Alcatel 7750 SR 设备查看命令贝尔阿尔卡特股份互联网事业部2006年10月1、系统运行状态查看1.1查看路由器硬件状态# show chassisA:YZ-SYL-R-AC7750-01# show chassis=============================================================================== Chassis Information=============================================================================== Name : YZ-SYL-R-AC7750-01 Type : 7750 SR-12 Location : Coordinates : CLLI code : Number of slots : 12 Number of ports : 60 Critical LED state : Off Major LED state : Off Minor LED state : Off Base MAC address : 00:03:fa:df:fb:56 Admin chassis mode : c Oper chassis mode : cHardware DataPart number : 3HE00104AAAB01 CLEI code : IPME400FRA Serial number : NS061751349 Manufacture date : 05022006 Manufacturing string : Manufacturing deviations : Time of last boot : 2006/11/15 01:39:03 Current alarm state : alarm clearedEnvironment InformationNumber of fan trays : 3 Number of fans : 6Fan tray number : 1 Status : up Speed : half speedFan tray number : 2Status : up Speed : half speedFan tray number : 3 Status : up Speed : half speedPower Supply InformationNumber of power supplies : 2Power supply number : 1 Defaulted power supply type : dc Status : upPower supply number : 2 Defaulted power supply type : dc Status : up =============================================================================== A:YZ-SYL-R-AC7750-01## show cardA:YZ-SYL-R-AC7750-01# show card=============================================================================== Card Summary=============================================================================== Slot Provisioned Equipped Admin Operational Card-type Card-type State State -------------------------------------------------------------------------------1 iom2-20g iom2-20g up up2 iom2-20g iom2-20g up up3 iom2-20g iom2-20g up upA sfm-400g sfm2-200g up up/activeB sfm-400g sfm2-200g up up/standby===============================================================================A:YZ-SYL-R-AC7750-01# show card a detail=============================================================================== Card A=============================================================================== Slot Provisioned Equipped Admin Operational Card-type Card-type State State------------------------------------------------------------------------------- A sfm-400g sfm2-200g up up/activeBOF last modified : N/A Config file version : TUE NOV 14 15:46:33 2006 UTC Config file last modified : 2006/11/29 23:23:28 Config file last saved : 2006/11/28 16:15:09 CPM redundancy status : activeFlash - cf1:Administrative State : up Operational state : not equippedFlash - cf2:Administrative State : up Operational state : not equippedFlash - cf3:Administrative State : up Operational state : up Serial number : 146CT066S0763SC0153 Firmware revision : V2.23 Model number : SILICONSYSTEMS INC 256MB Size : 253,932 KB Free space : 68,488 KBHardware DataPart number : 3HE01171AAAA01CLEI code : IPUCAEAFAA Serial number : NS061750736 Manufacture date : 05092006 Manufacturing string : Manufacturing deviations : Administrative state : up Operational state : up Temperature : 43C Temperature threshold : 75C Software boot version : X-4.0.R1 on Thu Apr 27 12:42:18 PST 2006 b* Software version : TiMOS-C-4.0.R3 cpm/hops ALCATEL SR 7750 Co* Time of last boot : 2006/11/15 01:39:03 Current alarm state : alarm cleared Base MAC address : 00:03:fa:ac:ea:da Memory capacity : 2,016 MB=============================================================================== A:YZ-SYL-R-AC7750-01## show mdaA:YZ-SYL-R-AC7750-01# show mda=============================================================================== MDA Summary=============================================================================== Slot Mda Provisioned Equipped Admin Operational Mda-type Mda-type State State -------------------------------------------------------------------------------1 1 m10-1gb-sfp m10-1gb-sfp up up2 m10-1gb-sfp m10-1gb-sfp up up 2 1 m10-1gb-sfp m10-1gb-sfp up up2 m10-1gb-sfp m10-1gb-sfp up up3 1 m10-1gb-sfp m10-1gb-sfp up up 2 m10-1gb-sfp m10-1gb-sfp up up ===============================================================================A:YZ-SYL-R-AC7750-01# show mda 1/1 detail=============================================================================== MDA 1/1 detail=============================================================================== Slot Mda Provisioned Equipped Admin Operational Mda-type Mda-type State State ------------------------------------------------------------------------------- 1 1 m10-1gb-sfp m10-1gb-sfp up upMDA Specific DataMaximum port count : 10 Number of ports equipped : 10 Network ingress queue policy : JSYZ-NIQ Capabilities : EthernetHardware DataPart number : 3HE00026AAAC01 CLEI code : IPPAAANBAA Serial number : NS061350207 Manufacture date : 03272006Manufacturing string : Manufacturing deviations : Administrative state : up Operational state : up Temperature : 41C Temperature threshold : 75C Time of last boot : 2006/11/15 01:39:51 Current alarm state : alarm cleared Base MAC address : 00:03:fa:c6:ff:4c =============================================================================== A:YZ-SYL-R-AC7750-01#1.2查看物理端口状态#show portA:YZ-SYL-R-AC7750-01# show port============================================================================== Ports on Slot 1============================================================================== Port Admin Link Port Cfg Oper LAG/ Port Port Port SFP/XFP/ Id State State MTU MTU Bndl Mode Encp Type MDIMDX ------------------------------------------------------------------------------ 1/1/1 Up Yes Up9212 9212 - netw null gige GIGE-LX 10KM1/1/2 Up Yes Up 9212 9212 - netw null gige GIGE-LX 10KM 1/1/3 Up Yes Up 1518 1518 - accs dotq gige GIGE-LX 10KM 1/1/4 Up Yes Up 1518 1518 - accs dotq gige GIGE-LX 10KM 1/1/5 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 1/1/6 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 1/1/7 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 1/1/8 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 1/1/9 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 1/1/10 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 1/2/1 Up Yes Up 1518 1518 - accs dotq gige GIGE-LX 10KM 1/2/2 Up No Down 1518 1518 - accs dotq gige GIGE-LX 10KM 1/2/3 Up No Down 1518 1518 - accs dotq gige GIGE-LX 10KM 1/2/4 Down No Down 1518 1518 - accs dotq gige GIGE-LX 10KM 1/2/5 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 1/2/6 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM1/2/8 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 1/2/9 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 1/2/10 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM============================================================================== Ports on Slot 2============================================================================== Port Admin Link Port Cfg Oper LAG/ Port Port Port SFP/XFP/ Id State State MTU MTU Bndl Mode Encp Type MDIMDX ------------------------------------------------------------------------------ 2/1/1 Up Yes Up 9212 9212 - netw null gige GIGE-LX 10KM 2/1/2 Up Yes Up 9212 9212 - netw null gige GIGE-LX 10KM 2/1/3 Up Yes Up 1518 1518 - accs dotq gige GIGE-LX 10KM 2/1/4 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 2/1/5 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 2/1/6 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 2/1/7 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 2/1/8 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 2/1/9 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 2/1/10 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 2/2/1 Up Yes Up 1518 1518 - accs dotq gige GIGE-LX 10KM 2/2/2 Down No Down 9212 9212 - netw null gige GIGE-LX 10KM 2/2/3 Down No Down 9212 9212 - netw null gige GIGE-LX 40KM 2/2/4 Down No Down 9212 9212 - netw null gige GIGE-LX 40KM 2/2/5 Down No Down 9212 9212 - netw null gige GIGE-LX 40KM 2/2/6 Down No Down 9212 9212 - netw null gige GIGE-LX 40KM 2/2/7 Down No Down 9212 9212 - netw null gige GIGE-LX 40KM 2/2/8 Down No Down 9212 9212 - netw null gige GIGE-LX 40KM 2/2/9 Down No Down 9212 9212 - netw null gige GIGE-LX 40KM 2/2/10 Down No Down 9212 9212 - netw null gige GIGE-LX 40KM============================================================================== Ports on Slot 3============================================================================== Port Admin Link Port Cfg Oper LAG/ Port Port Port SFP/XFP/ Id State State MTU MTU Bndl Mode Encp Type MDIMDX ------------------------------------------------------------------------------ 3/1/1 Down No Down 9212 9212 - netw null gige GIGE-LX 40KM 3/1/2 Down No Down 9212 9212 - netw null gige GIGE-LX 40KM 3/1/3 Down No Down 9212 9212 - netw null gige GIGE-LX 40KM 3/1/4 Down No Down 9212 9212 - netw null gige GIGE-LX 40KM 3/1/5 Down No Down 9212 9212 - netw null gige GIGE-LX 40KM 3/1/6 Down No Down 9212 9212 - netw null gige GIGE-LX 40KM3/1/8 Down No Down 9212 9212 - netw null gige GIGE-LX 80KM 3/1/9 Down No Down 9212 9212 - netw null gige GIGE-LX 80KM 3/1/10 Down No Down 9212 9212 - netw null gige GIGE-LX 80KM 3/2/1 Down No Down 9212 9212 - netw null gige GIGE-LX 80KM 3/2/2 Down No Down 9212 9212 - netw null gige GIGE-LX 80KM 3/2/3 Down No Down 9212 9212 - netw null gige GIGE-LX 80KM 3/2/4 Down No Down 9212 9212 - netw null gige GIGE-SX 3/2/5 Down No Down 9212 9212 - netw null gige GIGE-SX 3/2/6 Down No Down 9212 9212 - netw null gige GIGE-SX 3/2/7 Down No Down 9212 9212 - netw null gige 3/2/8 Down No Down 9212 9212 - netw null gige 3/2/9 Down No Down 9212 9212 - netw null gige 3/2/10 Down No Down 9212 9212 - netw null gige============================================================================== Ports on Slot A============================================================================== Port Admin Link Port Cfg Oper LAG/ Port Port Port SFP/XFP/ Id State State MTU MTU Bndl Mode Encp Type MDIMDX ------------------------------------------------------------------------------ A/1 Up No Down 1514 1514 - netw null faste============================================================================== Ports on Slot B============================================================================== Port Admin Link Port Cfg Oper LAG/ Port Port Port SFP/XFP/ Id State State MTU MTU Bndl Mode Encp Type MDIMDX ------------------------------------------------------------------------------ B/1 Up No Down 1514 1514 - netw null faste ============================================================================== A:YZ-SYL-R-AC7750-01##show port id(x/x/x,x/x/x..x) [detail]A:YZ-SYL-R-AC7750-01# show port 1/1/1 detail=============================================================================== Ethernet Interface=============================================================================== Description : 1-Gig Ethernet SFPInterface : 1/1/1 Oper Speed : 1 Gbps Link-level : Ethernet Config Speed : N/A Admin State : up Oper Duplex : full Oper State : up Config Duplex : N/A Physical Link : Yes MTU : 9212 IfIndex : 18907136 Hold time up : 0 seconds Last State Change : 11/15/2006 01:39:53 Hold time down : 0 secondsConfigured Mode : network Encap Type : null Dot1Q Ethertype : 0x8100 QinQ Ethertype : 0x8100 Net. Egr. Queue Pol: default Auto-negotiate : false MDI/MDX : N/A Accounting Policy : None Collect-stats : Disabled Egress Rate : Default Ingress Rate : Default Load-balance-algo : defaultConfigured Address : 00:03:fa:c6:ff:4cHardware Address : 00:03:fa:c6:ff:4cCfg Alarm :Alarm Status :Transceiver DataTransceiver Type : SFP Model Number : 3HE00028AAAA01 ALA IPUIAEMDAA= Transceiver Code : GIGE-LX TX Laser Wavelength: 1310 nm Diag Capable : no Connector Code : LC Vendor OUI : 00:0a:1d Manufacture date : 2006/05/05 Media : Ethernet Serial Number :Part Number : TRPNG1LXDBBS-TM Optical Compliance : GIGE-LX Link Length support: 10km for SMF;=============================================================================== Traffic Statistics=============================================================================== Input Output------------------------------------------------------------------------------- Octets 60 13PacketsErrors 0 0=============================================================================== Ethernet Statistics===============================================================================Broadcast Pckts : 2 Drop Events : 0 Multicast Pckts : 1543727 CRC/Align Errors : 0 Undersize Pckts : 0 Fragments : 0 Oversize Pckts : 0 Jabbers : 0 Collisions : 0Octets : 073Packets :Packets of 64 Octets : 4849684820Packets of 65 to 127 Octets : 7271812018Packets of 128 to 255 Octets : 1838819639Packets of 256 to 511 Octets : 585878818Packets of 512 to 1023 Octets : 1618216965Packets of 1024 to 1518 Octets : 8117037494Packets of 1519 or more Octets : 316907685============================================================================================================================================================== Port Statistics=============================================================================== Input Output ------------------------------------------------------------------------------- Unicast PacketsMulticast Packets 1208494 335233 Broadcast Packets 1 1 Discards 0 0 Unknown Proto Discards 0 ============================================================================================================================================================== Ethernet-like Medium Statistics===============================================================================Alignment Errors : 0 Sngl Collisions : 0 FCS Errors : 0 Mult Collisions : 0SQE Test Errors : 0 Late Collisions : 0 CSE : 0 Excess Collisns : 0 Too long Frames : 0 Int MAC Tx Errs : 0 Symbol Errors : 0 Int MAC Rx Errs : 0 ============================================================================================================================================================== Queue Statistics===============================================================================------------------------------------------------------------------------------- Ingress Queue 2 Packets OctetsIn Profile forwarded : 0 0 In Profile dropped : 0 0 Out Profile forwarded : 41Out Profile dropped : 0 0 Ingress Queue 3 Packets OctetsIn Profile forwarded : 0 0 In Profile dropped : 0 0 Out Profile forwarded : 0 0 Out Profile dropped : 0 0 Ingress Queue 4 Packets OctetsIn Profile forwarded : 44516 2932921 In Profile dropped : 0 0 Out Profile forwarded : 0 0 Out Profile dropped : 0 0 Ingress Queue 5 Packets OctetsIn Profile forwarded : 18029 1693345 In Profile dropped : 0 0 Out Profile forwarded : 0 0 Out Profile dropped : 0 0 Ingress Queue 6 Packets OctetsIn Profile forwarded : 0 0 In Profile dropped : 0 0 Out Profile forwarded : 0 0 Out Profile dropped : 0 0 Ingress Queue 12 Packets OctetsIn Profile forwarded : 0 0 In Profile dropped : 0 0 Out Profile forwarded : 0 0 Out Profile dropped : 0 0Egress Queue 1 Packets OctetsIn Profile forwarded : 0 0In Profile dropped : 0 0 Out Profile forwarded : 67Out Profile dropped : 0 0 Egress Queue 2 Packets OctetsIn Profile forwarded : 0 0 In Profile dropped : 0 0 Out Profile forwarded : 0 0 Out Profile dropped : 0 0 Egress Queue 3 Packets OctetsIn Profile forwarded : 0 0 In Profile dropped : 0 0 Out Profile forwarded : 0 0 Out Profile dropped : 0 0 Egress Queue 4 Packets OctetsIn Profile forwarded : 0 0 In Profile dropped : 0 0 Out Profile forwarded : 0 0 Out Profile dropped : 0 0 Egress Queue 5 Packets OctetsIn Profile forwarded : 0 0 In Profile dropped : 0 0 Out Profile forwarded : 0 0 Out Profile dropped : 0 0 Egress Queue 6 Packets OctetsIn Profile forwarded : 0 0 In Profile dropped : 0 0 Out Profile forwarded : 0 0 Out Profile dropped : 0 0 Egress Queue 7 Packets OctetsIn Profile forwarded : 581 108066 In Profile dropped : 0 0 Out Profile forwarded : 0 0 Out Profile dropped : 0 0 Egress Queue 8 Packets OctetsIn Profile forwarded : 363238 37062560 In Profile dropped : 0 0 Out Profile forwarded : 0 0 Out Profile dropped : 0 0 =============================================================================== A:YZ-SYL-R-AC7750-01#1.3查看系统环境状态# show chassis environmentA:YZ-SYL-R-AC7750-01# show chassis environment=============================================================================== Chassis Information===============================================================================Environment InformationNumber of fan trays : 3 Number of fans : 6Fan tray number : 1 Status : upSpeed : half speedFan tray number : 2 Status : up Speed : half speedFan tray number : 3 Status : up Speed : half speed =====================================================#show system cpuA:YZ-SYL-R-AC7750-01# show system cpu=========================================CPU Utilization (Test time 999455 uSec)=========================================Name CPU Time CPU Usage(uSec) -----------------------------------------System 19927 1.99%Icc 1941 0.19%RTM/Policies 580 0.05%OSPF 185 0.01%MPLS/RSVP 2437 0.24%LDP 13339 1.33%IS-IS 3854 0.38%RIP 0 0.00%VRRP 0 0.00%BGP 489 0.04%Services 291 0.02%IOM 0 0.00%CFLOWD 0 0.00%IGMP 0 0.00%PIM 0 0.00%MCast Stack 0 0.00%IP Stack 9250 0.92%MBUF 0 0.00%IGMP Snooping 114 0.01%TLS MFIB 693 0.06%WEB Redirect 131 0.01%Idle 946224 94.67%=========================================A:YZ-SYL-R-AC7750-01##show system memoryA:YZ-SYL-R-AC7750-01# show system memory-pools=============================================================================== Memory Pools=============================================================================== Name Max Allowed Current Size Max So Far In Use ------------------------------------------------------------------------------- System No limit 56,858,272 66,819,744 46,253,744 Icc 8,388,608 1,048,576 1,048,576 60,704 RTM/Policies No limit 3,145,728 3,145,728 1,809,896 OSPF No limit 1,048,576 1,048,576 433,560 MPLS/RSVP No limit 5,464,464 7,561,616 4,310,728 LDP No limit 4,194,304 4,194,304 3,380,800 IS-IS No limit 4,497,472 4,497,472 3,734,648 RIP No limit 0 0 0 VRRP No limit 1,048,576 1,048,576 72 BGP No limit 12,484,800 12,484,800 11,690,304Services No limit 3,145,728 3,145,728 2,833,144IOM No limit 0 0 0CFLOWD No limit 0 0 0IGMP No limit 0 0 0PIM No limit 0 0 0MCast Stack No limit 1,048,576 1,048,576 32,024IP Stack No limit 29,901,264 29,901,264 28,868,504MBUF No limit 5,837,312 5,837,312 4,831,872IGMP Snooping No limit 1,048,576 1,048,576 135,088TLS MFIB No limit 1,048,576 1,048,576 533,712WEB Redirect 8,388,608 2,097,152 2,097,152 1,361,648-------------------------------------------------------------------------------Current Total Size : 133,917,952 bytesTotal In Use : 110,270,448 bytesAvailable Memory : 1,857,171,136 bytes===============================================================================A:YZ-SYL-R-AC7750-01#1.4查看系统日志信息# show log log-id xxA:YZ-SYL-R-AC7750-01# show log log-id 99===============================================================================Event Log 99=============================================================================== Description : Default System LogMemory Log contents [size=500 next event=3478 (wrapped)]3477 2006/11/30 02:33:58.22 BEIJ WARNING: SYSTEM #2009 - IP"Status of vRtrIfTable: router 1 interface yajdgs (index 82) changed administrative state: inService, operational state: inService"3476 2006/11/30 02:33:58.22 BEIJ WARNING: SNMP #2005 - yajdgs"Interface yajdgs is operational"3475 2006/11/30 02:33:58.22 BEIJ MINOR: SVCMGR #2103 -"Status of service 21034048 (customer 10) changed to administrative state: up, operational state: up"3474 2006/11/30 02:33:58.21 BEIJ MINOR: SVCMGR #2108 -"Status of interface yajdgs in service 21034048 (customer 10) changed to admin=up oper=up"3473 2006/11/30 02:33:58.21 BEIJ MINOR: SVCMGR #2203 -"Status of SAP 2/1/3:4048 in service 21034048 (customer 10) changed to admin=up oper=up"3472 2006/11/30 02:33:58.21 BEIJ MINOR: SVCMGR #2103 -"Status of service 21034047 (customer 10) changed to administrative state: up, operational state: up"3471 2006/11/30 02:33:58.21 BEIJ WARNING: SYSTEM #2009 - IP"Status of vRtrIfTable: router 1 interface yz-lgbj (index 81) changed administrative state: inService, operational state: inService"3470 2006/11/30 02:33:58.21 BEIJ WARNING: SNMP #2005 - yz-lgbj"Interface yz-lgbj is operational"3469 2006/11/30 02:33:58.21 BEIJ MINOR: SVCMGR #2108 -"Status of interface yz-lgbj in service 21034047 (customer 10) changed to admin=up oper=up"3468 2006/11/30 02:33:58.20 BEIJ MINOR: SVCMGR #2203 -"Status of SAP 2/1/3:4047 in service 21034047 (customer 10) changed to admin=up oper=up"Press any key to continue (Q to quit)A:YZ-SYL-R-AC7750-01# show log log-id 100===============================================================================Event Log 100=============================================================================== Description : Default Serious Errors Logwarning: 3462 events dropped from logMemory Log contents [size=500 next event=16 (not wrapped)]15 2006/11/29 16:30:58.53 BEIJ MAJOR: LOGGER #2008 - log-id 11 file-id 11"Log file cf3:\log\log18-082916 on compact flash cf3 has been rolled over"14 2006/11/28 16:29:16.94 BEIJ MAJOR: LOGGER #2008 - log-id 11 file-id 11"Log file cf3:\log\log17-081615 on compact flash cf3 has been rolled over"13 2006/11/28 16:15:09.15 BEIJ MAJOR: SYSTEM #2002 - Configuration Save Succeeds "Configuration file saved to: cf3:\config.cfg"12 2006/11/27 16:16:15.26 BEIJ MAJOR: LOGGER #2008 - log-id 11 file-id 11"Log file cf3:\log\log16-075300 on compact flash cf3 has been rolled over"11 2006/11/26 15:53:00.68 BEIJ MAJOR: LOGGER #2008 - log-id 11 file-id 11"Log file cf3:\log\log15-074859 on compact flash cf3 has been rolled over"10 2006/11/25 15:48:59.84 BEIJ MAJOR: LOGGER #2008 - log-id 11 file-id 11"Log file cf3:\log\log14-045323 on compact flash cf3 has been rolled over"9 2006/11/21 11:00:04.78 BEIJ MAJOR: SYSTEM #2002 - Configuration Save Succeeds "Configuration file saved to: cf3:\config.cfg"8 2006/11/15 05:00:44.01 BEIJ MAJOR: SYSTEM #2002 - Configuration Save Succeeds "Configuration file saved to: cf3:\config.cfg"7 2006/11/15 01:39:34.85 BEIJ MAJOR: SYSTEM #2025 - Redundancy"Redundancy synchronization with standby CPM card B has completed. Standby CPM is ready."6 2006/11/15 01:39:34.06 BEIJ MAJOR: SYSTEM #2024 - Redundancy"Redundancy synchronization with standby CPM card B is in progress."Press any key to continue (Q to quit)1.5基本链路检测命令#ping ip-address(xxx..xxx.xxx.xxx)A:YZ-SYL-R-AC7750-01# ping 61.177.186.25PING 61.177.186.25 56 data bytes64 bytes from 61.177.186.25: icmp_seq=1 ttl=64 time<10ms.64 bytes from 61.177.186.25: icmp_seq=2 ttl=64 time<10ms.64 bytes from 61.177.186.25: icmp_seq=3 ttl=64 time<10ms.64 bytes from 61.177.186.25: icmp_seq=4 ttl=64 time<10ms.64 bytes from 61.177.186.25: icmp_seq=5 ttl=64 time<10ms.---- 61.177.186.25 PING Statistics ----5 packets transmitted, 5 packets received, 0.00% packet loss round-trip min < 10ms, avg < 10ms, max < 10ms, stddev < 10ms A:YZ-SYL-R-AC7750-01##traceroute ip-address(xxx..xxx.xxx.xxx)A:YZ-SYL-R-AC7750-01# traceroute 61.177.186.25traceroute to 61.177.186.25, 30 hops max, 40 byte packets1 61.177.186.25 (61.177.186.25) <10 ms <10 ms <10 ms#telnet ip-address(xxx..xxx.xxx.xxx)A:YZ-SYL-R-AC7750-01# telnet 61.177.186.25Trying 61.177.186.25...Login: adminPassword:Login: adminPassword:A:YZ-SYL-R-AC7750-01#1.6查看时钟信息#show timeA:YZ-SYL-R-AC7750-01# show timeThu Nov 30 02:48:24 BEIJ 2006A:YZ-SYL-R-AC7750-01#1.7查看主副引擎同步信息#show redundancy synchronizationA:YZ-SYL-R-AC7750-01# show redundancy synchronization=============================================================================== Synchronization Information=============================================================================== Standby Status : standby readyLast Standby Failure : N/A Standby Up Time : 2006/11/15 01:39:21 Standby Version : TiMOS-C-4.0.R3 cpm/hops ALCATEL SR 7750Copyright (c) 2000-2006 Alcatel. All rightsreserved. All use subject to applicable license agreements. Built on Wed Jul 5 09:06:04 PST2006 by builder in /rel4.0/b1/R3/panos/main Failover Time : N/A Failover Reason : N/A Boot/Config Sync Mode : Configuration Boot/Config Sync Status : Config only synchronized Last Config File Sync Time : 11/28/2006 16:15:13 Last Boot Env Sync Time : Never =============================================================================== A:YZ-SYL-R-AC7750-01#1.8检测系统软件版本# show versionA:YZ-SYL-R-AC7750-01# show versionTiMOS-C-4.0.R3 cpm/hops ALCATEL SR 7750 Copyright (c) 2000-2006 Alcatel.All rights reserved. All use subject to applicable license agreements.Built on Wed Jul 5 09:06:04 PST 2006 by builder in /rel4.0/b1/R3/panos/mainA:YZ-SYL-R-AC7750-01#2、路由协议查看2.1查看网络接口状态#show route interfaceA:YZ-SYL-R-AC7750-01# show router interface=============================================================================== Interface Table (Router: Base)=============================================================================== Interface-Name Adm Opr(v4/v6) Mode Port/SapId IP-Address PfxState ------------------------------------------------------------------------------- bwsm Up Up/Down IES2/1/3:401361.177.186.25/29 n/adpybx Up Up/Down IES 2/1/3:4017 61.155.65.121/29 n/adxsjqqy Up Up/Down IES 2/1/3:4014 61.155.62.97/29 n/afangchanju Up Up/Down IES 1/2/1:4003 61.132.38.97/28 n/afcjys Up Up/Down IES 2/2/1:4012 61.155.62.177/29 n/afgb Up Up/Down IES 1/2/1:4042 61.177.186.153/29 n/afzgs Up Up/Down IES 2/1/3:4042 61.155.65.185/29 n/aglqzf Up Up/Down IES 1/2/1:4001 61.177.181.185/29 n/ahtzq Up Up/Down IES 1/2/1:4019 61.177.181.169/29 n/ajiansheju Up Up/Down IES 1/2/1:4002 61.132.39.89/29 n/ajiaoH Up Up/Down IES 1/2/1:4012 61.132.34.169/29 n/ajs-hyjz Up Up/Down IES 2/2/1:4008 61.155.62.113/29 n/ajyss Up Up/Down IES 2/1/3:4033 61.155.65.241/29 n/akygj Up Up/Down IES 2/2/1:4018 221.229.116.97/30 n/anfzq Up Up/Down IES 1/2/1:4005 61.177.181.49/29 n/anh-huaiyang Up Up/Down IES 1/2/1:4029 61.177.186.17/29 n/aqhdz-yls Up Up/Down IES 2/2/1:4027 61.177.187.9/29 n/arsbx Up Up/Down IES 1/2/1:4007 61.177.187.129/28 n/asgyz-sxh Up Up/Down IES 2/2/1:4004 61.155.62.89/30 n/asgyz-zgh Up Up/Down IES 2/2/1:4003 61.155.62.77/30 n/aslj Up Up/Down IES 1/2/1:4010 61.177.181.105/29 n/asrh Up Up/Down IES 1/2/1:4023 61.177.182.121/29 n/assy-10m Up Up/Down IES 2/2/1:4011 61.155.62.169/29 n/astkj Up Up/Down IES 2/2/1:4015 61.155.62.201/29 n/asystem Up Up/Down Network system 58.220.170.3/32 n/atest1 Up Up/Down IES 1/2/1:4048 61.155.57.9/30 n/atlcz Up Up/Down IES 2/1/3:4019 61.177.187.81/29 n/ato_DBL12416-1_1 Up Up/Down Network 2/1/1 58.220.165.34/30 n/ato_DBL12416-1_2 Up Up/Down Network 1/1/2 58.220.165.38/30 n/ato_SYL12416-1_1 Up Up/Down Network 1/1/1 58.220.165.42/30 n/ato_SYL12416-1_2 Up Up/Down Network 2/1/2 58.220.165.46/30 n/ato_YZ-SFXY-S-HW3928-01 Up Up/Down IES 1/1/4:4002 222.189.220.61/30 n/a。

ALCATEL交换机用户配置手册2019-8-202019年8月20日目录1 设备管理 (6)1.1 交换机登录 (6)1.2 打开其它访问权限 (6)1.3 恢复到出厂设置 (6)1.4 文件系统操作 (7)1.5 上传系统软件到交换机 (7)1.6 重启交换机 (8)1.7 保存交换机配置 (9)1.8 显示交换机所有配置 (9)2 配置以太网端口 (10)2.1 配置以太网端口指南 (10)2.3 启用和关闭一个端口 (10)2.4 启用和关闭流控 (11)2.5 验证以太网端口配置 (11)3 管理源学习（Managing Sourcing learning） (12)3.1 MAC 地址表项配置例子 (12)3.2 显示MAC 地址表信息 (13)4 配置 VLAN(Configure VLAN) (13)4.1 VLAN 配置举例 (13)4.2 创建/修改VLAN (14)4.3 定义 VLAN 端口分配 (15)4.4 修改端口的缺省 VLAN 配置 (15)4.5 打开/关闭一个 VLAN 生成树 (15)4.6 配置 VLAN 路由网关地址(Ip interface) (16)4.7、配置端口隔离 (16)5 配置802.1Q (18)5.1 打开端口的标记(tag) (18)5.2 打开链路聚合的标记（tagging） (18)5.3 配置端口数据帧类型 (18)5.4 显示802.1Q 信息 (19)5.5 802.1Q 配置实例 (19)6 配置静态链路聚合 (21)6.1 创建静态聚合 (21)6.2 删除静态链路聚合 (22)6.3 添加/删除静态链路聚合中的端口 (22)6.4 激活/关闭静态链路聚合状态 (22)6.5 显示静态链路聚合配置和统计信息 (22)7 配置动态链路聚合 (23)7.1 创建动态聚合 (23)7.2 删除动态链路聚合组 (24)7.3 添加/删除动态链路聚合中的端口 (24)7.4 激活/关闭动态链路聚合状态 (25)7.5 显示动态链路聚合配置和统计信息 (25)7.6 LACP 配置实例 (26)8 配置IP (27)8.1 IP 转发快速配置 (27)8.2 创建静态路由 (28)8.3 创建缺省路由 (29)8.4 创建 ARP (29)8.5 使用PING 命令 (29)8.6 使用Trceroute 命令 (30)8.7 查看IP 配置 (30)9 配置RIP (31)9.1、RIP简介 (31)9.2、RIP 默认配置 (31)9.3、RIP 典型配置 (31)9.4、RIP具体配置 (32)9.4.1、启用RIP (32)9.4.2、创建RIP 端口 (33)9.4.3、启用RIP 端口 (33)9.4.4、配置RIP 端口的发送版本 (33)9.4.5、配置RIP 端口的接收版本 (33)9.4.6、配置RIP 端口Metric (34)9.5、RIP选项 (34)9.5.1、配置RIP 抑制时间 (34)9.5.2、配置RIP主机路由 (35)9.5.3、RIP 路由再分配 (35)9.6、RIP安全 (36)9.6.1、配置认证类型 (36)9.6.2、配置密码 (36)9.7、查看RIP 配置 (37)10配置VRRP (38)10.1、VRRP 默认配置 (38)10.2、VRRP 典型配置 (38)10.3、VRRP具本配置 (39)10.3.1、基本虚拟路由器配置 (39)10.3.2、创建虚拟路由器 (39)10.3.3、给虚拟路由器分配IP地址 (39)10.3.4、配置虚拟路由器的优先级 (40)10.3.5、设置虚拟路由器的占先 (40)10.3.6、设置VRRP 认证 (40)10.3.7、禁用和启用虚拟路由器 (41)10.3.8、查看VRRP 配置 (41)11、配置OSPF (42)11.1、OSPF默认配置 (42)11.3、OSPF具体配置 (44)11.3.1、加载OSPF (44)11.3.2、启用OSPF (44)11.3.3、创建OSPF 端口 (44)11.3.4、启用OSPF 端口 (44)11.3.5、配置OSPF 端口进入OSPF域 (45)11.3.6、OSPF路由再分配 (45)11.3.7、OSPF安全 (46)11.3.8、查看OSPF 配置 (47)12 配置IP组播 (47)12.1 IP组播简介 (47)12.1、IP 组播默认配置 (48)12.2、配置IPMS (48)12.2.1、在交换机上启用和禁用IPMS (48)12.2.2、配置和恢复IGMP版本 (49)12.2.3、配置和删除静态邻居 (49)12.3、更改IPMS 配置 (50)12.3.1、更改IGMP询问时间间隔 (50)12.3.2、更改IGMP最后成员询问时间间隔 (50)12.3.3、更改IGMP询问响应时间间隔 (51)12.2.4、启用和禁用IGMP询问 (51)12.4、查看IPMS 配置和状态 (51)13 配置DHCP 中继（Relay） (52)13.1 Per-VLAN DHCP (53)13.2 查看DHCP 中继配置 (53)14 配置QoS (53)14.1 配置总体QoS 参数 (54)14.2 配置QoS 端口参数 (54)14.3 创建策略 (55)14.4 查看策略配置 (57)15 配置访问控制列表(ACLs) (57)15.1 ACL 快速配置 (57)15.2 ACL 配置步骤 (58)15.3查看ACL 配置 (59)15.4 ACL 配置实例 (59)16、设置服务器负载均衡SLB (61)17、sFlow配置 (62)18、配置端口镜像 (63)19、配置802.1X (63)19.1、802.1X 典型配置 (63)19.2、802.1x再认证 (64)19.3、设置802.1X 交换机参数 (64)20、阿尔卡特网络管理软件 (66)20.2 网络管理软件快速使用 (67)21阿尔卡特OmniStack 6200 操作命令 (67)21.1 交换机管理登录 (67)21.2 打开其它访问权限 (67)21.3 Vlan 配置 (68)21.4 802.1Q配置 (68)21.5 具体案例配置 (69)21.6 访问控制列表（ACL） (70)21.7 开启交换机网管功能 (70)121.8 OmniStack 6200保存配置 (70)21.9 OmniStack 6200堆叠功能 (71)1 设备管理1.1 交换机登录OmniSwitch支持多种登录方式，包括console, telnet, http等，在缺省情况下，交换机只开放console 管理。

7950 XRS核心路由器交流2015.11COPYRIGHT © 2013 ALCATEL-LUCENT SHANGHAI BELL. ALL RIGHTS RESERVED.提 纲:1. IP网络发展趋势 2. 7950 XRS核心路由器介绍 3. 7950 XRS案例2COPYRIGHT © 2013 ALCATEL-LUCENT SHANGHAI BELL. ALL RIGHTS RESERVED.新一代 新一代IP网 IP网络演进的驱动力富媒体应用 4G/LTE 移动宽带720%On-net CDN向云计算转移ResidentialWi-FiMetrocellEPCL2/3 Aggregation企业业务440%Core CoreL2/3 VPN Services Data CenterMobileBusinessIP网 IP网络中流量增长预测Cumulative Traffic Growth7.00 6.00 5.00 4.00 3.00 2.00 1.00 Mobile Busin ess IPTV VoD IPTV Linear视频和云业务改变了网络流量模型Content Shift in Traffic DistributionMetroBackbon eIntrametroIntermetroBackbone transit0.00 2012 2013 2014 2015 2016 2017CloudMetro: 560 %Backbone: 320%57% 75%43% (Y12) 25% (Y17)>80%• 城域内的流量到2017年会有560％ 的增长（贝尔实验室） • 城域内的流量增长速度将是骨干网 的2倍 • 云业务、商企业务、移动业务以及 视频点播（VoD）业务会同互联网 业务保持一致的增长• 绝大多数的非互联网流量将会停留在 • 原有城域与骨干间交互的流量将正逐 步被转移到城域内部完成 城域范围内 • VoD业务和云业务会通过部署分布式 缓存／服务器的方式进行扩展 • 到2017年，75%到流量将只会停留在城 域内部。

中国电信采用上海贝尔阿尔卡特IP业务路由器近日，上海贝尔阿尔卡特今天宣布中国电信分公司——广东电信选择上海贝尔阿尔卡特为其进行城域网扩容和优化，以有效拓展其IP数据业务范围。

上海贝尔阿尔卡特的解决方案将使广东电信能够为广东省内的个人及企业级用户提供三重播放及高速稳定的互联网业务。

此项目由阿尔卡特在中国的旗舰公司——上海贝尔阿尔卡特赢得。

广东电信将在包括东莞、佛山、中山、珠海、惠州、江门及汕头在内的7个主要城市部署阿尔卡特7750业务路由器。

目前，广东省的宽带用户数量居全国之首，因而带来了对先进的以用户为核心的数据业务的大量需求。

项目预计于2005年6月完成，届时广东电信的个人用户将能够享受到全新的以用户为核心的业务，包括三重播放及先进的互联网业务。

与此同时，企业级用户将能够享受包括Layer2、Layer3 VPN（2层及3层虚拟专网）在内的基于SLA的网络服务，以满足其不同的业务需求。

采用单一网络平台取代多平台进行全部业务提供，使广东电信能够大幅度节省投资成本。

“通过进行城域网优化及业务增强，广东电信将能够满足不断增长的网络需求，在基于现有的高速互联网业务之上提供广泛的新数据业务。

” 上海贝尔阿尔卡特总裁狄加表示，“继中标中国电信新建IP/MPLS国家级网络-ChinaNet2之后，此项目的赢得再次巩固了我们在中国IP路由市场的领先地位，同时证明了客户对于我们的解决方案和专业能力能够帮助其进行业务提升的信心。

”上海贝尔阿尔卡特长期致力于IP产品的增强和扩展，以满足客户的多种需求并确保客户的满意度。

经业界独立分析师确认，上海贝尔阿尔卡特已成为三大主要IP解决方案提供商之一。

特别是，它还为整个行业引入了多业务边缘路由器的概念，为了满足那些希望采用IP/MPLS集成多种网络并同时获取利润及新业务的服务提供商配置了关键性的功能。

目前，全球已有超过70家领先的服务提供商选用了阿尔卡特的IP产品。

(n101)。

阿尔卡特7750SR路由器日常维护操作手册上海贝尔阿尔卡特股份有限公司互联网事业部二零零六年十月目录1. 总体概述................................................. 错误!未定义书签。

2. 常用软件操作............................................. 错误!未定义书签。

. 通过Console线缆连接路由器....................... 错误!未定义书签。

. SR系列路由器配置过程............................ 错误!未定义书签。

. 设备重启......................................... 错误!未定义书签。

. 路由引擎切换..................................... 错误!未定义书签。

. TiMOS软件升级步骤............................... 错误!未定义书签。

软件升级相关文件............................. 错误!未定义书签。

升级步骤..................................... 错误!未定义书签。

. 密码恢复......................................... 错误!未定义书签。

. 在CLI中获取帮助................................. 错误!未定义书签。

3. 7750SR-12 ................................................ 错误!未定义书签。

. 7750SR-12结构................................... 错误!未定义书签。

设备描述..................................... 错误!未定义书签。

【最新整理，下载后即可编辑】邢东坡2013.111830PSS-32 产品简介目录 1830PSS 产品线1830PSS 网络结构1830PSS-32 设备介绍1830PSS-32 波道规划1830PSS-32 板卡介绍1830PSS-32 拓扑及配置1830PSS-32 维护管理1830PSS Product FamilyULHLHRegional1830 PSS-361830 PSS-641830 PSS-32Metro1830 PSS-161830 PSS-1Access1830 PSS-41830 PSS Overview Network View from Access to the Core DWDM CoreDWDM MetroC/DWDM Access1830 PSS-11830 PSS-41830 PSS-11830 PSS-41830 PSS-11830 PSS-42.5G/10GLow rate aggregation Cost-efficiency10G/40G/100G FlexibilityAutomation plug & play1830 PSS-32/361830 PSS-361830 PSS-641830 PSS-321830 PSS-321830 PSS-32PSS-1/4: FOADMCost-effective C/DWDMMulti-service GE/TDM aggregation Easy in-band managementRouterIPPSS-36/64: 88 channels DWDM T&ROADM, Multi-degreeOTN Interoperable framing formats Photonic OAM1830 PSS-16OTN/TDM10GE/40GE PSS-32: 88 channels DWDM T&ROADM, Multi-degree Photonic OAMPSS-16: 88 channels DWDM FOADM and ROADM degree-2 Photonic OAM1850 TSS Optical支持 OTN / GbE / TDM 业务板卡C波段全波可调的基于OTN技术的Tunable OTU/可插拔CWDM/DWDM XFPs OTU 通用的客户接口卡 (11GANYRATE,10XANY in 10G,12xGbE in 10G 支持透明传送业务/汇聚传送业务业务分插复用多速率业务接入异种光接入的适配产品特点44/88波道DWDM/8波道 CWDM统一平台2-8方向基于WSS技术的 R/TOADM,具备彩色/无色接口业务上/下提供固定OADM /ROADM /Tunable OADM多种配置点对点,环网,网格网支持2.5G/10G/40G传送光层OAM: Wavelength Tracker 支持异种波长接入先进的网络规划工具(EPT 最优的产品集成度尺寸622mm (H x 439mm (W x 280mm (D1830 PSS-32 针对业务IP化设计的灵活的 xOADM 波分平台1830 PSS-32子架和板卡USER PANELU n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t Upper FanU n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o tU n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t U n i v S l o t E C电源设备控制器32 x 业务槽位SFD44SFD44OPS C W R 8B L A N KE CA L P H GA H P H G S F C 8S F D 5S F C 4S F C 2P F D C光放WSS FOADM公共板卡External shelf for 44 ch mux/demuxP F D CP F D C E C 11S T A R 111S T G E 1211S T M M 10光波长转发器11D P A R 111D P G E 1211D P M M 10CWDM波道规划(8波100-GHz DWDM波道规划(40/44波DWDM50-GHz DWDM波道规划(80/88波DWDM缩写描述种类尺寸公共板卡EC 设备控制器 1单槽位宽,半高 FAN 风扇 1子架专用槽位安装 PFDCxx电源滤波器 4: x=20, 30, 50, 70单槽位宽,半高 USRPNL 用户接口盘 1子架专用槽位安装放大器A2325A 23dBm高功率高增益 DWDM 放大器1单槽位宽,全高ALPHG 低功率高增益 DWDM放大器 1单槽位宽,全高 AHPHG高功率高增益 DWDM放大器 1单槽位宽,全高 AHPLG高功率低增益DWDM放大器 1单槽位宽,全高光滤波器SFD5x静态滤波器 DWDM 5 波道 8: x=A, B, C, D, E, F, G, HSFD8x静态滤波器 DWDM 8 波道 8: x=A, B, C, DSFD44 44波道光复用解复用器 2 (SFD44和SFD44BSFD40 40波道光复用解复用器 2 (SFD40和SFD40BCWR8/CWR88 8/88 波道无色波长路由器 1SFC8 静态滤波器 CWDM 8 波道 1SFC4x静态滤波器 CWDM 4 波道 2: x=A, BSFC2x静态滤波器 CWDM 2 波道 4: x=A, B, C, D光波长转换器和相应板卡11STAR1 11G 单端口可调任意速率 (1个客户接口 1单槽位宽,半高 11QPA4 11G 四端口可调任意速率 (4个客户接口 1单槽位宽,全高 11STMM10 11G 单端口可调多速率复用板 (10 个通用的客户接口 1单槽位宽,全高 11STGE12 11G 单端口可调 GbE复用板 (12个客户口 1单槽位宽,全高 11DPGE12 11G 双端口可调 GbE复用板(12个客户口 1单槽位宽,全高 43STA1 43G单端口可调任意速率 (1个客户口 1三槽位宽,全高 43STX4 43G单端口可调10G复用板 (4个客户口 1三槽位宽,全高 4DPA4 2.7G双端口多速率复用板 (4个客户口 1单槽位宽,半高 4DPA2 2.7G双端口多速率复用板 (2个客户口 1单槽位宽,半高 112SCA1 112G单端口可调板 (1个客户口 1三槽位宽,全高 112SCX10 112G单端口可调 10G复用板(10个客户口 1三槽位宽,全高 SVAC 单路可调衰耗器板卡 1单槽位宽,半高OPSA 增强型光保护倒换组件 1单槽位宽,半高色散补偿模块DMSMFxxx DCM 单模光纤 (G。

Echolink 和阿尔卡特路由器如何配置使用手册发本文专门针对使用Echolink软件遇到Alcatel路由器设置问题的朋友。

目前该方案只针对ADSL+ Alcatel SpeedTouch该系列的路由器。

网络环境如下ADSL——〉Alcatel SpeedTouch——〉PC——〉Echolink由于Echolink 需要放开UDP来进行网络QSO。

目前在Echolink英文网页上有位呼号VK3FFB 火腿提交过英文版操作手册。

澳大利亚的电信公司给ADSL客户的配置是用Alcatel speedtouch 系列路由器。

当我使用这个路由器，我的Echolink无法长时间的连接，我可以看到在线的名单但是不能连接任何一个HAM. Echolink的诊断程序提示UDP的连接出现问题。

最后我断定我必须在Modem的界面里填上5198和5199这二个端口。

下面是具体配置过程:1.从网络上下载并安装Nubz AlcaT ool 文件名的软件，软件版本0.9d82.打开配置界面进入“高级”菜单里选择NAPT 菜单3.进入菜单界面选择新增4.在内部IP里写上你自己电脑的IP, 端口号51985.外部地址写0.0.0.0:5198 端口号51986.保存后再向上面一样增加5199，保存后再试一下Echolink 的防火墙测试看结果。

7.需要注意的是配置5199时，外部地址写0.0.0.0:5199，其他与上面步骤相同。

做完这一切后完全可以让Echolink 在ADSL+Alcatel Speedtouch环境下正常工作。

这个修改一般称为“静态端口映射。

”其他人在遇到相同的问题时我希望这个信息可以帮到他们。
