SN661684-Channel Speech ControllerDecember 20, 2000
1 INTRODUCTION
SN66168 is a 168 seconds single chip 4-channel voice synthesizer IC whichcontains I/O ports and a tiny controller. By programming through the tinycontroller, user’s applications including section combination, trigger modes,output status, high performance melody, multiple voices, and other logicfunctions can be implemented. FEATURES Single power supply 2.4V – 5.1V Built in a tiny controller 168 seconds voice capacity are provided One 4-bit input port, two 4-bit I/O ports and one 4-bit output port areprovided 128*4 bits RAM are provided Maximum 64k program ROM is provided Readable ROM code data Built in a high quality speech synthesizer Four independent voice channels Adaptive playing speed from 4k-40kHz is provided for all 4 channelsindividually Automatic repetition for every channel A 6-bit*8-bit Multiplier is embed to modulate the volume of synthesizedvoices Two digital mixers (with saturation control) are provided Two 8-bit current output DA converters (Channel 1 + Channel 2 → DA1,Channel 3 + Channel 4 → DA2 ) System clock: 2M Hz ( R-type or Crystal Option)元器件交易网www.cecb2b.comSN661684-Channel Speech ControllerDecember 20, 2000
2 PIN ASSIGNMENTSymbolI/OFunction Description
P10IBit0 of input port 1
P11IBit1 of input port 1
P12IBit2 of input port 1
P13IBit3 of input port 1
P20I/OBit0 of I/O port 2
P21I/OBit1 of I/O port 2
P22I/OBit2 of I/O port 2
P23I/OBit3 of I/O port 2
P30I/OBit0 of I/O port 3
P31I/OBit1 of I/O port 3
P32I/OBit2 of I/O port 3
P33I/OBit3 of I/O port 3
P40OBit0 of output port 3
P41OBit1 of output port 3
P42OBit2 of output port 3
P43OBit3 of output port 3
VDDIPositive power supply
GNDINegative power supply
OSC/XINIOscillator / Crystal InXOUTOCrystal OutCKSELIClock type select‘L’ → R type (1M)‘H’ → 2M CrystalInternal pull low.VO1OD/A current output, for channel 1 and 2
VO2OD/A current output, for channel 3 and 4元器件交易网www.cecb2b.comSN661684-Channel Speech ControllerDecember 20, 2000
3 ABSOLUTE MAXIMUM RATINGItemsSymbolMinMaxUnit.
Supply VoltageVDD-V-0.36.0V
Input VoltageVINVSS-0.3VDD+0.3V
Operating TemperatureTOP-20.070.0oC
Storage TemperatureTSTG-55.0125.0oC
ELECTRICAL CHARACTERISTICSItemSym.Min.Typ.Max.UnitCondition
Operating VoltageVDD2.43.05.1V
Standby CurrentISBY--1.0uAVDD=3V
Operating CurrentIOPR--350uAVDD=3V, no load
Input Current of P1IIH-3.010.0uAVDD=3V,VIN=3V
Drive Current of P2, P3,P4IOD1.52-mAVDD=3V,VO=2.4V
Sink Current of P2,P3,P4IOS2.03-mAVDD=3V,VO=0.4V
VO1/VO2 Output CurrentIVO2.03.04.0mAVDD=3V,VO=0.7V
Oscillation Freq.FOSC-2.0-MHzVDD=3V元器件交易网www.cecb2b.comSN661684-Channel Speech ControllerDecember 20, 2000
4 BONDING PAD
SN66168
Note: The substrate MUST be connected to Vss in PCB layout.元器件交易网www.cecb2b.comSN661684-Channel Speech ControllerDecember 20, 2000
