WEFP电气火灾监控系统——操作使用说明施耐德万高（天津）电气设备有限公司 质量及客户支持部1 2 3 4 5 6产品简介 WEFPT-F分离式探测器设置 WEFPT-Z组合式探测器设置 WEFPJ监控单元快速设置 WEFPS监控主机操作使用说明 常见注意事项2度质量及客户支持部一、产品简介监控主机监控单元监控探测器度质量及客户支持部3二、WEFPT-F分离式探测器设置1、地址设置波特率位拨码开关共8位，其中： 1~6位为地址位，7~8位为波特率位； 1~6位根据拨码地址表进行设置； 7、8位位波特率（9600）：8为“ON”，7为“OFF”。
度质量及客户支持部4二、WEFPT-F分离式探测器设置2、地址拨码表度质量及客户支持部5三、WEFPT-组合式探测器设置1.按键说明上翻键 下翻键 前进键 回车键度质量及客户支持部6三、WEFPT-组合式探测器设置2.系统设置1.按“菜单”键，进入系统 设置界面； 2.通过“上翻键”或“下翻 键”将光标移到“系统设置 ”，按一下“回车键”进入 系统设置界面。
度质量及客户支持部7三、WEFPT-组合式探测器设置3.输入密码1.默认密码“0000” 2.按一下“回车键”进入下 一级菜单。
度质量及客户支持部8三、WEFPT-组合式探测器设置3.设置漏电报警值1.进入系统设置界面第一项 为“漏电报警值”设置； 2.按一下“回车键”进入设 置状态； 3.通过“前进键”调整数位 ； 4.通过“上翻键”或“下翻 建”调整数值； 5.设置完后按“回车键”保 存。
度质量及客户支持部9三、WEFPT-组合式探测器设置4.设置探测器地址1.进入系统设置界面后，通 过“上翻键”或“下翻建” 调整到通讯设置界面； 2.按一下“回车键”进入设 置状态； 3.通过“前进键”调整数位 ； 4.通过“上翻键”或“下翻 建”调整数值； 5.设置完后按“回车键”保 存。
注：波特率出产时已设置好，不 需再设置！度质量及客户支持部10三、WEFPT-组合式探测器设置5.返回主界面1.设置完成后，按“ 复位”按钮复位2.设备显示初始化3.返回主界面度质量及客户支持部11四、WEFPJ监控单元设置1.按键说明度质量及客户支持部12四、WEFPJ监控单元设置2.系统设置度质量及客户支持部13三、WEFPJ监控单元设置3.输入密码度质量及客户支持部14四、WEFPJ监控单元设置4.探测器设置度质量及客户支持部15四、WEFPJ监控单元设置5.设置参数1.进入“探测器设置界面”后 ，光标默认在“探测器”上；1.按一下“回车”键，光标移 到“编号”栏； 2.通过“上翻键”或“下翻建 ”选择需设置的探测器编号；1.按“前进键”将光标移到“ 使用状态”栏，再通过“上翻 键”或“下翻建”设置使用状 态； 2.设置完成后，按“回车键” 保存。
数字式控制器(PXW-5)使用说明书规格型号1、器件型号及输入信号·温度控制器PXW-5-NEE1-8V Pt100·湿度控制器 PXW-5-BEY2-8V 4-20mA（1-5Vdc）·风压控制器 PXW-5-BEY2-8V 4-20mA（1-5Vdc）2、控制输出信号·4-20mAdc（负载电阻：小于 600Ω）·（如用2-10V直流电压信号请在输出端并上500Ω电阻）3、调节动作·PID控制·也可为两位控制或比例控制4、设定与指示精度·±0.5％ FS±1数字5、供电电源·85-265 Vac，50/60 Hz故障指示1、控制器有故障指示功能，所以能快速诊断和排除故障。
2、故障排除后，必须先切断电源，再接通电源。
3、控制器异常显示和处理：各部分名称报警灯加热器断路报警灯控制输出2指示灯FUJI ℃工业值单位控制输出1指示灯○C1○C2○H○L○HBpv １２００ＰＶ（测量值）显示 sv· 1 2 0 0 ．自整定指示灯ＳＶ指示灯ＳＶ（设定值）显示SEL ∧∨■■■SEL键增／减键（参数选择键）ＰＸＷ-５操作键及功能基本操作方法1、PXW-5 的基本操作方法如下图所示：第 1 组参数第 2 组参数第 3 组参数2、第 2 组参数和第 3 组参数设定操作：5.1按SEL键Ｐ 5.0按SEL键∧∨4.9控制动作代码表主要参数表连接端子图Pt100输入 + ──○ 1 10 ○── +(或1-5V、4-20mA需接250Ω) 控制输出2(单输出型无)- ──○ 2 11 ○── 4-20mA──○ 3 12 ○── -──○ 4 13 ○──高报警输出+ ──○ 5 14 ○──低报警输出控制输出 14-20mA ──○ 6 15 ○──加热器断路报警输出- ──○ 7 16 ○──公共端电源──○ 8 17 ○──85--265 Vac50/60Hz ──○ 9 18 ○──使用注意事项1、接通电源，测量值 PV和设定值 SV 指示器显示．．．．几秒钟后，显示测量值和设定值。
Page 1Copyright © 2021 Sensata Technologies, Inc. External 1-1/4” BSP 316 grade SS -20ºC / +79ºC 10 bar 0.70.8300cm 0.5MM 2Tinned copper| FLPV SERIESFLAMEPROOF DUAL LEVEL VERTICAL STAINLESS FLOAT SWITCHSPECIFICATIONSThe FLPV is a flameproof vertical float switch range which has been designed to give the user a long reach float switch with a number of switching options, to cater for a wide variety of system requirements. Manufactured in Stainless Steel 316L material, these switches are suitable for use in many aggressive liquids or hygienic applications.The single float version gives high (make on rise) and low (make on fall) level indications for alarms and controls systems.The dual float versions give either make on rise for both high and low levels (used for tank emptying control) or make on fall for both high and low levels (used for tank filling control).The switches are screw mounted vertically via a 1 ¼” BSP thread, and does not require access to the inside of the tank.Also available with FLA15 flange mount option, contact Sensata for details.TechnicalElectricalFeatures• Dual switch point for high/low indication • Stainless Steel 316L material • PED Approved (10 Bar)• G1 ¼” mounting thread (optional flange mount)•II 1/2 GDEx db IIB T6 Ga/Gb Ex tb IIIB T85ºC Db Tamb = -20ºC to +79ºC IP66For use in Zones 1 and 2All ratings are for resistive load only.Page 2CONTACT US+44 (0)1202 897969*********************Cynergy3 Components Ltd.7 Cobham Road,Ferndown Industrial Estate,Wimborne, Dorset,BH21 7PE, United KingdomCopyright © 2021 Sensata Technologies, Inc.Sensata Technologies, Inc. (“Sensata”) data sheets are solely intended to assist designers (“Buyers”) who are developing systems that incorporate Sensata products (also referred to herein as “components”). Buyer understands and agrees that Buyer remains responsible for using its independent analysis, evaluation and judgment in designing Buyer’s systems and products. Sensata data sheets have been created using standard laboratory conditions and engineering practices. Sensata has not conducted any testing other than that specifically described in the published documentation for a particular data sheet. Sensata may make corrections, enhancements, improvements and other changes to its data sheets or components without notice.Buyers are authorized to use Sensata data sheets with the Sensata component(s) identified in each particular data sheet. HOWEVER, NO OTHER LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE TO ANY OTHER SENSATA INTELLECTUAL PROPERTY RIGHT, AND NO LICENSE TO ANY THIRD PARTY TECHNOLOGY OR INTELLECTUAL PROPERTY RIGHT, IS GRANTED HEREIN. SENSATA DATA SHEETS ARE PROVIDED “AS IS”. SENSATA MAKES NO WARRANTIES OR REPRESENTATIONS WITH REGARD TO THE DATA SHEETS OR USE OF THE DATA SHEETS, EXPRESS, IMPLIED OR STATUTORY, INCLUDING ACCURACY OR COMPLETENESS. SENSATA DISCLAIMS ANY WARRANTY OF TITLE AND ANY IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, QUIET ENJOYMENT, QUIET POSSESSION, AND NON-INFRINGEMENT OF ANY THIRD PARTY INTELLECTUAL PROPERTY RIGHTS WITH REGARD TO SENSATA DATA SHEETS OR USE THEREOF.All products are sold subject to Sensata’s terms and conditions of sale supplied at SENSATA ASSUMES NO LIABILITY FOR APPLICATIONS ASSISTANCE OR THE DESIGN OF BUYERS’ PRODUCTS. BUYER ACKNOWLEDGES AND AGREES THAT IT IS SOLELY RESPONSIBLE FOR COMPLIANCE WITH ALL LEGAL, REGULATORY AND SAFETY-RELATED REQUIREMENTS CONCERNING ITS PRODUCTS, AND ANY USE OF SENSATA COMPONENTS IN ITS APPLICATIONS, NOTWITHSTANDING ANY APPLICATIONS-RELATED INFORMATION OR SUPPORT THAT MAY BE PROVIDED BY SENSATA.Mailing Address: Sensata Technologies, Inc., 529 Pleasant Street, Attleboro, MA 02703, USA.ISO9001CERTIFIED Rev: Cynergy3-flpv-v1 02/24/21DIMENSIONSMade in the UKCustom versions can be made for particular applications.Please contact Sensata with your requirements.Flange mount optionFLA15Single float dual leveltype Dual float dual leveltype。
