Three-phase asynchronous motor
Abstract:
The three-phase asynchronous motor is motor's one with single phase asynchronous motor, three-phase asynchronous motor operating performance is good, and can save various the structure to be simple, the manufacture is easy, firm durable, the service is convenient,
cost inexpensive ,drag the ability is good,and so on a series of merits. thus becomes in each kind of electrical machinery the output
to be biggest utilizes the broadest one kind of electric motor.
Key words:
Moror Motor starting Star delta Starting
Three-phase asynchronous motor principle:
When the stator winding through into the three-phase ac three-phase symmetric arises when a synchronous speed n1 along the stator and rotor round for space in a clockwise rotation magnetic field. Because of a rotating magnetic field rotating speed to n1, rotor conductor of the static beginning, so the rotor conductor will cut
the stator and produce a rotating magnetic field induction emf (induction emf direction DingZe judge with the right hand). Because the child is short circuit loop ends conductor short meet, in the
role of the induced emf, will produce the rotor conductor with induction emf direction basic consistent induced current. The rotor current-carrying conductor at stator magnetic field is the role of
the electromagnetic force (the direction of the force with the left hand DingZe judge). The electromagnetic force of the rotor axis electromagnetic torque, drive along the rotor rotating magnetic field rotation direction.[1]Through the above analysis can be summed up the motor principle: when the three-phase motor stator winding (each
differ 120 KWH Angle), ventilation with three-phase ac, will produce
a rotating magnetic field, the rotating magnetic field cutting rotor winding, and thus to the rotor winding induced current (rotor winding
is closed access), load flow of rotor stator conductor under the action of a rotating magnetic field will produce the electromagnetic force, thus in the motor shaft formed on the electromagnetic torque, driving motor rotation, and motor rotation direction and the rotating magnetic field in the same direction.
Thestructureofthree-phaseasynchronousmotor:
Types of three-phase asynchronous motor, but all kinds of three-phase asynchronous motor is the same basic structure, they are the stator and rotor of these two basic components, the stator and rotor has a certain air gap between. In addition, end caps, bearings, cable boxes, rings and other accessories,
1).Statorpart
Stator is used to generate the rotating magnetic Three-phase motors generally shell, stator core, stator windings and other parts.
a.Shell?
Three-phase motor casing including base,end caps,bearing
caps,rings,such as junction boxes and comp onents
b. Stator Core
Induction motor stator core is part of the motor circuit from ~ thick coated with a thin insulating paint from silicon,
c.Thestatorwindings
Three-phase motor stator windings are part of the circuit,there are three-phase three-phase motor windings,summetrical three-phase current access,it will have a rotating magnetic winding consists of three separate components of the winding, and each has a number of coil windings a phase of each winding, each winding in the space angle difference between the 120 ° electrical[2].
2). Rotor part
a. Rotor Core
With mm thick steel from, set in the shaft, the role and the same stator core, on the one hand, as part of the motor magnetic circuit, on the one hand to place the rotor windings.
b. Rotor windings
The rotor winding induction motor winding is divided into two kinds of cage-shaped and which is divided into winding rotor asynchronous motor with cage induction motor.
3). Other parts of
Other parts including the cover, fans, etc.
Induction motor starting methods:
There are several general methods of starting induction motors: full voltage, reduced voltage,wyes-delta,and part winding reduced voltage type can include solid state starters, adjustable frequency drives, and following is the most common method.
1).Full voltage
