DIN 46247-2

德国标准 1975年3月份插头宽度为2.8的无绝缘套的插套不用于参照VDE标准的安全引线接头用于插头厚度为0.5（A）的，标称尺寸为2.8—0.5的，由CuSnF41（Bz）制成的插套的标称：插套A2.8—0.5DIN 46247－Bz母材：Ms：CuZn30F43参照DIN 17670标准Bz：CuZn6F41参照DIN 17670标准结构形式：有光泽，经过协商也可以镀锌（gal Sn3参照DIN 50965标准）或者镀银（gal Ag，镀层厚度最小为1µm），然后补充标称，例如用于镀锌的结构形式：……DIN 46247－Bz－gal Sn。

要求与检验：参照DIN 46249标准的第一分册（目前还是草案）。

适用范围：适用于终端不允许焊接的，超多股，多股，细线与极细股导线。

对于大量生产，插套可以制作成带状（Bd）形式，然后由机器卷曲到导线上，带状插套的标称为：插套A2.8－0.5 DIN 46247－Bz－Bd应用示例：用机器或者是手钳卷曲成插套。

1）其它形式的槽口凸缘必须在直径1.2mm之内。

2）底面成型由制造商根据需要进行选择。

尺寸a涉及到的底面必须是槽口凸缘超出底面（0.1±0.05）mm的底面。

3）尺寸涉及到的是以带状形式供货的插套，在单个零件的供货中这个尺寸根据制造商的选择允许存在偏差，这点取决于预成型夹头。

4）例如参照DIN 72 551第二分册的导线B，也可以把更多导线卷曲到一个插套上。

对其它标准的说明仪器扁形插头用插套参见DIN 46244标准直的圆角扁形插头用插套参见DIN 46342标准无绝缘扁形插塞连接装置，要求与检验参见DIN 46249标准第一分册（目前还是草案）用于插头宽度为6.3的扁形插头参见DIN 46248第三分册插头宽度为4.8的无绝缘套插套，参见DIN47247第二分册插头宽度为6.3的无绝缘套插套，参见DIN47247第三分册插头宽度为9.5的无绝缘套插套，参见DIN46247第四分册插头宽度为2.8的绝缘套插套，参见DIN46245第一分册插头宽度为4.8的无绝缘插套，参见DIN46245第二分册插头宽度为6.3的无绝缘插套，参见DIN47245第三分册插头宽度为2.8的快速插套，参见DIN46340第一分册（目前还是草案）插头宽度为6.3的快速插套，参见DIN46340第三分册（目前还是草案）注释参照DIN 46247标准第一分册至第四分册的所有插套尺寸都可以适用于所有的电动车与机动车行业，众所周知，插套主要是用于电线的简捷安装，特别是在批量生产中替代螺栓连接以及焊接连接。
