HSK和BT刀柄种类规格加工中心的主轴锥孔通常分为两大类，即锥度为7:24的通用系统和1:10的HSK真空系统。
7:24锥度的通用刀柄锥度为7:24的通用刀柄通常有五种标准和规格，即NT（传统型）、DIN 69871（德国标准）、IS0 7388/1 （国际标准）、MAS BT（日本标准）以及ANSI/ASME（美国标准）。
NT型刀柄德国标准为DIN 2080，是在传统型机床上通过拉杆将刀柄拉紧，国内也称为ST；其它四种刀柄均是在加工中心上通过刀柄尾部的拉钉将刀柄拉紧。
目前国内使用最多的是DIN 69871型（即JT）和MAS BT 型两种刀柄。
DIN 69871型的刀柄可以安装在DIN 69871型和ANSI/ASME主轴锥孔的机床上，IS0 7388/1型的刀柄可以安装在DIN 69871型、IS0 7388/1 和ANSI/ASME主轴锥孔的机床上，所以就通用性而言，IS0 7388/1型的刀柄是最好的。
（1）DIN 2080型（简称NT或ST）DIN 2080是德国标准，即国际标准ISO 2583 ，是我们通常所说NT型刀柄，不能用机床的机械手装刀而用手动装刀。
（2）DIN 69871 型（简称JT、DIN、DAT或DV）DIN 69871 型分两种，即DIN 69871 A/AD型和DIN 69871 B型，前者是中心内冷，后者是法兰盘内冷，其它尺寸相同。
（3）ISO 7388/1 型（简称IV或IT）其刀柄安装尺寸与DIN 69871 型没有区别，但由于ISO 7388/1 型刀柄的D4值小于DIN 69871 型刀柄的D4值，所以将ISO 7388/1型刀柄安装在DIN 69871型锥孔的机床上是没有问题的，但将DIN 69871 型刀柄安装在ISO 7388/1型机床上则有可能会发生干涉。
（4）MAS BT 型（简称BT）BT型是日本标准，安装尺寸与DIN 69871、IS0 7388/1 及ANSI 完全不同，不能换用。
1 powRgrip Toolholders - Features | Benefits2 Features | Benefits3 Information4 CAT | PG Toolholders5 TC | PG Toolholders6 BT | PG Toolholders7 CYL | PG Toolholders8 HSK | PG Toolholders10 REGO-FIX CAPTO | PG Toolholders11 VDI | PG - CYL | PG Toolholders12 Swiss Quick Tool Changing System13 CYL SSY | PG Toolholders (Softsyncro)14 XL Toolholder - Vibration Decay Chart15 CAT/PG | XL (Xtended Length Toolholders)16 BT/PG | XL (Xtended Length Toolholders)17 TC/PG | XL (Xtended Length Toolholders)18 HSK/PG | XL (Xtended Length Toolholders)19 REGO-FIX CAPTO | PG XL Toolholders20 powRgrip Collets - What are PG Collets21 PG 6 - PG 1022 PG 15 - PG 25 - PG 3223 PG Boring Bar Collets24 secuRgrip | PG25 CAT | BT secuRgrip | PG26 HSK-A | HSK-E&F secuRgrip | PG27 REGO-FIX CAPTO secuRgrip | PG28 secuRgrip | PG Collets & Accessories30 Matching Products31 Maximum & Minimum Tool Depth32 Weldon Flats & h6 Shank tolerancesPGHomepowRgrip®What is powRgrip?Swiss QualityMade in Switzerland to ISO 9001/ISO 14001.What is powRgripREGO-FIX’s powRgrip System is a unique collet-holding systemthat utilizes a special shallow-tapered collet that is pressed intoa holder with a matching taper. This state-of-the-art systemuses either a hydraulic hand-pump or a table top hydraulic pressspecifically designed to quickly insert these collets with up to 9tons of force.T.I.R. of the Whole System < 0.0001" (3 μm)Highest clamping force and lowest runout.Taper Accuracy AT3Better spindle-to-holder fit and accuracy.Surface Finish max. Ra 0.25Higher clamping force and higher transferable torque.Q+® Balancing100% balanced to lowest possible residual imbalance.• Steep Taper balanced to G2.5 @ 22,000 rpm• BT 30 Taper balanced to 30,000 rpm• HSK 25 balanced to 90,000 rpm• HSK 32 balanced to 60,000 rpm• HSK 40 balanced to 45,000 rpm• HSK 50 balanced to 30,000 rpm• HSK 63 G2.5 @ 25,000 rpm• HSK 80 G2.5 @ 25,000 rpm• HSK 100 G2.5 @ 25,000 rpm• HSK 125 G2.5 @ 25,000 rpmHi-Q® Balancing SystemReady to accept Hi-Q® balancing rings which will allow for theoffset of the imbalance introduced by the cutting tool up to80,000 rpm.Minimal Outside DimensionsSlim design provides more processing flexibility.FastTool clamping with hydraulic press < 10 seconds.Excellent at Small DiametersClamping of small diameter tools from Ø 0.2 mm.Presetable Tooling SystemRepeatability < 0.0004" (10 μm)PGHomepowRgrip®T.I.R. of < 0.0001" (3 μm)Clamping operation in less than10 seconds when using the PGUautomatic machine.High vibration dampening due tothe interupted surfaces betweenthe toolholder to collet and thecollet to tool shank.Highest transferable torque andlowest T.I.R., even after 20,000tool changesFor 5 years or 20,000 cycles,REGO-FIX® guarantees theT.I.R. of a properly maintainedpowRgrip® holder and collet willnot exceed 0.0001” and that theimpregnated surface treatmentwill not erode.Precise length adjustmentrepeatability <0.0004" (10 μm)Clamps all types of toolshanks andmaterials in h6 tolerance from Ø0.0079" – 1.0" (0.2 – 25.4 mm)Developed for optimal productivitysuch as High Speed Cutting(HSC) and High PerformanceCutting (HPC)Transferable Torque of the powRgrip® SystemPGHomeInformationPG ToolholdersApplicationsThese toolholders are designed for use on CNC machiningcenters with automatic tool changers. They are especiallysuited for High Speed Cutting (HSC) and High PerformanceCutting (HPC) operations where processing reaches themachine limits. The vibration dampening of PG colletholdersreduce spindle wear and extend tool life.BalancingREGO-FIX® Q+® System PG toolholders are balanced bydesign to G 2.5 @ 22,000 rpm for steep taper holders andup to 90,000 rpm for HSK holders. Type H toolholders areready to accept Hi-Q® balancing rings which allow precisionbalancing of the system up to 80,000 rpm depending on thebalancing rings used.Coolant ThroughFor use with coolant through tools.Peripheral CoolingPG-CF collets for peripheral cooling with non-coolantthrough tools.Matched Tooling System for Best FitFor highest precision and best results the whole systemcounts. For that reason REGO-FIX® components arecarefully matched to fit together. This guarantees bestrun-out and balancing.ToolPrecise preset repeatabilityfor both HSS and carbidetoolsColletSlightly tapered shapemaximizes clamping forceHolderSuperior runout andvibration dampening ina variety of taper stylesAs a Licensed BIG Plus manufacturer, REGO-FIX® usesnew state of the art measuring and grinding systems tocreate the most accurate dual contact holders that canbe produced.Flange ContactPGHomeStandardCAT ToolholdersCAT CAT+ PGForm B“BIG-PLUS SYSTEM - Licensed by BIG Daishowa”CAT+ 40 ToolholdersPGHomeStandardTC Toolholders (DIN 69871)Form BTC PGPGHomeBT ToolholdersStandardForm BBT BT+PG“BIG-PLUS SYSTEM - Licensed by BIG Daishowa”BT+ ToolholdersPGHome12Form BExtensionsPG Toolholders Type OMCYL PGBT OM PGPGHomeHSK - Form A HoldersHSK - Form A & E Holders ContinuedHSK PG* Not for use with balancing rings.+Compatible with Willemin-Macodel MachinesPGHomeHSK PGHSK - Form E Holders ContinuedPGHomeREGO-FIX CAPTO HoldersREGO-FIX CAPTO PGPGHomeVDI PGThe PG VDI holder program brings the benefits tolathes that until now, only milling machines have takenadvantage of for years. These include better TIR,improved tool dampening, easier presetting, longer toollife and unparalleled clamping forces.The PG Cylindrical Turning holders have all of the featuresthat you expect from the PG system, now available formachines that require cylindrical holders. Available inthe most common mounting block and turret diameters,these holders will bring new precision and repeatability toany machine application.Cylindrical PG VDI ToolholdersCylindrical ToolholdersPGHomePGU Automatic or PGC hand-pump is requiredfor use with the powRgrip SystemWhat is Swiss Quick?powRgrip / ER Reductions Swiss Quick Tool Changing SystemSwiss QualityMade in Switzerland to ISO 9001/ISO 14001.What is Swiss Quick Tool Changing SystemOne of the latest REGO-FIX innovations is the SwissQuick ER to ER adapter. These are short “mini-holders” with a solid ER body profile on the back end, and a smaller ER series cavity on the front end. This unique design results in the shortest and most rigid ER to ER reduction available. Because of the solid body design, accuracy can be improved with a taper to collet cavity TIR of less than 0.0001” (3 um), and are repeatable within 0.0005” on tool length.Locking RingSpecial locking ring to insure that the collet body is removed with the nut.Matched Tooling System for Best FitFor highest precision and best results the whole system counts. For that reason REGO-FIX ® components are carefully matched for optimum fit and accuracy. This guarantees the best run-out and balance.TIR of the SystemPG run-out of 0.0001” or better when using the REGO-FIX ® powRgrip ® System.ER run-out of 0.0002” or better with a REGO-FIX ®UP ColletPGHomeCYL SSY PGDIN 1835 B+EPG Softsynchro®Tapping HolderApplicationsREGO-FIX® Softsynchro® tapping holders are used onmachines that are designed for direct tapping. Manyof the newer CNC machines feature synchronizationbetween spindle feed and thread pitch. This allows touse rigid tapping holders. However due to the dynamicsof spindle and linear motors synchronization errorsoccur. To compensate for these synchronization errorsSoftsynchro® tapping holders with minimal lengthadjustment are necessary. Depending on the applicationSoftsynchro® tapping holders increase tool life up to150%.Comparison TestsThe two diagrams show the axial forces when cold-forming M10 threads in St37 steel.Conclusion: Axial forces increase with increasing rpm.With REGO-FIX® Softsynchro® tapping holders the forcesare considerably lower than when using rigid tappingtoolholders. Therefore the surface quality and tool life isoptimized when using Softsynchro® tapping holders on asynchronized machine spindle.CYL SSY/PGSoftsynchro®Tapping HoldersHSK-A SSY/PGSoftsynchro®Tapping HoldersAxialkraft[N]Zeit [s]Drehzahl 2000 min-1Zeit [s]Axialkraft[N]Zeit [s]REGO- F IX® Softsynchro®-GewindeschneidfutterMitbewerber Synchron-WerkzeugaufnahmeStarre Synchron-WerkzeugaufnahmeTime Sec.Time Sec.AxialForce[N]AxialForce[N]PGHomeVibration Decay Chart This New MICRO-FRICTION DAMPENING™ (MFD) technology (pat. pending) from REGO-FIX allows the holders to dissipate vibrations faster than standard long reach holders. Dampening the vibrations faster means that your cutting tool, part and spindle will see less vibrations resulting in better surface finishes, longer tool life and less spindle wear.Machining parameters have to be adapted to the gauge length of the Xtended LengthToolholders100200300400500600700B e s c h l e u n i g u n g i n m /s / A c c e l e r a t i o n i n m /s100200300400500600700Standard toolholderREGO-FIX ® Xtended Length Toolholder with MFD™ Technology.A c c e l e r a t i o n i n m /s2Time in msA c c e l e r a t i o n i n m /s 2Time in msREGO-FIX ® XL ToolholderNote: Maximum 5,000 r.p.m.ANSI B5.50MAS 403DIN 69871DIN 69893PGHomeREGO-FIX CAPTO PG XLPGHomepowRgrip® Collets What are PG Collets?Swiss QualityMade in Switzerland to ISO9001/ISO14001.What are PG ColletspowRgrip (PG) Collets are precisely engineered to exactingtolerances. This assures that once the collets are pressedinto the matching powRgrip holder, the result will be anaccurately assembled system of less than 0.0001” TIR.Special metal processing provides the collets unique blackappearance and results in an extremely hard surface finishthat allows users to experience unmatched longevity andrepeatability.PrecisionHighest T.I.R. <0.0001” .Accurate Length Adjustment <10 μmWith integrated adjustment screw.Clamping of all h6 Tool ShanksCylindrical, WELDON, Whistle-NotchClamping of all Shank MaterialsSolid carbide and HSS tool shanks.Clamping Diameters0.2 to 25.4 mmFastClamping in less than 10 seconds.Simple HandlingParameters are automatically set.High Vibration DampeningHigh vibration dampening due to the interface surfacesbetween the toolholder to collet and the collet to tool shank.Highest Transferable TorqueThe powRgrip® system yields the highest transferabletorque of all comparable systems.Productivity and Tool LifeSpecially designed to allow for maximum machiningcapability.PG Collets do not have a clamping range. Nominal diameter only. Requires h6 tolerance shanks which are listed on page 31.PG 10 ColletsPG 6 ColletsPG REGO-FIX ®Standard Collet Metallic SealedPG REGO-FIX ®Coolant FlushPG Collet OptionsPG REGO-FIX®Standard Collet Metallic Sealed PG REGO-FIX®Coolant FlushPG Collet Options PG 15 ColletsPG 25 & PG 32 ColletsPGHomeThe PG boring bar collets bring the ability to transformyour normal PG holder into a boring bar holder withoutlosing accuracy or repeatability. The collets are designedto hold the cylindrical boring bar and position it correctlyin the PG holder.Boring Bar Collets PG-TsecuRgripApplicationspowRgrip now offers an option for those most difficult machinging applications that require the ultimate in cutting tool security. secuRgrip utilizes powRgrips’ tremendous gripping strength in combination with a patented locking key system and threaded cap. These two additional levels of cutting tool security provide an added degree of confidence for those special applications such as expensive castings or complex parts.Ease of UseUnlike other systems, secuRgrip does not require the purchase of any expensive special modified endmills from limited manufacturers. Instead, it allows for the use of standard Weldon flat tools on any standard carbide or HSS endmill.LockingThe locking key fits into the Weldon flat prior to assembly and secures the endmill to the collet in this easy to assemble system. A special locking cap then locks the collet and cutter assembly to the holder once pressed in.PresettingAll secuRgrip collets are designed to provide “z” height adjustment when required. secuRgrip is currently available in both the PG 25 and PG 32 holder series.Level 1 Security Locking Key on Cutting ToolLevel 2 Security Locking Cap forPG ColletCAT+ PG-SG HoldersCAT PG-SG HoldersBT+ PG-SG HoldersBT PG-SG HoldersBT secuRgrip PG“BIG-PLUS SYSTEM - Licensed by BIG Daishowa”“BIG-PLUS SYSTEM - Licensed by BIG Daishowa”HSK A PG-SG HoldersHSK E & F PG-SG HoldersHSK E & F secuRgrip PGPGHomeREGO-FIX CAPTO PG-SG HoldersREGO-FIX CAPTO secuRgrip PGsecuRgrip Collets with InsertPGHomePGU 9006 automatic clamping unit with push-button operation and auto clamping insert recognition. Designed tomake operation easy, fast and reliable. Easy interchangeable inserts and safety interlocks make the machine safefor all operators.PGC hand pumps offer a price advantage over the PGU units while still performing the task of pressing in tools. Theoperator actuates the pressure by use of the lever arm until the desired pressure is achieved.Automatic Machine & InsertsHandpump & InsertsPGU 9006 PGC 2506PGHomeTaper CleanerCleaning Paper SetProvides a quick and easy method of cleaning the powRgrip® holderbore of oil and debris before insertion of the tool.A soft, absorbant paper specially prepared for cleaning thepowRgrip® holder bore. The paper is lint-free and chemicallyneutral. For one time use only!Each pack contains 250 papers.Matching ProductsPresetting ToolThe powRgrip® presetting tool accepts the powRgrip® collets,and is inserted into the toolholder. The tool has a small thumbwheel for precise tool length adjustments, and allows maximumrepeatability in the toolholder assembly.PGHomeLDia.Maximum & Minimum Tool DepthPGHomeWeldon Flatsh6 Shank Tolerances。
加工中心的主轴锥孔通常分为两大类，即锥度为7:24的通用系统和1:10的HSK真空系统。
7:24锥度的通用刀柄锥度为7:24的通用刀柄通常有五种标准和规格，即NT（传统型）、DIN 69871（德国标准）、IS0 7388/1 （国际标准）、MAS BT（日本标准）以及ANSI/ASME（美国标准）。
NT型刀柄德国标准为DIN 2080，是在传统型机床上通过拉杆将刀柄拉紧，国内也称为ST；其它四种刀柄均是在加工中心上通过刀柄尾部的拉钉将刀柄拉紧。
目前国内使用最多的是DIN 69871型（即JT）和MAS BT 型两种刀柄。
DIN 69871型的刀柄可以安装在DIN 69871型和ANSI/ASME主轴锥孔的机床上，IS0 7388/1型的刀柄可以安装在DIN 69871型、IS0 7388/1 和ANSI/ASME主轴锥孔的机床上，所以就通用性而言，IS0 7388/1型的刀柄是最好的。
（1）DIN 2080型（简称NT或ST）DIN 2080是德国标准，即国际标准ISO 2583 ，是我们通常所说NT型刀柄，不能用机床的机械手装刀而用手动装刀。
（2）DIN 69871 型（简称JT、DIN、DAT或DV）DIN 69871 型分两种，即DIN 69871 A/AD型和DIN 69871 B型，前者是中心内冷，后者是法兰盘内冷，其它尺寸相同。
（3）ISO 7388/1 型（简称IV或IT）其刀柄安装尺寸与DIN 69871 型没有区别，但由于ISO 7388/1 型刀柄的D4值小于DIN 69871 型刀柄的D4值，所以将ISO 7388/1型刀柄安装在DIN 69871型锥孔的机床上是没有问题的，但将DIN 69871 型刀柄安装在ISO 7388/1型机床上则有可能会发生干涉。
（4）MAS BT 型（简称BT）BT型是日本标准，安装尺寸与DIN 69871、IS0 7388/1 及ANSI 完全不同，不能换用。
