电机英文专业术语

电机英文专业术语

电机零配件中英文对照表

Part

No. Chinese Description English Description REMARK

图纸

编号 中文描述 英文描述 备注

定子片 STATOR LAMINATION

转子片 ROTOR LAMINATION

定子 FRAME-STATOR-COIL

定子铁芯 STATOR CORE

定子铁芯 STATOR-CORE INTERLOCKED

定子铁芯 STATOR CORE ASSEMBLY

转子铁芯 INTERLOCKED ROTOR CORE

铸铝端盖 END FRAME CAST

铸铝端盖 END-FRAME MACHINED

压铸端盖 END FRAME CASTING

铁端盖 END FRAME-STAMPING

后盖 END COVER

端盖 COVER BRACKET / BRKT CSTG OP/ENCL

铸铝转子 ROTOR CORE

铸铝转子 cast-aluminum rotor

铸铝转子 ROTOR-CORE (SPECIAL)

铸铝转子 ROTOR CORE CAST/MACH.

轴 SHAFT SHAFT(SINGLE FLAT)

机壳 MAIN FRAME

槽楔 SLOT-PEG / WEDGE

槽绝缘纸 SLOT-LINER /SLOT LINER

槽绝缘 INSULATION SLOT

绝缘材料 INSULATION MATERIAL

保护器 THERMOSTAT / PROTECTOR

热保护器 THERMOSTAT-ASSEMBLY

热保护器与线 THERMOSTAT-LEAD ASSEMBLY

轴承 / 球轴承 BEARING-BALL / BALL BEARING

球形含油轴承 BEARING SLEEVE

含油轴承 滑动轴承 BEARING SLEEVE / SLEEVE BEARING

48轴承压簧 0048 SPRING BRG.LOADING

48内固定盖 0048 CAP RETAINER INSIDE

48轴承压圈 0048 SLINGER SLEEVE BRG

挡圈 RING RETAINING

挡圈 RETAING RING RET. RING

平垫圈 WASHER PLAIN

调整垫圈 FELT WASHER

橡胶垫圈 PLASTIC WASHER

轴承波形垫圈 BEARING SPRING

轴承调整垫圈 BEARING SPACER

波形弹簧垫圈 WAVE SPRING

弹簧垫圈 WASHER SPRING

甩水圈 SLINGER WATER

橡胶甩水圈 SLINGER RUBBER

尼龙防水圈 SLINGER NYLON

防尘盖 DUST CAP

防护盖(轴承) SHIELD (BEARING)

喷漆防尘盖 PAINTED DUST CAP

减震圈 DAMPING RING

减振圈 SPLIT RING

护线圈 GROMMET

螺钉 SCREW

螺钉 STUD

铆钉 RIVET

螺钉 THRUBOLT

#8-32长螺钉 THRUBOLT #8-32

螺栓 THRUBOLT 8-32 .164

螺栓 STUD

螺母 NUT HEX SS

六角螺母 NUT HEX #8-32

六角螺母(加工螺纹) NUT-HEX

自攻螺钉 #10-32 NF SELF FORMING SCREW #10-32 NF

五金部件组件 HARDWARE-GROUP

端子片 TERMINAL LUG

端子 TERMINAL FM KW KQ GQ MV PD AH FX GZ

JD

公接插件 PLUG MALE-REVERSING

母接插件 PLUG FEMALE-REVERSING

旗形母端子 TERMINAL LEAD FLAG FEMALE

1叉公端子 TERMINAL MALE 1-PRONG

母直端子 STRAIGHT FEMALE

连接片 BONDING LUG

接头 SPLICE CONNECTOR

连接器（接头） CONNECTOR(SPLICE) FK

电容 CAPACITOR RUN

电容 CAPACITOR ROUND 370 VAC

电容罩 CAPACITOR HOUSING

电容罩衬垫 GASKET CAPACITOR HOUSING

引线 LEAD

引线 LEAD RED

引出线图 DWG-LEAD

引线组 / 线束 LEAD-GROUP / TERMINAL EK

引出线组件 LEAD-TERMINAL-ASSEMBLY

引出线组件 LEAD GROUP ASSEMBLY

引线端子组合 LEAD STRIPPED

引出线端子装配 DWG LEAD AND TERMINAL ASY

绑扎带 TIE CABLE

接地线 GROUND-LEAD

绝缘套管 INSULATING SLEEVE

套管 SNAP BUSHING

套管 SLEEVE

套管 SLEEVE INS

底座 RIGID BASE

插孔 PLUG-HOLE

尼龙调垫 WASHER-THRUST NYLON

轴承衬套 TNSERT BALL BRG

轴承垫片 WASHER STEEL BEARING

导向杯型垫圈 WASHER CUPPED LEAD

3叶波垫 3 LEGGED SPRING

塑料袋 PLASTIC BAG

装订钉 STAPLES

风叶

FAN

塑料风叶 PLASTIC FAN

纸箱 CARTON WITHOUT CAP.

铭牌 NAMEPLATE

铭牌 INS. LABLE PRINT

不干胶标签 STICKER-FIELD WIRING

不干胶铭牌 NAMEPLATE ADHESIVE

铭牌和标签图 DWG NAMEPLATE AND LABLE

其他部件中英文对照表

Part

No. Chinese Description English Description REMARK

图纸

编号 中文描述 英文描述 备注

盖子 COVOR

喷漆端盖 ENDFRAME PAINTED

端盖加工 /金加工端盖 END FRAME MACHINE /END FRAME MACHINED

端盖装配 /端盖组件 END FRAME ASSEMBLY /CANOPY ASSEMBLY

车加工端盖 0048 BRACKET MCHD OPEN/ENCL 17MM SB

0048 BRACKET ASY OPEN/ENCL SB

轴坯(C形轴) BODY(SHAFT-C)

标准轴图 SHAFT STDS. DWG

轴装配 SHAFT ASSEMBLY

转子装配 ROTATING-ASSEMBLY

转子端盖装配 ROTATING-END FRAME ASS.

嵌线定子 STATOR & COIL ASSEMBLY STATOR-COIL

嵌线定子标准 WOUND CORE STDS.

定子装配/机壳嵌线定子组件 FRAME-STATOR-COIL ASSEMBLY

定子铁芯装配 STATOR CORE ASSEMBLY

定子铁芯自铆 STATOR-CORE INTERLOCKED

转子铁芯自铆 ROTOR CORE INTERLOCKED

机壳组装 MAIN FRAME ASSEMBLY

机壳展开图 MAIN-FRAME BLANK

机壳展开 BLANK SHELL

互锁转子铁芯 ROTOR CORE INTERLOCKED

互锁定子铁芯 STATOR CORE INTERLOCK

绝缘定子铁心 INSULATED STATOR CORE

电机组装图 MOTOR ASSEMBLY

电机装配图 MOTOR ASSEMBLY SQUARE FLANGE

电机部装 MOTOR SUB-ASSEMBLY

装配图 DRAWING GENERAL-ASSEMBLY

电机外形图 OUTLINE MOTOR

外形图 MOTOR OUTLINE SQUARE FLANGE

电气说明 SPECIFICATION ELECTRICAL

连接图 CONNECTION DIAGRAM

内部连接图 DWG DIAG INT CONN

内接线图 CONNECTION-DIAGRAM INTRNL

外接线图 CONNECTION-DIAGRAM EXTRNL

外部连接图 EXTERNAL PARTS & CONNECTIONS

空白铭牌 BLANK NAMEPLATE

单独包装的部件组合 KIT PART-PACKED-SEPARATE

纸箱标签 LABEL CARTON

警告标贴 WARNING STICKER

警告标签 CAUTION LABEL

电机鉴别号码 WEBER GRAPHICS MOTOR IDENTIFICATION PART

NUMBER

开-关标签 LABEL ON-OFF

证书标签 LABEL CERTIFICATION

连接标签 CONNECTION TAG

接线片标签 BONDING LUG STICKER

标签 LABEL BLANK BLUE / LABEL

空白条形码 STICKER BAR CODE BLANK

保护器装配 THERMOSTAT ASSEMBLY

单个热保护器 THERMOSTAT

自动复位温度保护器 THERMO AUTO RESET

热保护器引线装配(2引线) THERMOSTAT&LEAD ASSEMBLY

温度保护器组装2(7AM) THERMOSTAT ASSEMBLY 2(7AM)

外部零件连接 EXTERNAL-PARTS-CONNECTION

压缩弹簧 COMPRESSION SPRING

电容夹 CLAMP CAPACITOR

支点盘 PLATE PIVOT

起动电容 CAPACITOR START

电容防护 GUARD CAPACITOR
