SA5.0(C)A - SA170(C)A
SA5.0(C)A - SA170(C)A, Rev. A
SA5.0(C)A - SA170(C)A
500 Watt Transient Voltage SuppressorsAbsolute Maximum Ratings* TA = 25°C unless otherwise noted
1998 Fairchild Semiconductor CorporationSymbolParameterValueUnitsPPPMPeak Pulse Power Dissipation on 10/1000 µs waveformminimum 500WIPPMPeak Pulse Current on 10/1000 µs waveformsee tableAPM(AV)Steady State Power Dissipation.375 " lead length @ TA = 75°C1.0Wif(surge)Peak Forward Surge Currentsuperimposed on rated load (JEDEC method) (Note 1)70ATstgStorage Temperature Range-65 to +175°CTJOperating Junction Temperature-65 to +175°CFeatures•Glass passivated junction.•500W Peak Pulse Power capability on10/1000 µs waveform.•Excellent clamping capability.•Low incremental surge resistance.•Fast response time; typically lessthan 1.0 ps from 0 volts to BV forunidirectional and 5.0 ns forbidirectional.•Typical IR less than 1.0 µA above 10V.1.0 min(25.4)
0.140(3.56)0.104(2.64)0.034(0.86)0.028(0.71)0.300(7.62)0.230(5.84)Dimensions ininches (mm)
DEVICES FOR BIPOLAR APPLICATIONS- Bidirectional types use CA suffix.- Electrical Characteristics apply in both directions.DO-15COLOR BAND DENOTES CATHODEEXCEPT BIPOLAR
*These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.Note 1: Measured on 8.3 ms single half-sine wave or equivalent square wave; Duty cycle = 4 pulses per minute maximum.元器件交易网www.cecb2b.comSA5.0(C)A - SA170(C)A
SA5.0(C)A - SA170(C)A, Rev. ATransient Voltage Supressors(continued)Electrical Characteristics TA = 25°C unless otherwise noted
* For bidirectional parts with VRWM<10V, the IR max limit is doubled.Uni-directionalBi-directional (C)DeviceReverseStand-off VoltageVRWM (V)Breakdown Voltage VBR (V) min max TestCurrent IT (mA)Max ClampingVoltage @IPPM VC (V)Max Peak Pulse Surge Current IPPM (A) Max ReverseLeakage VRWM IR (uA)*SA5.0(C)A5.0 6.40 7.00109.254.3600SA6.0(C)A6.0 6.67 7.371010.348.5600SA6.5(C)A6.5 7.22 7.981011.244.7400SA7.0(C)A7.0 7.78 8.601012.041.7150SA7.5(C)A7.5 8.33 9.211.012.938.850SA8.0(C)A8.0 8.89 9.831.013.636.725SA8.5(C)A8.5 9.44 10.41.014.434.710SA9.0(C)A9.0 10.0 11.11.015.432.55SA10(C)A10 11.1 12.31.017.029.41SA11(C)A11 12.2 13.51.018.227.41SA12(C)A12 13.3 14.71.019.925.11SA13(C)A13 14.4 15.91.021.523.21SA14(C)A14 15.6 17.21.023.221.51SA15(C)A15 16.7 18.51.024.420.61SA16(C)A16 17.8 19.71.026.019.21SA17(C)A17 18.9 20.91.027.618.11SA18(C)A18 20.0 22.11.029.217.21SA20(C)A20 22.2 24.51.032.415.41SA22(C)A22 24.4 26.91.035.514.11SA24(C)A24 26.7 29.51.038.912.81SA26(C)A26 28.9 31.91.042.111.91SA28(C)A28 31.1 34.41.045.411.01SA30(C)A30 33.3 36.81.048.410.31SA33(C)A33 36.7 40.61.053.39.41SA36(C)A36 40.0 44.21.058.18.61SA40(C)A40 44.4 49.11.064.57.81SA43(C)A43 47.8 52.81.069.47.21SA45(C)A45 50.0 55.31.072.76.91SA48(C)A48 53.3 58.91.077.46.51SA51(C)A51 56.7 62.71.082.46.11SA54(C)A54 60.0 66.31.087.15.71SA58(C)A58 64.4 71.21.093.65.31SA60(C)A60 66.7 73.71.096.85.21SA64(C)A64 71.1 78.61.0103.04.91SA70(C)A70 77.8 86.01.0113.04.41SA75(C)A75 83.3 92.11.0121.04.11SA78(C)A78 86.7 95.81.0126.04.01SA85(C)A85 94.4 104.01.0137.03.61SA90(C)A90100.0 111.01.0146.03.41SA100(C)A100 111.0 123.01.0162.03.11SA110(C)A110 122.0 135.01.0177.02.81SA120(C)A120 133.0 147.01.0193.02.71SA130(C)A130 144.0 159.01.0209.02.41SA150(C)A150 167.0 185.01.0243.02.11SA160(C)A160 178.0 197.01.0259.01.91SA170(C)A170 189.0 209.01.0275.01.81元器件交易网www.cecb2b.comSA5.0(C)A - SA170(C)A
SA5.0(C)A - SA170(C)A, Rev. ATransient Voltage Supressors(continued)Typical Characteristics
Steady State Power Derating Curve
025507510012515017520000.20.40.60.811.21.41.6
LEAD TEMPERATURE ( C)POWER DISSIPATION (W)
ºPulse Derating Curve
02550751001251501752000255075100
AMBIENT TEMPERATURE ( C)PULSE POWER (%)
º
Non-Repetitive Surge Current
125102050100102050100
NUMBER OF CYCLES AT 60HzFORWARD SURGE CURRENT (A) T = T max 8.3ms Single Half Sine-Wave JEDEC MethodA A Pulse Waveform
01234050100150
TIME (ms)PEAK PULSE CURRENT (%) T = 25 C ºA Pulse Width (td) is Defined as the Point Where the Peak Current Decays to 50% of Ipp 10/1000µsec Waveform as Defined by R.E.A. tf = 10µsec
e-kt Peak Value Ippm Half Value-Ipp 2 td Peak Pulse Power Rating Curve
0.00010.0010.010.11100.1110100
PULSE WIDTH (ms)PULSE POWER (kW) T = 25 C ºA
Junction Capacitance - Unidirectional
1510501002001020501002005001000200040006000
REVERSE VOLTAGE (V)CAPACITANCE (pF) T = 25 C ºA f = 1.0 MHz Visg = 50m Vp-p Measured at Zero Bias Measured at Stand-Off Voltage (V mw) 元器件交易网www.cecb2b.com
DO-15 (FS PKG Code P2)DO-15 Package Dimensions
August 1999, Rev. A1:1Scale 1:1 on letter size paperDimensions shown below are in:inches [millimeters]Part Weight per unit (gram): 0.4
