DSS26二极管规格书(常州星海)

恒流二极管系列特点z CRD就是恒流二极管，其正向工作区域存在一个恒流区，不管供电电源还是负载阻抗是否有波动，恒流二极管都可以提供稳定的电流。

z产品全部符合欧盟ROHS要求，并可按客户提供无卤素全环保产品。

z产品采用插件和片式4种封装，功耗分500mW和900mW两种，可灵活满足客户的多种需求。

应用z CRD可用于稳定和限制电流的场合。

由于其恒流性能好，价格低廉，使用方便，被广泛应用于恒流源、稳压源、放大器和电子电器的保护电路中。

典型的应用为LED供电、电子秤等。

命名规则夹断电流例如： 301→30×101μA=0.3mA102→10×102μA=1.0mA452→45×102μA=4.5 mA封装代码：Y：TO-92Z：TO-92LA：SOD-123G：SOT-891 2 3TO-92 TO-92L SOD-123 SOT-89 1(3): 阳极 1(3): 阳极 1: 阴极 1(2): 阳极 2: 阴极 2: 阴极 2: 阳极 3: 阴极恒流二极管系列极限参数 @ Ta=25℃ 除非另作说明项目 SOD-123和TO-92封装系列 SOT-89和TO-92L 封装系列 最大功耗 500mW 900mW 热阻 250℃/W 139℃/W反向电流 50mA 工作温度 -30℃~120℃ 存储温度-55℃~150℃电特性 @ Ta=25℃除非另作说明产品型号夹断电流（V=10V）起始电压耗散功率（mW ） Ipmax * VmaxSOD-123 SOT-89 TO-92 TO-92L 典型电流I P (mA) V K (V)I K (mA)最大 耐压SOD-123/TO-92SOT-89/ TO-92LA-101 G-101 Y-101 Z-101 0.1 0.05~0.210.5 100 21 21 A-301 G-301 Y-301 Z-301 0.3 0.20~0.420.8 100 42 42 A-501 G-501 Y-501 Z-501 0.5 0.40~0.63 1.1 100 63 63 A-701 G-701 Y-701 Z-701 0.7 0.60~0.92 1.4 100 9292A-102 G-102 Y-102 Z-102 1.0 0.88~1.32 1.7 100 132 132 A-152 G-152 Y-152 Z-152 1.5 1.28~1.72 2.0 100 172 172 A-202 G-202 Y-202 Z-202 2.0 1.68~2.32 2.3 100 232 232 A-272 G-272 Y-272 Z-272 2.7 2.28~3.10 2.7 100 310 310 A-352 G-352 Y-352 Z-352 3.5 3.00~4.10 3.2 100 410 410 A-452 G-452 Y-452 Z-452 4.5 3.90~5.10 3.7 100 500 510 A-562 G-562 Y-562 Z-562 5.6 5.00~6.50 4.5100 500 650 A-822 G-822 Y-822 Z-822 8.2 6.56~9.84 3.1 50 490 490 A-103 G-103 Y-103 Z-103 10.0 8.00~12.0 3.5 50 500 600 A-123 G-123 Y-123 Z-123 12.0 9.60~14.4 3.8 50 500 720 A-153 G-153 Y-153 Z-153 15.0 12.0~18.0 4.3 50 500 900 G-183 Z-183 18.0 16.0~20.0 4.6 40 800 G-203 Z-203 20.0 18.0~22.0 3.9 30 660 G-253 Z-25325.0 22.0~27.0 4.0 25 675 G-303 Z-303 30.0 27.0~33.04.20.8Ipmin25825恒流二极管系列特性曲线。

Power Bridge RectifiersSKD 26 Features∙ Square plastic case with isolated metal base plate and wire leads ∙ Ideal for printed circuit boards ∙ Blocking voltage up to 1600 V ∙ High surge currents∙ Notch moulded in casing for easy polarity identification ∙Easy chassis mountingTypical Applications∙ Three-phase rectifier for power supplies∙ Input rectifiers for variable frequency drives∙ Rectifier for DC motor field supplies ∙ Battery charger rectifiers∙Recommended snubber network: RC: 50 Ω, 0.1 µF (P R = 1 W)1)Soldered directly on a p.c.b. of 100 x 160 mm with tinned tracking of min. 2.5 mm2)Mounted on a painted metal sheet of min. 250 x 250 x 1 mm3)Recommended*IMPORTANT INFORMATION AND WARNINGSThe specifications of SEMIKRON products may not be considered as guarantee or assurance of product characteristics ("Beschaffenheitsgarantie"). The specifications of SEMIKRON products describe only the usual characteristics of products to be expected in typical applications, which may still vary depending on the specific application. Therefore, products must be tested for the respective application in advance. Application adjustments may be necessary. The user of SEMIKRON products is responsible for the safety of their applications embedding SEMIKRON products and must take adequate safety measures to prevent the applications from causing a physical injury, fire or other problem if any of SEMIKRON products become faulty. The user is responsible to make sure that the application design is compliant with all applicable laws, regulations, norms and standards. Except as otherwise explicitly approved by SEMIKRON in a written document signed by authorized representatives of SEMIKRON, SEMIKRON products may not be used in any applications where a failure of the product or any consequences of the use thereof can reasonably be expected to result in personal injury. No representation or warranty is given and no liability is assumed with respect to the accuracy, completeness and/or use of any informa tion herein, including without limitation, warranties of non-infringement of intellectual property rights of any third party. SEMIKRON does not assume any liability arising out of the applications or use of any product; neither does it convey any license under its patent rights, copyrights, trade secrets or other intellectual property rights, nor the rights of others. SEMIKRON makes no representation or warranty of non-infringement or alleged noninfringement of intellectual property rights of any third party which may arise from applications. Due to technical requirements our products may contain dangerous substances. For information on the types in question please contact the nearest SEMIKRON sales office. This document supersedes and replaces all information previously supplied and may be superseded by updates. SEMIKRON reserves the right to make changes.。

SUFACE MOUNT GENERAL PURPOSE SILICON RECTIFIERReverse Voltage - 50 to 1000 Volts Forward Current - 1.0 AmpereCase : JEDEC SOD-123FL molded plastic body over passivated chip Terminals : S olderable per MIL-STD-750,Method 2026Polarity : Color band denotes cathode end Mounting Position : AnyWeight :0.006 ounce, 0.02 gramsGlass passivated deviceIdeal for surface mouted applications FEATURESMECHANICAL DATAMAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICSMetallurgically bonded constructionHigh temperature soldering guaranteed:250 C/10 seconds,0.375”(9.5mm) lead length,5 lbs. (2.3kg) tensionLow reverse leakageNote: 3.Thermal resistance from junction to ambient at 0.375” (9.5mm)lead length,P.C.B. mountedELECTRONICS CO.,LTD.LING JIESTAR SEARatings at 25 C ambient temperature unless otherwise specified.Single phase half-wave 60Hz,resistive or inductive load,for capacitive load current derate by 20%.DSR1A THRU DSR1M2.Measured at 1MHz and applied reverse voltage of 4.0V D.C.1.Averaged over any 20ms period.DSR1B SYMBOLS10070100400280400200140200600420600800560800V RRM V RMS V DC I (AV)I FSM V F 1.025.01.1Operating junction and storage temperature rangeMaximum repetitive peak reverse voltage Maximum RMS voltageMaximum DC blocking voltageMaximum average forward rectified current at T A =65 C (NOTE 1)Peak forward surge current8.3ms single half sine-wave superimposed on rated load (JEDEC Method)Maximum instantaneous forward voltage at 1.0A Maximum DC reverse current T A =25 C at rated DC blocking voltage T A =125 C Typical junction capacitance (NOTE 2)I R 10.050.0R θJA C J T J ,T STG1804-55 to +150Typical thermal resistance (NOTE 3)UNITSVOLTS VOLTS VOLTS AmpAmps Volts pF CA µK/W DSR1D DSR1G DSR1JDSR1K S1BS1DS1GS1JS1KT L =25 C503550S1ADSR1A 10007001000DSR1M S1MSOD-123FLDimensions in millimetersRATINGS AND CHARACTERISTIC CURVES DSR1A THRU DSR1MELECTRONICS CO.,LTD.LING JIESTAR SEAm A M P E R E SC A P A C I T A N C E , p FFIG.1 --TY PIC A L FOR WA R D C H A R A C TE R ISTIC FIG.2 -- TY PIC A L JU N C TION C APA C ITA N C EIN ST AN T AN EO U S FOR WAR D VOLT AG E,mV R EVER SE VOLT AGE,VOLT SI N S T A N T A N E O U S F O R W A R D C U R R E N T100100060070080090010001100510152025303540109876543210 µA M P E R E SA V E R A G E F O R W A R D C U R R E N T ,A M P E R E SI N S T A N T A N E O U S R E V E R S E C U R R E N TFIG.3 -- TYPICAL INSTANTANEOUS FIG.4 -- FOR WA R D D E R A TIN G C U R VEAMBIEN T T EMPER AT U R E,INSTANTANEOUS REVERSE VOLTAGE,V10100REVERSE CHARACTERISTICS1.00.80.60.40.20 25 50 75 100 125 150 175【领先的片式无源器件整合供应商—南京南山半导体有限公司】 |样品申请单模板第2页共2页。

半导体二极管基本知识1概述二极管又称晶体二极管,简称二极管(diode)，半导体二极管是指利用半导体特性的两端电子器件。

最常见的半导体二极管是PN结型二极管和金属半导体接触二极管。

它们的共同特点是伏安特性的不对称性，即电流沿其一个方向呈现良好的导电性，而在相反方向呈现高阻特性。

可用作为整流、检波、稳压、恒流、变容、开关、发光及光电转换等。

利用高掺杂PN结中载流子的隧道效应可制成超高频放大或超高速开关的隧道二极管。

2结构PN结两端各引出一个电极并加上管壳，就形成了半导体二极管。

PN结的P型半导体一端引出的电极称为阳极，PN结的N型半导体一端引出的电极称为阴极。

半导体二极管按结构不同可分为点接触型、面接触型和平面型。

图1 二极管结构示意图及电路符号2.1点接触型半导体二极管由一根金属丝与半导体表面相接触，经过特殊工艺，在接触点上形成PN结，作出引线，加上管壳封装而成，见图2。

点接触型二极管的PN结面积小，高频性能好，适用于高频检波电路、开关电路。

图2 点接触型二极管示意图2.2面接触型半导体二极管，它的PN结是用合金法工艺制作而成的，见图3。

面接触型二极管的PN结面积大，可通过较大的电流，一般用于低频整流电路中。

图3 面接触型二极管示意图2.3平面型半导体二极管，它的PN结是用扩散法工艺制作的，见图4。

平面型二极管常用硅平面开关管，其PN结面积较大时，适用于大功率整流;其PN结面积较小时，适用于脉冲数字电路中做开关管使用。

图4 平面型二极管示意图2.4台面型半导体二极管，PN结的制作方法虽然与扩散型相同，但是，只保留PN结及其必要的部分，把不必要的部分用药品腐蚀掉。

其剩余的部分便呈现出台面形，因而得名。

初期生产的台面型，是对半导体材料使用扩散法而制成的。

因此，又把这种台面型称为扩散台面型。

对于这一类型来说，似乎大电流整流用的产品型号很少，而小电流开关用的产品型号却很多。

3主要参数3.1二极管（通用）开启电压V on:使二极管开始导通的临界电压称为开启电压V on。

TABLE OF CONTENTSGENERAL PURPOSE RECTIFIERS (1)ULTRA FAST RECOVERY RECTIFIERS (6)UF4001(G)---UF4007(G)1A1---1A7 UF5400(G)---UF5408(G)GP10A---GP10M1N4001(G)---1N4007(G) SURFACE MOUNT ULTRA FASTRL101(G)---RL107(G) RECOVERY RECTIFIERS (6)GP15A---GP15M US1A---US1M1N5391(G)---1N5399(G) UF1A---UF1MRL151(G)---RL157(G) US2A---US2MGP20A---GP20M UF2A---UF2MRL201(G)---RL207(G) UF3A---UF3MRL251(G)---RL257(G)1N5400(G)---1N5408(G) SUPER FAST RECOVERY RECTIFIERS (7)1N4139---1N4146GP30A---GP30M SF11---SF165A05---5A10 MUR105(G)---MUR11006A05---6A10 SF21---SF268A05---8A10 SF31---SF3610A05---10A10 MUR405---MUR4100SF51---SF56SURFACE MOUNT GENERAL SF61---SF66PURPOSE RECTIFIERS………………………………………………………3 MUR605CT---MUR660CTMURH805CT---MURH8100CTDL4001/SM4001---DL4007/SM4007 MUR(F)805---MUR(F)880GS1A/M1---GS1M/M7 MUR(F)805CT---MUR(F)880CTGS2A---GS2M MUR(F)1005CT---MUR(F)1080CTS1A---S1ZZ MUR(F)1605CT---MUR(F)1680CTS2A---S2M MUR(F)2005CT---MUR(F)2080CTS3A---S3M MUR3005PT---MUR3040PTS5A---S5M MUR5005PT---MUR5060PTS6A---S6MS8A---S8M SURFACE MOUNT SUPER FASTS10A---S10M RECOVERY RECTIFIERS (9)FAST RECOVERY RECTIFIERS……………………………………4 EMS101/DLSF11---EMS106/DLSF16ES1A---ES1M1F1---1F7 ES2A---ES2MFR101(G)---FR107(G) ER1A---ER1ZZFR151(G)---FR157(G) ER2A---ER2MFR201(G)---FR207(G) ER3A---ER3KFR251(G)---FR257(G) ER6A---ER6GFR301(G)---FR307(G) ER8A---ER8JFR501(G)---FR507(G) ER10A---ER10GFR601(G)---FR607(G)MR810---MR818 HIGH EFFICIENCY RECTIFIERS (10)MR850---MR856MR820---MR826 1H1---1H8HER101(G)---HER108(G)SURFACE MOUNT FAST RECOVERY HER151(G)---HER158(G)HER201(G)---HER208(G) RECTIFIERS (5)HER301(G)---HER308(G)DL4933/SM4933---DL4948/SM4948 HER501(G)---HER508(G)FS1A---FS1M HER601(G)---HER608(G)RS1A---RS1MFS2A---FS2M SCHOTTKY BARRIER RECTIFIERS (11)FR1A---FR1ZZFR2A---FR2M SB020---SB040FR3A---FR3M 1N5817---1N5819FR6A---FR6M SB120---SB160FR8A---FR8M SR120---SR1A0FR10A---FR10M SB220--SB260SR220---SR2A0 1N30641N5820---1N5822 1N4606SB320--SB360 1N4531SR320---SR3A0 1N4532SB520---SB560 1N4533SR520---SR5A0 1N4534MS820---MS8100 1N4536SR802---SR810 LL4148MBR(F)720---MBR(F)760 1SS244MBR(F)1020---MBR(F)10100 1SS130MBR(F)1020CT---MBR(F)10150CT 1SS131MBR(F)1520---MBR(F)1560 1SS132MBR(F)1520CT---MBR(F)1560CT 1SS134MBR(F)1620---MBR(F)1660 1SS133MBR(F)1620CT---MBR(F)16100CT BAV18MBR(F)2020CT---MBR(F)20200CT BAV19MBR(F)2520CT---MBR(F)2560CT BAV20MBR(F)3020CT---MBR(F)30100CT BAV21MBR3020PT---MBR3060PT 1SS245MBR4020PT---MBR4060PT 1S1553MBR5020PT---MBR5045PT 1S15551SS141SURFACE MOUNT SCHOTTKY 1SS1441SS145BARRIER RECTIFIERS (14)1SS146DL5817/SM5817---DLSR1010 1SS147SS12---SS110SK12---SK110 SURFACE MOUNT SWITCHING DIODES (19)SS22---SS210SK22---SK210 SURFACE MOUNT ZENER DIODES (21)SS32---SS310SK32A---SK310A BZT52C2V0S--- BZT52C39SSK32B---SK310B BZT52C2V4--- BZT52C51SK32---SK310 BZX84C2V4W---BZX84C39WSK52---SK510 BZX84C2V4---BZX84C51SK82---SK810 MMBZ5221BW---MMBZ5259BWSK102---SK1010 MMBZ5221B---MMBZ5262BSK152---SK1510 MMBZ5221BS---MMBZ5259BSMMSZ5221B---MMSZ5259BSURFACE MOUNT SMALL SIGNALSCHOTTKY DIODES (16)ZENER DIODES (23)SWITCHING DIODES……………………………………………………18 1N5221B/DL5221B---1N5227B/DL5227BBZX55-C2V4---BZX55-C361N4148 ZMM55-C2V4---ZMM55-C361N4151 1N4728/DL4728---1N4764/DL47641N4448 1ZB6.8---1ZB3901N4151 ZPY3V9---ZPY1101N3604 ZY1---ZY2001N4152 3EZ11---3EZ2001N3605 1N5342B---1N5388B1N41531N3606 TRANSIENT VOLTAGE SUPPRESSOR (31)1N41541N4446 P4KE6.8---P4KE440CA1N914A P6KE/SMBJ6.8---P6KE/SMBJ440CA1N4447 1.5KE/SMCJ6.8---1.5KE/SMCJ440CA1N916A1N4448 DIODES FOR TELEVISION AND MONITOR (37)1N914B1N4449 10DF1---10DF81N916B 10ELS1---10ELS61N4450 15DF4---15DF81N4454 1N4933---1N49371N5059---1N5062 ERB83-0061S1834---1S1835 ERB84-0091S1885---1S1888 ERB91-021S1941---1S1944 ERB93-0230DF1---30DF4 ERC01-02---ERA01-1031DF1---31DF4 ERC04-02F---ERC04-04F3JH45 ERC05-06---ERC05-083JH61 ERC06-13---ERC06-153TH41 ERC18-02---ERC18-04AG01Y---AG01A ERC25-04---ERC25-06AK03---AK04 ERC30-01---ERC30-02AM01Z---AM01A ERC33-02AU01Z---AU01A ERC35-02AU02Z---AU02A ERC38-04---ERC38-06BA157---BA159 ERC81-004---ERC81-006BY228 ERC84-009BY296---BY299S ERC91-02BY396---BY399S ERD07-13---ERD07-15BY448 ERD09-13---ERD09-15BYD31D-BYD31M ERD28-04---ERD28-06BYD33D---BYD33M ERD29-02---ERD29-06BYM6C ERD32-01---ERD32-02BYT52A---BYT52M ERD33-02BYT56A---BYT56M ERD38-04---ERD38-06BYV12---BYV16 ERE41-15BYV26A---BYV26E ES1Z---ES1FBYV27---(50---600) EU01Z---EU01ABYV37---BYV38 EU02Z---EU02ABYV95A---BYV95C EU1CBYV96D---BYV96E EU1Z---EU1ABYW32---BYW36 EU2YXBYW72---BYW76 EU2Z---EU2ABYW95A---BYW95C GP10K---GP10MBYW96D---BYW96E GP15A---GP15MDLE30B---DLE30E RC2EG01Y---EG01C RG2Y---RG2AEG1Y---EG1A RG4Y---RG4CEGP10A---EGP10G RGP02-12E--RGP02-20EEGP20A---EGP20G RGP10A---RGP10MEGP30A---EGP30G RGP15A---RGP15MEM01Z---EM01A RGP20A---RGP20MEM1Y---EM1C RGP30A---RGP30MERA15-01---ERA15-10 RM2Z---RM2CERA18-02---ERA18-04 RM11A---RM11CERA22-06---ERA22-10 RN1Z---RN4ZERA32-01---ERA32-02 RP1H RU1PERA34-10 RU2M---RU2AMERA38-04---ERA38-06 RU2YX---RU20AERA81-004 RU3---RU3YXERA82-004 RU30Z---RU30AERA83-004---ERA83-006 RU4D---RU4DSERA85-009 RU4Y---RU4CERA91-02 RU4YX---RU4AMERA92-02 S5295B---S5295JERB06-13---ERB06-15 TVR1B---TVR1JERB12-01---ERB12-10 TVR4J---TVR4NERB32-01---ERB32-02ERB35-02 BRIDGE RECTIFIERS (44)ERB37-08---ERB37-10ERB38-04---ERB38-06 MB2M---MB10MERB43-02---ERB43-04 MB2S---MB10SERB44-02---ERB44-10 DB101S---DB107SERB81-004 DB101---DB107ERB83-004 DB151S---DB157SDB151---DB157RB151(G)---RB157(G)W005(G)---W10(G)W005M(G)---W10M(G)2W005/RC201(G)---2W10/RC207(G)2W005M(G)---2W10M(G)KBP005/RS201---KBP10/RS207KBL005/RS401L---KBL10/RS407LKBU4A/RS401---KBU4M/RS407KBU6A/RS601---KBU6M/RS607KBU8A/RS801---KBU8M/RS807GBU4A---GBU4MGBU6A---GBU6MGBU8A---GBU8MGBU10A---GBU10MGBU15A---GBU15MGBU25A---GBU25MKBPC1005/BR305---KBPC110/BR310KBPC6005/BR605---KBPC610/BR610KBPC8005/BR805---KBPC810/BR810KBPC10005/BR1005---KBPC1010/BR1010KBPC15005/MB1505(W)---KBPC1510/MB1510(W) KBPC25005/MB2505(W)---KBPC2510/MB2510(W) KBPC35005/MB3505(W)---KBPC3510/MB3510(W) KBPC50005/MB5005(W)---KBPC5010/MB5010(W) GBPC15005/BR1505(W)---GBPC1510/BR1510(W) GBPC25005/BR2505(W)---GBPC2510/BR2510(W) GBPC35005/BR3505(W)---GBPC3510/BR3510(W) GBPC50005/BR5005(W)---GBPC5010/BR5010(W) KBJ/GBJ601---KBJ/GBJ607KBJ/GBJ801---KBJ/GBJ807KBJ/GBJ1001---KBJ/GBJ1007KBJ/GBJ1501---KBJ/GBJ1507KBJ/GBJ2001---KBJ/GBJ2007KBJ/GBJ2501---KBJ/GBJ2507PACKAGE OUTLINES (49)RECOMMENDED SOLDER PAD LAYOUTS (62)THROUGH HOLE-AXIAL LEADED (63)THROUGH HOLE-SURFACE MOUNT (64)V RRM (I=I RM )V FM I (AV)T A =25A V AV A A 1A1 1.050301.0 1.0 5.0501A2 1.0100301.0 1.0 5.0501A3 1.0200301.0 1.0 5.0501A4 1.0400301.0 1.0 5.050R--11A5 1.0600301.0 1.0 5.0501A6 1.0800301.0 1.0 5.0501A7 1.01000301.0 1.0 5.050GP10A 1.050301.0 1.0 5.050GP10B 1.0100301.0 1.0 5.050GP10D 1.0200301.0 1.0 5.050GP10G 1.0400301.0 1.0 5.050DO--41GP10J 1.0600301.0 1.0 5.050GP10K 1.0800301.0 1.0 5.050GP10M 1.01000301.0 1.0 5.0501N4001(G) 1.050301.0 1.0 5.0501N4002(G) 1.0100301.0 1.0 5.0501N4003(G) 1.0200301.0 1.0 5.0501N4004(G) 1.0400301.0 1.0 5.050DO--411N4005(G) 1.0600301.0 1.0 5.0501N4006(G) 1.0800301.0 1.0 5.0501N4007(G) 1.01000301.0 1.0 5.050RL101(G) 1.050301.0 1.0 5.050RL102(G) 1.0100301.0 1.0 5.050RL103(G) 1.0200301.0 1.0 5.050RL104(G) 1.0400301.0 1.0 5.050A--405RL105(G) 1.0600301.0 1.0 5.050RL106(G) 1.0800301.0 1.0 5.050RL107(G) 1.01000301.0 1.0 5.050GP15A 1.550501.1 1.5 5.050GP15B 1.5100501.1 1.5 5.050GP15D 1.5200501.1 1.5 5.050GP15G 1.5400501.1 1.5 5.050DO--15GP15J 1.5600501.1 1.5 5.050GP15K 1.5800501.1 1.5 5.050GP15M 1.51000501.1 1.5 5.0501N5391(G) 1.550501.1 1.5 5.0501N5392(G) 1.5100501.1 1.5 5.0501N5393(G) 1.5200501.1 1.5 5.0501N5394(G) 1.5300501.1 1.5 5.0501N5395(G) 1.5400501.1 1.5 5.050DO--151N5396(G) 1.5500501.1 1.5 5.0501N5397(G) 1.5600501.1 1.5 5.0501N5398(G) 1.5800501.1 1.5 5.0501N5399(G) 1.51000501.1 1.5 5.050RL151(G) 1.550501.1 1.5 5.050RL152(G) 1.5100501.1 1.5 5.050RL153(G) 1.5200501.1 1.5 5.050RL154(G) 1.5400501.1 1.5 5.050DO--15RL155(G) 1.5600501.1 1.5 5.050RL156(G) 1.5800501.1 1.5 5.050RL157(G) 1.51000501.1 1.5 5.050GP20A2.050701.22.0 5.050GP20B 2.0100701.22.0 5.050GP20D 2.0200701.12.0 5.050GP20G 2.0400701.12.0 5.050DO--15GP20J 2.0600701.12.0 5.050GP20K 2.0800701.12.0 5.050GP20M 2.0100070 1.1 2.0 5.050"G"SUFFIX SINGNIFIES A GLASS PASSIVATED DIE Type Forward Rectified CurrentRepetitive Reverse Voltage Forward Rectified Current Forward Voltage Peak Reverse Current Case Style I (AV)I FSM V FM I RM @V RRMV RRM (I=I RM )V FM I (AV)T A =25A V AV A A RL201(G) 2.050701.12.0 5.050RL202(G) 2.0100701.12.0 5.050RL203(G) 2.0200701.12.0 5.050RL204(G) 2.0400701.12.0 5.050DO--15RL205(G) 2.0600701.12.0 5.050RL206(G) 2.0800701.12.0 5.050RL207(G) 2.01000701.12.0 5.050RL251(G) 2.5501501.12.5 5.050RL252(G) 2.51001501.12.5 5.050RL253(G) 2.52001501.12.5 5.050RL254(G) 2.54001501.12.5 5.050R--3RL255(G) 2.56001501.12.5 5.050RL256(G) 2.58001501.12.5 5.050RL257(G) 2.510001501.12.5 5.0501N5400(G)3.0502001.0 3.0101001N5401(G) 3.01002001.0 3.0101001N5402(G) 3.02002001.0 3.0101001N5403(G) 3.03002001.0 3.0101001N5404(G) 3.04002001.0 3.010100DO--271N5405(G) 3.05002001.0 3.0101001N5406(G) 3.06002001.0 3.0101001N5407(G) 3.08002001.0 3.0101001N5408(G) 3.010002001.0 3.0101001N4139 3.0503001.0 3.0101001N4140 3.01003001.0 3.0101001N4141 3.02003001.0 3.0101001N4142 3.04003001.0 3.0101001N4143 3.06003001.0 3.0101001N4144 3.08003001.0 3.0101001N4145 3.010003001.0 3.0101001N4146 3.012003001.0 3.010100GP30A 3.0501251.2 3.0 5.050GP30B 3.01001251.2 3.0 5.050GP30D 3.02001251.1 3.0 5.050GP30G 3.04001251.1 3.0 5.050DO--27GP30J 3.06001251.1 3.0 5.050GP30K 3.08001251.1 3.0 5.050GP30M 3.010001251.1 3.0 5.0505A05(G) 5.0503001.0 5.0101005A1(G) 5.01003001.0 5.0101005A2(G) 5.02003001.0 5.0101005A4(G) 5.04003001.0 5.010100R--55A6(G) 5.06003001.0 5.0101005A8(G) 5.08003001.0 5.0101005A10(G) 5.010003001.0 5.0101006A05(G) 6.0504001.0 6.0101006A1(G) 6.01004001.0 6.0101006A2(G) 6.02004001.0 6.0101006A4(G) 6.04004001.0 6.010100R--66A6(G) 6.06004001.0 6.0101006A8(G) 6.08004001.0 6.0101006A10(G) 6.010004001.0 6.0101008A058.0504001.08.0101008A18.01004001.08.0101008A28.02004001.08.0101008A48.04004001.08.010100R--68A68.06004001.08.0101008A88.08004001.08.0101008A108.010004001.08.01010010A0510.0504001.010.01010010A110.01004001.010.01010010A210.02004001.010.01010010A410.04004001.010.010100R--610A610.06004001.010.01010010A810.08004001.010.01010010A1010.01000400 1.010.010100"G"SUFFIX SINGNIFIES A GLASS PASSIVATED DIE Peak Reverse Current Case Style I (AV)I FSM V FM I RM @V RRM DO--27Type Forward Rectified CurrentRepetitive Reverse Voltage Forward Rectified Current Forward VoltageV RRM(I=I RM)V FM I(AV)T A=25A V A V A ADL4001/SM4001 1.05030 1.1 1.0 5.050DL4002/SM4002 1.010030 1.1 1.0 5.050DL4003/SM4003 1.020030 1.1 1.0 5.050DL4004/SM4004 1.040030 1.1 1.0 5.050MELF DL4005/SM4005 1.060030 1.1 1.0 5.050DL4006/SM4006 1.080030 1.1 1.0 5.050DL4007/SM4007 1.0100030 1.1 1.0 5.050 GS1A/M1 1.05030 1.1 1.0 5.050GS1B/M2 1.010030 1.1 1.0 5.050GS1D/M3 1.020030 1.1 1.0 5.050 GS1G/M4 1.040030 1.1 1.0 5.050 GS1J/M5 1.060030 1.1 1.0 5.050 GS1K/M6 1.080030 1.1 1.0 5.050 GS1M/M7 1.0100030 1.1 1.0 5.050 GS2A 2.05050 1.1 2.0 5.050 GS2B 2.010050 1.1 2.0 5.050 GS2D 2.020050 1.1 2.0 5.050 GS2G 2.040050 1.1 2.0 5.050 GS2J 2.060050 1.1 2.0 5.050 GS2K 2.080050 1.1 2.0 5.050 GS2M 2.0100050 1.1 2.0 5.050 S1A 1.05030 1.1 1.0 5.050 S1B 1.010030 1.1 1.0 5.050 S1D 1.020030 1.1 1.0 5.050 S1G 1.040030 1.1 1.0 5.050 S1J 1.060030 1.1 1.0 5.050 S1K 1.080030 1.1 1.0 5.050 S1M 1.0100030 1.1 1.0 5.050 S1Q 1.0120030 1.1 1.010.0100 S1V 1.0140030 1.1 1.010.0100 S1Y 1.0160030 1.1 1.010.0100 S1Z 1.0180030 1.1 1.010.0100 S1ZZ 1.0200030 1.1 1.010.0100 S2A 2.05050 1.15 2.0 5.050 S2B 2.010050 1.15 2.0 5.050 S2D 2.020050 1.15 2.0 5.050 S2G 2.040050 1.15 2.0 5.050 S2J 2.060050 1.15 2.0 5.050 S2K 2.080050 1.15 2.0 5.050 S2M 2.0100050 1.15 2.0 5.050 S3A 3.050100 1.2 3.0 5.050 S3B 3.0100100 1.2 3.0 5.050 S3D 3.0200100 1.2 3.0 5.050 S3G 3.0400100 1.2 3.0 5.050 S3J 3.0600100 1.2 3.0 5.050 S3K 3.0800100 1.2 3.0 5.050 S3M 3.01000100 1.2 3.0 5.050 S5A 5.050200 1.2 5.010.0100 S5B 5.0100200 1.2 5.010.0100 S5D 5.0200200 1.2 5.010.0100 S5G 5.0400200 1.2 5.010.0100 S5J 5.0600200 1.2 5.010.0100 S5K 5.0800200 1.2 5.010.0100 S5M 5.01000200 1.2 5.010.0100 S6A 6.050200 1.2 6.010.0100 S6B 6.0100200 1.2 6.010.0100 S6D 6.0200200 1.2 6.010.0100 S6G 6.0400200 1.2 6.010.0100 S6J 6.0600200 1.2 6.010.0100 S6K 6.0800200 1.2 6.010.0100 S6M 6.01000200 1.2 6.010.0100 S8A8.050300 1.28.010.0100 S8B8.0100300 1.28.010.0100 S8D8.0200300 1.28.010.0100 S8G8.0400300 1.28.010.0100 S8J8.0600300 1.28.010.0100 S8K8.0800300 1.28.010.0100 S6M8.01000300 1.28.010.0100 S10A10.050300 1.210.010.0100 S10B10.0100300 1.210.010.0100 S10D10.0200300 1.210.010.0100 S10G10.0400300 1.210.010.0100 S10J10.0600300 1.210.010.0100 S10K10.0800300 1.210.010.0100 S10M10.01000300 1.210.010.0100SMA/HSMA/SMAESMB/HSMA/SMAE SMB/HSMBHSMC SMC/HSMCHSMCHSMCHSMC SMA/SMB/HSMBMaximum Forward Voltage MaximumPeakReverseCurrentCaseStyleI(AV)I FSM V FM I RM@V RRMType AverageForwardRectifiedCurrentPeakRepetitiveReverseVoltagePeakForwardRectifiedCurrentSURFACE MOUNT GENERAL PURPOSE RECTIFIERSVRRM (I=I RM )V FM I (AV)T A =25A VA V A A ns 1F1 1.05025 1.3 1.0 5.01001501F2 1.010025 1.3 1.0 5.01001501F3 1.020025 1.3 1.0 5.01001501F4 1.040025 1.3 1.0 5.0100150R--11F5 1.060025 1.3 1.0 5.01002501F6 1.080025 1.3 1.0 5.01005001F7 1.0100025 1.3 1.0 5.0100500FR101(G) 1.05030 1.3 1.0 5.0100150FR102(G) 1.010030 1.3 1.0 5.0100150FR103(G) 1.020030 1.3 1.0 5.0100150FR104(G) 1.040030 1.3 1.0 5.0100150DO--41FR105(G) 1.060030 1.3 1.0 5.0100250FR106(G) 1.080030 1.3 1.0 5.0100500FR107(G) 1.0100030 1.3 1.0 5.0100500FR151(G) 1.55060 1.3 1.5 5.0100150FR152(G) 1.510060 1.3 1.5 5.0100150FR153(G) 1.520060 1.3 1.5 5.0100150FR154(G) 1.540060 1.3 1.5 5.0100150DO--15FR155(G) 1.560060 1.3 1.5 5.0100250FR156(G) 1.580060 1.3 1.5 5.0100500FR157(G) 1.5100060 1.3 1.5 5.0100500FR201(G) 2.05070 1.3 2.0 5.0100150FR202(G) 2.010070 1.3 2.0 5.0100150FR203(G) 2.020070 1.3 2.0 5.0100150FR204(G) 2.040070 1.3 2.0 5.0100150DO--15FR205(G) 2.060070 1.3 2.0 5.0100250FR206(G) 2.080070 1.3 2.0 5.0100500FR207(G) 2.0100070 1.3 2.0 5.0100500FR301(G) 3.050200 1.3 3.010200150FR302(G) 3.0100200 1.3 3.010200150FR303(G) 3.0200200 1.3 3.010200150FR304(G) 3.0400200 1.3 3.010200150DO--27FR305(G) 3.0600200 1.3 3.010200250FR306(G) 3.0800200 1.3 3.010200500FR307(G) 3.01000200 1.3 3.010200500FR501(G) 5.050300 1.3 5.010200150FR502(G) 5.0100300 1.3 5.010200150FR503(G) 5.0200300 1.3 5.010200150FR504(G) 5.0400300 1.3 5.010200150R--5FR505(G) 5.0600300 1.3 5.010200250FR506(G) 5.0800300 1.3 5.010200500FR507(G) 5.01000300 1.3 5.010200500FR601(G) 6.050300 1.3 6.010200150FR602(G) 6.0100300 1.3 6.010200150FR603(G) 6.0200300 1.3 6.010200150FR604(G) 6.0400300 1.3 6.010200150R--6FR605(G) 6.0600300 1.3 6.010200250FR606(G) 6.0800300 1.3 6.010200500FR607(G) 6.01000300 1.3 6.010200500MR810 1.05030 1.2 1.0 5.0100750MR811 1.010030 1.2 1.0 5.0100750MR812 1.020030 1.2 1.0 5.0100750MR814 1.040030 1.2 1.0 5.0100750DO--41MR816 1.060030 1.2 1.0 5.0100750MR817 1.080030 1.2 1.0 5.0100750MR818 1.0100030 1.2 1.0 5.0100750MR850 3.050100 1.3 3.010200200MR851 3.0100100 1.3 3.010200200MR852 3.0200100 1.3 3.010200200DO--27MR854 3.0400100 1.3 3.010200200MR856 3.0600100 1.3 3.010200200MR820 5.050300 1.0 5.010200200MR821 5.0100300 1.0 5.010200200MR822 5.0200300 1.0 5.010200200R--5MR824 5.0400300 1.0 5.010200200MR826 5.0600300 1.0 5.010200200"G"SUFFIX SINGNIFIES A GLASS PASSIVATED DIEFAST RECOVERY RECTIFIERSV FM I RM @V RRM Reverse Recovery Time Trr Type Average Forward Rectified Current Peak Repetitive Reverse VoltagePeak Forward Rectified Current Maximum Forward Voltage Maximum Peak Reverse Current Case Style I (AV)I FSMV RRM (I=I RM )V FM I (AV)T A =25A V A V A A ns DL4933/SM4933 1.05030 1.3 1.0 5.0100150DL4934/SM4934 1.010030 1.3 1.0 5.0100150DL4935/SM4935 1.020030 1.3 1.0 5.0100150DL4936/SM4936 1.040030 1.3 1.0 5.0100150MELF DL4937/SM4937 1.060030 1.3 1.0 5.0100250DL4947/SM4947 1.080030 1.3 1.0 5.0100500DL4948/SM4948 1.0100030 1.3 1.0 5.0100500FS1A 1.05030 1.3 1.0 5.0100150FS1B 1.010030 1.3 1.0 5.0100150FS1D 1.020030 1.3 1.0 5.0100150FS1G 1.040030 1.3 1.0 5.0100150FS1J 1.060030 1.3 1.0 5.0100250FS1K 1.080030 1.3 1.0 5.0100500FS1M 1.0100030 1.3 1.0 5.0100500RS1A 1.05030 1.3 1.0 5.0100150RS1B 1.010030 1.3 1.0 5.0100150RS1D 1.020030 1.3 1.0 5.0100150RS1G 1.040030 1.3 1.0 5.0100150RS1J 1.060030 1.3 1.0 5.0100250RS1K 1.080030 1.3 1.0 5.0100500RS1M 1.0100030 1.3 1.0 5.0100500FS2A 2.05050 1.3 2.0 5.0100150FS2B 2.010050 1.3 2.0 5.0100150FS2D 2.020050 1.3 2.0 5.0100150FS2G 2.040050 1.3 2.0 5.0100150FS2J 2.060050 1.3 2.0 5.0100250FS2K 2.080050 1.3 2.0 5.0100500FS2M 2.0100050 1.3 2.0 5.0100500FR1A 1.05030 1.3 1.0 5.0100150FR1B 1.010030 1.3 1.0 5.0100150FR1D 1.020030 1.3 1.0 5.0100150FR1G 1.040030 1.3 1.0 5.0100150FR1J 1.060030 1.3 1.0 5.0100250FR1K 1.080030 1.3 1.0 5.0100500FR1M 1.0100030 1.3 1.0 5.0100500FR1Q 1.0120030 1.5 1.0 5.0100300FR1V 1.0140030 1.5 1.0 5.0100300FR1Y 1.0160030 1.5 1.0 5.0100300FR1Z 1.0180030 1.7 1.0 5.0100500FR1ZZ 1.0200030 1.7 1.0 5.0100500FR2A 2.05050 1.3 2.0 5.0100150FR2B 2.010050 1.3 2.0 5.0100150FR2D 2.020050 1.3 2.0 5.0100150FR2G 2.040050 1.3 2.0 5.0100150FR2J 2.060050 1.3 2.0 5.0100250FR2K 2.080050 1.3 2.0 5.0100500FR2M 2.0100050 1.3 2.0 5.0100500FR3A 3.050100 1.3 3.010200150FR3B 3.0100100 1.3 3.010200150FR3D 3.0200100 1.3 3.010200150FR3G 3.0 400 100 1.3 3.0 10 200 150 SMC FR3J 3.0600100 1.3 3.010200250FR3K 3.0800100 1.3 3.010200500FR3M 3.01000100 1.3 3.010200500FR6A 6.050300 1.3 6.010200150FR6B 6.0100300 1.3 6.010200150FR6D 6.0200300 1.3 6.010200150FR6G 6.0400300 1.3 6.010200150HSMC FR6J 6.0600300 1.3 6.010200250FR6K 6.0800300 1.3 6.010200500FR6M 6.01000300 1.3 6.010200500FR8A 8.050300 1.38.010200150FR8B 8.0100300 1.38.010200150FR8D 8.0200300 1.38.010200150FR8G 8.0400300 1.38.010200150HSMC FR8J 8.0600300 1.38.010200250FR8K 8.0800300 1.38.010200500FR8M 8.01000300 1.38.010200500FR10A 10.050300 1.310.010200150FR10B 10.0100300 1.310.010200150FR10D 10.0200300 1.310.010200150FR10G 10.0400300 1.310.010200150HSMC FR10J 10.0600300 1.310.010200250FR10K 10.0800300 1.310.010200500FR10M 10.01000300 1.310.010200500SMA/SMB/HSMB SMB/HSMB HSMA/SMAE SMA HSMA/SMAE Case StyleI (AV)I FSM V FM I RM @V RRM Trr Type Average Forward Rectified CurrentPeak Repetitive Reverse Voltage Peak Forward Rectified Current Maximum Forward Voltage Maximum Peak Reverse Current Reverse Recovery Time SURFACE MOUNT FAST RECOVERY RECTIFIERS/HSMCV RRM(I=I RM )V FM I (AV)T A =25A VAVAAnsUF4001(G) 1.05030 1.0 1.01010050UF4002(G) 1.010030 1.0 1.01010050UF4003(G) 1.020030 1.0 1.01010050UF4004(G) 1.040030 1.3 1.01010050DO--41UF4005(G) 1.060030 1.7 1.01010075UF4006(G) 1.080030 1.7 1.01010075UF4007(G) 1.0100030 1.7 1.01010075UF5400(G) 3.050150 1.0 3.01010050UF5401(G) 3.0100150 1.0 3.01010050UF5402(G) 3.0200150 1.0 3.01010050UF5403(G) 3.0300150 1.0 3.01010050UF5404(G) 3.0400150 1.3 3.01010050DO--27UF5405(G) 3.0500150 1.7 3.01010075UF5406(G) 3.0600150 1.7 3.01010075UF5407(G) 3.0800150 1.7 3.01010075UF5408(G) 3.01000150 1.73.01010075"G"SUFFIX SINGNIFIES A GLASS PASSIVATED DIEV RRM(I=I RM )V FM I (AV)T A =25A VAVAAnsUS1A 1.05030 1.0 1.01010050US1B 1.010030 1.0 1.01010050US1D 1.020030 1.0 1.01010050US1G 1.040030 1.3 1.01010050US1J 1.060030 1.7 1.01010075US1K 1.080030 1.7 1.01010075US1M 1.0100030 1.7 1.01010075UF1A 1.05030 1.0 1.01010050UF1B 1.010030 1.0 1.01010050UF1D 1.020030 1.0 1.01010050UF1G 1.040030 1.3 1.01010050SMB UF1J 1.060030 1.7 1.01010075UF1K 1.080030 1.7 1.01010075UF1M 1.0100030 1.7 1.01010075US2A 2.05050 1.0 2.01010050US2B 2.010050 1.0 2.01010050US2D 2.020050 1.0 2.01010050US2G 2.040050 1.3 2.01010050US2J 2.060050 1.7 2.01010075US2K 2.080050 1.7 2.01010075US2M 2.0100050 1.7 2.01010075UF2A 2.05050 1.0 2.01010050UF2B 2.010050 1.0 2.01010050UF2D 2.020050 1.0 2.01010050UF2G 2.040050 1.3 2.01010050SMB UF2J 2.060050 1.7 2.01010075UF2K 2.080050 1.7 2.01010075UF2M 2.0100050 1.7 2.01010075UF3A 3.050100 1.0 3.01010050UF3B 3.0100100 1.0 3.01010050UF3D 3.0200100 1.0 3.01010050UF3G 3.0 400 100 1.3 3.0 10 100 50 SMC UF3J 3.0600100 1.7 3.01010075UF3K 3.0800100 1.7 3.01010075UF3M 3.01000100 1.7 3.01010075SMA/SMAE SMA/SMAEI FSM V FMI RM @V RRM Trr SURFACE MOUNT ULTRA FAST RECOVERY RECTIFIERSTypeAverageForward Rectified CurrentPeak Repetitive ReverseVoltage PeakForward Rectified Current Maximum Forward Voltage Maximum Peak Reverse Current Reverse Recovery Time Case StyleI (AV)I FSM V FMI RM @V RRM Trr TypeForward Rectified Current Repetitive Reverse VoltageForward Rectified Current Forward Voltage Peak Reverse Current Recovery Time Case StyleI (AV)V RRM(I=I RM)V FM I(AV)T A=25A V A V A A nsSF11 1.050300.95 1.0 5.05035 SF12 1.0100300.95 1.0 5.05035 SF13 1.0150300.95 1.0 5.05035 SF14 1.0200300.95 1.0 5.05035 SF15 1.030030 1.25 1.0 5.05035 SF16 1.040030 1.25 1.0 5.05035 MUR105(G) 1.050350.975 1.0 5.05045 MUR110(G) 1.0100350.975 1.0 5.05045 MUR115(G) 1.0150350.975 1.0 5.05045 MUR120(G) 1.020035 1.35 1.0 5.05045 MUR140(G) 1.040035 1.35 1.0 5.05060 MUR160(G) 1.060035 1.35 1.0 5.05060 MUR180 1.080035 1.75 1.0 5.05075 MUR1100 1.0100035 1.75 1.0 5.05075 SF21 2.050500.95 2.0 5.05035 SF22 2.0100500.95 2.0 5.05035 SF23 2.0150500.95 2.0 5.05035 SF24 2.0200500.95 2.0 5.05035 SF25 2.030050 1.25 2.0 5.05035 SF26 2.040050 1.25 2.0 5.05035 SF31 3.0501250.95 3.0 5.05035 SF32 3.01001250.95 3.0 5.05035 SF33 3.01501250.95 3.0 5.05035 SF34 3.02001250.95 3.0 5.05035 SF35 3.0300125 1.25 3.0 5.05035 SF36 3.0400125 1.25 3.0 5.05035 MUR405 4.050150 1.0 4.010.020045 MUR410 4.0100150 1.0 4.010.020045 MUR415 4.0150150 1.0 4.010.020045 MUR420 4.0200150 1.35 4.010.020060 MUR440 4.0400150 1.35 4.010.020060 MUR460 4.0600150 1.35 4.010.020060 MUR480 4.0800150 1.85 4.010.020075 MUR4100 4.01000150 1.85 4.010.020075 SF51 5.0501500.95 5.0 5.010035 SF52 5.01001500.95 5.0 5.010035 SF53 5.01501500.95 5.0 5.010035 SF54 5.02001500.95 5.0 5.010035 SF55 5.0300150 1.25 5.0 5.010035 SF56 5.0400150 1.25 5.0 5.010035 SF61 6.0501500.95 6.0 5.010035 SF62 6.01001500.95 6.0 5.010035 SF63 6.01501500.95 6.0 5.010035 SF64 6.02001500.95 6.0 5.010035 SF65 6.0300150 1.25 6.0 5.010035 SF66 6.0400150 1.25 6.0 5.010035 MUR605CT 6.05040 1.25 3.0 5.010035 MUR610CT 6.010040 1.25 3.0 5.010035 MUR620CT 6.020040 1.25 3.0 5.010035 MUR640CT 6.040040 1.35 3.0 5.010060 MUR660CT 6.060040 1.35 3.0 5.010060 MURH805CT8.050100 1.25 4.050.050035 MURH810CT8.0100100 1.25 4.050.050035 MURH820CT8.0200100 1.25 4.050.050035MURH840CT8.0400100 1.25 4.050.050060 MURH860CT8.0600100 2.8 4.050.050060 MURH880CT8.0800100 2.8 4.050.050060 MURH8100CT8.01000100 2.8 4.050.050060TO-220AB DO--27 DO--27 DO--27 TO-220AB DO--41 DO--41 DO--15 DO--27I FSM V FM I RM@V RRMTrrType ForwardRectifiedCurrentRepetitiveReverseVoltageForwardRectifiedCurrentForwardVoltagePeakReverseCurrentRecoveryTime CaseStyle I(AV)V RRM(I=I RM )V FM I (AV)T A =25A VAVAAnsMUR(F)8058.050125 1.08.010.050035MUR(F)8108.0100125 1.08.010.050035MUR(F)8208.0200125 1.08.010.050035MUR(F)8308.0300125 1.38.010.050035MUR(F)8408.0400125 1.38.010.050035MUR(F)8608.0600125 1.58.010.050050MUR(F)8808.0800125 1.58.010.050050MUR(F)805CT 8.050100 1.0 4.010.050035MUR(F)810CT 8.0100100 1.0 4.010.050035MUR(F)820CT 8.0200100 1.0 4.010.050035MUR(F)830CT 8.0300100 1.3 4.010.050035MUR(F)840CT 8.0400100 1.3 4.010.050035MUR(F)860CT 8.0600100 1.5 4.010.050050MUR(F)880CT 8.0800100 1.5 4.010.050050MUR(F)1005CT 10.050125 1.0 5.010.050035MUR(F)1010CT 10.0100125 1.0 5.010.050035MUR(F)1020CT 10.0200125 1.0 5.010.050035MUR(F)1030CT 10.0300125 1.3 5.010.050035MUR(F)1040CT 10.0400125 1.3 5.010.050035MUR(F)1060CT 10.0600125 1.5 5.010.050050MUR(F)1080CT 10.0800125 1.5 5.010.050050MUR(F)1605CT 16.050125 1.08.010.050035MUR(F)1610CT 16.0100125 1.08.010.050035MUR(F)1620CT 16.0200125 1.08.010.050035MUR(F)1630CT 16.0300125 1.38.010.050035MUR(F)1640CT 16.0400125 1.38.010.050035MUR(F)1660CT 16.0600125 1.58.010.050050MUR(F)1680CT 16.0800125 1.58.010.050050MUR(F)2005CT 20.050150 1.010.010.050035MUR(F)2010CT 20.0100150 1.010.010.050035MUR(F)2020CT 20.0200150 1.010.010.050035MUR(F)2030CT 20.0300150 1.310.010.050035MUR(F)2040CT 20.0400150 1.310.010.050035MUR(F)2060CT 20.0600150 1.510.010.050050MUR(F)2080CT 20.0800150 1.510.010.050050MUR3005PT 30.050300 1.015.010.050035MUR3010PT 30.0100300 1.015.010.050035MUR3020PT 30.0200300 1.015.010.050035MUR3030PT 30.0300300 1.315.010.050035MUR3040PT 30.0400300 1.315.010.050035MUR150515.050150 1.2515.050.050035MUR151015.0100150 1.2515.050.050035MUR152015.0200150 1.2515.050.050035MUR154015.0400150 1.515.050.050060MUR156015.06001501.515.050.050060Peak Reverse Current Recovery Time Case StyleI (AV)I FSM V FMI RM @V RRM Trr TO-220AB(ITO-220AB)TO-220AB(ITO-220AB)TO-3P (TO-247AD)TO-220ACTO-220AC(ITO-220AC)TO-220AB(ITO-220AB)TO-220AB(ITO-220AB)TypeForward Rectified Current Repetitive Reverse VoltageForward Rectified Current Forward VoltageV RRM(I=I RM )V FM I (AV)T A =25A VAVAAnsEMS101/DLSF11 1.050300.95 1.0 5.05035EMS102/DLSF12 1.0100300.95 1.0 5.05035EMS103/DLSF13 1.0150300.95 1.0 5.05035EMS104/DLSF14 1.0200300.95 1.0 5.05035EMS105/DLSF15 1.030030 1.25 1.0 5.05050EMS106/DLSF161.040030 1.25 1.0 5.05050ES1A 1.050300.95 1.0 5.05050ES1B 1.0100300.95 1.0 5.05050ES1C 1.0150300.95 1.0 5.05050ES1D 1.0200300.95 1.0 5.05050ES1E 1.030030 1.25 1.0 5.05050ES1G 1.040030 1.25 1.0 5.05050ES1J 1.060030 1.35 1.0 5.05060ES1K 1.080030 1.35 1.0 5.05060ES1M 1.0100030 1.60 1.0 5.050100ES2A2.050500.95 2.0 5.05050ES2B 2.0100500.95 2.0 5.05050ES2D 2.0200500.95 2.0 5.05050ES2G 2.040050 1.25 2.0 5.05050ES2J 2.060050 1.35 2.0 5.05060ES2K 2.080050 1.35 2.0 5.05060ES2M 2.0100050 1.60 2.0 5.050100ER1A 1.050300.95 1.0 5.05050ER1B 1.0100300.95 1.0 5.05050ER1C 1.0150300.95 1.0 5.05050ER1D 1.0200300.95 1.0 5.05050ER1E 1.030030 1.25 1.0 5.05050ER1G 1.040030 1.25 1.0 5.05050ER1J 1.060030 1.35 1.0 5.05060ER1K 1.080030 1.35 1.0 5.05060ER1M 1.0100030 1.60 1.0 5.050100ER1Q 1.0120030 1.85 1.0 5.050150ER1V 1.0140030 1.85 1.0 5.050150ER1Y 1.0160030 2.00 1.0 5.050150ER1Z 1.0180030 2.00 1.0 5.050300ER1ZZ 1.0200030 2.00 1.0 5.050300ER2A 2.050500.95 2.0 5.05050ER2B 2.0100500.95 2.0 5.05050ER2C 2.0150500.95 2.0 5.05050ER2D 2.0200500.95 2.0 5.05050ER2E 2.030050 1.25 2.0 5.05050ER2G 2.040050 1.25 2.0 5.05050ER2J 2.060050 1.35 2.0 5.05060ER2K 2.080050 1.35 2.0 5.05060ER2M 2.0100050 1.60 2.0 5.050100ER3A3.0501000.95 3.0 5.05035ER3B 3.01001000.95 3.0 5.05035ER3C 3.01501000.95 3.0 5.05035ER3D 3.02001000.95 3.0 5.05035ER3E 3.0300100 1.25 3.0 5.05035ER3G 3.0400100 1.25 3.0 5.05035ER3J 3.0600100 1.70 3.0 5.05035ER3K 3.0800100 1.70 3.0 5.05035ER6A 6.050125 1.25 6.010.010050ER6B 6.0100125 1.25 6.010.010050ER6D 6.0200125 1.25 6.010.010050ER6G 6.0400125 1.25 6.010.010060ER8A 8.050150 1.358.010.010050ER8B 8.0100150 1.358.010.010050ER8D 8.0200150 1.358.010.010050HSMCER8G 8.0400150 1.358.010.010050ER8J 8.0600150 1.358.010.010060ER10A 10.050200 1.0010.010.010035ER10B 10.0100200 1.0010.010.010035ER10D 10.0200200 1.0010.010.010035ER10G10.04002001.0010.010.010060HSMCHSMCSMA/SMB/HSMBSMB/HSMBSMC/HSMCMELFSMA/HSMA/SMAESMB/HSMA/SMAEI FSM V FMI RM @V RRM Trr SURFACE MOUNT SUPER FAST RECOVERY RECTIFIERSTypeAverageForward Rectified CurrentPeak Repetitive ReverseVoltage Peak Forward Rectified Current Maximum Forward Voltage Maximum Peak Reverse Current Reverse Recovery Time Case StyleI (AV)。

安徽富信半导体科技有限公司ANHUI FOSAN SEMICONDUCTOR TECHNOLOGY CO.,LTD.BAV19WS-BAV21WS SOD-323Switching Diode开关二极管■Features特点Fast Switching Speed快的开关速度Surface mount device表面贴装器件High Conductance高电导率Case封装:SOD-323■Maximum Rating最大额定值(T A=25℃unless otherwise noted如无特殊说明，温度为25℃)Characteristic特性参数Symbol符号BAV19WS BAV20WS BAV21WS Unit单位Peak Reverse Voltage反向峰值电压V RRM120200250VDC Reverse Voltage直流反向电压V R120200250V RMS Reverse Voltage反向电压均方根值V R(RMS)100150200V Forward Rectified Current正向整流电流I F0.25A@1SPeak Surge Current峰值浪涌电流@1mS@1µS I FSM139APower Dissipation耗散功率P D200mW Thermal Resistance J-A结到环境热阻RθJA625℃/W Junction/Storage Temperature结温/储藏温度T J,T stg-50to+150℃℃■Electrical Characteristics电特性(T A=25℃unless otherwise noted如无特殊说明，温度为25℃)Characteristic特性参数Symbol符号BAV19WS BAV20WS BAV21WS Unit单位Condition条件Reverse Voltage反向电压V R120200250V I R=1mA Forward Voltage正向电压V F 1.25V I F=0.2A Reverse Current反向电流I R0.1µA V R=V RRM Reverse Recovery Time Trr50nSDiode Capacitance二极管电容C T5pF V R=4V,f=1MHzANHUI FOSAN SEMICONDUCTOR TECHNOLOGY CO.,LTD.BAV19WS-BAV21WS ■Typical Characteristic Curve典型特性曲线ANHUI FOSAN SEMICONDUCTOR TECHNOLOGY CO.,LTD.BAV19WS-BAV21WS ■Dimension外形封装尺寸SOD-323。

安徽富信半导体科技有限公司ANHUI FOSAN SEMICONDUCTOR TECHNOLOGY CO.,LTD.DSK22-DSK210SOD-123FL Schottky Barrier Rectifier Diode肖特基势垒整流二极管■Features 特点Low forward voltage drop 低正向压降High current capability 高电流能力Surface mount device 表面贴装器件Case 封装:SOD-123FL■Maximum Rating 最大额定值(T A =25℃unless otherwise noted 如无特殊说明，温度为25℃)Characteristic 特性参数Symbol 符号DSK 22DSK 23DSK 24DSK 25DSK 26DSK 27DSK 28DSK 29DSK 210Unit 单位Marking 印字K22K23K24K25K26K27K28K29K210Peak Reverse Voltage 反向峰值电压V RRM 2030405060708090100V DC Reverse Voltage 直流反向电压V R 2030405060708090100V RMS Reverse Voltage 反向电压均方根值V R(RMS)142128354249566370V Forward Rectified Current 正向整流电流I F 2A Peak Surge Current 峰值浪涌电流I FSM 50AThermal Resistance J-A 结到环境热阻R θJA 85℃/WJunction/Storage Temperature 结温/储藏温度T J,T stg -50to+150℃℃■Electrical Characteristics 电特性(T A =25℃unless otherwise noted 如无特殊说明，温度为25℃)Characteristic 特性参数Symbol 符号DSK22-DSK25DSK26-DSK27DSK28-DSK210Unit 单位Condition 条件Forward Voltage 正向电压V F 0.550.700.85V I F =2A Reverse Current 反向电流I R (25℃)(100℃)0.550.33mA V R =V RRM Diode Capacitance 二极管电容C D22080pFV R =4V,f=1MHz安徽富信半导体科技有限公司ANHUI FOSAN SEMICONDUCTOR TECHNOLOGY CO.,LTD.DSK22-DSK210■Typical Characteristic Curve典型特性曲线■SOD-123FL Dimension外形封装尺寸Unit in millimeters单位：毫米。
