机械专业外文文献翻译--论药品包装机械的概念设计

译文标题论药品包装机械的概念设计原文标题Comment on medicines and chemical reagents package machineryconceptual design作者BRIAN HUGH W ARNER译名布莱恩·休·沃纳国籍美国原文出处JOURNAL OF DYNAMIC SYSTEMS MEASUREMENT& CONTROL动力系统，测量与控制杂志论药品包装机械的概念设计近年来，由于我国经济形势的持续高涨和国家对制药行业强制性推行GMP(药品生产质量规范)认证制度，药品包装机械取得了长足的进步。

新产品日益增多，技术水平有了很大的改进。

但与国际水平相比还存在着很大的差距，近60%的产品达不到发达国家上世纪80年代的水平，先进大型的设备主要依赖进口。

我国药品包装机械的低技术水平在很大程度上是由我国企业设计人员低水平设计引起的。

一、我国药品包装机械现状分析我国药品包装机械与国际先进水平相比尚有较大的差距.国产药品包装机械设计上主要存在以下几点不足：1) 机械性能落后，国产药品包装机械大多精度低、速度慢、平稳性差。

包装机械运转过程包含大量复杂的间歇式运动，主要由凸轮、连杆来实现。

然而许多设计人员不会根据工作循环图和精度要求独立设计计算凸轮连杆机构的运动学和动力学参数，只是简单的把国外样机的凸轮连杆零件拆卸下来进行逐点测绘，造成执行机构误差很大。

国产药品包装机械大多运行速度较低，如铝塑泡罩包装机的冲裁频率一般为100～300个/min，全自动药盒包装机的装盒速度50～200盒/min，而国际上先进的铝塑泡罩包装机的冲裁频率能够达到600个/min，全自动药盒包装机的装盒速度能够达到600~ 800盒/min。

国产药品包装机械不仅运行速度慢，而且还伴有较大的噪音。

2) 控制水平落后。

国产药品包装机械大多控制水平低、自动性差、故障率高。

国产药品包装机械(主要指盒装和灌装机械)大多采用PLC作现场控制，而国外先进的药品包装机械大多由计算机系统实现监控，控制水平相对落后。

中文译文包装机械的发展包装是必要的产品进入流通领域,包装是主要的手段,包装机械包装是产品进入流通领域的必要条件，而实现包装的主要手段是包装机械。

简单来说，包装机就是把产品包装起来的机器，起着保护，美观的作用。

包装机主要分为两个方面，一是流水线式的整体生产包装，二是产品外围包装设备随着时代的发展，科技的进步，包装机械在包装领域中正起着越来越大的作用。

我国包装机行业起步于20世纪70年代，在80年代末和90代中期的到了迅速发展。

已经成为机械行业中的10大行业之一，无论产量，还是品种上，都取得了令人瞩目的成就，为我我国的包装工业的快速发张提供了有力的保障目前。

目前，我国已成为世界包装机械工业生产和消费十大国之一。

新型包装机往往是机、电、气、一体化的设备.充分利用信息产品的最新成果，采用气动执行机构、伺服电机驱动等分离传动技术，可使整机的传动链大大缩短，结构大为化简，工作精度和速度大大提高。

机电一体化的实质就是从系统观点出发，运用过程控制原理，将机械、电子与信息、检测等有关技术进行有机组合，实现整体最佳化。

21世纪包装机发展趋势1.高生产率。

包装机的生产效率已经从每分钟数件发展到数10件，热成型-充填-封口机的生产率可达500件每分钟以上。

2.自动化。

3.单机多功能。

在单机上实现多功能，可方便地扩大使用范围，代表性的是德国BOSCH 公司所属的HESSER厂生产的心轴轮多工位制袋真空包装，其制袋、称重、充填、抽真空、封口等多功能可在一台单机上完成。

4.组成生产线。

当需要的功能越来越多是，将所有的功能集中在一个单机上结构非常复杂，这是可以把功能不同、效率相比配的几种机器组合成功铰齐全的生产线上。

外国包装机的发展现状：德国：德国的包装机械在计量、制造、技术性能方面均属于世界一流。

该国生产的啤酒、饮料灌装成套设备生产速率快、自动化程度高、可靠性好。

主要体现在：工艺流程的自动化、生产效率高，满足了交货期短和降低工艺流程成本的要求；设备具有更高的柔性和灵活性。

中英文对照资料外文翻译文献打包机打包机是一种农业机械,它用于压缩已切割和倾斜的作物（如草、稻草或青贮饲料）成易于处理、运输和储存的小包。

常用的打包机有几个不同类型,分别生产不同类型的包-矩形的、圆柱形的,大小各不相同,用麻绳、网或金属丝缠绕起来。

工业打包机还可以用在材料回收设备上,主要用于包装需要运输的金属、塑料或纸。

圆形打包机在工业化国家最常用的打包机是这种又大又圆的打包机。

它生产圆柱状的“圆”或“筒状”的包。

草在打包机内被捲起，使用橡胶带、固定滚筒,或两者的组合。

当包达到规定尺寸时,用网或麻绳裹住它,以保持其固有的形状。

打包机的后面打开,包被排出。

包在这个阶段完成,但也可以用塑料薄膜包裹,当在室外储存时能保持干草的干燥或者将潮湿的草变成青贮饲料。

可变仓打包机通常生产直径为48至72英寸（120~ 180厘米）、宽达60英寸（150厘米）的包。

无论在任何地区，这些包可以重达1100至2200磅（500-1000公斤），包的重量取决于大小，材料，和水分含量。

最初，圆形打包机的构思由Ummo Luebbens于大约1910年提出,第一台圆形打包机才生产出来,一直到1947年Allis-Chalmers 引进了旋转打包机之后。

由于它的干草包脱水干燥和重量轻的特点从而得以推向市场，到1960年生产结束时，AC已经销售了近70000台接下来的一个重大创新是在1972年，当时Vermeer公司开始出售其型号为605的第一台现代圆形打包机。

以前,圆的干草包仅仅是干草缚在一起的肿块,但Vermeer设计使用皮带将干草紧密结合起来形成一个圆柱体,正如今天所看到的样子。

大型矩形打包机另一种常用类型的打包机生产大型的矩形包,每个包缠绕半打左右的麻绳,然后再打结。

这样的包非常紧凑，重量又普遍比圆形的包大几分。

在加拿大的草原，它们被称为草原猛禽。

小型矩形打包机这种打包机现今是不常见的,但在许多国家却是相当流行,如新西兰和澳大利亚,除了大型包的生产，还生产小型矩形 (通常被称为“正方形的”) 包。
