1

Standard ICs

CR timer

BA225 / BA225F / BA235 / BA226 / BA226F / BA236

The BA225, BA225F, BA235, BA226, BA226F, and BA236 are monolithic ICs having independent monostable multi-

vibrator circuits which consume very low current (0.75mA typ.). Using external resistors and capacitors, the timing

control time can be set within a range from 0.01ms to 100ms.

As the BA225, BA225F, and BA235 are triggered at the rising edge of the signal, they have no trigger input differenti-

ating circuit and can be used in measuring instruments, control devices, digital data systems and other equipment as

sub-compact attachments. The BA226, BA226F, and BA236 are available as falling edge trigger types.•Block diagram

OUT1

CR1

TRIGGER1

4GND321

5678VCC

OUT2

CR2

TRIGGER2O

TCRO

TCR1

VCCOTCR

VCCVCCGND

2

OUT13

CR14

TRIGGER15

GND6

TRIGGER27

CR28

OUT29

VCCOTCRBA225 / BA225FBA226 / BA226FBA235 / BA236•Applications

Delay timers

Monostable multivibrator (ideal for VCR system con-

trollers)

Pulse generators

•Features1)As these are edge trigger types (BA225 / BA235: ris-

ing edge trigger types, BA226 / BA236: falling edge

trigger types), there is no need for an input differenti-

ating circuit.

2)The dual type design enables delay timer configura-

tion.

3)Fewer attachments are required.

4)Current dissipation is as low as 0.75mA for each cir-

cuit.5)Uniformity in the supply current between high and

low output states simplifies the design of the power

supply section.

6)Wide operating power supply voltage range of 4.0V

to 16V.

7)The BA235 and BA236 pin assignments are sym-

metrical, allowing reverse insertion.

8)Hysteresis in the input results in a high level of noise

withstand resistance.元器件交易网www.cecb2b.com2Standard ICsBA225 / BA225F / BA235 / BA226 / BA226F / BA236•Absolute maximum ratings (Ta = 25°C)

ParameterSymbolLimitsUnit

Power supply voltageVCC16V

Power dissipationBA225 / BA226

BA235 / BA236

BA225F / BA226FPd800∗1

950∗2

450∗3mW

mW

mW

Operating temperature Topr°C– 20 ~ + 75Storage temperature Tstg°C– 55 ~ + 125

∗1 Reduced by 8mW for each increase in Ta of 1°C over 25°C.∗2 Reduced by 9.5mW for each increase in Ta of 1°C over 25°C.∗3 Reduced by 4.5mW for each increase in Ta of 1°C over 25°C.

•Electrical characteristics (unless otherwise noted, Ta = 25°C, VCC= 5V)

BA236ParameterSymbolMin.Typ.Max.UnitConditionsMeasurementcircuit

Operating power supply voltage 4.05.016.0V—Fig.7

Quiescent current IQ—1.53.0mA—Fig.7

Timing accuracyTERR—10%Fig.7

Timing change with power supply TDS—0.53.0%5V¨16VFig.7

Timing change with temperatureTOT—200——Fig.7

Trigger voltageVT1.02.03.0V∗2Fig.70.71.62.5

Trigger currentIT—70200µAFig.7

Output low level voltageVOL—0.51.0VFig.7

Output high level voltageVOH3.04.0—VFig.7VCC

1R = 100kΩ, C = 0.1µF∗1

VT = 3.0V (BA225 / BA235)VT = 2.5V (BA226 / BA226F / BA236)ppm / °C

∗1 One-shot cycle T = 0.5 CR∗2 With input hysteresis (hysteresis width Լ 200 to 600mV)ISINK = 5mA

ISOURCE = 5mA

•Electrical characteristic curves

4

3"H" output

"L" output2

1

0QUIESCENT CURRENT: IO (mA)

POWER SUPPLY VOLTAGE: VCC (V)0412820

16

Fig. 1 Quiescent current vs. power supply voltage2.0

1.0

0SATURATION VOLTAGE: VOL (V)

SINK CURRENT: ISINK (mA)041282016VCC = 5V

Fig. 3 Output voltage (logic 0 side) characteristics

3.2

2.4VCC = 5V

1.6

0.82.8

2.0

1.2

0.40SATURATION VOLTAGE: VCC—VOH (V)

SOURCE CURRENT: ISOURCE (mA)041282016

Fig. 2 Output voltage (logic 1 side) characteristics元器件交易网www.cecb2b.com3Standard ICsBA225 / BA225F / BA235 / BA226 / BA226F / BA236

1.010

1.000C = 0.01µFR = 100kΩ

0.990

0.9801.005

0.995

0.985

0 DELAY TIME NORMALIZED: td

POWER SUPPLY VOLTAGE: VCC (V)0412820

16

Fig. 4 Power supply voltage vs. delay time10

0.001CAPACITANCE: C (µF)1.0

0.1

0.01

TIMING PERIOD: T (ms)0.010.110110010kΩ

100kΩ

1MΩ

Fig. 6 One-shot time characteristics AMBIENT TEMPERATURE: Ta (°C)

– 250502575VCC = 5VC = 0.01µFR = 100kΩ

1.0101.0151.020

1.000

0.990

0.9801.005

0.995

0.985DELAY TIME NORMALIZED: td

Fig. 5 Temperature vs. delay time

•Measurement circuit

VCC

CRmA

PGBA225BA225FBA235

GNDS3

5mA5mAD.VµAD.V

CounterOUTINS1

S0OFF

ONVCC

S2

0.1µF100kΩ

Fig. 7

•Attached components(1) Timing capacitors (Pins 2 and 6)

Connected between these pins and the ground (GND),

this capacitor determines the one-shot period. We rec-

ommend using a capacitor with a value greater than

1000pF. The one-shot cycle is determined by T = 1 / 2

C • R.

(2) Timing resistor (Pins 2 and 6)

Connected to the power supply line, these resistors

determine the one-shot period. The timing capacitor is

charged through this resistor. The recommended range

for the timing resistor is 10kΩto 1MΩ.(3) Power supply capacitor (Pin 8)

Connect a 0.02µF capacitor between the power supply

pin and the ground (GND) so as to prevent malfunction

resulting from a rise in the impedance of the power
