WBR5-450A中文资料

  • 格式：pdf
  • 大小：164.54 KB
  • 文档页数：2

Type WBR 85 ºC, Industrial Grade, Axial Leaded, Aluminum85 ºC, Industrial GradeType WBR capacitors are the preferred choice for many varied industrial applications because they have high capacitance and extended life characteristics. The rugged construction delivers the high vibration resis-tance required in industrial applicationsHigh capacitance Extended lifeRugged construction High vibration resistance••••HighlightsSpecificationsCapacitance Range:Voltage Range:Capacitance Tolerance:Operating Temperature Range:Leakage Current: Ripple Current Multipliers: 1.0 to 5,000 µF16 to 450 Vdc16 to 50 Vdc -10 + 150%, 75 to 350 Vdc–10 + 100%, 450 Vdc –10 + 50%–40 ºC +85ºC16-75 Vdc ≤ 0.01CV + 10 µA150-450 Vdc ≤ 0.03CV + 20 µA45 ºC 55 ºC 65 ºC 75 ºC 85 ºC 95 ºC 105 ºC 1.50 1.46 1.321.171.000.790.50Ambient TemperatureFrequency 60 Hz 120 Hz 400 Hz 1000 Hz 10 kHz 50 kHz 100 kHz 0-60 Vdc 0.85 1.00 1.10 1.15 1.15 1.15 1.1561-200 Vdc 0.83 1.00 1.15 1.20 1.20 1.20 1.20201-450 Vdc0.801.001.151.301.301.301.30Load Life:Shelf Life:Vibration: 2,000 h @ +85 ºC∆ Capacitance ±20% ∆ ESR 150% of limit ∆ DCL 100% of limit500 h @ 85 ºC∆ Capacitance ±20% ∆ ESR 150% of limit ∆ DCL 100% of limit10 to 55 Hz; 0.06” and 10 g max, 2 h in each planeOutline DrawingComplies with the EU Directive 2002/95/EC requirement restricting the use of Lead (Pb), Mercury (Hg), Cadmium (Cd), Hexavalent chromium (Cr(VI)), PolyBrominated Biphenyls (PBB) and PolyBrominated Diphenyl Ethers (PBDE).Type WBR 85 ºC, Industrial Grade, Axial Leaded, AluminumPart Numbering SystemRatingsWBR 500—16A EType Capacitance Voltage Lead Epoxy Endseal WBR500 = 500 µF16 = 16 VdcA = 1.5" 20 AWG E = Epoxy Blank = See tableBlank = No epoxyRippleMax Case Catalog Max ESR @ 85 ºC Size Cap Part Number 120 Hz 120 HzD x L (µF)(Ω)(A)(Inches)16 Vdc ( 20 Vdc Surge )100WBR100-16A 5.300.0570.340.76250WBR250-16A 2.100.1180.340.88500WBR500-16A 1.100.2700.40 1.001000WBR1000-16A 0.530.4200.40 1.322000WBR2000-16A 0.270.6600.47 1.573000WBR3000-16A 0.180.8200.52 1.834000WBR4000-16A 0.13 1.0000.65 1.835000WBR5000-16A 0.11 1.2000.65 1.8325 Vdc ( 30 Vdc Surge )10WBR10-25A 48.000.0180.280.5725WBR25-25A 19.000.0310.280.5750WBR50-25A 9.500.0440.340.76100WBR100-25A 4.800.0740.340.76250WBR250-25A 1.800.1550.40 1.00500WBR500-25A 0.950.2800.40 1.321000WBR1000-25A 0.480.4500.47 1.572000WBR2000-25A 0.230.7200.65 1.8335 Vdc ( 40 Vdc Surge )100WBR100-35A 4.400.0860.400.88150WBR150-35A 2.950.1140.40 1.00300WBR300-35A 1.450.1950.47 1.32500WBR500-35A 0.870.2850.52 1.671000WBR1000-35A 0.440.4500.54 1.672000WBR2000-35A 0.220.9100.65 1.833000WBR3000-35A 0.15 1.1500.74 1.6950 Vdc ( 65 Vdc Surge )1WBR1-50A 390.000.0100.280.572WBR2-50A 195.000.0120.280.575WBR5-50A 77.000.0140.280.5710WBR10-50A 39.000.0200.280.5725WBR25-50A 15.500.0350.340.7650WBR50-50A 7.700.0600.40 1.88100WBR100-50A 3.900.1400.40 1.00150WBR150-50A 2.500.1600.40 1.00250WBR250-50A 1.500.2200.40 1.32500WBR500-50A 0.770.3400.52 1.571000WBR1000-50A 0.390.5300.65 1.831500WBR1500-50A 0.250.7400.65 1.8375 Vdc ( 95 Vdc Surge )150WBR150-75A 2.500.1800.47 1.32275WBR275-75A 1.300.2800.52 1.57500WBR500-75A 0.720.4000.651.83RippleMax Case Catalog Max ESR @ 85 ºC Size Cap Part Number120 Hz 120 Hz D x L (µF)(Ω)(A)(Inches)150 Vdc ( 175 Vdc Surge )4WBR4-150A 78.000.0180.340.88 5WBR5-150A 62.000.0200.340.88 8WBR8-150A 39.000.0300.400.88 10WBR10-150A 31.000.0340.400.88 16WBR16-150A 19.500.0450.40 1.00 20WBR20-150A 15.500.0500.40 1.32 30WBR30-150A 10.500.0850.40 1.57 40WBR40-150A 7.800.0960.47 1.32 50WBR50-150A 6.200.1050.47 1.57 60WBR60-150A 5.200.1300.65 1.57 80WBR80-150A 3.900.1550.65 1.83 100WBR100-150A 3.100.1900.65 1.83 150WBR150-150A2.050.2300.74 1.69180 Vdc ( 250 Vdc Surge )125WBR125-180A 2.300.3000.74 1.69 250 Vdc ( 300 Vdc Surge )4WBR4-250A 64.000.0350.40 1.008WBR8-250A 32.000.0560.40 1.32 12WBR12-250A 21.500.0620.40 1.32 16WBR16-250A 16.000.0650.47 1.57 20WBR20-250A 12.500.0750.47 1.57 30WBR30-250A 8.400.1050.52 1.57 40WBR40-250A 6.300.1250.52 1.83 50WBR50-250A 5.000.1400.65 1.83 60WBR60-250A 4.200.1800.65 1.83 80WBR80-250A3.100.2000.74 1.69 350 Vdc ( 400 Vdc Surge )4WBR4-350A 51.000.0360.40 1.00 8WBR8-350A 26.000.0500.47 1.32 20WBR20-350A 10.000.0900.52 1.57 40WBR40-350A 5.100.1350.65 1.83 450 Vdc ( 525 Vdc Surge )1WBR1-450A 205.000.0230.40 1.00 2WBR2-450A 102.000.0300.40 1.00 4WBR4-450A 51.000.0380.47 1.57 5WBR5-450A 40.000.0420.47 1.57 8WBR8-450A 26.000.0530.47 1.57 10WBR10-450A 20.000.0580.52 1.57 12WBR12-450A 17.000.0620.65 1.83 16WBR16-450A 12.500.0840.65 1.83 20WBR20-450A 10.000.1050.65 1.83 30WBR30-450A6.700.1300.741.69。
