2012第六章输入输出接口技术北京理工大学2012 BIT 第一节接口技术的基本概念一、接口的概念和功能二、接口电路的典型结构三、接口功能第二节I/O端口的编址和译码一、I/O端口的编址方式二、输入/输出指令三、I/O端口的译码第三节CPU与外设间的数据传送方式一、无条件传送方式二、条件传送方式三、中断传送方式四、DMA传送方式2012 BIT 第一节接口技术的基本概念一、接口的概念和功能1 接口:指CPU与存储器和外设之间通过总线进行连接的电路部分,是CPU与外界进行信息交换的中转站。
为什么要在CPU与外设之间设置接口电路?其一,CPU与外设两者的信号线不兼容,在信号线功能定义、逻辑定义和时序关系上都不一致;其二,两者的工作速度不兼容,CPU速度高,外设速度低; 其三,若不通过接口,而由CPU直接对外设的操作实施控制,就会使CPU处于穷于应付与外设打交道之中,大大降低CPU的效率;其四,若外部设备直接由CPU控制,也会使外设的硬件结构依赖于CPU,对外设本身的发展不利。
因此,有必要设置接口电路,以便协调CPU与外设两者的工作,提高CPU的效率,并有利于外设按自身的规律发展。
C P U接口作用外设模/数转换(A/D)数/模转换(D/A)模拟量信息类型数字量三态缓冲、锁存数字量工作速度快解决传送方式慢串/并转换并/串转换串行通信方式并行三态缓冲、锁存并行2 接口技术:是研究CPU如何与外部世界进行最佳耦合与匹配,实现双方高效、可靠地交换信息的一门技术,是软件、硬件结合的体现,是微机应用的关键。
微机接口技术综合性很强,所涉及的知识面很宽,包括微机原理、汇编语言(或高级语言)程序设计、电子技术、自控原理以及通信技术等多门课程的基础理论和专业知识。
3.接口技术在微机应用中的作用微机应用系统的研究和微机化产品的开发,从硬件角度来讲,就是接口电路的研究和开发,接口技术已成为直接影响微机系统的功能和微机推广应用的关键。
微机的应用是随着外部设备的不断更新和接口技术的发展而深入到各个领域的。
1从编程角度看,接口内部主要包括一个或多个CPU 可以进行读/写操作的寄存器,又称为I/O 端口。
2各I/O 端口由端口地址区分。
I/O 端口1I/O 端口2I/O 端口3地址译码数据缓冲控制电路外设ABDBCBC P U3按存放信息的不同,I/O 端口可分为三种类型数据端口:用于存放CPU 与外设间传送的数据信息状态端口:用于暂存外设的状态信息控制端口:用于存放CPU 对外设或接口的控制信息,控制外设或接口的工作方式。
1001 0101 (状态端口)0110 1010(数据端口)1100 0110(控制端口)地址译码数据缓冲控制电路外设ABDBCBC P U4CPU 对外设输入/输出的控制,是通过对接口电路中各I/O 端口的读/写操作完成。
I/O 端口1I/O 端口2I/O 端口3地址译码数据缓冲控制电路外设ABDBCBC P U三、接口功能1. 执行CPU命令的功能CPU对被控对象外部设备的控制命令是以命令代码的形式先发送到接口中的命令寄存器,称之为“命令口”。
再由接口电路对命令代码进行识别和分析,分解成若干个控制信号,传送到I\O设备,使其产生相应的具体操作。
可见,CPU并不是直接把命令送到被控对象,而是通过接口电路来进行控制的。
2. 返回外设状态的功能(联络)接口电路在执行CPU命令之前、执行命令过程中和执行命令之后,外部设备和接口电路都会有一些情况发生,这些"情况"就是所谓"状态",包括正常工作状态和故障状态。
如"忙"、"闲"、"准备就绪"、"未准备就绪"、"满"、"空",以及"溢出错""格式错"、"校验错"等状态。
接口中一般都设置状态寄存器,称之为"状态口"。
这些状态信号以状态代码形式存放在接口电路的状态寄存器中,以便向CPU报告。
CPU从"状态口"读取这些状态信息,就可以"知道"正在发生或已发生了哪些情况,以共CPU作出判断和处理。
3. 数据缓冲功能为了解决主机高速与外设低速的矛盾,避免因速度不一致而丢失数据,接口中一般都设置数据缓冲存储器(简称数据缓存器)。
称之为“数据口”。
数据缓存器又分为输入和输出缓存器两种,前者暂存外设送来的数据,以待CPU将它取走;后者暂存CPU送往外设的数据。
有了数据缓存器,就可以使高速工作的CPU与慢速工作的外设协调合作。
由于数据缓存器直接连在系统数据总线上,因此它应具有三态特性。
4. 信号转换功能由于外设所需的控制信号和它所能提供的状态信号往往同微机的总线的信号不兼容。
不兼容性表现在两者的信号功能定义、逻辑关系、电平高低以及工作时序的不一致。
因此,信号转换(包括CPU的信号与外设的信号的逻辑关系上、时序配合上以及电平匹配上的转换),就成为接口设计中的一个重要任务。
5. 设备选择功能在微机系统中一般有多种外设,在同一种外设中也可以有多台,而一个CPU在同一时间里只能与一台外设交换信息,这就要在接口中设置I\O端口地址译码电路对外设进行寻址。
CPU将I\O设备的端口地址代码送到接口中的地址译码电路,并经译码电路,把地址代码翻译成I\O设备的选择信号。
一般是把高位地址用于接口芯片选择,低位地址进行芯片内部寄存器的选择,以选定需要与自己交换信息的设备端口,只有被选中的设备才能与CPU进行数据交换或通信。
没有选中的设备,就不能与CPU交换数据。
6. 数据宽度与数据格式转换的功能CPU所处理的是并行数据(8位、16位或32位),而有的外设(如串行通信设备)只能处理串行数据,在这种情况下,接口就应具有数据"并→串"和"串→并"的转换能力。
为此,在接口中设置移位存储器。
CPU 与有些外设交换数据时,要求按一定的数据格式传送,如串行通信中的起止式异步通信数据格式及面向字符的同步通信数据格式。
此时,需要在CPU与通信设备之间进行数据格式转换。
7.产生中断请求及DMA请求解决实时性和高速传输数据的问题。
接口与系统的连接2012 BIT 第二节I/O端口的编址和译码一、I/O端口的编址方式1.存储器映射(存储器与I/O端口统一编址)存储器映射的主要优点是:由于访问存储器的指令类型多,功能齐全,也方便了访问外设端口的操作,不仅对端口进行数据传送,还可以对端口内容进行算术逻辑运算、移位等,同时也为端口提供了较大的编址空间。
内存空间I/O空间2012 BIT2.I/O 独立编址方式这种方式的端口地址采用单独编址,构成一个I/O 空间,微处理器设置了专用的输入输出指令来访问端口,这种方式也常称为数据通道式的输入输出。
对于386 ,IO 空间64kB ,00F8H ——00FFH 保留。
I/O 空间内存空间2012 BIT I/O 独立编址方式(端口编址方式)Port 65535Port 255Port 3Port 2Port 1 Port 0Port 0(16位)Port 1(16位)Port 0 (32位)PC系列机采用I/O端口独立编址方式2012 BIT 端口地址是一种重要资源2012 BIT输入/输出指令实现I/O 端口与CPU 之间的数据传送I/O 端口1I/O 端口2I/O 端口3地址译码数据缓冲控制电路外设ABDBCBC P U1.输入指令IN2.输出指令OUT二、输入/输出指令2012 BIT可寻址216= 64 K 个I/O 端口I/O 端口范围0000 ~ FFFFH I/O 端口的地址由:一个8位二进制数直接寻址或DX 寄存器间接寻址CPU 采用I/O 端口与存储器分别独立编址I/O 空间内存空间2012 BIT 1. 输入指令IN格式执行操作IN AL, port(AL) ← (port端口)IN AX, port(AL) ← (port端口)(AH) ← (port+1端口)IN AL, DX(AL) ← ((DX)端口)IN AX, DX(AL) ← ((DX)端口)(AH) ← ((DX)+1端口) port 为数字形式的端口地址, 大小为0~255 或0~FFH例(1)IN AL,28H若(28H端口) = 1010 1111B执行后(AL) = (28H端口)= 0AFH(2)IN AX,28H若(28H端口)= 1010 1111B(29H端口)= 0101 0000B执行后(AL) = (28H端口)= 0AFH(AH) = (29H端口)= 50H(3)MOV DX,300HIN AL,DX若(300H端口)= 69H执行后(AL) = (300H端口)= 69H2. 输出指令OUTport 为数字形式的端口地址, 大小为0~255 或0~FFH格式执行操作OUT port, AL (port 端口) ←(AL)OUT port, AX (port 端口) ←(AL)(port+1端口) ←(AH)OUT DX, AL ((DX)端口) ←(AL)OUT DX, AX((DX)端口) ← (AL)((DX)+1端口) ←(AH)例(1)OUT 21H, AL若(AL)= 1100 1100B执行后(21H端口)= 0CCH(2)MOV DX ,21BHOUT DX,AL若(AL)= 1010 0110B执行后(21BH端口)= (AL) = 0A6H输入/输出指令(IN、OUT)特点:(1) 累加器AL、AX的专用指令对输入指令IN ,目的操作数只能为AL, 或AXIN AL, 21HIN AX, DXIN BX, 21H对输出指令OUT ,源操作数只能为AL, 或AXOUT 20H, ALOUT DX, AXOUT DX, CX2012 BIT(2)端口地址可由直接方式或间接方式给出例OUT 219H , AL ×MOV DX , 219H OUT DX , AL例IN AL, 218H×MOV DX , 218H IN AL, DX2当端口号>FFH ,即>255时,需把端口号放在DX 寄存器中,DX 是一个16位寄存器,范围在0~FFFFh 之间。
1当端口号在0~FFH ,即0~255时,可在指令中直接指定端口号例IN AL, 21HOUT 20H , AL2012 BIT当端口号在0~FFH,即0~255时,可在指令中直接指定端口号,称长格式指令当端口号>FFH,即>255时,需把端口号放在DX寄存器中,称短格式指令原因是使用直接端口方式的指令机器码相对长例指令机器码IN AL, 21H E421 ;两个字节OUT 20H, AL E620IN AL, DX EC ;一个字节OUT DX, AL EE2012 BIT三、I/O端口的译码1.译码电路的作用2.译码电路的构成3.设计译码电路的方法4.片内译码和片选译码2012 BIT1、译码电路的作用将CPU 执行IN/OUT 指令发出的地址信号,“翻译”成欲操作端口的选通信号,解决存储器、I/O 设备与CPU 连接时地址总线失配问题。
