T-13/4 (5 mm) Precision Optical Performance AlInGaP LED LampsTechnical DataFeatures• Well Defined Spatial Radiation Patterns• Viewing Angles: 6°, 15°, 23°, 30°• High Luminous Output• Colors:590 nm Amber605 nm Orange615 nm Reddish-Orange626 nm Red• High Operating Temperature:T J LED=+130°C• Superior Resistance to Moisture• Four Package Options:With or Without Flange Base; With or Without Lead Stand-OffsBenefits• Viewing Angles Match Traffic Management Sign Requirements• Colors Meet Automotive and Pedestrian Signal Specifications• Superior Performance in Outdoor Environments• Suitable for Autoinsertion onto PC Boards Applications• Traffic Management:Traffic SignalsPedestrian SignalsWork Zone Warning LightsVariable Message Signs• Commercial OutdoorAdvertising:SignsMarquees• Automotive:Exterior and Interior LightsDescriptionThese Precision Optical Perform-ance AlInGaP LEDs providesuperior light output for excellentreadability in sunlight and areextremely reliable. AlInGaP LEDtechnology provides extremelystable light output over longperiods of time. Precision OpticalPerformance lamps utilize thealuminum indium gallium phos-phide (AlInGaP) technology.These LED lamps are untinted,nondiffused, T-13/4 packagesincorporating second generationoptics producing well definedspatial radiation patterns atspecific viewing cone angles.SunPower SeriesHLMP-DLXXHLMP-DJXXHLMP-DHXXHLMP-DGXXHLMP-GLXXHLMP-GJXXThese lamps are made with anadvanced optical grade epoxy,offering superior high tempera-ture and high moisture resistanceperformance in outdoor signaland sign applications. The highmaximum LED junction tempera-ture limit of +130°C enables hightemperature operation in brightsunlight conditions. The packageepoxy contains both uv-a anduv-b inhibitors to reduce theeffects of long term exposure todirect sunlight.These lamps are available in fourpackage options to give thedesigner flexibility with devicemounting.HLMP-GHXXHLMP-GGXXHLMP-ULXXHLMP-UJXXHLMP-UHXXHLMP-UGXXDevice Selection GuideColor,Luminous Intensity,Part Typical Dominant I v (mcd),[1,2]Number Viewing Angle,Wavelength,@ 20 mA Leads with Flanged Package HLMP-2θ1/2 (Deg.)[4]λd (nm),[3] Typ.Min.Typ.Stand-Offs Base Drawing DL08[5]6Amber, 59040009300No Yes A GL08[5]6Amber, 59040009300No No B DL10[5]6Amber, 59040009300Yes Yes C GL10[5]6Amber, 59040009300Yes No D UL06[5]6Amber, 59016004000No Yes A UL07[5]6Amber, 59016004000Yes Yes C DJ08[5]6Orange, 60542009500No Yes A GJ08[5]6Orange, 60542009500No No B DJ10[5]6Orange, 60542009500Yes Yes C GJ10[5]6Orange, 60542009500Yes No D UJ06[5]6Orange, 60520004500No Yes A UJ07[5]6Orange, 60520004500Yes Yes C DH08[5]6Red-Orange, 61529008000No Yes A GH08[5]6Red-Orange, 61529008000No No B DH10[5]6Red-Orange, 61529008000Yes Yes C GH10[5]6Red-Orange, 61529008000Yes No D UH06[5]6Red-Orange, 61514003500No Yes A UH07[5]6Red-Orange, 61514003500Yes Yes C DG08[5]6Red, 62629006500No Yes A GG08[5]6Red, 62629006500No No B DG10[5]6Red, 62629006500Yes Yes C GG10[5]6Red, 62629006500Yes No D UG06[5]6Red, 62610003000No Yes A UG07[5]6Red, 62610003000Yes Yes C DL1515Amber, 59016003100No Yes A GL1515Amber, 59016003100No No B DL1715Amber, 59016003100Yes Yes C GL1715Amber, 59016003100Yes No D UL1315Amber, 590 7001600No Yes A UL1415Amber, 590 7001600Yes Yes C DJ1515Orange, 60514003400No Yes A GJ1515Orange, 60514003400No No B DJ1715Orange, 60514003400Yes Yes C GJ1715Orange, 60514003400Yes No DNotes:1. The luminous intensity is measured on the mechanical axis of the lamp package.2. The optical axis is closely aligned with the package mechanical axis.3. The dominant wavelength, λd, is derived from the CIE Chromaticity Diagram and represents the color of the lamp.4. θ1/2 is the off-axis angle where the luminous intensity is one half the on-axis intensity.5. The intensity of narrow viewing angle lamps is measured at the intensity peak.Device Selection Guide, continuedColor,Luminous Intensity,Part Typical Dominant I v (mcd),[1,2]Number Viewing Angle,Wavelength,@ 20 mA Leads with Flanged Package HLMP-2θ1/2 (Deg.)[4]λd (nm),[3] Typ.Min.Typ.Stand-Offs Base Drawing UJ1315Orange, 605 7001800No Yes A UJ1415Orange, 605 7001800Yes Yes C DH1515Red-Orange, 61514002500No Yes A GH1515Red-Orange, 61514002500No No B DH1715Red-Orange, 61514002500Yes Yes C GH1715Red-Orange, 61514002500Yes No D UH1315Red-Orange, 615 5001400No Yes A UH1415Red-Orange, 615 5001400Yes Yes C DG1515Red, 62614002100No Yes A GG1515Red, 62614002100No No B DG1715Red, 62614002100Yes Yes C GG1715Red, 62614002100Yes No D UG1315Red, 626 500 1000No Yes A UG1415Red, 626 500 1000Yes Yes C DL2423Amber, 59010001800No Yes A GL2423Amber, 59010001800No No B DL2623Amber, 59010001800Yes Yes C GL2623Amber, 59010001800Yes No D UL2223Amber, 590 450 1000No Yes A UL2323Amber, 590 450 1000Yes Yes C DJ2423Orange, 605 10002000No Yes A GJ2423Orange, 605 10002000No No B DJ2623Orange, 605 10002000Yes Yes C GJ2623Orange, 60510002000Yes No D UJ2223Orange, 605 2901200No Yes A UJ2323Orange, 605 290 1200Yes Yes C DH2423Red-Orange, 615 700 1500No Yes A GH2423Red-Orange, 615 700 1500No No B DH2623Red-Orange, 615 700 1500Yes Yes C GH2623Red-Orange, 615 700 1500Yes No D UH2223Red-Orange, 615 290 900No Yes A UH2323Red-Orange, 615 290 900Yes Yes CNotes:1. The luminous intensity is measured on the mechanical axis of the lamp package.2. The optical axis is closely aligned with the package mechanical axis.3. The dominant wavelength, λd, is derived from the CIE Chromaticity Diagram and represents the color of the lamp.4. θ1/2 is the off-axis angle where the luminous intensity is one half the on-axis intensity.5. The intensity of narrow viewing angle lamps is measured at the intensity peak.Device Selection Guide, continuedColor,Luminous Intensity,Part Typical Dominant I v (mcd),[1,2]Number Viewing Angle,Wavelength,@ 20 mA Leads with Flanged Package HLMP-2θ1/2 (Deg.)[4]λd (nm),[3] Typ.Min.Typ.Stand-Offs Base Drawing DG2423Red, 626 7001300No Yes A GG2423Red, 626 7001300No No B DG2623Red, 626 7001300Yes Yes C GG2623Red, 626 7001300Yes No D UG2223Red, 626 290 700No Yes A UG2323Red, 626 290 700Yes Yes C DL3030Amber, 590 7001300No Yes A GL3030Amber, 590 7001300No No B DL3230Amber, 590 7001300Yes Yes C GL3230Amber, 590 7001300Yes No D UL2830Amber, 590 300 750No Yes A UL2930Amber, 590 300 750Yes Yes C DJ3030Orange, 605 7001500No Yes A GJ3030Orange, 605 7001500No No B DJ3230Orange, 605 7001500Yes Yes C GJ3230Orange, 605 7001500Yes No D UJ2830Orange, 605 200 800No Yes A UJ2930Orange, 605 200 800Yes Yes C DH3030Red-Orange, 615 5001100No Yes A GH3030Red-Orange, 615 5001100No No B DH3230Red-Orange, 615 5001100Yes Yes C GH3230Red-Orange, 615 5001100Yes No D UH2830Red-Orange, 615 200 600No Yes A UH2930Red-Orange, 615 200 600Yes Yes C DG3030Red, 626 500 900No Yes A GG3030Red, 626 500 900No No B DG3230Red, 626 500 900Yes Yes C GG3230Red, 626 500 900Yes No D UG2830Red, 626 200 500No Yes A UG2930Red, 626 200 500Yes Yes CNotes:1. The luminous intensity is measured on the mechanical axis of the lamp package.2. The optical axis is closely aligned with the package mechanical axis.3. The dominant wavelength, λd, is derived from the CIE Chromaticity Diagram and represents the color of the lamp.4. θ1/2 is the off-axis angle where the luminous intensity is one half the on-axis intensity.5. The intensity of narrow viewing angle lamps is measured at the intensity peak.DCPackage DimensionsBAPART NO.d HLMP-XX10 -XX0712.37 ± 0.25(0.487 ± 0.010)HLMP-XX17 -XX1412.42 ± 0.25(0.489 ± 0.010)HLMP-XX26 -XX2312.52 ± 0.25(0.493 ± 0.010)HLMA-XX32 -XX2911.96 ± 0.25(0.471 ± 0.010)(0.039)(0.039)MAX.(0.039)2.54 ± 0.380.50 ± 0.10SQ. TYP.NOTES:1. ALL DIMENSIONS ARE IN MILLIMETERS (INCHES).2. LEADS ARE MILD STEEL, SOLDER DIPPED.3. TAPERS SHOWN AT TOP OF LEADS (BOTTOM OF LAMP PACKAGE) INDICATE AN EPOXY MENISCUS THAT MAY EXTEND ABOUT 1 mm (0.040 in.) DOWN THE LEADS.4. RECOMMENDED PC BOARD HOLE DIAMETERS:• LAMP PACKAGES A AND B WITHOUT STAND-OFFS: FLUSH MOUNTING AT BASE OF LAMP PACKAGE = 1.143/1.067 (0.044/0.042).• LAMP PACKAGES C AND D WITH STAND-OFFS: MOUNTING AT LEAD STAND-OFFS = 0.965/0.889 (0.038/0.035).5. FOR DOME HEIGHTS ABOVE LEAD STAND-OFF SEATING PLANE, d, LAMP PACKAGESC AND D, SEE TABLE.(0.039)2.54 ± 0.38SQ. TYP.Electrical/Optical Characteristics at T A = 25°CParameter SymbolMin.Typ.Max.UnitsTest Conditions Forward VoltageI F = 20 mAAmber (λd = 590 nm) 2.02Orange (λd = 605 nm)V F 1.98 2.4VRed-Orange (λd = 615 nm) 1.94Red (λd = 626 nm) 1.90Reverse Voltage V R 520VI F = 100 µAPeak Wavelength:Peak of Wavelength of Amber (λd = 590 nm)592Spectral Distribution Orange (λd = 605 nm)λPEAK609nmat I F = 20 mARed-Orange (λd = 615 nm)621Red (λd = 626 nm)635Spectral Halfwidth∆λ1/217nmWavelength Width at Spectral Distribution 1/2 Power Point at I F = 20 mASpeed of Response τs 20ns Exponential Time Constant, e -t/τCapacitanceC 40pF V F = 0, f = 1 MHzThermal Resistance R θJ-PIN240°C/WLED Junction-to-Cathode LeadLuminous Efficacy [1]Emitted LuminousAmber (λd = 590 nm)480Power/Emitted Radiant Orange (λd = 605 nm)ηv370lm/WPowerRed-Orange (λd = 615 nm)260Red (λd = 626 nm)150Note:1. The radiant intensity, I e , in watts per steradian, may be found from the equation I e = I v /ηv , where I v is the luminous intensity in candelas and ηv is the luminous efficacy in lumens/watt.Absolute Maximum Ratings at T A = 25°CDC Forward Current [1,2,3]............................................................50 mA Peak Pulsed Forward Current [2,3]................................................70 mA Average Forward Current [3].........................................................30 mA Reverse Voltage (I R = 100 µA).........................................................5 V LED Junction Temperature..........................................................130°C Operating Temperature ..............................................-40°C to +100°C Storage Temperature ..................................................-40°C to +120°C Soldering Temperature ..........................................260°C for 5 seconds [1.59 mm (0.060 in.) below seating plane]Notes:1. Derate linearly as shown in Figure 4.2. For long term performance with minimal light output degradation, drive currents between 10 mA and 30 mA are recommended.3. Please contact your Hewlett-Packard sales representative about operating currents below 10 mA.sFigure 2. Forward Current vs.Forward Voltage.Figure 3. Relative Luminous Intensity vs. Forward Current.Figure 4. Maximum Forward Current vs. Ambient Temperature. Derating Based on T JMAX = 130°C.Figure 1. Relative Intensity vs. Peak Wavelength.Figure 5. Representative Spatial Radiation Pattern for 6° Viewing Angle Lamps.WAVELENGTH – nmR E L A T I V E I N T E N S I T YI F – F O R W A R D C U R R E N T – m AT A – AMBIENT TEMPERATURE – °CR E L A T I V E I N T E N S I T Y – %1000θ – ANGULAR DISPLACEMENT – DEGREES8060507020-20-15103040-1051015202590-25-5C U R RE N T – m AV F – FORWARD VOLTAGE – V R E L A T I V E L U M I N O U S I N T E N S I T Y (N O R M A L I Z E D A T 20 m A )00I F – DC FORWARD CURRENT – mA 403.02.01.51.00.520602.5For technical assistance or the location of your nearest Hewlett-Packard sales office, distributor or representative call: Americas/Canada: 1-800-235-0312 or 408-654-8675Far East/Australasia: (65) 290-6305 Japan: (81 3) 3335-8152Europe: Call your local HP sales office. Data subject to change.Copyright © 1997 Hewlett-Packard Co. Obsoletes 5965-5265EPrinted in U.S.A.5965-6807E (1/97)。
