KEYSTONE GR 系列弹性阀座蝶阀GRW/GRL (ISO)重载型工业弹性阀座蝶阀特点• 对夹及支耳式阀体设计，结构长度尺寸符合EN 558 20系列及API 609。
• 设计标准符合EN 593和API 609。
• 阀座可更换并能完全把阀体和阀杆与过流介质隔离。
• 第一级阀杆密封力超越了阀门的额定压力，能有效防止过流介质通过阀杆部分泄漏到外部环境。
• 第二级阀杆密封作为备用密封可保证更加安全可靠。
• 阀座两端模压O 型圈可代替密封垫作为法兰密封。
• 阀杆密封圈可防止水汽渗入阀杆区域。
• 双阀杆使得薄阀板设计发挥了其低流阻特点(最大可至DN 300)。
• 圆形抛光阀板边缘保证阀门实现完全的同心密封、更低的扭矩、更长的阀座寿命和气泡级密封。
• 阀体定位孔便于安装并适合在法兰间对中。
• 延长的阀体颈部实现了管道保温。
• 执行机构连接标准依据ISO 5211。
• 上下阀杆轴承提供了良好的支撑，极小的摩擦保证了阀门低扭矩。
• 顶部衬套可吸收执行机构侧的轴向推力载荷。
• 所有阀门均符合"压力设备指令"(2014/68/EU) B + D ，CE 标识。
• 已获认证：NSF/ANSI 61, ACS, KIWA, WRAS, DVGW-G, ABS, CU-TR• 阀门口径为DN 20至DN 40时部分特性有所不同，请咨询工厂。
典型应用水、空气、散装干料传送等。
适合一切需要气泡级密封且需要具有最大流通面积。
技术参数尺寸： DN 20 - 900压力： 16 巴 DN 20 - 30010 巴 DN 350 - 900 加固阀座：16 巴 DN 350 - 600下线生产： 10 巴 DN 20 - 300 6 巴 DN 350 - 900 加固阀座：10 巴 DN 350 - 600真空装置： 0.4 bar 温度： -28°C ~ 160°C 法兰标准： PN 6/10/16 ASME 125/150 JIS 10K JIS 16KBS 表 E AS4087 PN 16AS2129 表 E32部件清单部件号数量部件名称11阀体21阀座31阀板41上阀杆51下阀杆61上衬套71密封圈81阀体卡环91阀杆卡环102上下轴承111堵头系列(GRW 型)部件清单项目数量描述11阀体21密封31阀瓣41阀杆51衬套61阀杆卡环71阀体卡环81阀体 O 形圈91阀杆 O 形圈101阀板螺钉111阀板螺钉 O 形圈124*上下轴承131旋塞141旋塞 O 形圈151旋塞卡环(GRL 型)注* DN 350 阀门尺寸仅适用 2 条轴承。
