电机的冷却方式我们常见的电机冷却方式有：自然冷却，强迫风冷，风-风冷，风水冷，水冷，IC411,IC416,IC816等，其表征什么意思，怎么理解，见如下解释。

电机的冷却介质内容规定：• 初级冷却介质：温度低于电机某部件的气体或液体介质，他与电机的该部件相接触，并将其释放出的热量带走；• 次级冷却介质：温度低于初级冷却介质的气体或液体，通过电机的外表或冷却器将初级冷却介质释放出的热量带走。

电机冷却方式代码的内容规定： 电机冷却方式代码主要由：• 冷却方式标识IC(International Cooling)； • 冷却介质回路布置代码； • 冷却介质代码；• 冷却介质的推动方法代码组成。

1. 冷却介质回路布置代码的意义：氢气 H 氮气 N 二氧化碳 C 水 W 油U3. 冷却介质的推动方法：特征数字 含义备注 0 依靠温度差促使冷却介质运动 自由对流 1 冷却介质运动与电机转速有关自循环6由安装在电机上的独立驱动部件驱动介质运动，该部件所需动力与主机转速无关，外装式独立部件驱动7与电机分开安装的独立的电气或机械部件驱动冷却介质运动分装式独立部件驱动4. 比较常用的冷却方式有：IC01, IC06, IC411, IC416, IC81W---IC411, 表示内循环风冷，外循环风冷，自由循环冷却，往往表示电机安装同轴散热风扇；---IC416, 表示内循环风冷，外循环风冷，强迫风冷；---IC81W, 表示内循环风冷，外循环水冷，即我们常说的空水冷。

5. IC416(强迫风冷)冷却方式的优缺点冷却方式的优缺点：：优点优点：：结构简单结构简单，，维护方便维护方便，，运行稳定可靠运行稳定可靠，，安装尺寸小安装尺寸小；； 缺点缺点：：冷却效力低冷却效力低，，电机运行噪音大电机运行噪音大；； 6. IC81W （水冷）冷却方式的优缺点冷却方式的优缺点：： 优点优点：：冷却效力高冷却效力高，，运行噪声低运行噪声低；；缺点缺点：：结构复杂结构复杂，，维护复杂维护复杂（（需要外需要外接去离子循环水路接去离子循环水路接去离子循环水路），），），由于水路的锈蚀由于水路的锈蚀等，造成局部堵塞等隐患造成局部堵塞等隐患，，有短路有短路、、漏电等故障漏电等故障。
