Eaton Gigabit Industrial Gateway X2 CardIndustrial gateway cardThe Eaton Gigabit IndustrialGateway X2 Card (INDGW-X2) is Eaton’s latest UPS connectivity device that delivers industrial professionals with new andexciting capabilities and features. The first UPS network card to meet both UL 2900-1 and IEC 62443-4-2 cybersecurity standards, the Gigabit Industrial Gateway X2 Card improves power system reliability by providing warnings of pending issues to administrators and helping to perform orderly graceful shutdown of servers and storage. The new network card works with Intelligent Power Manager (IPM) v1.61 (and higher) to improve business continuity by triggering policies configured to keep missioncritical applications running in the event of power or environmental anomalies, including virtualmachine relocation or automated disaster recovery action.Details• G igabit speed: compatible with better performing, cost effective and widely deployed gigabit network switches • C ompliance with Gigabit only data center networks• C ybersecurity enhancements for UL 2900-1 and IEC 62443-4-2 certifications,including stronger encryption, configurable passwordpolicy and X.509 Public Key Infrastructure• R eal-time clock with battery backup and linkage to NTP (Network Time Protocol) server• I ncreased memory for improved operation and larger data storage• A dvanced Management with RESTful API over HTTPS • S ecure SMTP for email alertsEaton1000 Eaton Boulevard Cleveland, OH 44122 United States © 2021 EatonAll Rights Reserved Printed in USA BR152075EN / GG October 2021Eaton is a registered trademark.All other trademarks are property of their respective owners.Optional monitoring probeEaton is also offering a new Environmental Monitoring Probe (EMP) Gen 2 (EMPDT1H1C2), an environmental monitoring probe with sensors (temperature, humidity and dry-contact monitoring) and the ability to be daisy-chained (up to 3 per host), allowing multiple sensorconnection to a single host. The probe is compatible with the Gigabit Industrial Gateway X2 Card and Eaton rackPDUs including G3 (firmware 4.x or later), G3HD and G3+.Technical specifications 1Eaton Gigabit Industrial Gateway X2 CardFunction Web/Industrial communicationsHardware compatibility BladeUPS, 9155, 9355, 9395, 9395P , 9395C Compatible with IPv4/IPv6 TLS 1.2Catalog number INDGW-X2Protocol support HTTPS, TLS 1.2, SNMPv1, SNMPv3, NTP , TFTP , SMTP , SMTPS,B OOTP , DHCP , SLAAC, SSH, MQTTS, ModbusTCP , Modbus RTU, BACnet IP , BACnet BBMD UPS slot type X-SlotNetwork support Ethernet 10/100/1000BaseTTemperature and Yes, only with the Eaton Environmental Monitoring humidity monitoring Probe Gen 2Software supportI ntelligent Power Manager 1.61 and higher (visit /IPM for all power management capabilities including hyperconverged infrastructure), Intelligent Power Protector 1.61 and higher (visit /IPP for a full compatibility operating system matrix), any SNMP compliant Network Management System (NMS)Supported MIB MIB II – Standard IETF UPS MIB (RFC 1628) – Eaton xUPS MIB Supported browsersC hrome and Firefox Local language support English, French, German, Italian, Spanish, Chinese Simplified,Chinese Traditional, Japanese, Russian Operating temperature 32 to 104° F (0 to 40° C)Operating humidity 90% RH max. without condensation Power input 5 V – 12 VCurrent consumption 500/1000mA max. depending on UPS Dimensions (H x W x D) 4.4 x 1.5 x 4.5 in. (112 x 38 x 115 mm)Weight 4.6 oz. (131 g)RegulatorySame as UPSFor more information, please visit:/INDGW-X21. D ue to continuous product improvements, program specifications are subject to change without notice.Follow us on social media to get thelatest product and support information.Eaton Gigabit IndustrialGateway Card (installed)Eaton Gigabit IndustrialGateway X2 Card (front)。
(13) SCHEDULE(14) to EC-Type Examination Certificate KEMA 09ATEX0048 Issue No. 4(15) DescriptionDifferential Pressure Transmitters DELTABAR M Model PMD55 and Pressure transmittersCERABAR M Model PMC51, Model PMP51 and Model PMP55 and DELTAPILOT M Model FMB50, Model FMB51, Model FMB52 and Model FMB53 are used in potentially explosive atmospheres caused by the presence of flammable gases, liquids, vapours or dusts for the measurement of level, flow, differential pressure, over- and under pressure.The pressure signal at the ceramic or metal sensor is converted into an electrical signal.The output of the Pressure or Differential Pressure Transmitter is a 4 - 20 mA current output signal with or without a superimposed HART digital signal, or the transmitter is intended to be connected to a fieldbus system (Profibus PA or Foundation Fieldbus).The several versions of the Pressure and Differential Pressure Transmitters differ in type of sensor, type of enclosure, process connection etc.Optionally all versions of the Pressure and Differential Pressure Transmitters may be provided with an indicator.Optionally, the display connector can be used for temporary connection of a service tool (e.g.Endress+Hauser Commubox type FXA191 or type FXA195).Optionally the Pressure Transmitters that are intended for application in explosive gas atmospheres, may be provided with a sensor with extension cable.Ambient temperature range -50 ºC to +70 ºC.The relation between temperature class, ambient temperature and process temperature is given in the following table.temperatureclassambienttemperatureprocess temperatureFMB50 FMB51 FMB52,FMB53PMD55 PMP55 1),PMC51, PMP51T6 ≤ 40 °C ≤ 80 °C ≤ 80 °C ≤ 80 °C ≤ 80 °C ≤ 80 °CT4 ≤ 70 °C ≤ 100 °C ≤ 85 °C ≤ 80 °C ≤ 120 °C ≤ 100 °C 2)T3 ≤ 70 °C ≤ 150 °CNOTE 1: Depending on the diaphragm seal used in model PMP55, a higher process temperature is permitted. For details, refer to the relevant equipment manual.NOTE 2: Process temperature for Models PMC51 and PMP51 with hygienic process connection ≤ 130 °C.. The maximum surface temperature of the enclosure T75 °C, respectively T500 100 °C (transmitters with interface 4 - 20 mA) or T500 105 °C (transmitters with Fieldbus interface) is b ased on the maximum ambient temperature of 70 °C for a dust lay er with a maximum thickness of 5 mm respectively 500 mm.(13) SCHEDULE(14) to EC-Type Examination Certificate KEMA 09ATEX0048 Issue No. 4Electrical dataTransmitters in type of protection intrinsic safety Ex iaInterface 4 - 20 mA (with or without HART communication):Supply and output circuit (terminals + and - or connector):in type of protection intrinsic safety Ex ia IIC, only for connection to a certified intrinsically safe circuit, with the following maximum values:U i = 30 V; I i = 300 mA; P i = 1 W; L i = 0 mH; C i = 10 nF.Interface Profibus PA or Foundation Fieldbus:Supply and data circuit (terminals + and - or connector):in type of protection intrinsic safety Ex ia IIC, only for connection to a certified intrinsically safecircuit, with the following maximum values:U i = 24 V; I i = 250 mA; P i = 1,2 W; L i = 10 µH; C i = 5 nF;or to an intrinsically safe fieldbus in accordance with FISCO, with the following maximum values: U i = 17,5 V; I i = 500 mA; P i = 5,5 W; L i = 10 µH; C i = 5 nF.Display connector:in type of protection intrinsic safety Ex ia IIC, for connection to a certified intrinsically safe circuit, with following maximum values:U o = 8,6 V; I o = 39 mA; P o = 124 mW andU i = 8,5 V; I i = 7 mA; P i = 10 mW; C i = 0 nF; L o = 0 mH.Transmitters in type of protection Ex tU max = 45 V (interface 4 - 20 mA), respectively 32 V (fieldbus interface).Installation instructionsThe instructions provided with the equipment shall be followed in detail to assure safe operation. (16) Test ReportNo. NL/KEM/ExTR09.0017/**.(17) Special conditions for safe useNone.(18) Essential Health and Safety RequirementsCovered by the standards listed at (9).(19) Test documentationAs listed in Test Report No. NL/KEM/ExTR09.0017/**.。
