2N5962/ MMBT5962

Discrete POWER & SignalTechnologies

NPN General Purpose Amplifier

This device is designed for use as low noise, high gain, generalpurpose amplifiers requiring collector currents to 50 mA.Sourced from Process 07. See 2N5088 for characteristics.

Absolute Maximum Ratings* TA = 25°C unless otherwise noted

*

These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.

NOTES:1) These ratings are based on a maximum junction temperature of 150 degrees C.2)

These are steady state limits. The factory should be consulted on applications involving pulsed or low duty cycle operations.

Thermal Characteristics TA = 25°C unless otherwise notedSymbolParameterValueUnits

VCEOCollector-Emitter Voltage45V

VCBOCollector-Base Voltage45VVEBOEmitter-Base Voltage8.0V

ICCollector Current - Continuous100mA

TJ, TstgOperating and Storage Junction Temperature Range-55 to +150°C

SymbolCharacteristicMaxUnits

2N5962*MMBT5962PDTotal Device DissipationDerate above 25°C6255.03502.8mWmW/°CRθJCThermal Resistance, Junction to Case83.3°C/WRθJAThermal Resistance, Junction to Ambient200357°C/WC

BE

SOT-23Mark: 117MMBT59622N5962

CBETO-92

*Device mounted on FR-4 PCB 1.6" X 1.6" X 0.06."

© 1997 Fairchild Semiconductor Corporation元器件交易网www.cecb2b.com2N5962/ MMBT5962NPN General Purpose Amplifier

(continued)

Electrical Characteristics TA = 25°C unless otherwise noted

OFF CHARACTERISTICSSymbolParameterTest ConditionsMinMaxUnits

V(BR)CEOCollector-Emitter Breakdown Voltage*IC = 5.0 mA, IB = 045V

V(BR)CBOCollector-Base Breakdown VoltageIC = 10 µA, IE = 045VV(BR)EBOEmitter-Base Breakdown VoltageIE = 10 µA, IC = 08.0V

ICBOCollector Cutoff CurrentVCB = 30 V, IE = 0VCB = 30 V, IE = 0, TA = 65 °C2.050nAnAIEBOEmitter Cutoff CurrentVEB = 5.0 V, IC = 01.0nA

ON CHARACTERISTICS*

hFEDC Current GainVCE = 5.0 V, IC = 10 µAVCE = 5.0 V, IC = 100 µAVCE = 5.0 V, IC = 1.0 mAVCE = 5.0 V, IC = 10 mA4505005506001400VCE(sat)Collector-Emitter Saturation VoltageIC = 10 mA, IB = 0.5 mA0.2V

VBE(on)Base-Emitter On VoltageVCE = 5.0 V, IC = 1.0 mA0.50.7V

SMALL SIGNAL CHARACTERISTICS

CcbCollector-Base CapacitanceVCB = 5.0 V4.0pF

CebEmitter-Base CapacitanceVEB = 0.5 V6.0pF

hfeSmall-Signal Current GainIC = 10 mA, VCE = 5.0 V,f = 1.0 kHzIC = 10 mA, VCE = 5.0 V,f = 100 MHz600

1.0200

NFNoise FigureVCE = 5.0 V, IC = 10 µA,RS = 10 kΩ, f = 1.0 kHz,BW = 400 HzVCE = 5.0 V, IC = 100 µA,RS = 1.0 kΩ, f = 1.0 kHz,BW = 400 HzVCE = 5.0 V, IC = 100 µA,RS = 10 kΩ, f = 1.0 kHz,BW = 400 HzVCE = 5.0 V, IC = 100 µA,RS = 100 kΩ, f = 1.0 kHz,BW = 400 HzVCE = 5.0 V, IC = 10 µA,RS = 10 kΩ, f = 10 Hz -10 kHzBW = 15.7 kHz3.0

6.0

4.0

8.0

3.0dB

dB

dB

dB

dB

*Pulse Test: Pulse Width ≤ 300 µs, Duty Cycle ≤ 2.0%元器件交易网www.cecb2b.com
