MC10EP101, MC100EP101 3.3V / 5V ECL Quad 4−Input OR/NORDescriptionThe MC10/100EP101 is a Quad 4−input OR/NOR gate. The device is functionally equivalent to the E101. With AC performance faster than the E101 device, the EP101 is ideal for applications requiring the fastest AC performance available.The 100 Series contains temperature compensation.Features•250 ps Typical Propagation Delay•Maximum Frequency > 3 GHz Typical•PECL Mode Operating Range: V CC = 3.0 V to 5.5 Vwith V EE = 0 V•NECL Mode Operating Range: V CC = 0 Vwith V EE = −3.0 V to −5.5 V•Open Input Default State•Pb−Free Packages are Available**For additional information on our Pb−Free strategy and soldering details, please download the ON Semiconductor Soldering and Mounting Techniques Reference Manual, SOLDERRM/D.See detailed ordering and shipping information in the package dimensions section on page 7 of this data sheet.ORDERING INFORMATIONNCV EE D3d D3c V CC D3b D3a D2d V CCV CC Q0Q0V EE D0a D0b D0c Figure 1. 32−Lead LQFP Pinout (Top View)Warning: All V CC and V EE pins must be externally connected to Power Supply to guarantee proper operation.Q 0Q 0Q 1Q 1Q 2Q 2Q 3Q 3NC 2526272829303132151413121110912345678242322212019181716V EE D3d D3c V CC D3b D3a D2dV CC V CC Q0Q0V EE D0a D0b D0c V CCQ2V CC D2cD2b D2a D1d D1c D1bD0d D1a Q1Q2Q3Q3Q1MC10EP101MC100EP101Figure 2. 32−Lead QFN Pinout (Top View)Table 3. ATTRIBUTESCharacteristics Value Internal Input Pulldown Resistor75 k W Internal Input Pullup Resistor N/AESD Protection Human Body ModelMachine ModelCharged Device Model > 4 kV > 100 V > 2 kVMoisture Sensitivity, Indefinite Time Out of Drypack (Note 1)Pb Pkg Pb−Free PkgLQFP−32 QFN−32Level 2Level 2Level 1Flammability Rating Oxygen Index: 28 to 34UL−94 V−0 @ 0.125 inTransistor Count173 DevicesMeets or exceeds JEDEC Spec EIA/JESD78 IC Latchup Test1.For additional information, see Application Note AND8003/D.Table 4. MAXIMUM RATINGSSymbol Parameter Condition 1Condition 2Rating Unit V CC PECL Mode Power Supply V EE = 0 V6V V EE NECL Mode Power Supply V CC = 0 V−6VV I PECL Mode Input VoltageNECL Mode Input Voltage V EE = 0 VV CC = 0 VV I≤ V CCV I≤ V EE6−6VVI out Output Current ContinuousSurge 50100mAmAI BB V BB Sink/Source± 0.5mA T A Operating Temperature Range−40 to +85°C T stg Storage Temperature Range−65 to +150°Cq JA Thermal Resistance (Junction−to−Ambient)0 lfpm500 lfpm 32 LQFP32 LQFP8055°C/W°C/Wq JC Thermal Resistance (Junction−to−Case)Standard32 LQFP12 to 17°C/Wq JA Thermal Resistance (Junction−to−Ambient)0 lfpm500 lfpm QFN−32QFN−323127°C/W°C/Wq JC Thermal Resistance (Junction−to−Case)2S2P QFN−3212°C/WT sol Wave Solder PbPb−Free 265265°CRecommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect device reliability.Symbol Characteristic Min Typ Max Min Typ Max Min Typ Max Unit I EE Power Supply Current455775455875455975mA V OH Output HIGH Voltage (Note 3)216522902415223023552480229024152540mV V OL Output LOW Voltage (Note 3)136514901615143015551680149016151740mV V IH Input HIGH Voltage (Single−Ended)209024152155248022152540mV V IL Input LOW Voltage (Single−Ended)136516901460175514901815mV I IH Input HIGH Current150150150m AI IL Input LOW Current−150−150−150m A NOTE:Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit board with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declaredoperating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit values are applied individually under normal operating conditions and not valid simultaneously.2.Input and output parameters vary 1:1 with V CC. V EE can vary +0.3 V to −2.2 V.3.All loading with 50 W to V CC− 2.0 V.Table 6. 10EP DC CHARACTERISTICS, PECL V CC= 5.0 V, V EE = 0 V (Note 4)−40°C25°C85°CSymbol Characteristic Min Typ Max Min Typ Max Min Typ Max Unit I EE Power Supply Current455775455875455975mA V OH Output HIGH Voltage (Note 5)386539904115393040554180399041154240mV V OL Output LOW Voltage (Note 5)306531903315313032553380319033153440mV V IH Input HIGH Voltage (Single−Ended)379041153855418039154240mV V IL Input LOW Voltage (Single−Ended)306533903130345531903515mV I IH Input HIGH Current150150150m AI IL Input LOW Current−150−150−150m A NOTE:Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit board with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declaredoperating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit values are applied individually under normal operating conditions and not valid simultaneously.4.Input and output parameters vary 1:1 with V CC. V EE can vary +2.0 V to −0.5 V.5.All loading with 50 W to V CC− 2.0 V.Table 7. 10EP DC CHARACTERISTICS, NECL V CC = 0 V, V EE= −5.5 V to −3.0 V (Note 6)−40°C25°C85°CSymbol Characteristic Min Typ Max Min Typ Max Min Typ Max Unit I EE Power Supply Current455775455875455975mA V OH Output HIGH Voltage (Note 7)−1135−1010−885−1070−945−820−1010−885−760mV V OL Output LOW Voltage (Note 7)−1935−1810−1685−1870−1745−1620−1810−1685−1560mV V IH Input HIGH Voltage (Single−Ended)−1210−885−1145−820−1085−760mV V IL Input LOW Voltage (Single−Ended)−1935−1610−1870−1545−1810−1485mV I IH Input HIGH Current150150150m AI IL Input LOW Current−150−150−150m A NOTE:Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit board with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declaredoperating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit values are applied individually under normal operating conditions and not valid simultaneously.6.Input and output parameters vary 1:1 with V.Symbol Characteristic Min Typ Max Min Typ Max Min Typ Max Unit I EE Power Supply Current405575405875456085mA V OH Output HIGH Voltage (Note 9)215522802405215522802405215522802405mV V OL Output LOW Voltage (Note 9)135514801605135514801605135514801605mV V IH Input HIGH Voltage (Single−Ended)207524202075242020752420mV V IL Input LOW Voltage (Single−Ended)135516751355167513551675mV I IH Input HIGH Current150150150m AI IL Input LOW Current−150−150−150m A NOTE:Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit board with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declaredoperating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit values are applied individually under normal operating conditions and not valid simultaneously.8.Input and output parameters vary 1:1 with V CC. V EE can vary +0.3 V to −2.2 V.9.All loading with 50 W to V CC− 2.0 V.Table 9. 100EP DC CHARACTERISTICS, PECL V CC= 5.0 V, V EE = 0 V (Note 10)−40°C25°C85°CSymbol Characteristic Min Typ Max Min Typ Max Min Typ Max Unit I EE Power Supply Current405875406175456485mA V OH Output HIGH Voltage (Note 11)385539804105385539804105385539804105mV V OL Output LOW Voltage (Note11)305531803305305531803305305531803305mV V IH Input HIGH Voltage (Single−Ended)377541203775412037754120mV V IL Input LOW Voltage (Single−Ended)305533753055337530553375mV I IH Input HIGH Current150150150m AI IL Input LOW Current−150−150−150m A NOTE:Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit board with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declaredoperating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit values are applied individually under normal operating conditions and not valid simultaneously.10.Input and output parameters vary 1:1 with V CC. V EE can vary +2.0 V to −0.5 V.11.All loading with 50 W to V CC− 2.0 V.Table 10. 100EP DC CHARACTERISTICS, NECL V CC = 0 V, V EE= −5.5 V to −3.0 V (Note 12)−40°C25°C85°CSymbol Characteristic Min Typ Max Min Typ Max Min Typ Max UnitI EE Power Supply Current V CC = −3.3VV CC = −5.0 V 404055587575404058617575454560648585mAI EE Power Supply Current506380556785607088mA V OH Output HIGH Voltage (Note 13)−1145−1020−895−1145−1020−895−1145−1020−895mV V OL Output LOW Voltage (Note 13)−1945−1820−1695−1945−1820−1695−1945−1820−1695mV V IH Input HIGH Voltage (Single−Ended)−1225−880−1225−880−1225−880mV V IL Input LOW Voltage (Single−Ended)−1945−1625−1945−1625−1945−1625mV I IH Input HIGH Current150150150m AI IL Input LOW Current−150−150−150m A NOTE:Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit board with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declaredoperating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit values are applied individually under normal operating conditions and not valid simultaneously.12.Input and output parameters vary 1:1 with V.Table 11. AC CHARACTERISTICS V CC = 0 V; V EE = −3.0 V to −5.5 V or V CC = 3.0 V to 5.5 V; V EE = 0 V (Note 14)−40°C25°C 85°C Symbol CharacteristicMinTyp MaxMinTyp MaxMinTyp MaxUnit f max Maximum Frequency(See Figure 4. F max /JITTER)> 3> 3> 3GHz t PLH ,t PHL Propagation DelayD to Q, Q10100125180225280325380150200250300370400170250300320420450pst SKEW Within Device SkewQ, Q Device to Device Skew (Note 15)155020020502002050200ps t JITTER Cycle −to −Cycle Jitter(See Figure 4. F max /JITTER)0.2< 10.2< 10.2< 1ps t r t fOutput Rise/Fall Times Q, Q(20% − 80%)100150200120170220150190250psNOTE:Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuitboard with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declaredoperating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit values are applied individually under normal operating conditions and not valid simultaneously.14.Measured using a 750 mV source, 50% duty cycle clock source. All loading with 50 W to V CC − 2.0 V.15.Skew is measured between outputs under identical transitions.1002003004005006007008009001000010002000300040005000Figure 4. F max /JitterFREQUENCY (MHz)V O U T p p (m V )Figure 5. Typical Termination for Output Driver and Device Evaluation V TTV TT = V CC − 2.0 VORDERING INFORMATIONDevice Package Shipping†MC10EP101FA LQFP−32250 Units / Tray MC10EP101FAG LQFP−32(Pb−Free)250 Units / Tray MC10EP101FAR2LQFP−322000 / Tape & ReelMC10EP101FAR2G LQFP−32(Pb−Free)2000 / Tape & Reel MC100EP101FA LQFP−32250 Units / TrayMC100EP101FAG LQFP−32(Pb−Free)250 Units / Tray MC100EP101FAR2LQFP−322000 / Tape & ReelMC100EP101FAR2G LQFP−32(Pb−Free)2000 / Tape & ReelMC10EP101MNGQFN−32(Pb−Free)74 Units / RailMC10EP101MNR4G1000 / Tape & ReelMC100EP101MNG74 Units / RailMC100EP101MNR4G1000 / Tape & Reel†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging Specifications Brochure, BRD8011/D.Resource Reference of Application NotesAN1405/D−ECL Clock Distribution TechniquesAN1406/D−Designing with PECL (ECL at +5.0 V)AN1503/D−ECLinPS t I/O SPiCE Modeling KitAN1504/D−Metastability and the ECLinPS FamilyAN1568/D−Interfacing Between LVDS and ECLAN1672/D−The ECL Translator GuideAND8001/D−Odd Number Counters DesignAND8002/D−Marking and Date CodesAND8020/D−Termination of ECL Logic DevicesAND8066/D−Interfacing with ECLinPSAND8090/D−AC Characteristics of ECL DevicesAET −U M0.20 (0.008)ZA C NOTES:1.DIMENSIONING AND TOLERANCING PER ANSI Y14.5M, 1982.2.CONTROLLING DIMENSION:MILLIMETER.3.DATUM PLANE −AB − IS LOCATED AT BOTTOM OF LEAD AND IS COINCIDENT WITH THE LEAD WHERE THE LEAD EXITS THE PLASTIC BODY AT THE BOTTOM OF THE PARTING LINE.4.DATUMS −T −, −U −, AND −Z − TO BE DETERMINED AT DATUM PLANE −AB −.5.DIMENSIONS S AND V TO BEDETERMINED AT SEATING PLANE −AC −.6.DIMENSIONS A AND B DO NOT INCLUDE MOLD PROTRUSION. ALLOWABLEPROTRUSION IS 0.250 (0.010) PER SIDE.DIMENSIONS A AND B DO INCLUDE MOLD MISMATCH AND AREDETERMINED AT DATUM PLANE −AB −.7.DIMENSION D DOES NOT INCLUDE DAMBAR PROTRUSION. DAMBARPROTRUSION SHALL NOT CAUSE THE D DIMENSION TO EXCEED 0.520 (0.020).8.MINIMUM SOLDER PLATE THICKNESS SHALL BE 0.0076 (0.0003).9.EXACT SHAPE OF EACH CORNER MAY VARY FROM DEPICTION.DIM A MIN MAX MIN MAX INCHES 7.000 BSC 0.276 BSC MILLIMETERS B 7.000 BSC 0.276 BSC C 1.400 1.6000.0550.063D 0.3000.4500.0120.018E 1.350 1.4500.0530.057F 0.3000.4000.0120.016G 0.800 BSC 0.031 BSC H 0.0500.1500.0020.006J 0.0900.2000.0040.008K 0.4500.7500.0180.030M 12 REF 12 REF N 0.0900.1600.0040.006P 0.400 BSC 0.016 BSC Q 1 5 1 5 R 0.1500.2500.0060.010V 9.000 BSC 0.354 BSC V1 4.500 BSC 0.177 BSC ______B1 3.500 BSC 0.138 BSC A1 3.500 BSC 0.138 BSC S 9.000 BSC 0.354 BSC S1 4.500 BSC 0.177 BSC W 0.200 REF 0.008 REF X1.000 REF 0.039 REF32 LEAD LQFP CASE 873A −02QFN32 5*5*1 0.5 P CASE 488AM −01ISSUE O2 X*For additional information on our Pb −Free strategy and soldering details, please download the ON Semiconductor Soldering and Mounting Techniques Reference Manual, SOLDERRM/D.ON Semiconductor and are registered trademarks of Semiconductor Components Industries, LLC (SCILLC). SCILLC reserves the right to make changes without further notice to any products herein. SCILLC makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does SCILLC assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation special, consequential or incidental damages.“Typical” parameters which may be provided in SCILLC data sheets and/or specifications can and do vary in different applications and actual performance may vary over time. All operating parameters, including “Typicals” must be validated for each customer application by customer’s technical experts. SCILLC does not convey any license under its patent rights nor the rights of others. SCILLC products are not designed, intended, or authorized for use as components in systems intended for surgical implant into the body, or other applications intended to support or sustain life, or for any other application in which the failure of the SCILLC product could create a situation where personal injury or death may occur. Should Buyer purchase or use SCILLC products for any such unintended or unauthorized application, Buyer shall indemnify and hold SCILLC and its officers, employees, subsidiaries, affiliates,and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such claim alleges that SCILLC was negligent regarding the design or manufacture of the part. SCILLC is an Equal Opportunity/Affirmative Action Employer. This literature is subject to all applicable copyright laws and is not for resale in any manner.PUBLICATION ORDERING INFORMATIONECLinPS is a trademark of Semiconductor Components INdustries, LLC (SCILLC).。

Advantech B+B SmartWorx - Americas707 Dayton RoadOttawa, IL 61350 USAPhone (815) 433-5100Fax (815) 433-5105Advantech B+B SmartWorx - European HeadquartersWestlink Commercial ParkOranmore, Co. Galway, IrelandPhone +353 91-792444Fax +353 91-792445B+B SMARTWORX TECHNICAL SUPPORTUSA/Canada: 1 (800) 346-3119 (Ottawa IL USA location)(Monday - Friday, 7:00 a.m. to 7:00 p.m. CST) Europe: +353 91 792444 (Ireland location)(Monday - Friday, 8 a.m. to 5:00 p.m. GMT) Email: ************************Web: CONTENTSB+B SMARTWORX TECHNICAL SUPPORT (i)List of Figures (ii)List of Tables (iii)FCC RADIO FREQUENCY INTERFERENCE STATEMENT (iii)WARRANTY (iv)ABOUT THE IE-MINIMC (1)HARDWARE INSTALLATION -both product lines (2)hardware mounting options (2)powering options (3)LEDS (4)DC terminal block wiring instructions (5)Cascading DC Power (5)SPECIFICATIONS (6)CERTIFICATIONS/APPROVALS (7)ELECTROSTATIC DISCHARGE PRECAUTIONS (8)FIBER OPTIC CLEANING GUIDELINES (9)CERTIFICATIONS (10)LIST OF FIGURESFigure 1. Wall Mount Bracket (2)Figure 2. DIN Rail Mounting (3)LIST OF TABLESTable 1. LEDS (4)Table 2. Specifications (6)Table 3. Certifications (7)FCC RADIO FREQUENCY INTERFERENCE STATEMENTThis equipment has been tested and found to comply with the limits for a Class B computing device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which the user will be required to correct the interference at his own expense.Any changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. The use of non-shielded I/O cables may not guarantee compliance with FCC RFI limits. This digital apparatus does not exceed the Class B limits for radio noise emission from digital apparatus set out in the Radio Interference Regulation of the Canadian Department of Communications. Le présent appareil numérique n’émet pas de bruits radioélectriquesdépassant les limites applicables aux appareils numériques de classe B prescrites dans le Règlement sur le brouillage radioélectrique publié par le ministère des Communications du Canada.WARRANTYEffective for products of B+B SmartWorx shipped on or after May 1, 2013, B+B SmartWorx warrants that each such product shall be free from defects in material and workmanship for its lifetime. This limited lifetime warranty is applicable solely to the original user and is not transferable.This warranty is expressly conditioned upon proper storage, installation, connection, operation and maintenance of products in accordance with their written specifications. Pursuant to the warranty, within the warranty period, B+B SmartWorx, at its option will:1. Replace the product with a functional equivalent;2. Repair the product; or3. Provide a partial refund of purchase price based on a depreciated value.Products of other manufacturers sold by B+B SmartWorx are not subject to any warranty or indemnity offered by B+B SmartWorx, but may be subject to the warranties of the other manufacturers.Notwithstanding the foregoing, under no circumstances shall B+B SmartWorx have any warranty obligations or any other liability for: (i) any defects resulting from wear and tear, accident, improper use by the buyer or use by any third party except in accordance with the written instructions or advice of the B+B SmartWorx or the manufacturer of the products, including without limitation surge and overvoltage conditions that exceed specified ratings, (ii) any products which have been adjusted, modified or repaired by any party other than B+B SmartWorx or (iii) any descriptions, illustrations, figures as to performance, drawings and particulars of weights and dimensions contained in the B+B SmartWorx’ catalogs, price lists, marketing materials or elsewhere since they are merely intended to represent a general idea of the products and do not form part of this price quote and do not constitute a warranty of any kind, whether express or implied, as to any of the B+B SmartWorx’ products.THE REPAIR OR REPLACEMENT OF THE DEFECTIVE ITEMS IN ACCORDANCE WITH THE EXPRESS WARRANTY SET FORTH ABOVE IS B+B SMARTWORX’ SOLE OBLIGATION UNDER THIS WARRANTY. THE WARRANTY CONTAINED IN THIS SECTION SHALL EXTEND TO THE ORIGINAL USER ONLY, IS IN LIEU OF ANY AND ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, AND ALL SUCH WARRANTIES AND INDEMNITIES ARE EXPRESSLY DISCLAIMED, INCLUDING WITHOUT LIMITATION (I) THE IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE AND OF MERCHANTABILITY AND (II) ANY WARRANTY THAT THE PRODUCTS ARE DO NOT INFRINGE OR VIOLATE THE INTELLECTUAL PROPERTY RIGHTS OF ANY THIRD PARTY. IN NO EVENT SHALL B+B SMARTWORX BE LIABLE FOR LOSS OF BUSINESS, LOSS OF USE OR OF DATA INTERRUPTION OF BUSINESS, LOST PROFITS OR GOODWILL OR OTHER SPECIAL, INCIDENTAL, EXEMPLARY OR CONSEQUENTIAL DAMAGES. B&B ELECTRONIC SHALL DISREGARD AND NOT BE BOUND BY ANY REPRESENTATIONS, WARRANTIES OR INDEMNITIES MADE BY ANY OTHER PERSON, INCLUDING WITHOUT LIMITATION EMPLOYEES, DISTRIBUTORS, RESELLERS OR DEALERS OF B+B SMARTWORX WHICH ARE INCONSISTENT WITH THE WARRANTY, SET FORTH ABOVE.ABOUT THE IE-MINIMCThe IE-MiniMc Industrial Ethernet media converter features 10/100 switching copper-to-fiber conversion. Miniature in size, it offers plug-and-play operation, and supports an extended voltage range as well as extended operating temperature.. The media converter can function as a PD device, and is compliant to the IEEE 802.3af Power Over Ethernet (PoE) standard. Available in a variety of Single Mode and Multi Mode fiber types, it supports an MTU of 1916 bytes. Several mounting options and powering options are available and detailed in the following sections of the manual.HARDWARE INSTALLATION -BOTH PRODUCT LINES The IE-MiniMc installs virtually anywhere as a standalone device in locations with extremely limited space. Installation options include:·Velcro strips·DIN rail mounting with DIN Rail clips· A wall mount bracket· A PowerTray/18 for high density applicationsHARDWARE MOUNTING OPTIONSThe IE-MiniMc can be mounted on a DIN rail or using wall mount brackets (shown below).Figure 1. Wall Mount BracketDIN rail clips (part number 806-39105) and wall mount brackets (part number 895-39229) are available for purchase through an B&B Electronics Distributor. The DIN Rail clips include screws, to allow the installation onto a DIN Rail. Install the screws into DIN Rail clips, which should be mounted parallel or perpendicular to the DIN Rail. Snap the converter onto the clips. To remove the converter from the DIN Rail, use a flat-head screwdriver into the slot to gently pry the converter from the rail.Figure 2. DIN Rail MountingPOWERING OPTIONSThe IE-MiniMc includes multiple powering options:· A country-specific, high-reliability AC power adapter (included)·The IEEE 802.3af Power over Ethernet standard; draws power from power sourcing equipment (NON-Telco version only)·The 4-terminal DC power block·IE-PowerTray/18 for Rack MountingPower Over EthernetPower Over Ethernet technology allows the IE-MiniMc to be a Powered Draw device (PD) and draw power when connected to Power Sourcing Equipment (PSE). Power Sourcing Equipment distributes an electrical current across existing copper data cabling.LEDSEach IE-MiniMc includes two LEDs, located on the RJ-45 connector.LED functions are as follows:FXLNK/ACT Glows green when a link is established on the fiber port; blinks green when activity is detected on the fiber port.TXLNK/ACT Glows amber when a link is established on the copper port; blinks amber when activity is detected on the copper port.Table 1. LEDSDC TERMINAL BLOCK WIRING INSTRUCTIONSThe IE-MiniMc can also be powered with the DC terminal block. From a power source, connect to any one positive and any one negative terminal on the IE-MiniMcFigure 3. DC Terminal BlockNOTEWhen using stranded wire, the leads must be tinned and equivalent to a 16 AWG solid conductor. The DC terminal block is protected against mis-wiring. If the unit is mis-wired, positive power lead to the negative terminal and negative power lead to the positive terminal, it will not function. When powering a unit with voltages near the upper limit of the device’s specification (for example: 50 volts) take precautions to limit the voltage at the units terminal block. When turning on high voltage DC circuits, initial voltages may exceed the maximum allowed duration of the unit’s transient protection devices.Cascading DC PowerWhen installing multiple IE-MiniMc units on a DIN rail, the end user can connect to one DC input source, and then cascade from one DC block to the next, until reaching the maximum current available.SPECIFICATIONSConnectorsCopper RJ-45Fiber ST, SCEnvironmental -- Intended for indoor and outdoor use.Operating Temperature -40°F to +185°F (-40°C to +85°C) DC configuration +14°F to +122°F (-10°C to +50°C) with AC wall adapterStorage Temperature-40°F to +185°F (-40°C to +85°C)Operating Humidity 5 to 95% (non-condensing); 0 to 10,000 ft. altitude LED Indicators One Green LEDCopper RJ-45 port LNK/ACT Color = GREENBlink = GREEN when data is passing Off = NO COLORFiber Port LNK/ACT Color = AMBERBlink = AMBER when data is passing Off = NO COLORPower InputDC Terminal Block 7 to 50 VDC, 1-0.1ADC jack 5 to 24 VDCPoE When IE-MiniMc uses PoE technology to be a PD,the maximum supply voltage is 50VTable 2. SpecificationsCERTIFICATIONS/APPROVALSCertificationsFCC FCC Part 15 Class BCEEN55022 CISPR 22 Class BEN61000-3-2 Generic Standards for Residential, Commercial, & Light IndustrialEN61000-4-2 ESD (15kV air & 4kV contact)EN61000-4-3 RFIEN61000-4-4 EFTEN61000-4-5 SurgeEN61000-4-6 CIEN61000-4-8 Power Frequency MagneticVoltage Dips & InterruptionsEN61000-4-11Regulatory ApprovalsROHS and WEEE CompliantTable 3. CertificationsELECTROSTATIC DISCHARGE PRECAUTIONS Electrostatic discharge (ESD) can cause damage to any product, add-in modules or stand-alone units, containing electronic components. Always observe the following precautions when installing or handling these kinds of products:Do not remove unit from its protective packaging until ready to install. Wear an ESD wrist grounding strap before handling any module or component. If the wrist strap is not available, maintain grounded contact with the system unit throughout any procedure requiring ESD protection. Hold the units by the edges; do not touch the electronic components or gold connectors.After removal, always place the boards on a grounded, static-free surface, ESD pad or in a proper ESD bag. Do not slide the modules orstand-alone units over any surface. WARNING! Integrated circuits and fiber optic components are extremely susceptible to electrostatic dischargedamage. Do not handle these components directly unless you are a qualified service technician and use tools andtechniques that conform to accepted industry practices.FIBER OPTIC CLEANING GUIDELINESFiber optic transmitters and receivers are extremely susceptible to contamination by particles of dirt or dust, which can obstruct the optic path and cause performance degradation. Good system performance requires clean optics and connector ferrules.Use fiber patch cords (or connectors, if you terminate your own fiber) only from a reputable supplier; low-quality components can cause many hard-to-diagnose problems in an installation.Dust caps are installed at B+B SmartWorx to ensure factory-clean optical devices. These protective caps should not be removed until the moment of connecting the fiber cable to the device. Should it be necessary to disconnect the fiber device, reinstall the protective dust caps.Store spare caps in a dust-free environment such as a sealed plastic bag or box so that when reinstalled they do not introduce any contamination to the optics.If you suspect that the optics have been contaminated, alternate between blasting with clean, dry, compressed air and flushing with methanol to remove particles of dirt.CERTIFICATIONSCE: The products described herein comply with the Council Directive on Electromagnetic Compatibility (2004/108/EC). For further details, contact B+B SmartWorx.European Directive 2002/96/EC (WEEE) requires that any equipment that bears this symbol on product or packaging must not be disposed of with unsorted municipal waste. This symbol indicates that the equipment should be disposed of separately from regular household waste. It is the consumer’s responsibility to dispose of this and all equipment so marked through designated collection facilities appointed by government or local authorities. Following these steps through proper disposal and recycling will help prevent potential negative consequences to the environment and human health. For more detailed information about proper disposal, please contact local authorities, waste disposal services, or the point of purchase for this equipment.____________________________________________________© 2017 B+B SmartWorx. All rights reserved. The information in this document is subject to change without notice. B+B SmartWorx assumes no responsibility for any errors that may appear in this document. IE-MiniMc is a trademark of B+BSmartWorx. Other brands or product names may be trademarks and are the property of their respective companies.Document #: 55-80722-00-A8_1017。

154N 超稳定性型316不锈钢压力传感器 0-100 mV 量程输出用于表压、密封压和绝压的测量 温度补偿医疗设备过程控制废水处理制冷/压缩设备压力变送器物位系统产品介绍154N 型是一种经过补偿的、与介质兼容的压阻硅压力传感器，316不锈钢封装。

传感外壳利用硅油把压力从316不锈钢膜片上传递到传感元件上。

154N 型设计用于低压场合。

陶瓷基底具有经过激光调整的电阻器用于温度补偿和漂移调节。

陶瓷基底上的另一电阻器可被用于调节灵敏度变化（通过设置外部差分放大器的增益，互换性±1.0%）。

替代品包括84或86型（O 形环），96型（1/4NPT ），和85型。

还提供高压传感器。

特征 尺寸图 （请点击此处看放大图）O 型环安装0.1%压力非线性补偿温度范围：-20℃－+85℃互换性：1.0% (由增益调节电阻提供) 固态产品,性能可靠 低功耗标准量程量程 psig psia 0-5 联系厂家0-15 ● ●0-30 ● ● 0-50 ● ● 0-100 ● ● 0-300 ● ● 0-500●●LEADER Electronic Co Ltd - 116, Jianghuali, Jianghua Road, Jiangmen City, GD, PRC1Tel: + 86 750 3379183、3101711 Fax: + 86 750 3388669 BQQ: 7284 1936Website: - e-mail: leader@性能参数电源电流=1.5mA,室温=25℃,预热10秒钟后(除非另有说明) （除非特殊指明，这些参数均指每一部份被测试，所有参数仅对补偿型而言）参数 最小值 标准值 最大值 单位 注释满量程输出 75 100 150 mV 1,2 零漂 -1 0 1 mV 2 压力非线性 -0.10 0.10 ±%量程 3 压力迟滞 -0.05 0.02 0.05 ±%量程 输入电阻2000 3500 4500 Ω 输出电阻 4000 25000 Ω 温度误差-满量程 -0.75 0.75 %量程 4 温度误差-漂移 -0.5 0.5 %量程 4,5 热迟滞-满量程0.05 %量程 4 热迟滞-漂移 0.05 %量程 4 长期稳定性-漂移 0.1 ±%量程/年 长期稳定性-满量程 0.1 ±%量程/年 供电电流 0.5 1.5 2.0 mA 6 输出负载电阻 5 M Ω 7 绝缘电阻（50VDC ） 50 M Ω 8 压力过载 3X 额定值 补偿温度 -20℃ — +85℃ 9工作温度 -40℃ — +125℃ 9 存贮温度 -50℃ — +125℃ 9 介质-压力口 与316L 不锈钢兼容的液体、气体 介质-参考口 和硅、硼硅酸玻璃、金、氟化硅橡胶,316L 不锈钢兼容的液体、气体重量 24克 10注释1. 对于放大的输出电路,具有增益调整电阻的互换性为3.012V ±1%。
