。

伊顿电气集团亚太区市场部总监赛纳吉(NagibSayegh)表示: 凭借伊顿在真空领域的领导优势和创新精神,我们始终秉承环保、可持续发展的理念。

XIRIAPlus采用固体绝缘实现无SF6有害气体。

该绿色、安全、可靠的解决方案适用于中压配电网络的各种应用,特别是智能电网。

不伊顿其他所有中压开关柜相同,该产品经过与门设计,确保其在整个产品周期内都具有环保特性。

此外,伊顿还一直致力于打造从设计到拆除及回收利用的整条产品链的环保理念,力争在产品的每个阶段都不会给环境带来危害,并确保所有材料均可在最后被回收利用。

SF6是《京都议定书》列出的六大温室气体之一,其对环境的危害已为众多环境机构和政府所熟知。

目前,丐界各地均已采取措施,在任何可行的地点逐步禁止SF6的使用,并鼓励降低SF6气体的排放。

伊顿始终致力于最大程度减少对环境的影响,同时帮助客户实现增长,而XIRIAPlus环网柜的推出正是对此承诺的充分体现。

赛纳吉补充道。

该产品在设计时充分考虑到操作人员的安全问题,提供了确保操作人员在不同机柜类型下安全操作的所有性能和联锁,可通过观察窗检查三工位刀闸的真实状态,做到万无一失。

此外,XIRIAPlus在产品设计中还预留了遥信、遥测,以及遥控等应用于智能电网馈线自动化及负荷管理的功能,同时配置高达6单元的共箱体方案,甚至大于6单元的扩展方案,使XIRIAPlus成为市场上最灵活的环网柜之一。
